这篇博客主要介绍了如何修改JMeter的测试结果详细报告样式，使其只显示统计运行的案例数和出错的接口信息。作者提供了两个XML样式文件，一个用于JMeter的jtl文件，另一个针对jdbc请求。文章中详细解释了XML样式文件中的关键部分，如统计信息的计算和展示，以及页面样式的定制，包括颜色、布局和交互。此外，还展示了如何通过JavaScript实现页面元素的展开和折叠功能。

摘要生成于 C知道 ，由 DeepSeek-R1 满血版支持， 前往体验 >

修改jmeter-results-detail-report_21.xs样式:只展示统计运行的案例数，和出错的接口信息

<?xml version="1.0"?>
<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" version="1.0">

<!--
   Licensed to the Apache Software Foundation (ASF) under one or more
   contributor license agreements.  See the NOTICE file distributed with
   this work for additional information regarding copyright ownership.
   The ASF licenses this file to You under the Apache License, Version 2.0
   (the "License"); you may not use this file except in compliance with
   the License.  You may obtain a copy of the License at

       http://www.apache.org/licenses/LICENSE-2.0

   Unless required by applicable law or agreed to in writing, software
   distributed under the License is distributed on an "AS IS" BASIS,
   WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
   See the License for the specific language governing permissions and
   limitations under the License.
-->

<!--
	Stylesheet for processing 2.1 output format test result files
	To uses this directly in a browser, add the following to the JTL file as line 2:
	<?xml-stylesheet type="text/xsl" href="../extras/jmeter-results-detail-report_21.xsl"?>
	and you can then view the JTL in a browser
-->

<xsl:output method="html" indent="yes" encoding="UTF-8" doctype-public="-//W3C//DTD HTML 4.01 Transitional//EN" />

<!-- Defined parameters (overrideable) -->
<xsl:param    name="showData" select="'y'"/>
<xsl:param    name="titleReport" select="'Test Results'"/>
<xsl:param    name="dateReport" select="'date not defined'"/>

<xsl:template match="testResults">
	<html>
		<head>
			<title><xsl:value-of select="$titleReport" /></title>
			<style type="text/css">
				body {
					font:normal 68% verdana,arial,helvetica;
					color:#000000;
				}
				table tr td, table tr th {
					font-size: 20px;
				}
				table.details tr th{
				    color: #ffffff;
					font-weight: bold;
					text-align:center;
					background:#2674a6;
					white-space: nowrap;
				}
				table.details tr td{
					background:#eeeee0;
					white-space: nowrap;
					font-weight: bold;
				}
				h1 {
					margin: 0px 0px 5px; font: 35px verdana,arial,helvetica
				}
				h2 {
					margin-top: 1em; margin-bottom: 0.5em; font: bold 30px verdana,arial,helvetica
				}
				h3 {
					margin-bottom: 0.5em; font: bold 115% verdana,arial,helvetica
				}
				.Failure {
					font-weight:bold; color:red;
				}


				{
				  border-width: 0px;
				}

				.expand_link
				{
				   position=absolute;
				   right: 0px;
				   width: 27px;
				   top: 1px;
				   height: 27px;
				}

				.page_details
				{
				   display: none;
				}

        .page_details_expanded
        {
        	 display: block;
           display/* hide this definition from  IE5/6 */: table-row;
        }


			</style>
			<script language="JavaScript"><![CDATA[
                           function expand(details_id)
			   {

			      document.getElementById(details_id).className = "page_details_expanded";
			   }

			   function collapse(details_id)
			   {

			      document.getElementById(details_id).className = "page_details";
			   }

			   function change(details_id)
			   {
			      if(document.getElementById(details_id+"_image").src.match("expand"))
			      {
			         document.getElementById(details_id+"_image").src = "collapse.png";
			         expand(details_id);
			      }
			      else
			      {
			         document.getElementById(details_id+"_image").src = "expand.png";
			         collapse(details_id);
			      }
                           }
			]]></script>
		</head>
		<body>

			<xsl:call-template name="pageHeader" />

			<xsl:call-template name="summary" />
			<hr size="1" width="95%" align="center" />

			<!--
			    <xsl:call-template name="pagelist" />
			    <hr size="1" width="95%" align="center" />
			-->
			<xsl:call-template name="detail" />

		</body>
	</html>
</xsl:template>

<xsl:template name="pageHeader">
	<h1><xsl:value-of select="$titleReport" /></h1>
	<table width="100%">
		<tr>
			<td align="left">Date report: <xsl:value-of select="$dateReport" /></td>
		</tr>
		<tr>
			<td align="right">Designed for MSlife</td>
		</tr>
	</table>
	<hr size="1" />
</xsl:template>

<xsl:template name="summary">
	<h2>Summary</h2>
	<table align="center" class="details" border="3" cellpadding="4" cellspacing="5" width="100%">
		<tr valign="top">
			<th>caseCounts</th>
			<th>Failures</th>
			<th>Success Rate</th>
			<th>Total Time</th>
			<th>Average Time</th>
			<!--
			<th>Min Time</th>
			<th>Max Time</th>
			-->
		</tr>
		<tr valign="top">
			<xsl:variable name="allCount" select="count(/testResults/sample[contains(@lb,'start')])" />
			<xsl:variable name="allFailureCount" select="count(/testResults/*[attribute::s='false'])" />
			<xsl:variable name="allSuccessCount" select="$allCount - $allFailureCount" />
			<xsl:variable name="allSuccessPercent" select="$allSuccessCount div $allCount" />
			<xsl:variable name="allTotalTime" select="sum(/testResults/*/@t)" />
			<xsl:variable name="allTime" select="$allTotalTime div 1000" />
			<xsl:variable name="allAverageTime" select="$allTotalTime div $allCount div 1000" />
			<xsl:variable name="allMinTime">
				<xsl:call-template name="min">
					<xsl:with-param name="nodes" select="/testResults/*/@t" />
				</xsl:call-template>
			</xsl:variable>
			<xsl:variable name="allMaxTime">
				<xsl:call-template name="max">
					<xsl:with-param name="nodes" select="/testResults/*/@t" />
				</xsl:call-template>
			</xsl:variable>
			<xsl:attribute name="class">
				<xsl:choose>
					<xsl:when test="$allFailureCount &gt; 0">Failure</xsl:when>
				</xsl:choose>
			</xsl:attribute>
			<td align="center">
				<xsl:value-of select="$allCount" />
			</td>
			<td align="center" style="color:red;font-weight:bolder;">
				<xsl:value-of select="$allFailureCount" />
			</td>
			<td align="center" style="color:green;font-weight:bolder;">
				<xsl:call-template name="display-percent">
					<xsl:with-param name="value" select="$allSuccessPercent" />
				</xsl:call-template>
			</td>
			<td align="center">
				<xsl:call-template name="display-time">
					<xsl:with-param name="value" select="$allTime" />
				</xsl:call-template>
			</td>
			<td align="center">
				<xsl:call-template name="display-time">
					<xsl:with-param name="value" select="$allAverageTime" />
				</xsl:call-template>
			</td>
		<!--
			<td align="center">
				<xsl:call-template name="display-time">
					<xsl:with-param name="value" select="$allMinTime" />
				</xsl:call-template>
			</td>
			<td align="center">
				<xsl:call-template name="display-time">
					<xsl:with-param name="value" select="$allMaxTime" />
				</xsl:call-template>
			</td>
			-->
		</tr>
	</table>
</xsl:template>

<xsl:template name="pagelist">
	<h2>Pages</h2>
	<table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%">
		<tr valign="top">
			<th>Interface</th>
			<th># Samples</th>
			<th>Failures</th>
			<th>Success Rate</th>
			<th>Average Time</th>
			<th>Min Time</th>
			<th>Max Time</th>
			<th></th>
		</tr>
		<xsl:for-each select="/testResults/httpSample[not(@lb = preceding::*/@lb)]">
			<xsl:variable name="label" select="@lb" />
			<xsl:variable name="count" select="count(../*[@lb = current()/@lb])" />
			<xsl:variable name="failureCount" select="count(../*[@lb = current()/@lb][attribute::s='false'])" />
			<xsl:variable name="successCount" select="count(../*[@lb = current()/@lb][attribute::s='true'])" />
			<xsl:variable name="successPercent" select="$successCount div $count" />
			<xsl:variable name="totalTime" select="sum(../*[@lb = current()/@lb]/@t)" />
			<xsl:variable name="averageTime" select="$totalTime div $count" />
			<xsl:variable name="minTime">
				<xsl:call-template name="min">
					<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
				</xsl:call-template>
			</xsl:variable>
			<xsl:variable name="maxTime">
				<xsl:call-template name="max">
					<xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" />
				</xsl:call-template>
			</xsl:variable>
			<tr valign="top">
				<xsl:attribute name="class">
					<xsl:choose>
						<xsl:when test="$failureCount &gt; 0">Failure</xsl:when>
					</xsl:choose>
				</xsl:attribute>
				<td>
				<xsl:if test="$failureCount > 0">
				  <a><xsl:attribute name="href">#<xsl:value-of select="$label" /></xsl:attribute>
				  <xsl:value-of select="$label" />
				  </a>
				</xsl:if>
				<xsl:if test="0 >= $failureCount">
				  <xsl:value-of select="$label" />
				</xsl:if>
				</td>
				<td align="center">
					<xsl:value-of select="$count" />
				</td>
				<td align="center">
					<xsl:value-of select="$failureCount" />
				</td>

				<td align="right">
					<xsl:call-template name="display-percent">
						<xsl:with-param name="value" select="$successPercent" />
					</xsl:call-template>
				</td>
				<td align="right">
					<xsl:call-template name="display-time">
						<xsl:with-param name="value" select="$averageTime" />
					</xsl:call-template>
				</td>
				<td align="right">
					<xsl:call-template name="display-time">
						<xsl:with-param name="value" select="$minTime" />
					</xsl:call-template>
				</td>
				<td align="right">
					<xsl:call-template name="display-time">
						<xsl:with-param name="value" select="$maxTime" />
					</xsl:call-template>
				</td>

				<td align="center">
				   <a href="">
				      <xsl:attribute name="href"><xsl:text/>javascript:change('page_details_<xsl:value-of select="position()" />')</xsl:attribute>
				      <img src="expand.png" alt="expand/collapse"><xsl:attribute name="id"><xsl:text/>page_details_<xsl:value-of select="position()" />_image</xsl:attribute></img>
				   </a>
				</td>
			</tr>

      <tr class="page_details">
          <xsl:attribute name="id"><xsl:text/>page_details_<xsl:value-of select="position()" /></xsl:attribute>
                           <td colspan="8" bgcolor="#FF0000">
                              <div align="center">
			         <b>Details for Page "<xsl:value-of select="$label" />"</b>
			         <table bordercolor="#000000" bgcolor="#2674A6" border="0"  cellpadding="1" cellspacing="1" width="95%">
			         <tr>
			            <th>Thread</th>
			            <th>Iteration</th>
			            <th>Time (milliseconds)</th>
			            <th>Bytes</th>
			            <th>Success</th>
			         </tr>

			         <xsl:for-each select="../*[@lb = $label and @tn != $label]">
			            <tr>
			               <td><xsl:value-of select="@tn" /></td>
			               <td align="center"><xsl:value-of select="position()" /></td>
			               <td align="right"><xsl:value-of select="@t" /></td>

			               <td align="right"><xsl:value-of select="@by" /></td>
			               <td align="center"><xsl:value-of select="@s" /></td>
			            </tr>
			         </xsl:for-each>

			         </table>
			      </div>
                           </td>
                        </tr>

		</xsl:for-each>
	</table>
</xsl:template>

<xsl:template name="detail">
	<xsl:variable name="allFailureCount" select="count(/testResults/*[attribute::s='false'])" />

	<xsl:if test="$allFailureCount > 0">
		<h2>Failure Detail</h2>

		<xsl:for-each select="/testResults/*[not(@lb = preceding::*/@lb)]">

			<xsl:variable name="failureCount" select="count(../*[@lb = current()/@lb][attribute::s='false'])" />

			<xsl:if test="$failureCount > 0">
				<h3><xsl:value-of select="@lb" /><a><xsl:attribute name="name"><xsl:value-of select="@lb" /></xsl:attribute></a></h3>

			<table align="center" class="details" border="3" cellpadding="4" cellspacing="5" width="100%">
				<tr valign="top">
					<th>Response</th>
					<th>Failure Message</th>
					<xsl:if test="$showData = 'y'">
					   <th>Response Data</th>
					</xsl:if>
				</tr>
			<!--
				<xsl:for-each select="/testResults/*[@lb = current()/@lb][attribute::s='false']">
					<tr>
						<td><xsl:value-of select="@rc | @rs" /> - <xsl:value-of select="@rm" /></td>
						<td><xsl:value-of select="assertionResult/failureMessage" /></td>
						<xsl:if test="$showData = 'y'">
							<td><xsl:value-of select="./binary" /></td>
						</xsl:if>
					</tr>
				</xsl:for-each>
				-->
				<xsl:for-each select="/testResults/*[@lb = current()/@lb][attribute::s='false']">
                    <tr>
                        <td><xsl:value-of select="@rc | @rs" /> - <xsl:value-of select="@rm" /></td>
                        <td><xsl:value-of select="assertionResult/failureMessage" /></td>
                        <xsl:if test="$showData = 'y'">
                            <td><xsl:value-of select="responseData" /></td>
                        </xsl:if>
                    </tr>
                </xsl:for-each>
				</table>
			</xsl:if>

		</xsl:for-each>
	</xsl:if>
</xsl:template>

<xsl:template name="min">
	<xsl:param name="nodes" select="/.." />
	<xsl:choose>
		<xsl:when test="not($nodes)">NaN</xsl:when>
		<xsl:otherwise>
			<xsl:for-each select="$nodes">
				<xsl:sort data-type="number" />
				<xsl:if test="position() = 1">
					<xsl:value-of select="number(.)" />
				</xsl:if>
			</xsl:for-each>
		</xsl:otherwise>
	</xsl:choose>
</xsl:template>

<xsl:template name="max">
	<xsl:param name="nodes" select="/.." />
	<xsl:choose>
		<xsl:when test="not($nodes)">NaN</xsl:when>
		<xsl:otherwise>
			<xsl:for-each select="$nodes">
				<xsl:sort data-type="number" order="descending" />
				<xsl:if test="position() = 1">
					<xsl:value-of select="number(.)" />
				</xsl:if>
			</xsl:for-each>
		</xsl:otherwise>
	</xsl:choose>
</xsl:template>

<xsl:template name="display-percent">
	<xsl:param name="value" />
	<xsl:value-of select="format-number($value,'0.00%')" />
</xsl:template>

<xsl:template name="display-time">
	<xsl:param name="value" />
	<xsl:value-of select="format-number($value,'0 s')" />
</xsl:template>

</xsl:stylesheet>

    <xsl:variable name="allCount" select="count(/testResults/sample[contains(@lb,'start')])" />这句话对应你的jtl里面的内容，你的线程组包含start

  修改shanhe.xls样式：只展示接口和jdbc请求：

<?xml version="1.0" encoding="UTF-8"?>
<xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" version="1.0">
    <xsl:output method="html" indent="no" encoding="UTF-8" doctype-public="-//W3C//DTD HTML 4.01 Transitional//EN" doctype-system="http://www.w3.org/TR/html4/loose.dtd"/>
    <xsl:strip-space elements="*"/>
    <xsl:template match="/testResults">
        <html lang="en">
        <head>
            <meta name="Author" content="shanhe.me"/>
            <title>JMeter Test Results</title>
            <style type="text/css"><![CDATA[

                * { margin: 0; padding: 0 }
                html, body { width: 100%; height: 100%; background: #b4b4b4; font-size: 12px }
                table { border: none; border-collapse: collapse; table-layout: fixed}
                td { vertical-align: baseline; font-size: 12px;word-break:break-all }
                #left-panel { position: absolute; left: 0; top: 0; bottom: 0; width: 300px; overflow: auto; background: #dee4ea }
                #left-panel li.success { color: #565b60 }
                #left-panel li.failure { color: red }
                #left-panel li { list-style: none; color: black; cursor: pointer }
                #left-panel div { line-height: 20px; background-position: 25px 3px; background-repeat: no-repeat; padding: 0 0 0 45px }
                #left-panel div.detail { display: none }
                #right-panel { position: absolute; right: 0; top: 0; bottom: 0; left: 301px; overflow: auto; background: white ;word-break:break-all;}
				#right-panel .data { line-height: 19px; white-space: nowrap }
                #right-panel pre.data { white-space: pre}
                #right-panel tbody.failure { color: red }
                #right-panel td.key { min-width: 108px }
                #right-panel td.delimiter { min-width: 18px }
                #right-panel td.assertion:before { counter-increment: assertion; content: counter(assertion) ". " }
                #right-panel td.assertion { color: black }
                #right-panel .trail { border-top: 1px solid #b4b4b4 }
            ]]></style>
            <script type="text/javascript"><![CDATA[

                var onclick_li = (function() {
                    var last_selected = null;
                    return function(li) {
                        if( last_selected == li )
                            return;
                        if( last_selected )
                            last_selected.className = "";
                        last_selected = li;
                        last_selected.className = "selected";
                        document.getElementById("right-panel").innerHTML = last_selected.firstChild.nextSibling.innerHTML;
                        return false;
                    };
                })();

                var patch_timestamp = function() {
                    var spans = document.getElementsByTagName("span");
                    var len = spans.length;
                    for( var i = 0; i < len; ++i ) {
                        var span = spans[i];
                        if( "patch_timestamp" == span.className )
                            span.innerHTML = new Date( parseInt( span.innerHTML ) );
                    }
                };

                var patch_navigation_class = (function() {

                    var set_class = function(el, flag) {
                        if(el) {
                            el.className += flag ? " success" : " failure";
                        }
                    };

                    var traverse = function(el, group_el, flag) {
                        while(1) {
                            if(el) {
                                if(el.className == 'navigation') {
                                    set_class(group_el, flag);
                                    group_el = el;
                                    flag = true;
                                } else {
                                    var o = el.firstChild;
                                    o = o ? o.className : null;
                                    flag = flag ? (o == 'success') : false;
                                }
                                el = el.nextSibling;
                            } else {
                                set_class(group_el, flag);
                                break;
                            }
                        }
                    };

                    return function() {
                        var o = document.getElementById("result-list");
                        o = o ? o.firstChild : null;
                        if(o)
                            traverse(o, null, true);
                    };
                })();

                window.onload = function() {
                    patch_timestamp();
                    patch_navigation_class();
                    var o = document.getElementById("result-list");
                    o = o ? o.firstChild : null;
                    o = o ? o.nextSibling : null;
                    if(o)
                        onclick_li(o);
                };

            ]]></script>
        </head>
        <body>
            <div id="left-panel">
                <ol id="result-list">
                    <xsl:for-each select="*">
					<xsl:variable name="ssss">
						<xsl:number value="position()-1" format="1" />
					</xsl:variable>

						<xsl:if test="@tn!=preceding-sibling::*[$ssss]/@tn">
							<li class="navigation">Thread: <xsl:value-of select="@tn"/></li>
						</xsl:if>
						<xsl:param name="isRequest">
							<xsl:value-of select = "contains(@lb,'Request') or contains(@lb,'Start')"/>
						</xsl:param>
								<!-- group with the previous sibling -->
							<xsl:if test="$isRequest = 'true'">
							<li onclick="return onclick_li(this);">
								<div>
									<xsl:attribute name="class">
										<xsl:choose>
											<xsl:when test="@s = 'true'">success</xsl:when>
											<xsl:otherwise>failure</xsl:otherwise>
										</xsl:choose>
									</xsl:attribute>
									<!--<xsl:value-of select="substring-after(@lb,'Request')"/>-->
									<xsl:value-of select="@lb"/>

								</div><div class="detail">
									<div class="group">Sampler</div>
									<div class="zebra">
										<table>
											<tr><td class="data key">Thread Name</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@tn"/></td></tr>
											<tr><td class="data key">Timestamp</td><td class="data delimiter">:</td><td class="data"><span class="patch_timestamp"><xsl:value-of select="@ts"/></span></td></tr>
											<tr><td class="data key">Time</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@t"/> ms</td></tr>
											<tr><td class="data key">Latency</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@lt"/> ms</td></tr>
											<tr><td class="data key">Bytes</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@by"/></td></tr>
											<tr><td class="data key">Sample Count</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@sc"/></td></tr>
											<tr><td class="data key">Error Count</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@ec"/></td></tr>
											<tr><td class="data key">Response Code</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@rc"/></td></tr>
											<tr><td class="data key">Response Message</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="@rm"/></td></tr>
										</table>
									</div>
									<div class="trail"></div>
									<xsl:if test="count(assertionResult) &gt; 0">
										<div class="group">Assertion</div>
										<div class="zebra">
											<table>
												<xsl:for-each select="assertionResult">
													<tbody>
														<xsl:attribute name="class">
															<xsl:choose>
																<xsl:when test="failure = 'true'">failure</xsl:when>
																<xsl:when test="error = 'true'">failure</xsl:when>
															</xsl:choose>
														</xsl:attribute>
														<tr><td class="data assertion" colspan="3"><xsl:value-of select="name"/></td></tr>
														<tr><td class="data key">Failure</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="failure"/></td></tr>
														<tr><td class="data key">Error</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="error"/></td></tr>
														<tr><td class="data key">Failure Message</td><td class="data delimiter">:</td><td class="data"><xsl:value-of select="failureMessage"/></td></tr>
													</tbody>
												</xsl:for-each>
											</table>
										</div>
										<div class="trail"></div>
									</xsl:if>
									<div class="group">Request</div>
									<div class="zebra">
										<table>
											<tr><td class="data key">Method/Url</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="method"/><xsl:text> </xsl:text><xsl:value-of select="java.net.URL"/></pre></td></tr>
											<tr><td class="data key">Query String</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="queryString"/></pre></td></tr>
											<tr><td class="data key">Cookies</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="cookies"/></pre></td></tr>
											<tr><td class="data key">Request Headers</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="requestHeader"/></pre></td></tr>
										</table>
									</div>
									<div class="trail"></div>
									<div class="group">Response</div>
									<div class="zebra">
										<table>
											<tr><td class="data key">Response Headers</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="responseHeader"/></pre></td></tr>
											<tr><td class="data key">Response Data</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="responseData"/></pre></td></tr>
											<tr><td class="data key">Response File</td><td class="data delimiter">:</td><td class="data"><pre class="data"><xsl:value-of select="responseFile"/></pre></td></tr>
										</table>
									</div>
									<div class="trail"></div>
								</div>
							</li>
						</xsl:if>
                    </xsl:for-each>
                </ol>
            </div>
            <div id="right-panel"></div>
        </body>
        </html>
    </xsl:template>
</xsl:stylesheet>

这里你的build.xml文件不需要添加下面的内容：


		<path id="xslt.classpath">
            <fileset dir="${jmeter.home}/lib" includes="xalan*.jar"/>
            <fileset dir="${jmeter.home}/lib" includes="serializer*.jar"/>
        </path>

  报告展示信息：



评论
添加红包

请填写红包祝福语或标题

个

红包个数最小为10个

元

红包金额最低5元

当前余额3.43元 前往充值 >
需支付：10.00元
成就一亿技术人!
领取后你会自动成为博主和红包主的粉丝 规则
hope_wisdom
发出的红包

打赏作者

程序员路同学

你的鼓励将是我创作的最大动力

¥1 ¥2 ¥4 ¥6 ¥10 ¥20
扫码支付：¥1
获取中
扫码支付

您的余额不足，请更换扫码支付或充值

打赏作者

实付元
使用余额支付
点击重新获取
扫码支付
钱包余额 0

抵扣说明：

1.余额是钱包充值的虚拟货币，按照1:1的比例进行支付金额的抵扣。
2.余额无法直接购买下载，可以购买VIP、付费专栏及课程。

余额充值
