【深度之眼cs231n第七期】笔记（十三）

FullyConnedtedNets.ipynb

上一个作业中实现了一个两层全连接网络，但是它并非结构化的，因为它在同一个函数中计算整个网络的梯度。这种做法在浅层神经网络中还容易实现，但是在深度神经网络就难以实现了。所以需要构造一个结构化的神经网络。

首先，每一层实现一个forward()和一个backward()函数。
forward()主要计算输出，结构如下：

def layer_forward(x, w):
  """ 接收输入x和权重w"""
  # 做一些计算……
  z = # ……得到一些中间值
  # 做更多的计算……
  out = # 输出

  cache = (x, w, z, out) # 保存计算梯度是所需的值

  return out, cache

backward()主要计算梯度，结构如下：

def layer_backward(dout, cache):
  """
  接收上游传回来的导数∂loss/∂outputs和cache中保存的计算梯度所需的值,
  然后计算∂loss/∂x和∂loss/∂w
  """
  # 取出cache里保存的值
  x, w, z, out = cache

  # 使用cache里的值计算梯度
  dx = # 赋值
  dw = # 赋值
  return dx, dw

刚开始运行下面的代码时可能会出错。懂得解决的话自己解决就好了，不懂的话可以参考这篇文章。

# 像以前一样，为后续代码做准备
from __future__ import print_function
import time
import numpy as np
import matplotlib.pyplot as plt
from cs231n.classifiers.fc_net import *
from cs231n.data_utils import get_CIFAR10_data
from cs231n.gradient_check import eval_numerical_gradient, eval_numerical_gradient_array
from cs231n.solver import Solver

%matplotlib inline
plt.rcParams['figure.figsize'] = (10.0, 8.0) # 设置画图的默认大小
plt.rcParams['image.interpolation'] = 'nearest'
plt.rcParams['image.cmap'] = 'gray'

# 自动加载额外的文件
%load_ext autoreload
%autoreload 2

def rel_error(x, y):
  """ 返回相对误差 """
  return np.max(np.abs(x - y) / (np.maximum(1e-8, np.abs(x) + np.abs(y))))

加载预处理过（减均值）的CIFAR-10数据，函数内部和以前的差不多，只不过现在封装起来了。

data = get_CIFAR10_data()
for k, v in list(data.items()):
  # 输出数据的维度
  print(('%s: ' % k, v.shape))
'''('X_train: ', (49000, 3, 32, 32))
('y_train: ', (49000,))
('X_val: ', (1000, 3, 32, 32))
('y_val: ', (1000,))
('X_test: ', (1000, 3, 32, 32))
('y_test: ', (1000,))
'''

affine层的forward和backward

先完成cs231n/layers.py里的affine_forward()再运行下面代码

# 测试affine_forward()是否编程正确
num_inputs = 2
input_shape = (4, 5, 6)
output_dim = 3

# np.prod()函数用来计算数组中所有元素的乘积
input_size = num_inputs * np.prod(input_shape)
weight_size = output_dim * np.prod(input_shape)

# reshape只接受整数，所以要使用*input_shape
x = np.linspace(-0.1, 0.5, num=input_size).reshape(num_inputs, *input_shape)
w = np.linspace(-0.2, 0.3, num=weight_size).reshape(np.prod(input_shape), output_dim)
b = np.linspace(-0.3, 0.1, num=output_dim)

out, _ = affine_forward(x, w, b)
correct_out = np.array([[ 1.49834967,  1.70660132,  1.91485297],
                        [ 3.25553199,  3.5141327,   3.77273342]])

# 比较编程输出和给定的输出，误差应该小于1e-9.
print('Testing affine_forward function:')
print('difference: ', rel_error(out, correct_out))
# Testing affine_forward function:
# difference:  9.769849468192957e-10

先完成cs231n/layers.py里的affine_backward()再运行下面代码

# 固定随机种子，使结果可以复现
np.random.seed(231)
x = np.random.randn(10, 2, 3)
w = np.random.randn(6, 5)
b = np.random.randn(5)
dout = np.random.randn(10, 5)

# 计算数值梯度
dx_num = eval_numerical_gradient_array(lambda x: affine_forward(x, w, b)[0], x, dout)
dw_num = eval_numerical_gradient_array(lambda w: affine_forward(x, w, b)[0], w, dout)
db_num = eval_numerical_gradient_array(lambda b: affine_forward(x, w, b)[0], b, dout)

# 计算解析梯度（自己实现的）
_, cache = affine_forward(x, w, b)
dx, dw, db = affine_backward(dout, cache)

# 相对误差应该都小于1e-10
print('Testing affine_backward function:')
print('dx error: ', rel_error(dx_num, dx))
print('dw error: ', rel_error(dw_num, dw))
print('db error: ', rel_error(db_num, db))
# Testing affine_backward function:
# dx error:  5.399100368651805e-11
# dw error:  9.904211865398145e-11
# db error:  2.4122867568119087e-11

ReLU层的forward和backward

**先完成cs231n/layers.py里的relu_forward()和relu_backward()**再运行下面代码

# 测试relu_forward()
x = np.linspace(-0.5, 0.5, num=12).reshape(3, 4)

# 调用函数计算输出
out, _ = relu_forward(x)
correct_out = np.array([[ 0.,          0.,          0.,          0.,        ],
                        [ 0.,          0.,          0.04545455,  0.13636364,],
                        [ 0.22727273,  0.31818182,  0.40909091,  0.5,       ]])

# 相对误差应该在5e-8左右
print('Testing relu_forward function:')
print('difference: ', rel_error(out, correct_out))
# Testing relu_forward function:
# difference:  4.999999798022158e-08


# 测试relu_backward()
np.random.seed(231)
x = np.random.randn(10, 10)
# randn()只接受整数，所以要使用*x.shape
dout = np.random.randn(*x.shape)

# 计算数值梯度
dx_num = eval_numerical_gradient_array(lambda x: relu_forward(x)[0], x, dout)
# 计算解析梯度
_, cache = relu_forward(x)
dx = relu_backward(dout, cache)

# 相对误差应该在3e-12左右
print('Testing relu_backward function:')
print('dx error: ', rel_error(dx_num, dx))
# Testing relu_backward function:
# dx error:  3.2756349136310288e-12

affine层和ReLU层的forward和backward合并

在cs231n/layer_utils.py中实现了合并，代码如下：

def affine_relu_forward(x, w, b):
    # affine的前向传播
    a, fc_cache = affine_forward(x, w, b)
    # ReLU的前向传播
    out, relu_cache = relu_forward(a)
    cache = (fc_cache, relu_cache)
    return out, cache

def affine_relu_backward(dout, cache):
    fc_cache, relu_cache = cache
    # ReLU的反向传播
    da = relu_backward(dout, relu_cache)
    # affine的反向传播
    dx, dw, db = affine_backward(da, fc_cache)
    return dx, dw, db

运行下面代码，验证affine+ReLU的正确性

from cs231n.layer_utils import affine_relu_forward, affine_relu_backward
# 固定随机种子数
np.random.seed(231)
x = np.random.randn(2, 3, 4)
w = np.random.randn(12, 10)
b = np.random.randn(10)
dout = np.random.randn(2, 10)

# 前向传播
out, cache = affine_relu_forward(x, w, b)
# 反向传播
dx, dw, db = affine_relu_backward(dout, cache)

# 计算数值梯度
dx_num = eval_numerical_gradient_array(lambda x: affine_relu_forward(x, w, b)[0], x, dout)
dw_num = eval_numerical_gradient_array(lambda w: affine_relu_forward(x, w, b)[0], w, dout)
db_num = eval_numerical_gradient_array(lambda b: affine_relu_forward(x, w, b)[0], b, dout)

print('Testing affine_relu_forward:')
print('dx error: ', rel_error(dx_num, dx))
print('dw error: ', rel_error(dw_num, dw))
print('db error: ', rel_error(db_num, db))
# Testing affine_relu_forward:
# dx error:  2.299579177309368e-11
# dw error:  8.162011105764925e-11
# db error:  7.826724021458994e-12

损失层：softmax和SVM

在cs231n/layers.py里实现了两个损失，代码如下：

def svm_loss(x, y):
    """
    输入:
    - x: 维度为(N, C)，其中x[i, j]表示第i个输入关于第j个类的得分
    - y: 标签，维度为(N,)
    返回:
    - loss: 损失
    - dx: x（也就是得分）的梯度
    """
    N = x.shape[0]
    # x[np.arange(N), y]得到的维度是(N,)
    correct_class_scores = x[np.arange(N), y]
    # correct_class_scores[:, np.newaxis]的维度是(N,1)
    margins = np.maximum(0, x - correct_class_scores[:, np.newaxis] + 1.0)
    # 正确类得分不参与计算
    margins[np.arange(N), y] = 0
    loss = np.sum(margins) / N

    # 计算梯度
    num_pos = np.sum(margins > 0, axis=1)
    dx = np.zeros_like(x)
    dx[margins > 0] = 1
    dx[np.arange(N), y] -= num_pos
    dx /= N
    return loss, dx

def softmax_loss(x, y):
    # 减去最大值，使其全部小于0，这样exp(shifted_logits)就会在0到1之间，
    # 防止exp(x)过大而溢出。而且该减去操作不影响最终损失。
    shifted_logits = x - np.max(x, axis=1, keepdims=True)
    Z = np.sum(np.exp(shifted_logits), axis=1, keepdims=True)
    log_probs = shifted_logits - np.log(Z)
    N = x.shape[0]
    # 只使用正确类的得分
    loss = -np.sum(log_probs[np.arange(N), y]) / N

    # 计算梯度
    probs = np.exp(log_probs)
    dx = probs.copy()
    dx[np.arange(N), y] -= 1
    dx /= N
    return loss, dx

验证两个损失层的正确性

np.random.seed(231)
num_classes, num_inputs = 10, 50
x = 0.001 * np.random.randn(num_inputs, num_classes)
y = np.random.randint(num_classes, size=num_inputs)
# 计算数值梯度和解析梯度
dx_num = eval_numerical_gradient(lambda x: svm_loss(x, y)[0], x, verbose=False)
loss, dx = svm_loss(x, y)
# 损失应该是n(10)-1=9左右，dx的相对误差一个在1e-9左右
print('Testing svm_loss:')
print('loss: ', loss)
print('dx error: ', rel_error(dx_num, dx))
# Testing svm_loss:
# loss:  8.999602749096233
# dx error:  1.4021566006651672e-09

dx_num = eval_numerical_gradient(lambda x: softmax_loss(x, y)[0], x, verbose=False)
loss, dx = softmax_loss(x, y)
# 损失应该是ln(10)≈2.3，dx的相对误差一个在1e-8左右
print('\nTesting softmax_loss:')
print('loss: ', loss)
print('dx error: ', rel_error(dx_num, dx))
# Testing softmax_loss:
# loss:  2.302545844500738
# dx error:  9.384673161989355e-09

训练两层全连接网络

完成cs231n/classifiers/fc_net.py里的TwoLayerNet类后再运行以下代码，测试代码是否正确

np.random.seed(231)
N, D, H, C = 3, 5, 50, 7
X = np.random.randn(N, D)
y = np.random.randint(C, size=N)

std = 1e-3
# 初始化模型
model = TwoLayerNet(input_dim=D, hidden_dim=H, num_classes=C, weight_scale=std)

# 测试初始化
print('Testing initialization ... ')
W1_std = abs(model.params['W1'].std() - std)
b1 = model.params['b1']
W2_std = abs(model.params['W2'].std() - std)
b2 = model.params['b2']
# 两个标准差的误差小于std的十分之一
assert W1_std < std / 10, 'First layer weights do not seem right'
assert np.all(b1 == 0), 'First layer biases do not seem right'
assert W2_std < std / 10, 'Second layer weights do not seem right'
assert np.all(b2 == 0), 'Second layer biases do not seem right'

# 测试前向传播得到的得分
print('Testing test-time forward pass ... ')
model.params['W1'] = np.linspace(-0.7, 0.3, num=D*H).reshape(D, H)
model.params['b1'] = np.linspace(-0.1, 0.9, num=H)
model.params['W2'] = np.linspace(-0.3, 0.4, num=H*C).reshape(H, C)
model.params['b2'] = np.linspace(-0.9, 0.1, num=C)
X = np.linspace(-5.5, 4.5, num=N*D).reshape(D, N).T
scores = model.loss(X)
correct_scores = np.asarray(
  [[11.53165108,  12.2917344,   13.05181771,  13.81190102,  14.57198434, 15.33206765,  16.09215096],
   [12.05769098,  12.74614105,  13.43459113,  14.1230412,   14.81149128, 15.49994135,  16.18839143],
   [12.58373087,  13.20054771,  13.81736455,  14.43418138,  15.05099822, 15.66781506,  16.2846319 ]])
scores_diff = np.abs(scores - correct_scores).sum()
assert scores_diff < 1e-6, 'Problem with test-time forward pass'

# 测试损失（无正则化）
print('Testing training loss (no regularization)')
y = np.asarray([0, 5, 1])
loss, grads = model.loss(X, y)
correct_loss = 3.4702243556
assert abs(loss - correct_loss) < 1e-10, 'Problem with training-time loss'


# 测试损失（有正则化）
model.reg = 1.0
loss, grads = model.loss(X, y)
correct_loss = 26.5948426952
assert abs(loss - correct_loss) < 1e-10, 'Problem with regularization loss'

# 测试梯度，分有正则化和无正则化两种情况
for reg in [0.0, 0.7]:
  print('Running numeric gradient check with reg = ', reg)
  model.reg = reg
  loss, grads = model.loss(X, y)
  for name in sorted(grads):
    f = lambda _: model.loss(X, y)[0]
    grad_num = eval_numerical_gradient(f, model.params[name], verbose=False)
    print('%s relative error: %.2e' % (name, rel_error(grad_num, grads[name])))

查看cs231n/solver.py，然后使用一个Solver实例训练一个两层网络，使其在验证集上至少达到50%的准确率

model = TwoLayerNet(reg=0.7)
solver = None
solver = Solver(model,data,
                update_rule='sgd',
                optim_config={
                    'learning_rate': 1e-3,
                },
                lr_decay=0.95,
                num_epochs=10, batch_size=100,
                print_every=100)
solver.train()

可视化训练损失和准确率

# 可视化训练损失
plt.subplot(2, 1, 1)
plt.title('Training loss')
plt.plot(solver.loss_history, 'o')
plt.xlabel('Iteration')

# 可视化准确率
plt.subplot(2, 1, 2)
plt.title('Accuracy')
plt.plot(solver.train_acc_history, '-o', label='train')
plt.plot(solver.val_acc_history, '-o', label='val')
# [0.5]表示虚线在0.5处，len(solver.val_acc_history)代表虚线的长度
plt.plot([0.5] * len(solver.val_acc_history), 'k--')
plt.xlabel('Epoch')
plt.legend(loc='lower right')
plt.gcf().set_size_inches(15, 12)
plt.show()

训练多层全连接网络

完成cs231n/classifiers/fc_net.py里的FullyConnectedNet类后再运行下面的代码
梯度的相对误差应该在1e-6左右或者更小

np.random.seed(231)
N, D, H1, H2, C = 2, 15, 20, 30, 10
X = np.random.randn(N, D)
y = np.random.randint(C, size=(N,))

for reg in [0, 3.14]:
  print('Running check with reg = ', reg)
  model = FullyConnectedNet([H1, H2], input_dim=D, num_classes=C,
                            reg=reg, weight_scale=5e-2, dtype=np.float64)
  loss, grads = model.loss(X, y)
  print('Initial loss: ', loss)
  for name in sorted(grads):
    f = lambda _: model.loss(X, y)[0]
    grad_num = eval_numerical_gradient(f, model.params[name], verbose=False, h=1e-5)
    print('%s relative error: %.2e' % (name, rel_error(grad_num, grads[name])))

另一个检查神经网络是否正常的方法是：使用小数据集在较复杂的网络上训练，使其在训练集上达到100%的准确率，也就是过拟合。

# 使用一个三层网络训练50个数据集，调整学习率和初始化标准差使其过拟合
num_train = 50
small_data = {
  'X_train': data['X_train'][:num_train],
  'y_train': data['y_train'][:num_train],
  'X_val': data['X_val'],
  'y_val': data['y_val'],
}

# 原始数据weight_scale = 1e-2 和 learning_rate = 1e-4
# 改为weight_scale = 1或改为learning_rate = 1e-2都可达到过拟合
weight_scale = 1e-2
learning_rate = 1e-2
model = FullyConnectedNet([100, 100],
              weight_scale=weight_scale, dtype=np.float64)
solver = Solver(model, small_data,
                print_every=10, num_epochs=20, batch_size=25,
                update_rule='sgd',
                optim_config={
                  'learning_rate': learning_rate,
                }
         )
solver.train()

# 画出损失的变化过程
plt.plot(solver.loss_history, 'o')
plt.title('Training loss history')
plt.xlabel('Iteration')
plt.ylabel('Training loss')
plt.show()

使用一个5层的神经网络，调整学习率和初始化标准差，使得50个训练数据在epochs=20时达到过拟合

num_train = 50
small_data = {
  'X_train': data['X_train'][:num_train],
  'y_train': data['y_train'][:num_train],
  'X_val': data['X_val'],
  'y_val': data['y_val'],
}

# 原始数据为weight_scale = 1e-5
learning_rate = 1e-3
weight_scale = 5.7e-2
model = FullyConnectedNet([100, 100, 100, 100],
                weight_scale=weight_scale, dtype=np.float64)
solver = Solver(model, small_data,
                print_every=10, num_epochs=20, batch_size=25,
                update_rule='sgd',
                optim_config={
                  'learning_rate': learning_rate,
                }
         )
solver.train()

# 画出损失变化
plt.plot(solver.loss_history, 'o')
plt.title('Training loss history')
plt.xlabel('Iteration')
plt.ylabel('Training loss')
plt.show()

Q：训练三层网络和训练五层网络相比，有什么不同吗？
A：在训练五层网络的时候，损失对weight_scale更敏感，调整weight_scale能使神经网络更容易收敛到局部最小。原因是五层网络的复杂度使模型有更多可能性的同时，也会使损失函数更复杂，从而更难优化，也就更依赖于初始化。

fc_net.py

两层全连接网络

from builtins import range
from builtins import object
import numpy as np
from cs231n.layers import *
from cs231n.layer_utils import *

class TwoLayerNet(object):
    """
    模块化的两层全连接网络，使用ReLU作为激活函数，softmax作为损失。
    网络结构为affine - relu - affine - softmax
    注意，这个类不实现梯度下降，梯度优化是在Solver类中实现的。
    """
    def __init__(self, input_dim=3*32*32, hidden_dim=100, num_classes=10,
                 weight_scale=1e-3, reg=0.0):
        """
        - weight_scale: 初始化权重时的标准差
        """
        self.params = {}
        self.reg = reg

        # 初始化权重和偏置
        self.params['W1'] = weight_scale*np.random.randn(input_dim,hidden_dim)
        self.params['W2'] = weight_scale*np.random.randn(hidden_dim,num_classes)
        self.params['b1'] = np.zeros((hidden_dim))
        self.params['b2'] = np.zeros((num_classes))

计算两层全连接网络的损失和梯度

    def loss(self, X, y=None):
        """
        输入:
        - X: 维度为(N, d_1, ..., d_k)
        - y: 维度为(N,)
        输出:
        如果y==None返回scores
        - scores: 维度为(N, C)
        否则，返回：
        - loss: 损失
        - grads: self.params里的参数的梯度
        """
        scores = None

        # 实现前向传播，计算得分
        W1,b1 = self.params['W1'],self.params['b1']
        W2,b2 = self.params['W2'],self.params['b2']
        out_relu,affine_relu_cache = affine_relu_forward(X, W1, b1)
        scores,fc_cache = affine_forward(out_relu,W2,b2)

        # 如果y==None，返回scores
        if y is None:
            return scores

        loss, grads = 0, {}
        # dscores维度(N,C)
        loss,dscores = softmax_loss(scores, y)
        # 加上正则化，loss/N在softmax_loss里已经实现了
        loss += self.reg*0.5*(np.sum(W1**2)+np.sum(W2**2))

        # 求梯度
        dout_relu,dW2,db2 = affine_backward(dscores,fc_cache)
        dx,dW1,db1 = affine_relu_backward(dout_relu,affine_relu_cache)

        grads['W1'] = dW1+self.reg*W1
        grads['b1'] = db1
        grads['W2'] = dW2+self.reg*W2
        grads['b2'] = db2

        return loss, grads

多层全连接网络

class FullyConnectedNet(object):
    """
    L层全连接的神经网络的结构为：{affine - relu} x (L - 1) - affine - softmax
    """
    def __init__(self, hidden_dims, input_dim=3*32*32, num_classes=10,
                 dropout=0, use_batchnorm=False, reg=0.0,
                 weight_scale=1e-2, dtype=np.float32, seed=None):
        """
        输入：
        - dropout: 现在暂时用不到的参数
        - use_batchnorm: 是否使用批量归一化
        - dtype: 如果使用float32，速度比较快，但是精度较差，所以在检验梯度时应该使用float64
        - seed: dropout时使用的，现在暂时不管
        """
        self.use_batchnorm = use_batchnorm
        self.use_dropout = dropout > 0
        self.reg = reg
        # 神经网络的总层数为隐藏层层数加一
        self.num_layers = 1 + len(hidden_dims)
        self.dtype = dtype
        self.params = {}

        # 初始化权重和偏置
        for i in range(len(hidden_dims)):
            D = hidden_dims[i]
            self.params['W'+str(i+1)] = weight_scale*np.random.randn(input_dim,D)
            self.params['b'+str(i+1)] = np.zeros((D))
            input_dim = D
        self.params['W'+str(self.num_layers)] = weight_scale*np.random.randn(hidden_dims[-1],num_classes)
        self.params['b'+str(self.num_layers)] = np.zeros((num_classes))

        # 下面本来有批量归一化和dropout的初始化的，但是暂时用不到就没粘出来

计算多次全连接网络的损失和梯度

    def loss(self, X, y=None):
        X = X.astype(self.dtype)
        mode = 'test' if y is None else 'train'
        # 这里本来有设置dropout和批量归一化的模式的，但是现在用不到，先删除了

        scores = None
        #实现前向传播，计算得分
        cache = {}
        input_X = X
        # 和两层网络的类似，只不过要加一层循环
        for i in range(self.num_layers-1):
            W,b = self.params['W'+str(i+1)],self.params['b'+str(i+1)]
            input_X,cache[i] = affine_relu_forward(input_X,W,b)
        W,b = self.params['W'+str(self.num_layers)],self.params['b'+str(self.num_layers)]
        scores,cache[self.num_layers-1] = affine_forward(input_X,W,b)

        # 如果是test模式，也就是说y==None，直接返回
        if mode == 'test':
            return scores

        loss, grads = 0.0, {}
        # 计算损失和损失层的梯度
        loss,dscores = softmax_loss(scores,y)
        # 损失层前一层的affine层后面没有ReLU层，所以要单独计算
        W = self.params['W'+str(self.num_layers)]
        # 损失加上该层的正则化损失
        loss += self.reg*0.5*np.sum(W**2)
        dout_relu,dW,db = affine_backward(dscores,cache[self.num_layers-1])
        grads['W'+str(self.num_layers)] = dW+self.reg*W
        grads['b'+str(self.num_layers)] = db

        for i in range(self.num_layers-1,0,-1):
            W = self.params['W'+str(i)]
            loss += self.reg*0.5*np.sum(W**2)
            dout_relu,dW,db = affine_relu_backward(dout_relu,cache[i-1])

            grads['W'+str(i)] = dW+self.reg*W
            grads['b'+str(i)] = db

        return loss, grads

FullyConnedtedNets.ipynb中还用到了solver.py，今天不想写了，明天（要不就是后天或大后天）写到下一篇去好了。
