本文介绍了如何进一步优化jmeter测试报告的样式，以显示接口的详细参数和返回信息。通过创建xsl文件并重新运行jmx脚本，测试报告不仅展示接口的总成功和失败情况，还能查看错误接口的具体请求和响应详情。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

旧的样式：
在这里插入图片描述

第一次优化jmeter报告的样式后，发现无法查看详细的接口参数出错信息，于是再次优化，新的报告样式如下：

在这里插入图片描述

不仅可以查看总的接口成功、失败，也可以查看错误接口的具体请求参数和返回参数，实现方式如下：
1.新建1个xsl文件，命名jmeter.results.shanhe.me.xsl


```xml
<?xml version="1.0" encoding="UTF-8"?>
<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" version="1.0">
    <xsl:output method="html" indent="no" encoding="UTF-8" doctype-public="-//W3C//DTD HTML 4.01 Transitional//EN" doctype-system="http://www.w3.org/TR/html4/loose.dtd"/>
    <xsl:param    name="showData" select="'y'"/>
<xsl:param    name="titleReport" select="'Interface Test Results'"/>
<xsl:param    name="dateReport" select="'date not defined'"/>
    <xsl:strip-space elements="*"/>
    <xsl:template match="/testResults">
        <html lang="en">
        <head>
            <meta name="Author" content="shanhe.me"/>
            <title>JMeter Test Results</title>
            <style type="text/css"><![CDATA[

                * {
       margin: 0; padding: 0 }
                html, body {
       width: 100%; height: 100%; background: #fffcfc; font-size: 12px }
                table {
       border: none; border-collapse: collapse; table-layout: fixed }
                td {
       vertical-align: baseline; font-size: 12px }
                #left-panel {
       position: absolute; left: 0; top: 50px; bottom: 0; width: 300px; overflow: auto; background: #dee4ea }
                #left-panel li.navigation {
                #left-panel li.success {
       color: #565b60 }
                #left-panel li.failure {
       color: red }
                #left-panel li {
       list-style: none; color: black; cursor: pointer }
                #left-panel li.selected {
                #left-panel div {
       line-height: 20px; background-position: 25px 3px; background-repeat: no-repeat; padding: 0 0 0 45px }
                #left-panel div.success {
                #left-panel div.failure {
                #left-panel div.detail {
       display: none }
                #right-panel {
       position: absolute; right: 0; top: 50px; bottom: 0; left: 300px; overflow: auto; background: white }
                #right-panel .group {
                #right-panel .zebra {
                #right-panel .data {
       line-height: 19px; white-space: nowrap }
                #right-panel pre.data {
       white-space: pre }
                #right-panel tbody.failure {
       color: red }
                #right-panel td.key {
       min-width: 108px }
                #right-panel td.delimiter {
       min-width: 18px }
                #right-panel td.assertion:before {
       counter-increment: assertion; content: counter(assertion) ". " }
                #right-panel td.assertion {
       color: black }
                #right-panel .trail {
       border-top: 1px solid #b4b4b4 }
            ]]></style>
            <script type="text/javascript"><![CDATA[

                var onclick_li = (function() {

                    var last_selected = null;
                    return function(li) {

                        if( last_selected == li )
                            return;
                        if( last_selected )
                            last_selected.className = "";
                        last_selected = li;
                        last_selected.className = "selected";
                        document.getElementById("right-panel").innerHTML = last_selected.firstChild.nextSibling.innerHTML;
                        return false;
                    };
                })();

                var patch_timestamp = function() {

                    var spans = document.getElementsByTagName("span");
                    var len = spans.length;
                    for( var i = 0; i < len; ++i ) {

                        var span = spans[i];
                        if( "patch_timestamp" == span.className )
                            span.innerHTML = new Date( parseInt( span.innerHTML ) );
                    }
                };

                var patch_navigation_class = (function() {


                    var set_class = function(el, flag) {

                        if(el) {

                            el.className += flag ? " success" : " failure";
                        }
                    };

                    var traverse = function(el, group_el, flag) {

                        while(1) {

                            if(el) {

                                if(el.className == 'navigation') {

                                    set_class(group_el, flag);
                                    group_el = el;
                                    flag = true;
                                } else {

                                    var o = el.firstChild;
                                    o = o ? o.className : null;
                                    flag = flag ? (o == 'success') : false;
                                }
                                el = el.nextSibling;
                            } else {

                                set_class(group_el, flag);
                                break;
                            }
                        }
                    };

                    return function() {

                        var o = document.getElementById("result-list");
                        o = o ? o.firstChild : null;
                        if(o)
                            traverse(o, null, true);
                    };
                })();

                window.onload = function() {

                    patch_timestamp();
                    patch_navigation_class();
                    var o = document.getElementById("result-list");
                    o = o ? o.firstChild :
