Spring Cloud Gateway
Spring Cloud Gateway 是 Spring Cloud 的一个全新项目,该项目是基于 Spring 5.0,Spring Boot 2.0 和 Project Reactor 等技术开发的网关,它旨在为微服务架构提供一种简单有效的统一的 API 路由管理方式。
Spring Cloud Gateway 作为 Spring Cloud 生态系统中的网关,目标是替代 Netflix Zuul,其不仅提供统一的路由方式,并且基于 Filter 链的方式提供了网关基本的功能,例如:安全,监控/指标,和限流。
相关概念:
- Route(路由):这是网关的基本构建块。它由一个 ID,一个目标 URI,一组断言和一组过滤器定义。如果断言为真,则路由匹配。
- Predicate(断言):这是一个 Java 8 的 Predicate。输入类型是一个 ServerWebExchange。我们可以使用它来匹配来自 HTTP 请求的任何内容,例如 headers 或参数。
- Filter(过滤器):这是
org.springframework.cloud.gateway.filter.GatewayFilter
的实例,我们可以使用它修改请求和响应。
工作流程:
客户端向 Spring Cloud Gateway 发出请求。如果 Gateway Handler Mapping 中找到与请求相匹配的路由,将其发送到 Gateway Web Handler。Handler 再通过指定的过滤器链来将请求发送到我们实际的服务执行业务逻辑,然后返回。 过滤器之间用虚线分开是因为过滤器可能会在发送代理请求之前(“pre”)或之后(“post”)执行业务逻辑。
Spring Cloud Gateway 的特征:
- 基于 Spring Framework 5,Project Reactor 和 Spring Boot 2.0
- 动态路由
- Predicates 和 Filters 作用于特定路由
- 集成 Hystrix 断路器
- 集成 Spring Cloud DiscoveryClient
- 易于编写的 Predicates 和 Filters
- 限流
- 路径重写
快速上手
引入spring-boot 2.1.1.RELEASE ,springcloud的版本为 Greenwich.M3
<parent>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-parent</artifactId>
<version>2.1.1.RELEASE</version>
<relativePath/> <!-- lookup parent from repository -->
</parent>
<properties>
<java.version>1.8</java.version>
<spring-cloud.version>Greenwich.M3</spring-cloud.version>
</properties>
<dependencyManagement>
<dependencies>
<dependency>
<groupId>org.springframework.cloud</groupId>
<artifactId>spring-cloud-dependencies</artifactId>
<version>${spring-cloud.version}</version>
<type>pom</type>
<scope>import</scope>
</dependency>
</dependencies>
</dependencyManagement>
添加的依赖包如下
<dependency>
<groupId>org.springframework.cloud</groupId>
<artifactId>spring-cloud-starter-gateway</artifactId>
</dependency>
<dependency>
<groupId>org.springframework.cloud</groupId>
<artifactId>spring-cloud-starter-netflix-hystrix</artifactId>
</dependency>
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-webflux</artifactId>
</dependency>
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-data-redis-reactive</artifactId>
</dependency>
注意springcloud gateway使用的web框架为webflux,和springMVC不兼容。引入的限流组件是hystrix。redis底层不再使用jedis,而是lettuce。
路由断言
接下来就是配置了,可以使用java代码硬编码配置路由过滤器,也可以使用yml配置文件配置。下面我们首先介绍配置文件配置方式
application.yml
server.port: 8082
spring:
application:
name: gateway
cloud:
gateway:
routes:
- id: path_route
uri: http://localhost:8000
order: 0
predicates:
- Path=/foo/**
filters:
- StripPrefix=1
上面给出了一个根据请求路径来匹配目标uri的例子,如果请求的路径为/foo/bar,则目标uri为 http://localhost:8000/bar。如果上面例子中没有加一个StripPrefix=1过滤器,则目标uri 为http://localhost:8000/foo/bar,StripPrefix过滤器是去掉一个路径。
其他的路由断言和过滤器使用方法请查看官网
接下来我们来看一下设计一个网关应该需要的一些功能
修改接口返回报文
因为网关路由的接口返回报文格式各异,并且网关也有有一些限流、认证、熔断降级的返回报文,为了统一这些报文的返回格式,网关必须要对接口的返回报文进行修改,过滤器代码如下:
package org.gateway.filter.global;
import java.nio.charset.Charset;
import org.gateway.response.Response;
import org.reactivestreams.Publisher;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.cloud.gateway.filter.GlobalFilter;
import org.springframework.core.Ordered;
import org.springframework.core.io.buffer.DataBuffer;
import org.springframework.core.io.buffer.DataBufferFactory;
import org.springframework.core.io.buffer.DataBufferUtils;
import org.springframework.http.server.reactive.ServerHttpResponse;
import org.springframework.http.server.reactive.ServerHttpResponseDecorator;
import org.springframework.stereotype.Component;
import org.springframework.web.server.ServerWebExchange;
import com.alibaba.fastjson.JSON;
import reactor.core.publisher.Flux;
import reactor.core.publisher.Mono;
@Component
public class WrapperResponseFilter implements GlobalFilter, Ordered {
@Override
public int getOrder() {
// -1 is response write filter, must be called before that
return -2;
}
@Override
public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
ServerHttpResponse originalResponse = exchange.getResponse();
DataBufferFactory bufferFactory = originalResponse.bufferFactory();
ServerHttpResponseDecorator decoratedResponse = new ServerHttpResponseDecorator(originalResponse) {
@Override
