CentOS DNS (bind )服务

本专栏提供售后服务，帮助解决问题，文章底部扫描进群即可

题目

DNS
安装DNS服务相关软件包；
建立sdskills.com域，为所有除Internet区域的主机或服务器建立正\反的域名解析;
当出现无法解析的域名时，向域skills.com申请更高层次的解析。

一、关闭Selinux跟防火墙

setenforce 0

systemctl stop firewalld

二、安装dns服务

yum install bind -y

三、修改配置文件，设置正反向解析区域

vim /etc/named.conf

把13行和21行修改为any

listen-on port 53 {

any; };

allow-query {

any; };

设置转发

forwarders {

192.168.10.4;};

注销掉此三行代码

# recursion yes;

# dnssec-enable yes;

# dnssec-validation yes;

在末尾添加正反向解析区域

zone "sdskills.com" IN {

type master;

file "sdskills.com.zone";

};

zone "100.16.172.in-addr.arpa" IN {

type master;

file "172.16.100.zone";

};

然后保存退出再切换目录

cd /var/named/

复制模板

cp named.loopback sdskills.com.zone

cp named.loopback 172.16.100.zone

修改正向区域文件

vim sdskills.com.zone

$TTL 1D

@ IN SOA @ rname.invalid. (

0 ; serial

1D ; refresh

1H ; retry

1W ; expire

3H ) ; minimum

@ IN NS www.sdskills.com.

@ IN MX 10 mail

www IN A 172.16.100.201

ftp IN A 172.16.100.202

mail IN A 172.16.100.202

反向区域

vim 172.16.100.zone

$TTL 1D

@ IN SOA @ rname.invalid. (

0 ; serial

1D ; refresh

1H ; retry

1W ; expire

3H ) ; minimum

@ NS www.sdskills.com.

201 IN PTR www.sdskills.com.

202 IN PTR ftp.sdskills.com.

202 IN PTR mail.sdskills.com.

给文件赋权，并重启服务

chmod 777 sdskills.com.zone 172.16.100.zone

systemctl restart named

四、客户端测试

修改DNS地址

vim /etc/resolv.conf

设置DNS地址

nameserver 172.16.100.201

安装DNS工具

yum install bind-utils -y

解析

[root@Client ~]# nslookup www.sdskills.com

Server: 172.16.100.201

Address: 172.16.100.201#53



Name: www.sdskills.com

Address: 172.16.100.201



[root@Client ~]# nslookup ftp.sdskills.com

Server: 172.16.100.201

Address: 172.16.100.201#53



Name: ftp.sdskills.com

Address: 172.16.100.202



[root@Client ~]# nslookup 172.16.100.201

Server: 172.16.100.201

Address: 172.16.100.201#53



201.100.16.172.in-addr.arpa name = www.sdskills.com.



[root@Client ~]# nslookup 172.16.100.202

Server: 172.16.100.201

Address: 172.16.100.201#53



202.100.16.172.in-addr.arpa name = ftp.sdskills.com.

202.100.16.172.in-addr.arpa name = mail.sdskills.com.



[root@Client ~]#

[root@Client ~]# host -t MX sdskills.com. 172.16.100.201

Using domain server:

Name: 172.16.100.201

Address: 172.16.100.201#53

Aliases:



sdskills.com mail is handled by 10 mail.sdskills.com.
