- 简介-AudioFocus

简介-AudioFocus

AudioFocus是一个Audio协调机制，当多方需要使用Audio资源时可以通过AudioFocus机制来协调配合。

AudioFocus机制

使用AudioFocus机制主要通过android.media.AudioManager中的requestAudioFocus方法请求获取焦点，若获取成功返回int值AudioManager.AUDIOFOCUS_REQUEST_GRANTED,失败则返回AudioManager.AUDIOFOCUS_REQUEST_FAILED

实现流程

在这里插入图片描述

requestAudioFocus方法：

OnAudioFocusChangeListener: 是一个接口，仅定义了一个方法onAudioFocusChange,具体实现如下文

requestAttributes: 根据传进来的streamType构造AudioAttributes对象向下传递，该对象存储了一些音频流信息的属性，对flag进行&操作，(由于之前传入为0，则转换后还是0)

durationHint: 获取焦点的时长，同时通知其他获取音频焦点的OnAudioFocusChangeListener该相互配合，对应值信息：

AUDIOFOCUS_GAIN 代表此次申请的音频焦点需要长时间持有，原本获取了音频焦点的OnAudioFocusChangeListener 接口将会回调onAudioFocusChange(int focusChange) 方法，传入的参数为AUDIOFOCUS_LOSS。

AUDIOFOCUS_GAIN_TRANSIENT 代表此次申请的音频焦点只需短暂持有，原本获取了音频焦点的OnAudioFocusChangeListener 接口将会回调onAudioFocusChange(int focusChange) 方法，传入的参数为AUDIOFOCUS_LOSS_TRANSIENT。按照官方注释：适用于短暂的音频,在接收到事件通知等情景时可使用该durationHint。

AUDIOFOCUS_GAIN_TRANSIENT_EXCLUSIVE 代表此次申请的音频焦点只需短暂持有，原本获取了音频焦点的OnAudioFocusChangeListener 接口将会回调onAudioFocusChange(int focusChange) 方法，传入的参数为AUDIOFOCUS_LOSS_TRANSIENT。按照官方注释：在需要录音或语音识别等情景时可使用该durationHint。

AUDIOFOCUS_GAIN_TRANSIENT_MAY_DUCK 代表此次申请不需要暂停其它申请的音频播放,应用跟其他应用共用焦点但播放的时候其他音频会降低音量。原本获取了音频焦点的OnAudioFocusChangeListener 接口将会回调onAudioFocusChange(int focusChange) 方法，传入的参数为AUDIOFOCUS_LOSS_TRANSIENT_CAN_DUCK。

- frameworks/base/media/java/com/android/media/AudioManager.java
 @SystemApi
public int requestAudioFocus(OnAudioFocusChangeListener l,
        @NonNull AudioAttributes requestAttributes,
        int durationHint,
        int flags,
        AudioPolicy ap) throws IllegalArgumentException {


    // parameter checking
    if (requestAttributes == null) {


        throw new IllegalArgumentException("Illegal null AudioAttributes argument");
    }
    // durationHint 表示获取焦点的时长
    if ((durationHint < AUDIOFOCUS_GAIN) ||
            (durationHint > AUDIOFOCUS_GAIN_TRANSIENT_EXCLUSIVE)) {


        throw new IllegalArgumentException("Invalid duration hint");
    }
    if (flags != (flags & AUDIOFOCUS_FLAGS_SYSTEM)) {


        throw new IllegalArgumentException("Illegal flags 0x"
            + Integer.toHexString(flags).toUpperCase());
    }
    if (((flags & AUDIOFOCUS_FLAG_DELAY_OK) == AUDIOFOCUS_FLAG_DELAY_OK) && (l == null)) {


        throw new IllegalArgumentException(
                "Illegal null focus listener when flagged as accepting delayed focus grant");
    }
    if (((flags & AUDIOFOCUS_FLAG_LOCK) == AUDIOFOCUS_FLAG_LOCK) && (ap == null)) {


        throw new IllegalArgumentException(
                "Illegal null audio policy when locking audio focus");
    }

    int status = AUDIOFOCUS_REQUEST_FAILED;
    // 注册所有的AudioFocusRequest，具体方法见下
    registerAudioFocusListener(l);
    IAudioService service = getService();
    try {


        // 通过IAudioService通信实现audio焦点的获取
        status = service.requestAudioFocus(requestAttributes, durationHint, mICallBack,
                mAudioFocusDispatcher, getIdForAudioFocusListener(l),
                getContext().getOpPackageName() /* package name */, flags,
                ap != null ? ap.cb() : null);
    } catch (RemoteException e) {


        throw e.rethrowFromSystemServer();
    }
    return status;
}
---------------------------------------------------------------

registerAudioFocusListener()

/**
 * @hide
 * Registers a listener to be called when audio focus changes. Calling this method is optional
 * before calling {@link #requestAudioFocus(OnAudioFocusChangeListener, int, int)}, as it
 * will register the listener as well if it wasn't registered already.
 * @param l the listener to be notified of audio focus changes.
 */
public void registerAudioFocusListener(OnAudioFocusChangeListener l) {


    synchronized(mFocusListenerLock) {


        // mAudioFocusIdListenerMap根据AudioFocusRequest中OnAudioFocusChangeListener对象生成一个key，value存储在mAudioFocusIdListenerMap对象中
        if (mAudioFocusIdListenerMap.containsKey(getIdForAudioFocusListener(l))) {


            return;
        }
        mAudioFocusIdListenerMap.put(getIdForAudioFocusListener(l), l);
    }
}

OnAudioFocusChangeListener:

是一个接口，仅定义了一个方法onAudioFocusChange(int focusChange),该方法在焦点状态变化时被调用，参数focusChange代表变化后当前状态，共有四个值:

AUDIOFOCUS_GAIN 重新获取到音频焦点时触发的状态。

AUDIOFOCUS_LOSS 失去音频焦点时触发的状态，且该状态应该会长期保持，此时应当暂停音频并释放音频相关的资源。

AUDIOFOCUS_LOSS_TRANSIENT 失去音频焦点时触发的状态，但是该状态不会长时间保持，此时应该暂停音频，且当重新获取音频焦点的时候继续播放。

AUDIOFOCUS_LOSS_TRANSIENT_CAN_DUCK 失去音频焦点时触发的状态，在该状态的时候不需要暂停音频，但是应该降低音频的声音

/**
 * Interface definition for a callback to be invoked when the audio focus of the system is
 * updated.
 */
public interface OnAudioFocusChangeListener {


    /**
     * Called on the listener to notify it the audio focus for this listener has been changed.
     * The focusChange value indicates whether the focus was gained,
     * whether the focus was lost, and whether that loss is transient, or whether the new focus
     * holder will hold it for an unknown amount of time.
     * When losing focus, listeners can use the focus change information to decide what
     * behavior to adopt when losing focus. A music player could for instance elect to lower
     * the volume of its music stream (duck) for transient focus losses, and pause otherwise.
     * @param focusChange the type of focus change, one of {@link AudioManager#AUDIOFOCUS_GAIN},
     *   {@link AudioManager#AUDIOFOCUS_LOSS}, {@link AudioManager#AUDIOFOCUS_LOSS_TRANSIENT}
     *   and {@link AudioManager#AUDIOFOCUS_LOSS_TRANSIENT_CAN_DUCK}.
     */
    public void onAudioFocusChange(int focusChange);
}

AudioManager中还有一个电话相关的调用

AudioService中的requestAudioFocus并且往其中设置了一个clientId为AudioSystem.IN_VOICE_COMM_FOCUS_ID的状态。

进入到AudioService.requestAudioFocus中首先会进行权限检查，这里面就用到了AudioSystem.IN_VOICE_COMM_FOCUS_ID 也就是说如果clientId等于AudioSystem.IN_VOICE_COMM_FOCUS_ID，且要申请到MODIFY_PHONE_STATE的权限，否则会申请焦点失败。

/**
 * @hide
 * Used internally by telephony package to request audio focus. Will cause the focus request
 * to be associated with the "voice communication" identifier only used in AudioService
 * to identify this use case.
 * @param streamType use STREAM_RING for focus requests when ringing, VOICE_CALL for
 *    the establishment of the call
 * @param durationHint the type of focus request. AUDIOFOCUS_GAIN_TRANSIENT is recommended so
 *    media applications resume after a call
 */
public void requestAudioFocusForCall(int streamType, int durationHint) {


    IAudioService service = getService();
    try {


        service.requestAudioFocus(new AudioAttributes.Builder()
                    .setInternalLegacyStreamType(streamType).build(),
                durationHint, mICallBack, null,
                AudioSystem.IN_VOICE_COMM_FOCUS_ID,
                getContext().getOpPackageName(),
                AUDIOFOCUS_FLAG_LOCK,
                null /* policy token */);
    } catch (RemoteException e) {


        throw e.rethrowFromSystemServer();
    }
}

requestAudioFocus方法实际的实现在AudioService.java

- frameworks/base/service/core/java/com/android/sever/audio/AudioService.java
//==========================================================================================
// Audio Focus
//==========================================================================================
public int requestAudioFocus(AudioAttributes aa, int durationHint, IBinder cb,
        IAudioFocusDispatcher fd, String clientId, String callingPackageName, int flags,
        IAudioPolicyCallback pcb) {


    // permission checks
    if ((flags & AudioManager.AUDIOFOCUS_FLAG_LOCK) == AudioManager.AUDIOFOCUS_FLAG_LOCK) {


        if
