第53节：跨平台输出 - Electron/Cordova打包

概述

将Three.js应用打包为桌面端或移动端应用可以显著扩展用户群体和使用场景。本节将深入讲解如何使用Electron和Cordova将Three.js Web应用打包为跨平台的桌面和移动应用。

跨平台打包架构：

Electron桌面应用打包

Electron基础架构

组件	职责	技术实现
主进程	应用生命周期、窗口管理	Node.js环境
渲染进程	UI渲染、Three.js运行	Chromium浏览器
预加载脚本	安全通信桥梁	受限Node.js API
IPC通信	进程间数据交换	事件驱动模式

完整Electron项目配置

1. 项目结构设计

threejs-electron-app/
├── package.json
├── electron/
│   ├── main.js          # 主进程
│   ├── preload.js       # 预加载脚本
│   └── helpers.js       # 工具函数
├── src/
│   ├── index.html       # 主页面
│   ├── css/
│   ├── js/
│   │   ├── app.js       # Three.js应用
│   │   └── utils.js
│   └── assets/          # 静态资源
├── build/               # 构建输出
└── dist/               # 分发包

2. 主进程配置 (electron/main.js)

const { app, BrowserWindow, Menu, ipcMain, shell, dialog } = require('electron');
const path = require('path');
const isDev = require('electron-is-dev');

class ThreeJSApp {
    constructor() {
        this.mainWindow = null;
        this.init();
    }

    init() {
        // 应用准备就绪
        app.whenReady().then(() => {
            this.createWindow();
            this.setMenu();
            this.setIPC();
        });

        // 所有窗口关闭
        app.on('window-all-closed', () => {
            if (process.platform !== 'darwin') {
                app.quit();
            }
        });

        app.on('activate', () => {
            if (BrowserWindow.getAllWindows().length === 0) {
                this.createWindow();
            }
        });
    }

    createWindow() {
        this.mainWindow = new BrowserWindow({
            width: 1200,
            height: 800,
            minWidth: 800,
            minHeight: 600,
            webPreferences: {
                nodeIntegration: false,
                contextIsolation: true,
                enableRemoteModule: false,
                preload: path.join(__dirname, 'preload.js'),
                webSecurity: !isDev,
                allowRunningInsecureContent: isDev
            },
            icon: path.join(__dirname, '../assets/icons/icon.png'),
            show: false,
            titleBarStyle: 'default'
        });

        // 加载应用
        const startUrl = isDev
            ? 'http://localhost:3000'
            : `file://${path.join(__dirname, '../build/index.html')}`;

        this.mainWindow.loadURL(startUrl);

        // 窗口准备好后显示
        this.mainWindow.once('ready-to-show', () => {
            this.mainWindow.show();

            if (isDev) {
                this.mainWindow.webContents.openDevTools();
            }
        });

        // 处理外部链接
        this.mainWindow.webContents.setWindowOpenHandler(({ url }) => {
            shell.openExternal(url);
            return { action: 'deny' };
        });

        // 窗口关闭事件
        this.mainWindow.on('closed', () => {
            this.mainWindow = null;
        });
    }

    setMenu() {
        const template = [
            {
                label: '文件',
                submenu: [
                    {
                        label: '新建场景',
                        accelerator: 'CmdOrCtrl+N',
                        click: () => {
                            this.mainWindow.webContents.send('menu-new-scene');
                        }
                    },
                    {
                        label: '导出场景',
                        accelerator: 'CmdOrCtrl+E',
                        click: () => {
                            this.mainWindow.webContents.send('menu-export-scene');
                        }
                    },
                    { type: 'separator' },
                    {
                        label: '退出',
                        accelerator: process.platform === 'darwin' ? 'Cmd+Q' : 'Ctrl+Q',
                        click: () => {
                            app.quit();
                        }
                    }
                ]
            },
            {
                label: '视图',
                submenu: [
                    { role: 'reload' },
                    { role: 'forceReload' },
                    { role: 'toggleDevTools' },
                    { type: 'separator' },
                    { role: 'resetZoom' },
                    { role: 'zoomIn' },
                    { role: 'zoomOut' },
                    { type: 'separator' },
                    { role: 'togglefullscreen' }
                ]
            },
            {
                label: '帮助',
                submenu: [
                    {
                        label: '关于',
                        click: () => {
                            this.showAboutDialog();
                        }
                    }
                ]
            }
        ];

        const menu = Menu.buildFromTemplate(template);
        Menu.setApplicationMenu(menu);
    }

    setIPC() {
        // 处理文件保存
        ipcMain.handle('save-file', async (event, data) => {
            const result = await dialog.showSaveDialog(this.mainWindow, {
                defaultPath: 'scene.json',
                filters: [
                    { name: 'JSON Files', extensions: ['json'] },
                    { name: 'All Files', extensions: ['*'] }
                ]
            });

            if (!result.canceled) {
                const fs = require('fs').promises;
                try {
                    await fs.writeFile(result.filePath, JSON.stringify(data, null, 2));
                    return { success: true, path: result.filePath };
                } catch (error) {
                    return { success: false, error: error.message };
                }
            }
            return { success: false, error: '用户取消' };
        });

        // 处理文件加载
        ipcMain.handle('load-file', async (event) => {
            const result = await dialog.showOpenDialog(this.mainWindow, {
                properties: ['openFile'],
                filters: [
                    { name: 'JSON Files', extensions: ['json'] },
                    { name: 'All Files', extensions: ['*'] }
                ]
            });

            if (!result.canceled) {
                const fs = require('fs').promises;
                try {
                    const data = await fs.readFile(result.filePaths[0], 'utf8');
                    return { success: true, data: JSON.parse(data) };
                } catch (error) {
                    return { success: false, error: error.message };
                }
            }
            return { success: false, error: '用户取消' };
        });

        // 获取应用信息
        ipcMain.handle('get-app-info', () => {
            return {
                version: app.getVersion(),
                platform: process.platform,
                isDev: isDev
            };
        });
    }

    showAboutDialog() {
        dialog.showMessageBox(this.mainWindow, {
            type: 'info',
            title: '关于',
            message: 'Three.js 3D应用',
            detail: `版本: ${app.getVersion()}\nElectron: ${process.versions.electron}\nChromium: ${process.versions.chrome}\nNode.js: ${process.versions.node}`
        });
    }
}

// 启动应用
new ThreeJSApp();

3. 预加载脚本 (electron/preload.js)

const { contextBridge, ipcRenderer } = require('electron');

// 暴露安全的API给渲染进程
contextBridge.exposeInMainWorld('electronAPI', {
    // 文件操作
    saveFile: (data) => ipcRenderer.invoke('save-file', data),
    loadFile: () => ipcRenderer.invoke('load-file'),

    // 应用信息
    getAppInfo: () => ipcRenderer.invoke('get-app-info'),

    // 菜单事件
    onMenuNewScene: (callback) => ipcRenderer.on('menu-new-scene', callback),
    onMenuExportScene: (callback) => ipcRenderer.on('menu-export-scene', callback),

    // 移除监听器
    removeAllListeners: (channel) => ipcRenderer.removeAllListeners(channel)
});

// 在加载时初始化
window.addEventListener('DOMContentLoaded', () => {
    console.log('预加载脚本执行完成');
});

4. Three.js应用适配 (src/js/app.js)

class ThreeJSDesktopApp {
    constructor() {
        this.scene = null;
        this.camera = null;
        this.renderer = null;
        this.isElectron = false;

        this.init();
    }

    async init() {
        // 检查运行环境
        this.isElectron = !!(window.electronAPI);

        // 初始化Three.js
        await this.initThreeJS();

        // 设置Electron特定功能
        if (this.isElectron) {
            await this.setupElectronFeatures();
        }

        // 启动渲染循环
        this.animate();
    }

    async initThreeJS() {
        // 创建场景
        this.scene = new THREE.Scene();
        this.scene.background = new THREE.Color(0x1a1a2e);

        // 创建相机
        this.camera = new THREE.PerspectiveCamera(75, window.innerWidth / window.innerHeight, 0.1, 1000);
        this.camera.position.set(5, 5, 5);
        this.camera.lookAt(0, 0, 0);

        // 创建渲染器
        this.renderer = new THREE.WebGLRenderer({
            antialias: true,
            powerPreference: "high-performance"
        });
        this.renderer.setSize(window.innerWidth, window.innerHeight);
        this.renderer.shadowMap.enabled = true;
        this.renderer.shadowMap.type = THREE.PCFSoftShadowMap;

        document.getElementById('app').appendChild(this.renderer.domElement);

        // 添加光源
        this.setupLighting();

        // 添加示例几何体
        this.createDemoScene();

        // 窗口大小调整
        window.addEventListener('resize', () => this.onWindowResize());
    }

    setupLighting() {
        const ambientLight = new THREE.AmbientLight(0x404040, 0.6);
        this.scene.add(ambientLight);

        const directionalLight = new THREE.DirectionalLight(0xffffff, 0.8);
        directionalLight.position.set(10, 10, 5);
        directionalLight.castShadow = true;
        this.scene.add(directionalLight);
    }

    createDemoScene() {
        // 创建地面
        const groundGeometry = new THREE.PlaneGeometry(10, 10);
        const groundMaterial = new THREE.MeshStandardMaterial({
            color: 0x3a3a4a,
            roughness: 0.8,
            metalness: 0.2
        });
        const ground = new THREE.Mesh(groundGeometry, groundMaterial);
        ground.rotation.x = -Math.PI / 2;
        ground.receiveShadow = true;
        this.scene.add(ground);

        // 创建立方体
        const cubeGeometry = new THREE.BoxGeometry(1, 1, 1);
        const cubeMaterial = new THREE.MeshStandardMaterial({
            color: 0xff6b6b,
            roughness: 0.7,
            metalness: 0.3
        });
        this.cube = new THREE.Mesh(cubeGeometry, cubeMaterial);
        this.cube.position.y = 0.5;
        this.cube.castShadow = true;
        this.scene.add(this.cube);

        // 创建球体
        const sphereGeometry = new THREE.SphereGeometry(0.5, 16, 16);
        const sphereMaterial = new THREE.MeshStandardMaterial({
            color: 0x4ecdc4,
            roughness: 0.6,
            metalness: 0.4
        });
        const sphere = new THREE.Mesh(sphereGeometry, sphereMaterial);
        sphere.position.set(2, 0.5, 0);
        sphere.castShadow = true;
        this.scene.add(sphere);
    }

    async setupElectronFeatures() {
        try {
            // 获取应用信息
            const appInfo = await window.electronAPI.getAppInfo();
            this.updateAppTitle(appInfo);

            // 监听菜单事件
            window.electronAPI.onMenuNewScene(() => {
                this.resetScene();
            });

            window.electronAPI.onMenuExportScene(() => {
                this.exportScene();
            });

            // 添加快捷键支持
            this.setupKeyboardShortcuts();

        } catch (error) {
            console.error('Electron功能设置失败:', error);
        }
    }

    updateAppTitle(appInfo) {
        const title = `Three.js桌面应用 - v${appInfo.version} (${appInfo.platform})`;
        document.title = title;

        // 更新UI显示
        const platformInfo = document.getElementById('platform-info');
        if (platformInfo) {
            platformInfo.textContent = `运行在 ${appInfo.platform} ${appInfo.isDev ? '开发模式' : '生产模式'}`;
        }
    }

    setupKeyboardShortcuts() {
        document.addEventListener('keydown', (event) => {
            // Ctrl+S / Cmd+S 保存场景
            if ((event.ctrlKey || event.metaKey) && event.key === 's') {
                event.preventDefault();
                this.exportScene();
            }

            // Ctrl+O / Cmd+O 加载场景
            if ((event.ctrlKey || event.metaKey) && event.key === 'o') {
                event.preventDefault();
                this.loadScene();
            }

            // Ctrl+N / Cmd+N 新建场景
            if ((event.ctrlKey || event.metaKey) && event.key === 'n') {
                event.preventDefault();
                this.resetScene();
            }
        });
    }

    async exportScene() {
        if (!this.isElectron) return;

        const sceneData = {
            metadata: {
                version: '1.0',
                generator: 'Three.js Desktop App',
                exportedAt: new Date().toISOString()
            },
            objects: this.collectSceneObjects()
        };

        try {
            const result = await window.electronAPI.saveFile(sceneData);
            if (result.success) {
                this.showNotification(`场景已保存到: ${result.path}`);
            } else {
                this.showNotification(`保存失败: ${result.error}`, 'error');
            }
        } catch (error) {
            this.showNotification(`保存错误: ${error.message}`, 'error');
        }
    }

    async loadScene() {
        if (!this.isElectron) return;

        try {
            const result = await window.electronAPI.loadFile();
            if (result.success) {
                this.loadSceneData(result.data);
                this.showNotification('场景加载成功');
            } else {
                this.showNotification(`加载失败: ${result.error}`, 'error');
            }
        } catch (error) {
            this.showNotification(`加载错误: ${error.message}`, 'error');
        }
    }

    collectSceneObjects() {
        const objects = [];
        this.scene.traverse((object) => {
            if (object.isMesh) {
                objects.push({
                    type: object.geometry.type,
                    position: object.position.toArray(),
                    rotation: object.rotation.toArray(),
                    scale: object.scale.toArray(),
                    material: {
                        color: object.material.color.getHex(),
                        roughness: object.material.roughness,
                        metalness: object.material.metalness
                    }
                });
            }
        });
        return objects;
    }

    loadSceneData(data) {
        // 清空当前场景
        while(this.scene.children.length > 0) {
            this.scene.remove(this.scene.children[0]);
        }

        // 重新创建场景
        this.setupLighting();

        // 加载保存的对象
        if (data.objects) {
            data.objects.forEach(objData => {
                this.createObjectFromData(objData);
            });
        }
    }

    createObjectFromData(objData) {
        let geometry;

        switch (objData.type) {
            case 'BoxGeometry':
                geometry = new THREE.BoxGeometry(1, 1, 1);
                break;
            case 'SphereGeometry':
                geometry = new THREE.SphereGeometry(0.5, 16, 16);
                break;
            default:
                geometry = new THREE.BoxGeometry(1, 1, 1);
        }

        const material = new THREE.MeshStandardMaterial({
            color: objData.material.color,
            roughness: objData.material.roughness,
            metalness: objData.material.metalness
        });

        const mesh = new THREE.Mesh(geometry, material);
        mesh.position.fromArray(objData.position);
        mesh.rotation.fromArray(objData.rotation);
        mesh.scale.fromArray(objData.scale);
        mesh.castShadow = true;

        this.scene.add(mesh);
    }

    resetScene() {
        // 清空场景
        while(this.scene.children.length > 0) {
            this.scene.remove(this.scene.children[0]);
        }

        // 重新初始化
        this.setupLighting();
        this.createDemoScene();

        this.showNotification('场景已重置');
    }

    showNotification(message, type = 'info') {
        // 创建通知元素
        const notification = document.createElement('div');
        notification.className = `notification ${type}`;
        notification.textContent = message;

        // 添加到页面
        document.body.appendChild(notification);

        // 自动移除
        setTimeout(() => {
            notification.remove();
        }, 3000);
    }

    onWindowResize() {
        this.camera.aspect = window.innerWidth / window.innerHeight;
        this.camera.updateProjectionMatrix();
        this.renderer.setSize(window.innerWidth, window.innerHeight);
    }

    animate() {
        requestAnimationFrame(() => this.animate());

        // 旋转立方体
        if (this.cube) {
            this.cube.rotation.x += 0.01;
            this.cube.rotation.y += 0.01;
        }

        this.renderer.render(this.scene, this.camera);
    }
}

// 启动应用
new ThreeJSDesktopApp();

5. 构建配置 (package.json)

{
  "name": "threejs-desktop-app",
  "version": "1.0.0",
  "description": "Three.js桌面3D应用",
  "main": "electron/main.js",
  "scripts": {
    "electron": "electron .",
    "electron-dev": "ELECTRON_IS_DEV=true electron .",
    "build-web": "webpack --mode=production",
    "build-electron": "electron-builder",
    "pack": "electron-builder --dir",
    "dist": "npm run build-web && electron-builder",
    "postinstall": "electron-builder install-app-deps"
  },
  "build": {
    "appId": "com.yourcompany.threejs-app",
    "productName": "Three.js 3D应用",
    "directories": {
      "output": "dist-electron"
    },
    "files": [
      "build/**/*",
      "electron/**/*",
      "node_modules/**/*",
      "package.json"
    ],
    "mac": {
      "category": "public.app-category.graphics-design",
      "icon": "assets/icons/icon.icns",
      "target": "dmg"
    },
    "win": {
      "icon": "assets/icons/icon.ico",
      "target": "nsis"
    },
    "linux": {
      "icon": "assets/icons/icon.png",
      "target": "AppImage"
    },
    "nsis": {
      "oneClick": false,
      "allowToChangeInstallationDirectory": true
    }
  },
  "devDependencies": {
    "electron": "^22.0.0",
    "electron-builder": "^24.0.0",
    "electron-is-dev": "^2.0.0",
    "webpack": "^5.0.0",
    "webpack-cli": "^4.0.0"
  },
  "dependencies": {
    "three": "^0.150.0"
  }
}

Cordova移动应用打包

Cordova项目配置

1. 创建Cordova项目

# 安装Cordova CLI
npm install -g cordova

# 创建项目
cordova create ThreeJSMobileApp com.yourcompany.threejsapp ThreeJSMobileApp

cd ThreeJSMobileApp

# 添加平台
cordova platform add android
cordova platform add ios

# 添加插件
cordova plugin add cordova-plugin-device
cordova plugin add cordova-plugin-screen-orientation
cordova plugin add cordova-plugin-statusbar
cordova plugin add cordova-plugin-splashscreen

2. Three.js移动端适配 (www/js/app.js)

class ThreeJSMobileApp {
    constructor() {
        this.scene = null;
        this.camera = null;
        this.renderer = null;
        this.controls = null;

        this.touchStart = { x: 0, y: 0 };
        this.rotation = { x: 0, y: 0 };

        this.init();
    }

    async init() {
        // 等待设备就绪
        if (window.cordova) {
            document.addEventListener('deviceready', () => this.onDeviceReady(), false);
        } else {
            this.onDeviceReady();
        }
    }

    onDeviceReady() {
        // 设置屏幕方向
        screen.orientation.lock('landscape');

        // 初始化Three.js
        this.initThreeJS();

        // 设置触摸控制
        this.setupTouchControls();

        // 设置性能监控
        this.setupPerformanceMonitor();

        // 启动渲染循环
        this.animate();
    }

    initThreeJS() {
        // 获取视口尺寸
        const width = window.innerWidth;
        const height = window.innerHeight;

        // 创建场景
        this.scene = new THREE.Scene();
        this.scene.background = new THREE.Color(0x1a1a2e);
        this.scene.fog = new THREE.Fog(0x1a1a2e, 20, 100);

        // 创建相机 - 移动端使用更宽的视野
        this.camera = new THREE.PerspectiveCamera(70, width / height, 0.1, 1000);
        this.camera.position.set(0, 5, 10);

        // 创建渲染器 - 移动端优化
        this.renderer = new THREE.WebGLRenderer({
            antialias: true,
            powerPreference: "high-performance",
            alpha: false
        });
        this.renderer.setSize(width, height);
        this.renderer.setPixelRatio(Math.min(window.devicePixelRatio, 2)); // 限制像素比
        this.renderer.shadowMap.enabled = true;
        this.renderer.shadowMap.type = THREE.PCFSoftShadowMap;

        // 添加到DOM
        document.getElementById('app').appendChild(this.renderer.domElement);

        // 设置光源
        this.setupLighting();

        // 创建场景内容
        this.createScene();

        // 窗口大小调整
        window.addEventListener('resize', () => this.onWindowResize(), false);

        // 处理返回按钮
        document.addEventListener('backbutton', () => this.onBackButton(), false);
    }

    setupLighting() {
        // 环境光
        const ambientLight = new THREE.AmbientLight(0x404040, 0.6);
        this.scene.add(ambientLight);

        // 方向光
        const directionalLight = new THREE.DirectionalLight(0xffffff, 0.8);
        directionalLight.position.set(10, 10, 5);
        directionalLight.castShadow = true;
        directionalLight.shadow.mapSize.width = 1024;
        directionalLight.shadow.mapSize.height = 1024;
        this.scene.add(directionalLight);
    }

    createScene() {
        // 创建地面
        const groundGeometry = new THREE.PlaneGeometry(50, 50);
        const groundMaterial = new THREE.MeshStandardMaterial({
            color: 0x3a3a4a,
            roughness: 0.8,
            metalness: 0.2
        });
        const ground = new THREE.Mesh(groundGeometry, groundMaterial);
        ground.rotation.x = -Math.PI / 2;
        ground.receiveShadow = true;
        this.scene.add(ground);

        // 创建多个物体
        this.createObjects();
    }

    createObjects() {
        const geometries = [
            new THREE.BoxGeometry(1, 1, 1),
            new THREE.SphereGeometry(0.5, 16, 16),
            new THREE.ConeGeometry(0.5, 1, 16),
            new THREE.CylinderGeometry(0.5, 0.5, 1, 16),
            new THREE.TorusGeometry(0.5, 0.2, 16, 32)
        ];

        const colors = [0xff6b6b, 0x4ecdc4, 0x45b7d1, 0x96ceb4, 0xffe66d];

        geometries.forEach((geometry, index) => {
            const material = new THREE.MeshStandardMaterial({
                color: colors[index],
                roughness: 0.7,
                metalness: 0.3
            });

            const mesh = new THREE.Mesh(geometry, material);
            mesh.position.set(
                (index - 2) * 2.5,
                1,
                0
            );
            mesh.castShadow = true;
            mesh.userData = { originalY: 1, speed: 0.5 + Math.random() * 1.0 };

            this.scene.add(mesh);
        });
    }

    setupTouchControls() {
        const canvas = this.renderer.domElement;

        // 触摸开始
        canvas.addEventListener('touchstart', (event) => {
            event.preventDefault();
            const touch = event.touches[0];
            this.touchStart.x = touch.clientX;
            this.touchStart.y = touch.clientY;
        }, { passive: false });

        // 触摸移动 - 旋转控制
        canvas.addEventListener('touchmove', (event) => {
            event.preventDefault();
            if (event.touches.length === 1) {
                const touch = event.touches[0];
                const deltaX = touch.clientX - this.touchStart.x;
                const deltaY = touch.clientY - this.touchStart.y;

                this.rotation.y += deltaX * 0.01;
                this.rotation.x += deltaY * 0.01;

                this.touchStart.x = touch.clientX;
                this.touchStart.y = touch.clientY;
            }
        }, { passive: false });

        // 双指缩放
        let initialDistance = 0;
        canvas.addEventListener('touchstart', (event) => {
            if (event.touches.length === 2) {
                initialDistance = this.getTouchDistance(event.touches[0], event.touches[1]);
            }
        }, { passive: false });

        canvas.addEventListener('touchmove', (event) => {
            if (event.touches.length === 2) {
                event.preventDefault();
                const currentDistance = this.getTouchDistance(event.touches[0], event.touches[1]);
                const zoomDelta = (currentDistance - initialDistance) * 0.01;

                this.camera.position.z = THREE.MathUtils.clamp(
                    this.camera.position.z - zoomDelta,
                    5,
                    50
                );

                initialDistance = currentDistance;
            }
        }, { passive: false });
    }

    getTouchDistance(touch1, touch2) {
        const dx = touch1.clientX - touch2.clientX;
        const dy = touch1.clientY - touch2.clientY;
        return Math.sqrt(dx * dx + dy * dy);
    }

    setupPerformanceMonitor() {
        // 创建FPS显示
        this.stats = {
            fps: 0,
            frameCount: 0,
            lastTime: performance.now()
        };

        const statsElement = document.createElement('div');
        statsElement.style.cssText = `
            position: fixed;
            top: 10px;
            right: 10px;
            background: rgba(0,0,0,0.8);
            color: white;
            padding: 5px 10px;
            border-radius: 5px;
            font-family: Arial, sans-serif;
            font-size: 12px;
            z-index: 1000;
        `;
        document.body.appendChild(statsElement);
        this.statsElement = statsElement;
    }

    updatePerformanceStats() {
        this.stats.frameCount++;
        const currentTime = performance.now();

        if (currentTime >= this.stats.lastTime + 1000) {
            this.stats.fps = Math.round((this.stats.frameCount * 1000) / (currentTime - this.stats.lastTime));
            this.stats.frameCount = 0;
            this.stats.lastTime = currentTime;

            if (this.statsElement) {
                this.statsElement.textContent = `FPS: ${this.stats.fps}`;
            }
        }
    }

    onWindowResize() {
        const width = window.innerWidth;
        const height = window.innerHeight;

        this.camera.aspect = width / height;
        this.camera.updateProjectionMatrix();
        this.renderer.setSize(width, height);
    }

    onBackButton() {
        // 处理Android返回按钮
        if (confirm('确定要退出应用吗？')) {
            navigator.app.exitApp();
        }
    }

    animate() {
        requestAnimationFrame(() => this.animate());

        // 更新相机旋转
        this.camera.position.x = 10 * Math.sin(this.rotation.y);
        this.camera.position.z = 10 * Math.cos(this.rotation.y);
        this.camera.lookAt(0, 0, 0);

        // 物体动画
        this.scene.traverse((object) => {
            if (object.isMesh && object.userData.originalY !== undefined) {
                object.position.y = object.userData.originalY + Math.sin(Date.now() * 0.001 * object.userData.speed) * 0.5;
                object.rotation.y += 0.01 * object.userData.speed;
            }
        });

        // 更新性能统计
        this.updatePerformanceStats();

        // 渲染场景
        this.renderer.render(this.scene, this.camera);
    }
}

// 启动应用
new ThreeJSMobileApp();

3. 移动端配置 (config.xml)

<?xml version='1.0' encoding='utf-8'?>
<widget id="com.yourcompany.threejsapp" version="1.0.0" xmlns="http://www.w3.org/ns/widgets" xmlns:cdv="http://cordova.apache.org/ns/1.0">
    <name>Three.js 3D应用</name>
    <description>基于Three.js的移动端3D应用</description>
    <author email="your@email.com" href="http://yourwebsite.com">Your Name</author>

    <!-- 支持的方向 -->
    <preference name="Orientation" value="landscape" />

    <!-- 全屏显示 -->
    <preference name="Fullscreen" value="true" />

    <!-- 状态栏设置 -->
    <preference name="StatusBarOverlaysWebView" value="false" />
    <preference name="StatusBarBackgroundColor" value="#000000" />
    <preference name="StatusBarStyle" value="lightcontent" />

    <!-- 启动画面 -->
    <preference name="AutoHideSplashScreen" value="true" />
    <preference name="SplashScreenDelay" value="3000" />
    <preference name="FadeSplashScreen" value="true" />
    <preference name="FadeSplashScreenDuration" value="500" />

    <!-- Android配置 -->
    <platform name="android">
        <allow-intent href="market:*" />
        <preference name="AndroidInsecureFileModeEnabled" value="true" />

        <!-- 图标 -->
        <icon src="res/icon/android/icon-36-ldpi.png" density="ldpi" />
        <icon src="res/icon/android/icon-48-mdpi.png" density="mdpi" />
        <icon src="res/icon/android/icon-72-hdpi.png" density="hdpi" />
        <icon src="res/icon/android/icon-96-xhdpi.png" density="xhdpi" />

        <!-- 启动画面 -->
        <splash src="res/screen/android/splash-land-hdpi.png" density="land-hdpi"/>
        <splash src="res/screen/android/splash-land-ldpi.png" density="land-ldpi"/>
        <splash src="res/screen/android/splash-land-mdpi.png" density="land-mdpi"/>
        <splash src="res/screen/android/splash-land-xhdpi.png" density="land-xhdpi"/>
    </platform>

    <!-- iOS配置 -->
    <platform name="ios">
        <allow-intent href="itms:*" />
        <allow-intent href="itms-apps:*" />

        <!-- 图标 -->
        <icon src="res/icon/ios/icon.png" width="57" height="57" />
        <icon src="res/icon/ios/icon@2x.png" width="114" height="114" />
        <icon src="res/icon/ios/icon-40.png" width="40" height="40" />
        <icon src="res/icon/ios/icon-40@2x.png" width="80" height="80" />

        <!-- 启动画面 -->
        <splash src="res/screen/ios/Default-Landscape~iphone.png" width="480" height="320"/>
        <splash src="res/screen/ios/Default-Landscape@2x~iphone.png" width="960" height="640"/>
    </platform>

    <!-- 插件 -->
    <plugin name="cordova-plugin-whitelist" spec="1" />
    <plugin name="cordova-plugin-device" spec="2" />
    <plugin name="cordova-plugin-screen-orientation" spec="3" />
    <plugin name="cordova-plugin-statusbar" spec="2" />
    <plugin name="cordova-plugin-splashscreen" spec="6" />

    <!-- 访问权限 -->
    <access origin="*" />
    <allow-intent href="http://*/*" />
    <allow-intent href="https://*/*" />
</widget>

性能优化与调试

跨平台性能优化策略

平台	性能挑战	优化方案
Electron	内存占用高	代码分割、懒加载
Cordova Android	GPU性能差异	简化着色器、LOD
Cordova iOS	内存限制严格	纹理压缩、对象池

调试技巧

// 跨平台调试工具
class CrossPlatformDebugger {
    static log(message, data = null) {
        const timestamp = new Date().toISOString();
        const logMessage = `[${timestamp}] ${message}`;

        // 控制台输出
        console.log(logMessage, data || '');

        // Electron主进程日志
        if (window.electronAPI) {
            window.electronAPI.sendLog(logMessage, data);
        }

        // Cordova设备日志
        if (window.cordova && console.log) {
            console.log(logMessage);
        }
    }

    static performanceMark(name) {
        if (performance.mark) {
            performance.mark(`start-${name}`);
        }
    }

    static performanceMeasure(name) {
        if (performance.measure) {
            performance.measure(name, `start-${name}`);
            const measures = performance.getEntriesByName(name);
            const duration = measures[measures.length - 1]?.duration;
            this.log(`Performance ${name}: ${duration?.toFixed(2)}ms`);
        }
    }

    static memoryUsage() {
        if (window.performance && performance.memory) {
            const memory = performance.memory;
            this.log('Memory Usage', {
                used: Math.round(memory.usedJSHeapSize / 1048576) + 'MB',
                total: Math.round(memory.totalJSHeapSize / 1048576) + 'MB',
                limit: Math.round(memory.jsHeapSizeLimit / 1048576) + 'MB'
            });
        }
    }
}

通过Electron和Cordova，我们可以将Three.js Web应用打包为功能完整的桌面和移动应用，充分利用各平台的特性和能力，为用户提供原生应用般的体验。
