<Window
x:Class="Animation.MainWindow"
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
xmlns:local="clr-namespace:Animation"
xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
xmlns:system="clr-namespace:System;assembly=mscorlib"
Title="MainWindow"
Width="800"
Height="450"
mc:Ignorable="d">
<Window.Resources>
<Storyboard x:Key="story1">
<DoubleAnimationUsingKeyFrames
Storyboard.TargetName="MyAnimatedTranslateTransform"
Storyboard.TargetProperty="X"
Duration="0:0:0.5">
<LinearDoubleKeyFrame KeyTime="0" Value="0" />
<LinearDoubleKeyFrame KeyTime="0:0:0.25" Value="10" />
<LinearDoubleKeyFrame KeyTime="0:0:0.5" Value="20" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<Storyboard
x:Key="story2"
Storyboard.TargetName="MyAnimatedTranslateTransform"
Storyboard.TargetProperty="X">
<DoubleAnimationUsingKeyFrames Duration="0:0:0.5">
<LinearDoubleKeyFrame KeyTime="0" Value="20" />
<LinearDoubleKeyFrame KeyTime="50%" Value="10" />
<LinearDoubleKeyFrame KeyTime="100%" Value="0" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<!-- 定义展开动画 -->
<Storyboard x:Key="ExpandSidebar">
<DoubleAnimation
Storyboard.TargetName="Sidebar"
Storyboard.TargetProperty="Width"
To="200"
Duration="0:0:0.35">
<DoubleAnimation.EasingFunction>
<CubicEase EasingMode="EaseInOut" />
</DoubleAnimation.EasingFunction>
</DoubleAnimation>
</Storyboard>
<!-- 定义收缩动画 -->
<Storyboard x:Key="CollapseSidebar">
<DoubleAnimation
Storyboard.TargetName="Sidebar"
Storyboard.TargetProperty="Width"
To="50"
Duration="0:0:0.35">
<DoubleAnimation.EasingFunction>
<CubicEase EasingMode="EaseInOut" />
</DoubleAnimation.EasingFunction>
</DoubleAnimation>
</Storyboard>
</Window.Resources>
<Grid>
<Grid.ColumnDefinitions>
<ColumnDefinition Width="Auto" />
<ColumnDefinition Width="*" />
</Grid.ColumnDefinitions>
<Border x:Name="Sidebar" Width="200">
<!--<ItemsControl VerticalAlignment="Top">
<system:String>ItemsControl</system:String>
<system:String>ItemsControl</system:String>
<system:String>ItemsControl</system:String>
<system:String>ItemsControl</system:String>
<system:String>ItemsControl</system:String>
</ItemsControl>-->
<StackPanel>
<Button Height="30" Content="Home" />
<Button Height="30" Content="Setting" />
<Button Height="30" Content="Message" />
</StackPanel>
</Border>
<Border
Grid.Column="1"
BorderBrush="#999999"
BorderThickness="1,0,0,0">
<ToggleButton
x:Name="ToggleSidebarButton"
Width="30"
Height="30"
Margin="5,0"
HorizontalAlignment="Left"
VerticalAlignment="Top"
IsChecked="True">
<ToggleButton.Style>
<Style TargetType="ToggleButton">
<Setter Property="Content" Value="▶" />
<Style.Triggers>
<Trigger Property="IsChecked" Value="True">
<Setter Property="Content" Value="◀" />
</Trigger>
</Style.Triggers>
</Style>
</ToggleButton.Style>
<ToggleButton.Triggers>
<EventTrigger RoutedEvent="ToggleButton.Checked">
<BeginStoryboard Storyboard="{StaticResource ExpandSidebar}" />
</EventTrigger>
<EventTrigger RoutedEvent="ToggleButton.Unchecked">
<BeginStoryboard Storyboard="{StaticResource CollapseSidebar}" />
</EventTrigger>
</ToggleButton.Triggers>
</ToggleButton>
</Border>
</Grid>
</Window>
wpf 点击展开/收缩侧边栏
于 2025-03-14 11:00:30 首次发布
