数据分析——阿里资金流入流出分析（task1-数据探索与分析）

数据分析——阿里资金流入流出分析（task1-数据探索与分析）

学习目标

熟悉数据分析的流程，了解金融时间序列分析的一般方法。

任务安排

数据集可在阿里天池下载：

https://tianchi.aliyun.com/competition/entrance/231573/information

数据实践

库导入

import pandas as  pd
import numpy as np
import warnings
import datetime
import seaborn as sns
import matplotlib.pyplot as plt
import datetime
from scipy import stats

import warnings
warnings.filterwarnings('ignore')

# 设置数据集路径

dataset_path = 'Dataset/'

# 读取数据

data_balance = pd.read_csv(dataset_path+'user_balance_table.csv')

# 为数据集添加时间戳

data_balance['date'] = pd.to_datetime(data_balance['report_date'], format= "%Y%m%d")
data_balance['day'] = data_balance['date'].dt.day
data_balance['month'] = data_balance['date'].dt.month
data_balance['year'] = data_balance['date'].dt.year
data_balance['week'] = data_balance['date'].dt.week
data_balance['weekday'] = data_balance['date'].dt.weekday

一、时间序列分析

# 聚合时间数据

total_balance = data_balance.groupby(['date'])['total_purchase_amt','total_redeem_amt'].sum().reset_index()

# 生成测试集区段数据

start = datetime.datetime(2014,9,1)
testdata = []
while start != datetime.datetime(2014,10,1):
    temp = [start, np.nan, np.nan]
    testdata.append(temp)
    start += datetime.timedelta(days = 1)
testdata = pd.DataFrame(testdata)
testdata.columns = total_balance.columns

# 拼接数据集

total_balance = pd.concat([total_balance, testdata], axis = 0)

# 为数据集添加时间戳

total_balance['day'] = total_balance['date'].dt.day
total_balance['month'] = total_balance['date'].dt.month
total_balance['year'] = total_balance['date'].dt.year
total_balance['week'] = total_balance['date'].dt.week
total_balance['weekday'] = total_balance['date'].dt.weekday

import matplotlib.pylab as plt

# 画出每日总购买与赎回量的时间序列图

fig = plt.figure(figsize=(20,6))
plt.plot(total_balance['date'], total_balance['total_purchase_amt'],label='purchase')
plt.plot(total_balance['date'], total_balance['total_redeem_amt'],label='redeem')

plt.legend(loc='best')
plt.title("The lineplot of total amount of Purchase and Redeem from July.13 to Sep.14")
plt.xlabel("Time")
plt.ylabel("Amount")
plt.show()

# 画出4月份以后的时间序列图

total_balance_1 = total_balance[total_balance['date'] >= datetime.date(2014,4,1)]
fig = plt.figure(figsize=(20,6))
plt.plot(total_balance_1['date'], total_balance_1['total_purchase_amt'])
plt.plot(total_balance_1['date'], total_balance_1['total_redeem_amt'])
plt.legend()
plt.title("The lineplot of total amount of Purchase and Redeem from April.14 to Sep.14")
plt.xlabel("Time")
plt.ylabel("Amount")
plt.show()

# 分别画出每个月中每天购买赎回量的时间序列图

fig = plt.figure(figsize=(15,15))

plt.subplot(4,1,1)
plt.title("The time series of total amount of Purchase and Redeem for August, July, June, May respectively")

total_balance_2 = total_balance[total_balance['date'] >= datetime.date(2014,8,1)]
plt.plot(total_balance_2['date'], total_balance_2['total_purchase_amt'])
plt.plot(total_balance_2['date'], total_balance_2['total_redeem_amt'])
plt.legend()


total_balance_3 = total_balance[(total_balance['date'] >= datetime.date(2014,7,1)) & (total_balance['date'] < datetime.date(2014,8,1))]
plt.subplot(4,1,2)
plt.plot(total_balance_3['date'], total_balance_3['total_purchase_amt'])
plt.plot(total_balance_3['date'], total_balance_3['total_redeem_amt'])
plt.legend()


total_balance_4 = total_balance[(total_balance['date'] >= datetime.date(2014,6,1)) & (total_balance['date'] < datetime.date(2014,7,1))]
plt.subplot(4,1,3)
plt.plot(total_balance_4['date'], total_balance_4['total_purchase_amt'])
plt.plot(total_balance_4['date'], total_balance_4['total_redeem_amt'])
plt.legend()


total_balance_5 = total_balance[(total_balance['date'] >= datetime.date(2014,5,1)) & (total_balance['date'] < datetime.date(2014,6,1))]
plt.subplot(4,1,4)
plt.plot(total_balance_5['date'], total_balance_5['total_purchase_amt'])
plt.plot(total_balance_5['date'], total_balance_5['total_redeem_amt'])
plt.legend()

plt.xlabel("Time")
plt.ylabel("Amount")
plt.show()

# 分别画出13年8月与9月每日购买赎回量的时序图

fig = plt.figure(figsize=(15,9))

total_balance_last8 = total_balance[(total_balance['date'] >= datetime.date(2013,8,1)) & (total_balance['date'] < datetime.date(2013,9,1))]
plt.subplot(2,1,1)
plt.plot(total_balance_last8['date'], total_balance_last8['total_purchase_amt'])
plt.plot(total_balance_last8['date'], total_balance_last8['total_redeem_amt'])
plt.legend()

total_balance_last9 = total_balance[(total_balance['date'] >= datetime.date(2013,9,1)) & (total_balance['date'] < datetime.date(2013,10,1))]
plt.subplot(2,1,2)
plt.plot(total_balance_last9['date'], total_balance_last9['total_purchase_amt'])
plt.plot(total_balance_last9['date'], total_balance_last9['total_redeem_amt'])
plt.legend()

plt.xlabel("Time")
plt.ylabel("Amount")
plt.show()

二、翌日特征分析

# 画出每个翌日的数据分布于整体数据的分布图

a = plt.figure(figsize=(10,10))
scatter_para = {
   'marker':'.', 's':3, 'alpha':0.3}
line_kws = {
   'color':'k'}
plt.subplot(2,2,1)
plt.title('The distrubution of total purchase')
sns.violinplot(x='weekday', y='total_purchase_amt', data = total_balance_1, scatter_kws=scatter_para, line_kws=line_kws)
plt.subplot(2,2,2)
plt.title('The distrubution of total purchase')
sns.distplot(total_balance_1['total_purchase_amt'].dropna())
plt.subplot(2,2,3)
plt.title('The distrubution of total redeem')
sns.violinplot(x='weekday', y='total_redeem_amt', data = total_balance_1, scatter_kws=scatter_para, line_kws=line_kws)
plt.subplot(2,2,4)
plt.title('The distrubution of total redeem')
sns.distplot(total_balance_1['total_redeem_amt'].dropna())

# 按翌日对数据聚合后取均值

week_sta = total_balance_1[['total_purchase_amt', 'total_redeem_amt', 'weekday']].groupby('weekday', as_index=False).mean()

# 分析翌日的中位数特征

plt.figure(figsize=(12, 5))
ax = plt.subplot(1,2,1)
plt.title('The barplot of average total purchase with each weekday')
ax = sns.barplot(x="weekday", y="total_purchase_amt", data=week_sta, label='Purchase')
ax.legend()
ax = plt.subplot(1,2,2)
plt.title('The barplot of average total redeem with each weekday')
ax = sns.barplot(x="weekday", y="total_redeem_amt", data=week_sta, label='Redeem')
ax.legend()

# 画出翌日的箱型图

plt.figure(figsize=(12, 5))
ax = plt.subplot(1,2,1)
plt.title('The boxplot of total purchase with each weekday')
ax = sns.boxplot(x="weekday", y="total_purchase_amt", data=total_balance_1)
ax = plt.subplot(1,2,2)
plt.title('The boxplot of total redeem with each weekday')
ax = sns.boxplot(x="weekday", y="total_redeem_amt", data=total_balance_1)

# 使用OneHot方法将翌日特征划分，获取划分后特征

from sklearn.preprocessing import OneHotEncoder
encoder = OneHotEncoder()
total_balance = total_balance.reset_index()
week_feature = encoder.fit_transform(np.array(total_balance['weekday']).reshape(-1, 1)).toarray()
week_feature = pd.DataFrame(week_feature,columns=['weekday_onehot']*len(week_feature[0]))
feature = pd.concat([total_balance, week_feature], axis = 1)[['total_purchase_amt', 'total_redeem_amt','weekday_onehot','date']]
feature.columns = list(feature.columns[0:2]) + [x+str(i) for i,x in enumerate(feature.columns[2:-1])] + ['date']

# 画出划分后翌日特征与标签的斯皮尔曼相关性

f, ax = plt.subplots(figsize = (15, 8))
plt.subplot(1,2,1)
plt.title('The spearman coleration between total purchase and each weekday')
sns.heatmap(feature[[x for x in feature.columns if x not in ['total_redeem_amt', 'date'] ]].corr(<
