拉普拉斯是使用二阶微分锐化图像，以3*3滤波器中心像素与上下左右像素计算差值，计算公式为：

$f(x,y)=f(x+1,y)+f(x-1,y)+f(x,y-1)+f(x,y+1)-4*f(x,y)$

一阶微分梯度锐化，以3*3滤波器中心像素上方三个像素之和减去下方三个像素之和的绝对值，与左边三个像素减去右边三个像素之和的绝对值，将两个绝对值相加作为中心像素值，公式：

$f(x,y)=|f(x-1,y-1)+f(x-1,y)+f(x-1,y+1)-f(x+1,y-1)-f(x+1,y)-f(x+1,y+1)|+|f(x-1,y-1)+f(x,y-1)+f(x+1,y)-f(x-1,y+1)-f(x,y+1)-f(x+1,y+1)|$

通过java代码实现两种锐化算法,代码如下：

package ImageFilter;

import java.awt.image.BufferedImage;
import java.util.ArrayList;
import java.util.List;

public class ImageSharpen {
	// singleton
	private static ImageSharpen imageSharpen = new ImageSharpen();

	private ImageSharpen() {

	}

	public static ImageSharpen getInstance() {
		return imageSharpen;
	}

	/**
	 * 图像锐化 二阶微分锐化，拉普拉斯算子 定义一个3*3滤波器，计算中心像素与上下左右四个像素差值
	 *
	 * @param image
	 */
	public BufferedImage lapLaceSharpDeal(BufferedImage image) {
		BufferedImage tempImage = new BufferedImage(image.getWidth(), image.getHeight(), image.getType());
		for (int i = 1; i < image.getWidth() - 1; i++) {
			for (int j = 1; j < image.getHeight() - 1; j++) {
				int rgb = image.getRGB(i, j);
				int rgb1 = image.getRGB(i - 1, j);
				int rgb2 = image.getRGB(i + 1, j);
				int rgb3 = image.getRGB(i, j - 1);
				int rgb4 = image.getRGB(i, j + 1);
				int[] R = new int[] { (rgb1 >> 16) & 0xff, (rgb2 >> 16) & 0xff, (rgb3 >> 16) & 0xff,
						(rgb4 >> 16) & 0xff, (rgb >> 16) & 0xff };
				int[] G = new int[] { (rgb1 >> 8) & 0xff, (rgb2 >> 8) & 0xff, (rgb3 >> 8) & 0xff, (rgb4 >> 8) & 0xff,
						(rgb >> 8) & 0xff };
				int[] B = new int[] { rgb1 & 0xff, rgb2 & 0xff, rgb3 & 0xff, rgb4 & 0xff, rgb & 0xff };
				double dR = R[0] + R[1] + R[2] + R[3] - 4 * R[4];
				double dG = G[0] + G[1] + G[2] + G[3] - 4 * G[4];
				double dB = B[0] + B[1] + B[2] + B[3] - 4 * B[4];

				double r = R[4] - dR;
				double g = G[4] - dG;
				double b = B[4] - dB;

				rgb = (255 & 0xff) << 24 | (clamp((int) r) & 0xff) << 16 | (clamp((int) g) & 0xff) << 8
						| (clamp((int) b) & 0xff);
				tempImage.setRGB(i, j, rgb);
			}
		}
		return tempImage;
	}

	/**
	 * 一阶微分梯度锐化
	 */
	public BufferedImage degreeSharpDeal(BufferedImage image) {
		BufferedImage tempImage = new BufferedImage(image.getWidth(), image.getHeight(), image.getType());
		for (int i = 1; i < image.getWidth() - 1; i++) {
			for (int j = 1; j < image.getHeight() - 1; j++) {
				List<Integer> rList = new ArrayList<>();
				List<Integer> gList = new ArrayList<>();
				List<Integer> bList = new ArrayList<>();
				for (int x = -1; x < 2; x++) {
					for (int y = -1; y < 2; y++) {
						int rgb = image.getRGB(i + x, j + y);
						int R = (rgb >> 16) & 0xff;
						int G = (rgb >> 8) & 0xff;
						int B = rgb & 0xff;
						rList.add(R);
						gList.add(G);
						bList.add(B);
					}
				}
				int r = getResult(rList);
				int g = getResult(gList);
				int b = getResult(bList);
				r = rList.get(4) + r / 4;
				g = gList.get(4) + g / 4;
				b = bList.get(4) + b / 4;
				int rgb = (255 & 0xff) << 24 | (clamp(r) & 0xff) << 16 | (clamp(g) & 0xff) << 8 | (clamp(b) & 0xff);
				tempImage.setRGB(i, j, rgb);
			}
		}
		return tempImage;
	}

	// 执行一阶微分计算
	private int getResult(List<Integer> list) {
		int result = Math.abs(list.get(0) + list.get(3) + list.get(6) - list.get(2) - list.get(5) - list.get(8))
				+ Math.abs(list.get(0) + list.get(1) + list.get(2) - list.get(6) - list.get(7) - list.get(8));
		return result;
	}

	// 判断a,r,g,b值，大于256返回256，小于0则返回0,0到256之间则直接返回原始值
	private int clamp(int rgb) {
		if (rgb > 255)
			return 255;
		if (rgb < 0)
			return 0;
		return rgb;
	}
}

测试类：

package ImageFilter;

import java.awt.image.BufferedImage;
import java.io.File;

import javax.imageio.ImageIO;

public class test {
	public static void main(String[] args) throws Exception{
		File input = new File("E:/桌面/AverageFilter/1.jpg");
		File output = new File("E:/桌面/AverageFilter/3.jpg");
		BufferedImage image = ImageIO.read(input);
		BufferedImage image2 = ImageSharpen.getInstance().degreeSharpDeal(image);
		ImageIO.write(image2, "jpg", output);
	}
}

原图：
