该博客展示了使用SaltStack自动化配置Apache、MySQL和PHP7的过程，以及在CentOS系统上部署Zabbix监控框架的详细步骤。内容包括安装依赖包、下载和解压源码、设置服务和权限，以及配置httpd、mysqld和php-fpm服务。此外，还涉及到Zabbix的Apache和MySQL配置，以及Zabbix服务的启动和验证。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

编写状态文件

[root@master prod]# tree
.
├── modules
│   ├── application
│   │   └── php7
│   │       ├── files
│   │       │   ├── install.sh
│   │       │   ├── oniguruma-devel-6.8.2-2.el8.x86_64.rpm
│   │       │   ├── php-7.4.24.tar.gz
│   │       │   ├── php-fpm
│   │       │   ├── php-fpm.conf
│   │       │   ├── php-fpm.service
│   │       │   └── www.conf
│   │       └── install.sls
│   ├── database
│   │   └── mysql
│   │       ├── files
│   │       │   ├── install.sh
│   │       │   ├── mysql-5.7.34-linux-glibc2.12-x86_64.tar.gz
│   │       │   ├── mysqld.service
│   │       │   └── mysql.server
│   │       └── install.sls
│   └── web
│       └── apache
│           ├── files
│           │   ├── apr-1.7.0.tar.gz
│           │   ├── apr-util-1.6.1.tar.gz
│           │   ├── httpd-2.4.49.tar.gz
│           │   ├── httpd.conf
│           │   ├── httpd.service
│           │   └── install.sh
│           └── install.sls
└── zabbix
    ├── apache.sls
    ├── files
    │   ├── index.php
    │   ├── my.cnf
    │   ├── mysql.conf
    │   ├── php.ini
    │   ├── vhosts.conf
    │   ├── zabbix-5.4.4.tar.gz
    │   ├── zabbix_server.conf
    │   └── zabbix.sh
    ├── install.sls
    ├── main.sls
    └── mysql.sls

12 directories, 32 files
[root@master prod]#

[root@master prod]# cat modules/web/apache/install.sls
apache-dep-package:
  pkg.installed:
    - pkgs:
      - openssl-devel
      - pcre-devel
      - expat-devel
      - libtool
      - gcc
      - gcc-c++
      - make

apache:
  user.present:
    - shell: /sbin/nologin
    - createhome: false
    - system: true

apache-download:
  file.managed:
    - names:
      - /usr/src/apr-1.7.0.tar.gz:
        - source: salt://modules/web/apache/files/apr-1.7.0.tar.gz
      - /usr/src/apr-util-1.6.1.tar.gz:
        - source: salt://modules/web/apache/files/apr-util-1.6.1.tar.gz
      - /usr/src/httpd-2.4.49.tar.gz:
        - source: salt://modules/web/apache/files/httpd-2.4.49.tar.gz

/usr/lib/systemd/system/httpd.service:
  file.managed:
    - source: salt://modules/web/apache/files/httpd.service
    - user: root
    - group: root
    - mode: '0644'

salt://modules/web/apache/files/install.sh:
  cmd.script

/usr/local/httpd/conf/httpd.conf:
  file.managed:
    - source: salt://modules/web/apache/files/httpd.conf
    - user: root
    - group: root
    - mode: '0644'
[root@master prod]#

[root@master prod]# cat modules/database/mysql/install.sls
ncurses-compat-libs:
  pkg.installed
create-mysql-user:
  user.present:
    - name: mysql
    - system: true
    - createhome: false
    - shell: /sbin/nologin

create-datadir:
  file.directory:
    - name: /opt/data
    - user: mysql
    - group: mysql
    - mode: '0755'
    - makedirs: true

/usr/src/mysql-5.7.34-linux-glibc2.12-x86_64.tar.gz:
  file.managed:
    - source: salt://modules/database/mysql/files/mysql-5.7.34-linux-glibc2.12-x86_64.tar.gz
    - user: root
    - group: root
    - mode: '0644'

salt://modules/database/mysql/files/install.sh:
  cmd.script

trasfer-files:
  file.managed:
    - names:
      - /usr/local/mysql/support-files/mysql.server:
        - source: salt://modules/database/mysql/files/mysql.server
      - /usr/lib/systemd/system/mysqld.service:
        - source: salt://modules/database/mysql/files/mysqld.service


[root@master prod]#

[root@master prod]# cat modules/application/php7/install.sls
php-dep-packages:
  pkg.installed:
    - pkgs:
      - libxml2
      - libxml2-devel
      - openssl
      - openssl-devel
      - bzip2
      - bzip2-devel
      - libcurl
      - libcurl-devel
      - libicu-devel
      - libjpeg-turbo
      - libjpeg-turbo-devel
      - libpng
      - libpng-devel
      - openldap-devel
      - pcre-devel
      - freetype
      - freetype-devel
      - gmp
      - gmp-devel
      - libmcrypt
      - libmcrypt-devel
      - readline
      - readline-devel
      - libxslt
      - libxslt-devel
      - mhash
      - mhash-devel
      - libsqlite3x-devel
      - php-mysqlnd
      - libzip-devel
      - gcc
      - gcc-c++
      - make

/usr/src/oniguruma-devel-6.8.2-2.el8.x86_64.rpm:
  file.managed:
    - source: salt://modules/application/php7/files/oniguruma-devel-6.8.2-2.el8.x86_64.rpm
    - user: root
    - group: root
    - mode: '0644'
  cmd.run:
    - name: yum -y install /usr/src/oniguruma-devel-6.8.2-2.el8.x86_64.rpm

/usr/src:
  archive.extracted:
    - source: salt://modules/application/php7/files/php-7.4.24.tar.gz

salt://modules/application/php7/files/install.sh:
  cmd.script

copysoft:
  file.managed:
    - names:
      - /etc/init.d/php-fpm:
        - source: salt://modules/application/php7/files/php-fpm
        - user: root
        - group: root
        - mode: '0755'
      - /usr/local/php7/etc/php-fpm.conf:
        - source: salt://modules/application/php7/files/php-fpm.conf
      - /usr/local/php7/etc/php-fpm.d/www.conf:
        - source: salt://modules/application/php7/files/www.conf
      - /usr/lib/systemd/system/php-fpm.service:
        - source: salt://modules/application/php7/files/php-fpm.service

php-fpm.service:
  service.running:
    - enable: true

[root@master prod]#

[root@master prod]# cat zabbix/apache.sls
"Development Tools":
  pkg.group_installed

#include:
#  - modules.web.apache.install

/usr/include/httpd:
  file.symlink:
    - target: /usr/local/httpd/include

create-testdir:
  file.directory:
    - name: /usr/local/httpd/htdocs/zabbix
    - user: root
    - group: root
    - mode: '0755'

/usr/local/httpd/htdocs/zabbix/index.php:
  file.managed:
    - source: salt://zabbix/files/index.php
    - user: root
    - group: root
    - mode: '0644'

/usr/local/httpd/conf/extra/vhosts.conf:
  file.managed:
    - source: salt://zabbix/files/vhosts.conf
    - user: root
    - group: root
    - mode: '0644'


zabbix-apache-service:
  service.running:
    - name: httpd
    - enable: true
[root@master prod]#

[root@master prod]# cat zabbix/mysql.sls
lamp-dep-package:
  pkg.installed:
    - pkgs:
      - ncurses-devel
      - openssl-devel
      - openssl
      - cmake
      - mariadb-devel

include:
- modules.database.mysql.install

provides-mysql-file:
  file.managed:
    - user: root
    - group: root
    - mode: '0644'
    - names:
      - /etc/my.cnf:
        - source: salt://zabbix/files/my.cnf
      - /etc/ld.so.conf.d/mysql.conf:
        - source: salt://zabbix/files/mysql.conf

/usr/local/include/mysq:
  file.symlink:
    - target: /usr/local/include/mysq/include

mysqld.service:
  service.running:
    - enable: true

mysqld-set-password:
  cmd.run:
    - name: /usr/local/mysql/bin/mysql -e "set password = password('1');"
[root@master prod]#

[root@master prod]# cat zabbix/main.sls
include:
  - zabbix.apache
#  - zabbix.mysql
#  - modules.application.php7.install
[root@master prod]#

[root@master prod]# cat zabbix/mysql.sls
lamp-dep-package:
  pkg.installed:
    - pkgs:
      - ncurses-devel
      - openssl-devel
      - openssl
      - cmake
      - mariadb-devel

include:
- modules.database.mysql.install

provides-mysql-file:
  file.managed:
    - user: root
    - group: root
    - mode: '0644'
    - names:
      - /etc/my.cnf:
        - source: salt://zabbix/files/my.cnf
      - /etc/ld.so.conf.d/mysql.conf:
        - source: salt://zabbix/files/mysql.conf

/usr/local/include/mysq:
  file.symlink:
    - target: /usr/local/include/mysq/include

mysqld.service:
  service.running:
    - enable: true

mysqld-set-password:
  cmd.run:
    - name: /usr/local/mysql/bin/mysql -e "set password = password('1');"

请添加图片描述

[root@master prod]# cat zabbix/main.sls
include:
  - zabbix.apache
#  - zabbix.mysql
#  - modules.application.php7.install
[root@master prod]# cat zabbix/install.sls
zabbix-dep-packages:
  pkg.installed:
    - pkgs:
      - net-snmp-devel
      - libevent-devel

/usr/src:
  archive.extracted:
    - source: salt://zabbix/files/zabbix-5.4.4.tar.gz

zabbix:
  user.present:
    - shell: /sbin/nologin
    - createhome: false
    - system: true

salt://zabbix/files/zabbix.sh:
  cmd.script

/usr/local/etc/zabbix_server.conf:
  file.managed:
    - source: salt://zabbix/files/zabbix_server.conf

  cmd.run:
    - name: "zabbix_server ; zabbix_agentd "

create-testdir:
  file.directory:
    - name: /usr/local/httpd/htdocs/zabbix
    - user: root
    - group: root
    - mode: '0755'

  cmd.run:
    - name: " cp -r /usr/src/zabbix-5.4.4/ui/* /usr/local/httpd/htdocs/zabbix/ "

/usr/local/httpd/conf/extra/vhosts.conf:
  file.managed:
    - source: salt://zabbix/files/vhosts.conf

/etc/php.ini:
  file.managed:
    - source: salt://zabbix/files/php.ini

zabbix-zabbix-service:
  service.running:
    - names:
      - php-fpm
      - httpd
    - restart: true

[root@master prod]#

验证效果

[root@node1 ~]# ss -antl
State         Recv-Q        Send-Q               Local Address:Port                Peer Address:Port
LISTEN        0             128                        0.0.0.0:22                       0.0.0.0:*
LISTEN        0             128                        0.0.0.0:10050                    0.0.0.0:*
LISTEN        0             128                      127.0.0.1:9000                     0.0.0.0:*
LISTEN        0             128                              *:80                             *:*
LISTEN        0             128                           [::]:22                          [::]:*
LISTEN        0             80                               *:3306                           *:*
[root@node1 ~]#

在这里插入图片描述
