本文介绍了如何使用C#直接发送打印机命令，特别是针对条码打印机的ZPL语言进行详细讲解。MSCL超级工具类库为开发者提供了便捷的C#工具类，涵盖数据库操作、字符串处理、网络请求等多个领域，旨在提升编程效率和质量。通过提供的CHM文档和示例，开发者可以快速掌握并应用到实际项目中。
using System;
using System.Collections.Generic;
using System.Text;
using System.Runtime.InteropServices;
namespace BarCodeLibrary
{
public class ZebraGesigner
{
[StructLayout(LayoutKind.Sequential)]
private struct OVERLAPPED
{
int Internal;
int InternalHigh;
int Offset;
int OffSetHigh;
int hEvent;
}
[DllImport("kernel32.dll")]
private static extern int CreateFile(string lpFileName, uint dwDesiredAccess, int dwShareMode, int lpSecurityAttributes, int dwCreationDisposition, int dwFlagsAndAttributes, int hTemplateFile);
[DllImport("kernel32.dll")]
private static extern bool WriteFile(int hFile, byte[] lpBuffer, int nNumberOfBytesToWriter, out int lpNumberOfBytesWriten, out OVERLAPPED lpOverLapped);
[DllImport("kernel32.dll")]
private static extern bool CloseHandle(int hObject);
[DllImport("fnthex32.dll")]
public static extern int GETFONTHEX(string barcodeText,string fontName,int orient,int height,int width,int isBold,int isItalic,StringBuilder returnBarcodeCMD);
private int iHandle;
//打开LPT 端口
public bool Open()
{
iHandle = CreateFile("lpt1", 0x40000000, 0, 0, 3, 0, 0);
if (iHandle != -1)
{
return true;
}
else
{
return false;
}
}
//打印函数，参数为打印机的命令或者其他文本！
public bool Write(string MyString)
{
if (iHandle != -1)
{
int i;
OVERLAPPED x;
byte[] mybyte = System.Text.Encoding.Default.GetBytes(MyString);
return WriteFile(iHandle, mybyte, mybyte.Length, out i, out x);
}
else
{
throw new Exception("端口未打开~！");
}
}
//关闭打印端口
public bool Close()
{
return CloseHandle(iHandle);
}
}
}
vate void button1_Click(object sender, EventArgs e)
{
ZebraGesigner zb = new ZebraGesigner();
string mycommanglines = System.IO.File.ReadAllText("print.txt");//print.txt里写了条码机的命令
zb.Open();
zb.Write(mycommanglines);
zb.Close();
}
/*
^XA ^XA指令块的开始
^MD30 ^MD是设置色带颜色的深度,取值范围从-30到30,上面的示意指令将颜色调到了最深.
^LH60,10 ^LH是设置条码纸的边距的,这个东西在实际操作上来回试几次即可.
^FO20,10 ^FO是设置条码左上角的位置的,这个对程序员应该很容易理解. 0,0代表完全不留边距.
^ACN,18,10 ^ACN是设置字体的.因为在条码下方会显示该条码的内容,所以要设一下字体.这个跟条码无关.
^BY1.4,3,50 ^BY是设置条码样式的,1.4是条码的缩放级别,3是条码中粗细柱的比例,50是条码高度.
^BCN,,Y,N ^BC是打印code128的指令,具体参数详见ZPL的说明书(百度云盘)
^FD01008D004Q-0^FS ^FD设置要打印的内容, ^FS表示换行.
^XZ ^XZ指令块的开始
*/
StringBuilder builder = new StringBuilder();
builder.AppendLine("^XA");
builder.AppendLine("^MD30");
builder.AppendLine("^LH60,10");
builder.AppendLine("^FO20,10");
builder.AppendLine("^ACN,18,10");
builder.AppendLine("^BY1.4,3,50");
builder.AppendLine("^BCN,,Y,N");
builder.AppendLine("^FD01008D004Q-0^FS");
builder.AppendLine("^XZ");
在实践中, 常常会需要一次横打两张, 其实可以把一排的两张想像成一张, 连续执行两个打印命令, 把第二个FO的横坐标设置得大一些就行了.
例如:
^XA
^FO20,10
^FD001^FS
^FO60,10
^FD002^FS
^XZ
第一对FO/FD命令打印左侧, 第二对FO/FD命令打印右侧.
例如:
^XA
^FO20,10
^FD001^FS
^FO60,10
^FD002^FS
^XZ
第一对FO/FD命令打印左侧, 第二对FO/FD命令打印右侧.
using System; using System.Collections.Generic; using System.Text; using System.IO; using System.Drawing; using System.Drawing.Printing; using System.Windows.Forms; using System.Runtime.InteropServices; namespace ZPLPrinter { class RawPrinterHelper { // Structure and API declarions: [StructLayout(LayoutKind.Sequential, CharSet = CharSet.Ansi)] public class DOCINFOA { [MarshalAs(UnmanagedType.LPStr)] public string pDocName; [MarshalAs(UnmanagedType.LPStr)] public string pOutputFile; [MarshalAs(UnmanagedType.LPStr)] public string pDataType; } [DllImport("winspool.Drv", EntryPoint = "OpenPrinterA", SetLastError = true, CharSet = CharSet.Ansi, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool OpenPrinter([MarshalAs(UnmanagedType.LPStr)] string szPrinter, out IntPtr hPrinter, IntPtr pd); [DllImport("winspool.Drv", EntryPoint = "ClosePrinter", SetLastError = true, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool ClosePrinter(IntPtr hPrinter); [DllImport("winspool.Drv", EntryPoint = "StartDocPrinterA", SetLastError = true, CharSet = CharSet.Ansi, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool StartDocPrinter(IntPtr hPrinter, Int32 level, [In, MarshalAs(UnmanagedType.LPStruct)] DOCINFOA di); [DllImport("winspool.Drv", EntryPoint = "EndDocPrinter", SetLastError = true, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool EndDocPrinter(IntPtr hPrinter); [DllImport("winspool.Drv", EntryPoint = "StartPagePrinter", SetLastError = true, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool StartPagePrinter(IntPtr hPrinter); [DllImport("winspool.Drv", EntryPoint = "EndPagePrinter", SetLastError = true, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool EndPagePrinter(IntPtr hPrinter); [DllImport("winspool.Drv", EntryPoint = "WritePrinter", SetLastError = true, ExactSpelling = true, CallingConvention = CallingConvention.StdCall)] public static extern bool WritePrinter(IntPtr hPrinter, IntPtr pBytes, Int32 dwCount, out Int32 dwWritten); // SendBytesToPrinter() // When the function is given a printer name and an unmanaged array // of bytes, the function sends those bytes to the print queue. // Returns true on success, false on failure. public static bool SendBytesToPrinter(string szPrinterName, IntPtr pBytes, Int32 dwCount) { Int32 dwError = 0, dwWritten = 0; IntPtr hPrinter = new IntPtr(0); DOCINFOA di = new DOCINFOA(); bool bSuccess = false; // Assume failure unless you specifically succeed. di.pDocName = "My C#.NET RAW Document"; di.pDataType = "RAW"; // Open the printer. if (OpenPrinter(szPrinterName.Normalize(), out hPrinter, IntPtr.Zero)) { // Start a document. if (StartDocPrinter(hPrinter, 1, di)) { // Start a page. if (StartPagePrinter(hPrinter)) { // Write your bytes. bSuccess = WritePrinter(hPrinter, pBytes, dwCount, out dwWritten); EndPagePrinter(hPrinter); } EndDocPrinter(hPrinter); } ClosePrinter(hPrinter); } // If you did not succeed, GetLastError may give more information // about why not. if (bSuccess == false) { dwError = Marshal.GetLastWin32Error(); } return bSuccess; } public static bool SendFileToPrinter(string szPrinterName, string szFileName) { // Open the file. FileStream fs = new FileStream(szFileName, FileMode.Open); // Create a BinaryReader on the file. BinaryReader br = new BinaryReader(fs); // Dim an array of bytes big enough to hold the file's contents. Byte[] bytes = new Byte[fs.Length]; bool bSuccess = false; // Your unmanaged pointer. IntPtr pUnmanagedBytes = new IntPtr(0); int nLength; nLength = Convert.ToInt32(fs.Length); // Read the contents of the file into the array. bytes = br.ReadBytes(nLength); // Allocate some unmanaged memory for those bytes. pUnmanagedBytes = Marshal.AllocCoTaskMem(nLength); // Copy the managed byte array into the unmanaged array. Marshal.Copy(bytes, 0, pUnmanagedBytes, nLength); // Send the unmanaged bytes to the printer. bSuccess = SendBytesToPrinter(szPrinterName, pUnmanagedBytes, nLength); // Free the unmanaged memory that you allocated earlier. Marshal.FreeCoTaskMem(pUnmanagedBytes); return bSuccess; } public static bool SendStringToPrinter(string szPrinterName, string szString) { IntPtr pBytes; Int32 dwCount; // How many characters are in the string? dwCount = szString.Length; // Assume that the printer is expecting ANSI text, and then convert // the string to ANSI text. pBytes = Marshal.StringToCoTaskMemAnsi(szString); // Send the converted ANSI string to the printer. SendBytesToPrinter(szPrinterName, pBytes, dwCount); Marshal.FreeCoTaskMem(pBytes); return true; } } }
public string Print(string stuNo, string liuBookNo, string suoBookNum, string stuName)
{
if (string.IsNullOrEmpty(liuBookNo) || string.IsNullOrEmpty(suoBookNum))
{
return "参数错误,打印失败!";
}
StringBuilder tiaomaStr = new StringBuilder();
tiaomaStr.AppendLine();
tiaomaStr.AppendLine("N");
tiaomaStr.AppendLine("B0,10,0,1,2,3,100,B,$" + suoBookNum + "$");
tiaomaStr.AppendLine("A2050,10,5,9,1,1,N,$" + liuBookNo + "$");
tiaomaStr.AppendLine("A0,160,0,8,1,1,N,$未知$");
tiaomaStr.AppendLine("A0,210,0,8,1,1,N,$捐书人:" + stuName + "$");
tiaomaStr.AppendLine("D15");
tiaomaStr.AppendLine("P1");
FileStream fs = null;
try
{
string path = Server.MapPath("~/BooksManagement\\File\\tiaoma.txt");
fs = new FileStream(path, FileMode.Create, FileAccess.Write);
StreamWriter sw = new StreamWriter(fs, Encoding.Default);//ANSI编码格式
if (File.Exists(path))
{
sw.Write(tiaomaStr.ToString().Replace('$', '"'));
tiaomaStr.Clear();
sw.Flush();
sw.Close();
if (RunCmd("COPY " + path + " LPT1"))
return string.Empty;
else
return "参数错误,打印失败!";
}
}
catch
{
}
finally
{
fs.Close();
}
return "参数错误,打印失败!";
}
private bool RunCmd(string command)
{
//实例一个Process类，启动一个独立进程
Process p = new Process();
//Process类有一个StartInfo属性，這個是ProcessStartInfo类，包括了一些属性和方法，下面我們用到了他的几个属性：
p.StartInfo.FileName = "cmd.exe";//设定程序名
p.StartInfo.Arguments = "/c " + command;//设定程式执行参数
p.StartInfo.UseShellExecute = false;//关闭Shell的使用
p.StartInfo.RedirectStandardInput = true;//重定向标准输入
p.StartInfo.RedirectStandardOutput = true;//重定向标准输出
p.StartInfo.RedirectStandardError = true;//重定向错误输出
p.StartInfo.CreateNoWindow = true;//设置不显示窗口
//p.StandardInput.WriteLine(command);//也可以用这种方式输入要执行的命令
//p.StandardInput.WriteLine("exit");//不过要记得加上Exit要不然下一行程式执行的時候会当机
try
{
p.Start();//开始进程
return true;
}
catch
{
}
finally
{
if (p != null)
p.Close();
}
return false;
}
/*
中文或其它复杂设计成图片，然后用ZPL命令发送给条码打印机打印
//定义字体
Font drawFont = new Font("Arial", 10, FontStyle.Bold, GraphicsUnit.Millimeter);
//生成图片
Bitmap img = CreateImage("出厂日期：" + DateTime.Now, drawFont);
var imgCode = ConvertImageToCode(img);
var t = ((img.Size.Width / 8 + ((img.Size.Width % 8 == 0) ? 0 : 1)) * img.Size.Height).ToString(); //图形中的总字节数
var w = (img.Size.Width / 8 + ((img.Size.Width % 8 == 0) ? 0 : 1)).ToString(); //每行的字节数
string zpl = string.Format("~DGR:imgName.GRF,{0},{1},{2}", t, w, imgCode); //发送给打印机
*/
/// <summary>
/// 生成Bitmap
/// </summary>
/// <param name="data">字符串</param>
/// <param name="f">文本格式</param>
/// <returns></returns>
protected Bitmap CreateImage(string data, Font f)
{
if (string.IsNullOrEmpty(data))
return null;
var txt = new TextBox();
txt.Text = data;
txt.Font = f;
//txt.PreferredSize.Height只能取到一行的高度(连边距)
//所以需要乘以行数, 但是必须先减掉边距, 乘了以后,再把边距加上.
//5是目测的边距
var image = new Bitmap(txt.PreferredSize.Width, (txt.PreferredSize.Height - 5) * txt.Lines.Length + 5);
var g = Graphics.FromImage(image);
var b = new System.Drawing.Drawing2D.LinearGradientBrush(new Rectangle(0, 0, image.Width, image.Height), Color.Black, Color.Black, 1.2f, true);
g.Clear(System.Drawing.Color.White);
g.DrawString(data, f, b, 1, 1);
return image;
}
/// <summary>
/// 序列化图片
/// </summary>
/// <param name="img">Bitmap</param>
/// <returns></returns>
protected string ConvertImageToCode(Bitmap img)
{
var sb = new StringBuilder();
long clr = 0, n = 0;
int b = 0;
for (int i = 0; i < img.Size.Height; i++)
{
for (int j = 0; j < img.Size.Width; j++)
{
b = b * 2;
clr = img.GetPixel(j, i).ToArgb();
string s = clr.ToString("X");
if (s.Substring(s.Length - 6, 6).CompareTo("BBBBBB") < 0)
{
b++;
}
n++;
if (j == (img.Size.Width - 1))
{
if (n < 8)
{
b = b * (2 ^ (8 - (int)n));
sb.Append(b.ToString("X").PadLeft(2, '0'));
b = 0;
n = 0;
}
}
if (n >= 8)
{
sb.Append(b.ToString("X").PadLeft(2, '0'));
b = 0;
n = 0;
}
}
sb.Append(System.Environment.NewLine);
}
return sb.ToString();
}
