操作系统 -- java实现进程调度FCFS算法

本文链接：https://blog.youkuaiyun.com/qq_56056920/article/details/127260291
package com.test2;


import java.util.ArrayList;
import java.util.Scanner;

/**
 * @author : YWJ
 * @date : 2022/10/7 : 17:23
 */


public class Test {
    static int totalTime;//总周转时间
    static double totalTurnTime ;//总带权周转时间
    static final int TOTAL_MEMORY = 100;//总内存
    static final int TOTAL_TAPE_DRIVE = 4; //总磁盘
    static int sumMemory = 0; //以使用内存
    static int sumTapeDrive = 0; //已使用磁盘
    static ArrayList<Problem> allProblem = new ArrayList<>(); //进程列表
    static ArrayList<Problem> inProgress = new ArrayList<>();//正在运行的进程列表

    public static void main(String[] args) {
        init();//初始化进程列表
        fcfs(allProblem);
    }


    //初始化进程列表
    public static void init() {
        Scanner sc = new Scanner(System.in);
        System.out.print("请输入进程数：");
        int num = sc.nextInt();
        sc.nextLine();
        for (int i = 0; i < num; i++) {
            System.out.println("请输入第"+(i+1)+"个作业的名称，开始时间(小时 分钟)，所需时间，所需内存，所需磁盘（用空格隔开）:");
            String[] str = sc.nextLine().split(" ");
            allProblem.add(new Problem(str[0], new DateTime(Integer.parseInt(str[1]), Integer.parseInt(str[2])),
                    Integer.parseInt(str[3]),
                    Integer.parseInt(str[4]),
                    Integer.parseInt(str[5])));
        }

        sc.close();

        //按进程开始时间排序
        timeSort(allProblem);

    }

    public static void  timeSort(ArrayList<Problem> allProblem){

        for (int i = 0; i < allProblem.size() - 1; i++) {
            for (int j = 0; j < allProblem.size() - 1 - i; j++) {
                if (allProblem.get(j).getStartTime().compareTo(allProblem.get(j + 1).getStartTime()) > 0) {
                    Problem temp = allProblem.get(j);
                    allProblem.set(j, allProblem.get(j + 1));
                    allProblem.set(j + 1, temp);
                }
            }
        }
    }


    //FCFS（First Come First Severd，先来先服务）
    public static void fcfs(ArrayList<Problem> allProblems) {
        for (int i = 0; i < allProblems.size(); i++) {
            Problem obj = allProblems.get(i);
            //判断可执行性
            if (obj.getMemory() > TOTAL_MEMORY || obj.getTapeDrive() > TOTAL_TAPE_DRIVE) {
                //证明该进程所需空间或磁盘，超出硬件可承受范围
                System.out.println(obj.getName() + " 硬件要求过高，无法执行！ 已自行跳过...");
                continue;
            }
            //打印信息
            System.out.println("正在等待进程 : " + obj.getName());
            for (int j = 0; j < inProgress.size(); ) {
                if (inProgress.get(j).getEndTime().compareTo(obj.getStartTime()) <= 0) {
                   remove(j);
                }
                j++ ;
            }
            //此时已经剔除早于该进程的进程，
            //添加进运行队列
            inProgress.add(obj);
            //更新系统内存，以及磁盘占用情况
            sumTapeDrive += obj.getTapeDrive();
            sumMemory += obj.getMemory();
            if (i == 0 || inProgress.size() == 0) {
                //设置等待时间 为 0;
                obj.setWaitTime(0);
                //设置结束时间
                obj.setEndTime();
                System.out.println("进程开始执行 : " + obj.print());
                continue;
            }
            if(sumMemory <= TOTAL_MEMORY && sumTapeDrive <= TOTAL_TAPE_DRIVE){
                //设置等待时间 为 0;
                obj.setWaitTime(0);
            }
            while(sumMemory>TOTAL_MEMORY||sumTapeDrive>TOTAL_TAPE_DRIVE) {
                //否则不可执行，此时依次移除进程，并设置等待时间
                obj.setWaitTime(inProgress.get(0).getEndTime().diff(obj.getStartTime()));
                remove(0);
            }//设置结束时间
            obj.setEndTime();
            System.out.println("进程开始执行 : " + obj.print());
        }
        //最后输出进程信息
        for (int i = 0; i < inProgress.size();) {
           remove(i);
        }
        printRe();
        System.out.println("平均周转时间： "+totalTime/allProblems.size());
        System.out.println("平均带权周转时间 : "+totalTurnTime/allProblems.size());
    }

    public static void remove(int i){
        //同时 释放磁盘空间 内存空间
        sumMemory -= inProgress.get(i).getMemory();
        sumTapeDrive -= inProgress.get(i).getTapeDrive();
        //计算周转时间，带权周转时间
        inProgress.get(i).setTurnaroundTime(inProgress.get(i).getEndTime().diff(inProgress.get(i).getStartTime()));
        inProgress.get(i).setTurnaroundTimeWithRight((double) inProgress.get(i).getTurnaroundTime() / inProgress.get(i).getDuration());
        totalTime += inProgress.get(i).getTurnaroundTime() ;
        totalTurnTime += inProgress.get(i).getTurnaroundTimeWithRight();
        System.out.println("进程执行结束: " + inProgress.get(i).getName());
        inProgress.remove(i);
    }

    public static void printRe(){
        System.out.println("所有进程执行完毕");
        for (Problem problem : allProblem) {
            System.out.println(problem);
        }
    }

}

class Problem{//进程类
    private final String name ;
    private final DateTime startTime ;
    private final int duration ; //耗时
    private final int memory ;// 内存
    private final int tapeDrive ;//磁盘
    private DateTime endTime ;
    private int waitTime ;//等待时间
    private int turnaroundTime ; //周转时间
    private double turnaroundTimeWithRight ; //带权周转时间

    public int getTurnaroundTime() {
        return turnaroundTime;
    }

    public double getTurnaroundTimeWithRight() {
        return turnaroundTimeWithRight;
    }

    public Problem(String name , DateTime startTime, int duration, int memory, int tapeDrive) {
        this.name = name ;
        this.startTime = startTime;
        this.duration = duration;
        this.memory = memory;
        this.tapeDrive = tapeDrive;
    }

    public String getName() {
        return name;
    }

    public DateTime getStartTime() {
        return startTime;
    }

    public int getDuration() {
        return duration;
    }

    public DateTime getEndTime() {
        return endTime;
    }

    public void setEndTime() {
        this.endTime = new DateTime(0,0).addTime(startTime,waitTime,duration);
    }

    public int getMemory() {
        return memory;
    }

    public void setWaitTime(int waitTime) {
        this.waitTime = waitTime;
    }

    public int getTapeDrive() {
        return tapeDrive;
    }




    public void setTurnaroundTime(int turnaroundTime) {
        this.turnaroundTime = turnaroundTime;
    }

    public void setTurnaroundTimeWithRight(double turnaroundTimeWithRight) {
        this.turnaroundTimeWithRight = turnaroundTimeWithRight;
    }


    public String print() {
        return  name+" {" +
                " startTime=" + startTime +
                ", duration=" + duration +
                ", memory=" + memory +
                ", tapeDrive=" + tapeDrive +
                '}';
    }

    @Override
    public String toString() {
        return name +"{" +
                " startTime=" + startTime +
                ", duration=" + duration +
                ", memory=" + memory +
                ", tapeDrive=" + tapeDrive +
                ", endTime=" + endTime +
                ", waitTime=" + waitTime +
                ", turnaroundTime=" + turnaroundTime +
                ", turnaroundTimeWithRight=" + turnaroundTimeWithRight +
                '}';
    }

    public int getWaitTime() {
        return this.waitTime;
    }
}


class DateTime implements Comparable<DateTime>{
    private int h ;
    private int m ;

    public DateTime(int h, int m) {
        if (h<0||h>23||m<0||m>59) {
            this.h = 0;
            this.m = 0;
            return ;
        }
        this.h = h;
        this.m = m;
    }

    public int getH() {
        return h;
    }


    public int getM() {
        return m;
    }

    public DateTime addTime(DateTime startTime,int m1 , int m2){
        m = m1 + m2 ;
        this .h  = startTime.getH()+m/60 ;
        this.m = startTime.getM()+m%60 ;
        if(this.m > 60){
            this.h += 1 ;
            this.m -= 60 ;
        }
        return this ;
    }

    public int diff(DateTime startTime){
        return (h*60+ m) - (startTime.h*60+startTime.m);
    }

    @Override
    public String toString() {
        return  h + " : "+String.format("%02d",m) ;
    }

    @Override
    public int compareTo(DateTime o) {
        if(this.h == o.h && this.m == o.m) return 0 ;
        if(this.h>o.h) return 1 ;
        if(this.h<o.h) return -1 ;
        if(this.m>o.m) return 1 ;
        return -1 ;
    }


}
