本文介绍如何使用Summernote富文本编辑器实现图文混排、图片上传及自定义配置等功能。通过前端代码示例和后端对接说明，帮助开发者快速上手。
中文官网
官网：官网地址
首先掌握，不懂得地方进来看summernote基本使用
前端代码
<!DOCTYPE html SYSTEM "http://www.thymeleaf.org/dtd/xhtml1-strict-thymeleaf-spring4-4.dtd">
<html xmlns="http://www.w3.org/1999/xhtml"
xmlns:th="http://www.thymeleaf.org"
xmlns:layout="http://www.ultraq.net.nz/web/thymeleaf/layout"
xmlns:sec="http://www.thymeleaf.org/thymeleaf-extras-springsecurity5"
layout:decorator="base/base-layout">
<head>
<meta charset="UTF-8">
<title>Summernote</title>
<link href="https://stackpath.bootstrapcdn.com/bootstrap/3.4.1/css/bootstrap.min.css" rel="stylesheet">
<script src="https://code.jquery.com/jquery-3.5.1.min.js"></script>
<script src="https://stackpath.bootstrapcdn.com/bootstrap/3.4.1/js/bootstrap.min.js"></script>
<link href="https://cdn.jsdelivr.net/npm/summernote@0.8.18/dist/summernote.min.css" rel="stylesheet">
<script src="https://cdn.jsdelivr.net/npm/summernote@0.8.18/dist/summernote.min.js"></script>
</head>
<body>
<form method="post">
<textarea id="summernote" name="editordata"></textarea>
</form>
<div>
<input type="button" id="sub">
</div>
<script th:inline="javascript">
//<![CDATA[
$(document).ready(function() {
$('#summernote').summernote({
toolbar:[
['style', ['style']],
['font', ['bold', 'italic', 'underline', 'superscript', 'subscript', 'strikethrough', 'clear']],//加粗、斜体、下划线、删除线
['fontname', ['fontname']],
['fontsize', ['fontsize']],
['color', ['color']],
['para', ['ul', 'ol', 'paragraph']],
['height', ['height']],
['table', ['table']],
['insert', ['link', 'picture', 'hr']], //, 'video'
['view', ['fullscreen']],
['help', ['help']]
],
lang: 'zh-CN' ,// default: 'en-US'
placeholder: '输入文字或者相片',
//tabsize: 2,
height: 300, // set editor height
minHeight: null, // set minimum height of editor
maxHeight: null, // set maximum height of editor
focus: true , // set focus to editable area after initializing summernote
dialogsInBody: true, // 不设置，会出现，点击 summernote 弹出窗口级联关闭父窗口问题
callbacks: {
onImageUpload: function(files, editor, $editable) {
sendFile(files);
},
//删除图片时调用
onMediaDelete: function(target){
removeImage(target[0].dataset.id);//$target[0]是当前对象img标签，获取data-id
},
}
});
$('#sub').click(function () {
var content=$('#summernote').html()
console.log(content)
$.ajax({
url:"/dev/josion/base/test",
type:"POST",
data: {info : content},
success: function(data){
console.log(data)
}
})
})
});
function sendFile(files, editor, $editable) {
var size = files[0].size;
if(size > 5*1024*1024) {
alert("图片大小不能超过5M...");
return false;
}
//console.log("size="+size);
var formData = new FormData();
formData.append("file", files[0]);
$.ajax({
data : formData,
type : "POST",
url : "/dev/josion/base/file", // 图片上传出来的url，返回的是图片上传后的路径，http格式
cache : false,
contentType : false,
processData : false,
dataType : "json",
success: function(data) {
// $('.summernote').summernote('insertImage',data);
console.log(data.data)
//var image= `<p><img src="/dev/assets/images/2022/01/12/3b42cb28-3d7b-46c3-8de4-07dd9c97200b.png"></p> `//"<img src="+"file://,"+data.data+">"
var image= `<p><img src="/dev/assets`+`${data.data}`+`"></p> `//"<img src="+"file://,"+data.data+">"
//$('#summernote').summernote('insertImage', url, filename);插入图片，都行，但如果是static中的因为刷新问题不一定行
$('#summernote').summernote('pasteHTML', image);
console.log("上传成功")
},
error:function(data){
console.log(data)
console.log("上传失败")
//alert("上传失败");
}
});
}
</script>
</body>
</html>
后端代码
@PostMapping("/base/test")
public R<Boolean> base(Summernote summernote) {
Boolean result = false;
String localeMessage = "系统接受了您的操作";
Integer rst = R.SUCCESS;
System.out.println(summernote.getInfo());
if(summernote.getInfo()==null)return new R<Boolean>(false, "参数为空", rst);
String uid=UUID.fastUUID().toString();
String info=summernote.getInfo();
josionUserMapper.base(uid,info);
return new R<Boolean>(result, localeMessage, rst);
}
private String tempFilePath = "E:/workspaces/test/src/main/resources/static/assets/images";
@PostMapping("/base/file")
public R<String> file(@RequestPart("file") MultipartFile file, HttpServletRequest request) throws FileNotFoundException {
if(file == null || file.isEmpty()){
return null;
}
//获取文件名
String fileName = file.getOriginalFilename();
//获取文件的后缀名
String suffixName = fileName.substring(fileName.lastIndexOf("."));
//获取文件大小
//int fileSize = (int)file.getSize();
//获取日期
Date date = new Date();
SimpleDateFormat formatDate = new SimpleDateFormat("yyyy-MM-dd"); //new SimpleDateFormat("yyyy-MM-dd hh:mm:ss");
String time = formatDate.format(date).replaceAll("-", "/");
String r=UUID.fastUUID().toString();
String newFileName=r+suffixName;
//文件路径
String path = tempFilePath+"/"+time+"/"+newFileName;
File saveFilePath= new File(path);
// 判断路径是否存在，如果不存在则创建
if(!saveFilePath.getParentFile().exists()) {
saveFilePath.getParentFile().mkdirs();
}
try {
file.transferTo(saveFilePath);
} catch (Exception e) {
e.printStackTrace();
return null;
}
String a="/images/"+time+"/"+newFileName;
return new R<String>(a, "完成", R.SUCCESS);
}
接收显示
同样，由summernote上传到后端保存的带标签的字符串，当前端接收到后端发来的还html标签的字符串是，直接
$('#summernote').summernote('pasteHTML', data);
就能搞定，包括像之类的直接显示图片
$('#lblQuestionV').summernote({
airMode: true,
disableDragAndDrop: true, //禁止拖放
shortcuts: false,//禁止快捷键
});
$('#summernote').summernote('disable');
let newCss = {};
newCss.backgroundColor = "white";
$('.note-editable').css(newCss);
$('#summernote').summernote('pasteHTML', data);
//$('#summernote').summernote('enable');//恢复编辑
扩展
删除图片
onImageUploadError //当图片上传发生错误时
常用规则
options: {
modules: {
'editor': Editor,
'clipboard': Clipboard,
'dropzone': Dropzone,
'codeview': Codeview,
'statusbar': Statusbar,
'fullscreen': Fullscreen,
'handle': Handle,
// FIXME: HintPopover must be front of autolink
// - Script error about range when Enter key is pressed on hint popover
'hintPopover': HintPopover,
'autoLink': AutoLink,
'autoSync': AutoSync,
'placeholder': Placeholder,
'buttons': Buttons,
'toolbar': Toolbar,
'linkDialog': LinkDialog,
'linkPopover': LinkPopover,
'imageDialog': ImageDialog,
'imagePopover': ImagePopover,
'videoDialog': VideoDialog,
'helpDialog': HelpDialog,
'airPopover': AirPopover
},
buttons: {},
lang: 'zh-CN',
// toolbar工具栏默认
toolbar: [
['style', ['style']],
['font', ['bold', 'underline', 'clear']],
['fontname', ['fontname']],
['color', ['color']],
['para', ['ul', 'ol', 'paragraph']],
['table', ['table']],
['insert', ['link', 'picture', 'video']],
['view', ['fullscreen', 'codeview', 'help']]
],
// popover
popover: {
image: [
['imagesize', ['imageSize100', 'imageSize50', 'imageSize25']],
['float', ['floatLeft', 'floatRight', 'floatNone']],
['remove', ['removeMedia']]
],
link: [
['link', ['linkDialogShow', 'unlink']]
],
air: [
['color', ['color']],
['font', ['bold', 'underline', 'clear']],
['para', ['ul', 'paragraph']],
['table', ['table']],
['insert', ['link', 'picture']]
]
},
// air mode: inline editor
airMode: false,
width: null,
height: null,
focus: false,
tabSize: 4,
styleWithSpan: false,
shortcuts: true,
textareaAutoSync: true,
direction: null,
styleTags: ['p', 'blockquote', 'pre', 'h1', 'h2', 'h3', 'h4', 'h5', 'h6'],
fontNames: [
'Arial', 'Arial Black', 'Comic Sans MS', 'Courier New',
'Helvetica Neue', 'Helvetica', 'Impact', 'Lucida Grande',
'Tahoma', 'Times New Roman', 'Verdana'
],
fontSizes: ['8', '9', '10', '11', '12', '14', '18', '24', '36'],
// pallete colors(n x n)
colors: [
['#000000', '#424242', '#636363', '#9C9C94', '#CEC6CE', '#EFEFEF', '#F7F7F7', '#FFFFFF'],
['#FF0000', '#FF9C00', '#FFFF00', '#00FF00', '#00FFFF', '#0000FF', '#9C00FF', '#FF00FF'],
['#F7C6CE', '#FFE7CE', '#FFEFC6', '#D6EFD6', '#CEDEE7', '#CEE7F7', '#D6D6E7', '#E7D6DE'],
['#E79C9C', '#FFC69C', '#FFE79C', '#B5D6A5', '#A5C6CE', '#9CC6EF', '#B5A5D6', '#D6A5BD'],
['#E76363', '#F7AD6B', '#FFD663', '#94BD7B', '#73A5AD', '#6BADDE', '#8C7BC6', '#C67BA5'],
['#CE0000', '#E79439', '#EFC631', '#6BA54A', '#4A7B8C', '#3984C6', '#634AA5', '#A54A7B'],
['#9C0000', '#B56308', '#BD9400', '#397B21', '#104A5A', '#085294', '#311873', '#731842'],
['#630000', '#7B3900', '#846300', '#295218', '#083139', '#003163', '#21104A', '#4A1031']
],
lineHeights: ['1.0', '1.2', '1.4', '1.5', '1.6', '1.8', '2.0', '3.0'],
tableClassName: 'table table-bordered',
insertTableMaxSize: {
col: 10,
row: 10
},
dialogsInBody: false,
dialogsFade: false,
maximumImageFileSize: null,
callbacks: {
onInit: null,//初始化回调函数
onFocus: null,//聚集
onBlur: null,//失去焦点
onEnter: null,//回车键的回调函数
onKeyup: null,
onKeydown: null,
onSubmit: null,//提交时回调函数
onImageUpload: null,//这就是上传图片的回调函数
onImageUploadError: null//上传图片出错
},
codemirror: {
mode: 'text/html',
htmlMode: true,
lineNumbers: true
},
keyMap: {
pc: {
'ENTER': 'insertParagraph',
'CTRL+Z': 'undo',
'CTRL+Y': 'redo',
'TAB': 'tab',
'SHIFT+TAB': 'untab',
'CTRL+B': 'bold',
'CTRL+I': 'italic',
'CTRL+U': 'underline',
'CTRL+SHIFT+S': 'strikethrough',
'CTRL+BACKSLASH': 'removeFormat',
'CTRL+SHIFT+L': 'justifyLeft',
'CTRL+SHIFT+E': 'justifyCenter',
'CTRL+SHIFT+R': 'justifyRight',
'CTRL+SHIFT+J': 'justifyFull',
'CTRL+SHIFT+NUM7': 'insertUnorderedList',
'CTRL+SHIFT+NUM8': 'insertOrderedList',
'CTRL+LEFTBRACKET': 'outdent',
'CTRL+RIGHTBRACKET': 'indent',
'CTRL+NUM0': 'formatPara',
'CTRL+NUM1': 'formatH1',
'CTRL+NUM2': 'formatH2',
'CTRL+NUM3': 'formatH3',
'CTRL+NUM4': 'formatH4',
'CTRL+NUM5': 'formatH5',
'CTRL+NUM6': 'formatH6',
'CTRL+ENTER': 'insertHorizontalRule',
'CTRL+K': 'linkDialog.show'
},
mac: {
'ENTER': 'insertParagraph',
'CMD+Z': 'undo',
'CMD+SHIFT+Z': 'redo',
'TAB': 'tab',
'SHIFT+TAB': 'untab',
'CMD+B': 'bold',
'CMD+I': 'italic',
'CMD+U': 'underline',
'CMD+SHIFT+S': 'strikethrough',
'CMD+BACKSLASH': 'removeFormat',
'CMD+SHIFT+L': 'justifyLeft',
'CMD+SHIFT+E': 'justifyCenter',
'CMD+SHIFT+R': 'justifyRight',
'CMD+SHIFT+J': 'justifyFull',
'CMD+SHIFT+NUM7': 'insertUnorderedList',
'CMD+SHIFT+NUM8': 'insertOrderedList',
'CMD+LEFTBRACKET': 'outdent',
'CMD+RIGHTBRACKET': 'indent',
'CMD+NUM0': 'formatPara',
'CMD+NUM1': 'formatH1',
'CMD+NUM2': 'formatH2',
'CMD+NUM3': 'formatH3',
'CMD+NUM4': 'formatH4',
'CMD+NUM5': 'formatH5',
'CMD+NUM6': 'formatH6',
'CMD+ENTER': 'insertHorizontalRule',
'CMD+K': 'linkDialog.show'
}
},
icons: {
'align': 'icon-align',
'alignCenter': 'icon-align-center',
'alignJustify': 'icon-align-justify',
'alignLeft': 'icon-align-left',
'alignRight': 'icon-align-right',
'indent': 'icon-indent-right',
'outdent': 'icon-indent-left',
'arrowsAlt': 'icon-resize-full',
'bold': 'icon-bold',
'caret': 'icon-caret-down',
'circle': 'icon-circle',
'close': 'icon-close',
'code': 'icon-code',
'eraser': 'icon-eraser',
'font': 'icon-font',
'frame': 'icon-frame',
'italic': 'icon-italic',
'link': 'icon-link',
'unlink': 'icon-chain-broken',
'magic': 'icon-magic',
'menuCheck': 'icon-check',
'minus': 'icon-minus',
'orderedlist': 'icon-list-ol',
'pencil': 'icon-pencil',
'picture': 'icon-picture',
'question': 'icon-question',
'redo': 'icon-redo',
'square': 'icon-square',
'strikethrough': 'icon-strikethrough',
'subscript': 'icon-subscript',
'superscript': 'icon-superscript',
'table': 'icon-table',
'textHeight': 'icon-text-height',
'trash': 'icon-trash',
'underline': 'icon-underline',
'undo': 'icon-undo',
'unorderedlist': 'icon-list-ul',
'video': 'icon-facetime-video'
}
}
