数据库版本:
MySQL 8.0.36
问题现象:
慢SQL:执行耗时11分钟
SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240826' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
结果集:631
快SQL:0.17秒
CHECKTIME=‘20240826’ 条件执行慢，20240826 的前一天和后一天执行都很快，而且结果集相同
SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240825' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240827' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
结果集:631
问题分析
检查数据量:
---16242914
select count(*) from xxxxxxxxxxxxx;
---1049
select count(*) from yyyyyyyy;
---71018
select count(*) from xxxxxxxxxxxxx where CHECKTIME='20240826';
---38462
select count(*) from xxxxxxxxxxxxx where CHECKTIME='20240825';
---38362
select count(*) from xxxxxxxxxxxxx where CHECKTIME='20240827';
对比SQL执行计划:
慢:
mysql> explain format=tree SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240826' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN |
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Nested loop inner join (cost=72929 rows=31.7)
-> Filter: (t2.inspection_flag = 0) (cost=107 rows=105)
-> Table scan on t2 (cost=107 rows=1049)
-> Filter: ((t1.checktime = TIMESTAMP'2024-08-26 00:00:00') and (t1.keyname = 'cpuLoad5')) (cost=606 rows=0.302)
-> Index lookup on t1 using idx_xxxxxxxxxxxxx_hostid (hostid=t2.hostid) (cost=606 rows=880)
|
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.01 sec)
执行过程:
1.全表扫描t2表（yyyyyyyy）：
执行Table scan on t2（全表扫描）
扫描全部1049行数据
成本：107
2.过滤t2表：
应用条件t2.xxx_flag = 0
过滤后保留约105行（1049 × 10%）
成本：107（主要消耗在扫描）
3.嵌套循环连接（对t2的每行）：
对t2的105行中的每一行：
a. 使用idx_xxxxxxxxxxxxx_hostid索引查找t1表
b. 每次查找返回约880行（总 105×880=92400行）
c. 对每批880行应用过滤条件：
t1.checktime=‘20240826’
t1.keyname=‘xxxLoad5’
d. 过滤后保留约0.302行（最终105*0.302=31.7行）
快：
mysql> explain format=tree SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240825' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN |
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Nested loop inner join (cost=49699 rows=285)
-> Filter: ((t1.keyname = 'cpuLoad5') and (t1.hostid is not null)) (cost=48701 rows=2851)
-> Index lookup on t1 using i_xxxxxxxxxxxxx_checktime (checktime=TIMESTAMP'2024-08-25 00:00:00') (cost=48701 rows=70288)
-> Filter: (t2.inspection_flag = 0) (cost=0.25 rows=0.1)
-> Single-row index lookup on t2 using PRIMARY (hostid=t1.hostid) (cost=0.25 rows=1)
|
+------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
执行顺序与过程：
1.索引扫描t1表：
使用i_xxxxxxxxxxxxx_checktime索引定位checktime=‘20240825’
返回70288行（某日全量数据）
成本：48701
2.过滤t1表：
应用keyname='xxxLoad5’条件
保留约2851行
成本：48701（主要消耗在索引扫描）
3.嵌套循环连接（对t1的每行）：
对t1的2851行中的每一行：
a. 使用主键索引查找t2表
b. 精确匹配（hostid=t1.hostid）
c. 单行查找（成本仅0.25）
d. 应用xxx_flag=0过滤
e. 保留约0.1行（最终2851*0.1=285行）
对比执行快的执行计划，表关联顺序和选择的索引不一样，hint强制关联顺序和强制走索引速度都很快
SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 force index(i_xxxxxxxxxxxxx_checktime) ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240826' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
631 rows in set (0.23 sec)
+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN |
+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Nested loop inner join (cost=96269 rows=1311)
-> Filter: ((t1.keyname = 'cpuLoad5') and (t1.hostid is not null)) (cost=91683 rows=13105)
-> Index lookup on t1 using i_xxxxxxxxxxxxx_checktime (checktime=TIMESTAMP'2024-08-26 00:00:00') (cost=91683 rows=131052)
-> Filter: (t2.inspection_flag = 0) (cost=0.25 rows=0.1)
-> Single-row index lookup on t2 using PRIMARY (hostid=t1.hostid) (cost=0.25 rows=1)
|
+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
SELECT /*+ JOIN_ORDER(t1,t2)*/ t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240826' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
631 rows in set (0.21 sec)
+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN |
+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Nested loop inner join (cost=92764 rows=532)
-> Filter: ((t1.keyname = 'cpuLoad5') and (t1.hostid is not null)) (cost=90904 rows=5315)
-> Index lookup on t1 using i_xxxxxxxxxxxxx_checktime (checktime=TIMESTAMP'2024-08-26 00:00:00') (cost=90904 rows=131052)
-> Filter: (t2.inspection_flag = 0) (cost=0.25 rows=0.1)
-> Single-row index lookup on t2 using PRIMARY (hostid=t1.hostid) (cost=0.25 rows=1)
|
+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
慢SQL现象：
1.索引选择不当：
(1)使用hostid索引而非checktime索引;
2.过滤顺序错误：
(1)先关联再过滤（最耗资源步骤）
实际需要数据：checktime=‘20240826’（单日数据）
3.回表代价高昂：
每次索引查找后需回表验证checktime和keyname
4.嵌套循环放大问题：
小表驱动大表时合理，但此处驱动方式错误
应先用时间条件过滤大表，再关联小表
问题分析:
慢SQL未走高效索引的原因与优化方案
为什么CHECKTIME索引未被使用？
- 优化器成本估算错误
MySQL优化器基于统计信息计算成本，但统计信息可能过时或不准确
查看统计信息
SHOW INDEX FROM xxxxxxxxxxxxx;
+---------------+------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+------+------------+---------+---------------+---------+------------+
| Table | Non_unique | Key_name | Seq_in_index | Column_name | Collation | Cardinality | Sub_part | Packed | Null | Index_type | Comment | Index_comment | Visible | Expression |
+---------------+------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+------+------------+---------+---------------+---------+------------+
| xxxxxxxxxxxxx | 0 | PRIMARY | 1 | valuesid | A | 15469519 | NULL | NULL | | BTREE | | | YES | NULL |
| xxxxxxxxxxxxx | 1 | i_xxxxxxxxxxxxx_keyname | 1 | keyname | A | 23283 | NULL | NULL | YES | BTREE | | | YES | NULL |
| xxxxxxxxxxxxx | 1 | i_xxxxxxxxxxxxx_checktime | 1 | checktime | A | 18634 | NULL | NULL | YES | BTREE | | | YES | NULL |
| xxxxxxxxxxxxx | 1 | idx_xxxxxxxxxxxxx_hostid | 1 | hostid | A | 17578 | NULL | NULL | YES | BTREE | | | YES | NULL |
+---------------+------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+------+------------+---------+---------------+---------+------------+
4 rows in set (0.13 sec)
检查行数估算
预估CHECKTIME 索引成本比实际偏高
统计信息预估 rows=131052 实际 rows=71018
EXPLAIN SELECT COUNT(*) FROM xxxxxxxxxxxxx WHERE CHECKTIME='20240826';
+----+-------------+---------------+------------+------+---------------------------+---------------------------+---------+-------+--------+----------+-------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+-------------+---------------+------------+------+---------------------------+---------------------------+---------+-------+--------+----------+-------------+
| 1 | SIMPLE | xxxxxxxxxxxxx | NULL | ref | i_xxxxxxxxxxxxx_checktime | i_xxxxxxxxxxxxx_checktime | 6 | const | 131052 | 100.00 | Using index |
+----+-------------+---------------+------------+------+---------------------------+---------------------------+---------+-------+--------+----------+-------------+
1 row in set, 1 warning (0.02 sec)
统计信息预估 rows=70288 实际 rows=38462
EXPLAIN SELECT COUNT(*) FROM xxxxxxxxxxxxx WHERE CHECKTIME='20240825';
+----+-------------+---------------+------------+------+---------------------------+---------------------------+---------+-------+-------+----------+-------------+
| id | select_type | table | partitions | type | possible_keys | key | key_len | ref | rows | filtered | Extra |
+----+-------------+---------------+------------+------+---------------------------+---------------------------+---------+-------+-------+----------+-------------+
| 1 | SIMPLE | xxxxxxxxxxxxx | NULL | ref | i_xxxxxxxxxxxxx_checktime | i_xxxxxxxxxxxxx_checktime | 6 | const | 70288 | 100.00 | Using index |
+----+-------------+---------------+------------+------+---------------------------+---------------------------+---------+-------+-------+----------+-------------+
1 row in set, 1 warning (0.00 sec)
可能是统计信息不准或表碎片引起的
查询表的碎片率不是很高。
预估表关联成本偏低
统计信息预估: rows=923172 实际 rows=16242099
EXPLAIN format=tree SELECT COUNT(*) FROM xxxxxxxxxxxxx INNER JOIN yyyyyyyy ON xxxxxxxxxxxxx.hostid=yyyyyyyy.hostid;
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Aggregate: count(0) (cost=185369 rows=1)
-> Nested loop inner join (cost=93052 rows=923172)
-> Index scan on yyyyyyyy using i_yyyyyyyy_ip (cost=107 rows=1049)
-> Covering index lookup on xxxxxxxxxxxxx using idx_xxxxxxxxxxxxx_hostid (hostid=yyyyyyyy.hostid) (cost=0.683 rows=880)
|
+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
所以当达到某个CHECKTIME数据量阈值时，优化器认为 idx_xxxxxxxxxxxxx_hostid 索引比 i_xxxxxxxxxxxxx_checktime 索引成本低。
检查统计信息
表统计信息
mysql> show table status like 'xxxxxxxxxxxxx';
+---------------+--------+---------+------------+----------+----------------+-------------+-----------------+--------------+-----------+----------------+---------------------+-------------+------------+--------------------+----------+----------------+-----------------+
| Name | Engine | Version | Row_format | Rows | Avg_row_length | Data_length | Max_data_length | Index_length | Data_free | Auto_increment | Create_time | Update_time | Check_time | Collation | Checksum | Create_options | Comment |
+---------------+--------+---------+------------+----------+----------------+-------------+-----------------+--------------+-----------+----------------+---------------------+-------------+------------+--------------------+----------+----------------+-----------------+
| xxxxxxxxxxxxx | InnoDB | 10 | Dynamic | 15469519 | 92 | 1438646272 | 0 | 1258192896 | 3145728 | 16609944 | 2025-04-30 09:14:52 | NULL | NULL | utf8mb4_general_ci | NULL | | 巡检结果表 |
+---------------+--------+---------+------------+----------+----------------+-------------+-----------------+--------------+-----------+----------------+---------------------+-------------+------------+--------------------+----------+----------------+-----------------+
1 row in set (0.06 sec)
mysql> select * from information_schema.tables where table_schema='cjc' and table_name='xxxxxxxxxxxxx';
+---------------+--------------+---------------+------------+--------+---------+------------+------------+----------------+-------------+-----------------+--------------+-----------+----------------+---------------------+-------------+------------+--------------------+----------+----------------+-----------------+
| TABLE_CATALOG | TABLE_SCHEMA | TABLE_NAME | TABLE_TYPE | ENGINE | VERSION | ROW_FORMAT | TABLE_ROWS | AVG_ROW_LENGTH | DATA_LENGTH | MAX_DATA_LENGTH | INDEX_LENGTH | DATA_FREE | AUTO_INCREMENT | CREATE_TIME | UPDATE_TIME | CHECK_TIME | TABLE_COLLATION | CHECKSUM | CREATE_OPTIONS | TABLE_COMMENT |
+---------------+--------------+---------------+------------+--------+---------+------------+------------+----------------+-------------+-----------------+--------------+-----------+----------------+---------------------+-------------+------------+--------------------+----------+----------------+-----------------+
| def | cjc | xxxxxxxxxxxxx | BASE TABLE | InnoDB | 10 | Dynamic | 15469519 | 92 | 1438646272 | 0 | 1258192896 | 3145728 | 16609944 | 2025-04-30 09:14:52 | NULL | NULL | utf8mb4_general_ci | NULL | | 巡检结果表 |
+---------------+--------------+---------------+------------+--------+---------+------------+------------+----------------+-------------+-----------------+--------------+-----------+----------------+---------------------+-------------+------------+--------------------+----------+----------------+-----------------+
1 row in set (0.00 sec)
索引统计信息
show index from xxxxxxxxxxxxx;
+---------------+------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+------+------------+---------+---------------+---------+------------+
| Table | Non_unique | Key_name | Seq_in_index | Column_name | Collation | Cardinality | Sub_part | Packed | Null | Index_type | Comment | Index_comment | Visible | Expression |
+---------------+------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+------+------------+---------+---------------+---------+------------+
| xxxxxxxxxxxxx | 0 | PRIMARY | 1 | valuesid | A | 15469519 | NULL | NULL | | BTREE | | | YES | NULL |
| xxxxxxxxxxxxx | 1 | i_xxxxxxxxxxxxx_keyname | 1 | keyname | A | 23283 | NULL | NULL | YES | BTREE | | | YES | NULL |
| xxxxxxxxxxxxx | 1 | i_xxxxxxxxxxxxx_checktime | 1 | checktime | A | 18634 | NULL | NULL | YES | BTREE | | | YES | NULL |
| xxxxxxxxxxxxx | 1 | idx_xxxxxxxxxxxxx_hostid | 1 | hostid | A | 17578 | NULL | NULL | YES | BTREE | | | YES | NULL |
+---------------+------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+------+------------+---------+---------------+---------+------------+
4 rows in set (0.02 sec)
select * from information_schema.statistics where table_schema='cjc' and table_name='xxxxxxxxxxxxx';
+---------------+--------------+---------------+------------+--------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+----------+------------+---------+---------------+------------+------------+
| TABLE_CATALOG | TABLE_SCHEMA | TABLE_NAME | NON_UNIQUE | INDEX_SCHEMA | INDEX_NAME | SEQ_IN_INDEX | COLUMN_NAME | COLLATION | CARDINALITY | SUB_PART | PACKED | NULLABLE | INDEX_TYPE | COMMENT | INDEX_COMMENT | IS_VISIBLE | EXPRESSION |
+---------------+--------------+---------------+------------+--------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+----------+------------+---------+---------------+------------+------------+
| def | cjc | xxxxxxxxxxxxx | 1 | cjc | i_xxxxxxxxxxxxx_checktime | 1 | checktime | A | 18634 | NULL | NULL | YES | BTREE | | | YES | NULL |
| def | cjc | xxxxxxxxxxxxx | 1 | cjc | i_xxxxxxxxxxxxx_keyname | 1 | keyname | A | 23283 | NULL | NULL | YES | BTREE | | | YES | NULL |
| def | cjc | xxxxxxxxxxxxx | 1 | cjc | idx_xxxxxxxxxxxxx_hostid | 1 | hostid | A | 17578 | NULL | NULL | YES | BTREE | | | YES | NULL |
| def | cjc | xxxxxxxxxxxxx | 0 | cjc | PRIMARY | 1 | valuesid | A | 15469519 | NULL | NULL | | BTREE | | | YES | NULL |
+---------------+--------------+---------------+------------+--------------+---------------------------+--------------+-------------+-----------+-------------+----------+--------+----------+------------+---------+---------------+------------+------------+
4 rows in set (0.01 sec)
列直方图
mysql> SELECT * FROM information_schema.column_statistics where SCHEMA_NAME='cjc' and table_name='xxxxxxxxxxxxx';
Empty set (0.00 sec)
优化方案:
1.改写SQL
把on条件提前，然后再where条件。或者把表关联改成子查询，想先过滤再关联。但是执行计划都没有变化，SQL还是执行很慢。
2.统计信息、直方图
重新收集了表统计信息，checktime 和 hostid列直方图(列数据有倾斜)，执行计划都没有变化，SQL还是执行很慢。
show variables like 'innodb_stats_persistent';
set global innodb_stats_persistent_sample_pages=100;
ANALYZE TABLE xxxxxxxxxxxxx;
ANALYZE TABLE xxxxxxxxxxxxx UPDATE HISTOGRAM ON checktime;
ANALYZE TABLE xxxxxxxxxxxxx UPDATE HISTOGRAM ON hostid;
SELECT * FROM information_schema.column_statistics where SCHEMA_NAME='cjc' and table_name='xxxxxxxxxxxxx'\G;
3.复合索引
覆盖where列和查询列，checktime列在索引最左测
没测试，应该会有效果
4.重建表
优化器预估的checktime列索引偏高，怀疑和表碎片有关，尝试重建表。
mysql> alter table xxxxxxxxxxxxx engine=InnoDB;
Query OK, 0 rows affected (4 min 10.61 sec)
Records: 0 Duplicates: 0 Warnings: 0
重建表后，执行计划发生变化，SQL执行速度由11分钟，降到0.19秒。
新执行计划如下:
mysql> explain format=tree SELECT t1.HOSTID,t1.KEYATTR,t1.VALUE FROM xxxxxxxxxxxxx t1 ,yyyyyyyy t2 WHERE t1.KEYNAME='cpuLoad5' AND t1.CHECKTIME='20240826' and t1.HOSTID=t2.HOSTID and t2.inspection_flag=0;
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| EXPLAIN |
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
| -> Nested loop inner join (cost=111499 rows=635)
-> Filter: ((t1.checktime = TIMESTAMP'2024-08-26 00:00:00') and (t1.keyname = 'cpuLoad5') and (t1.hostid is not null)) (cost=109275 rows=6355)
-> Intersect rows sorted by row ID (cost=109275 rows=6356)
-> Index range scan on t1 using i_xxxxxxxxxxxxx_checktime over (checktime = '2024-08-26 00:00:00') (cost=246 rows=143504)
-> Index range scan on t1 using i_xxxxxxxxxxxxx_keyname over (keyname = 'cpuLoad5') (cost=102088 rows=714612)
-> Filter: (t2.inspection_flag = 0) (cost=0.25 rows=0.1)
-> Single-row index lookup on t2 using PRIMARY (hostid=t1.hostid) (cost=0.25 rows=1)
|
+----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (0.00 sec)
5.分区表
改成分区表，按月分区
没执行，应该也会有效果
###chenjuchao 20250717###
