Koltin42.Takeout首页详情界面底部购物栏数据的处理(28)

博客主要围绕界面刷新展开,涉及BusinessActivity.kt界面的数字和小红点刷新,GoodsAdapter.kt点击事件后调用Activity刷新UI,以及GoodsFragmentPresenter.kt界面刷新业务逻辑的处理。

BusinessActivity.kt界面的刷新数字和小红点

package com.example.takeout.ui.activity

import android.content.Context
import android.os.Bundle
import android.util.TypedValue
import android.view.View
import android.widget.ImageButton
import androidx.appcompat.app.AppCompatActivity
import androidx.fragment.app.Fragment
import androidx.fragment.app.FragmentPagerAdapter
import com.example.takeout.R
import com.example.takeout.ui.fragment.CommentsFragment
import com.example.takeout.ui.fragment.GoodsFragment
import com.example.takeout.ui.fragment.SellerFragment
import com.example.takeout.utils.PriceFormater
import kotlinx.android.synthetic.main.activity_business.*

class BusinessActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_business)

        //微调底部的导航栏适配
        if (checkDeviceHasNavigationBar(this)) {
            fl_Container.setPadding(0, 0, 0, 48.dp2px())
        }

        vp.adapter = BusinessFragmentPagerAdapter()
        tabs.setupWithViewPager(vp)

    }

    val fragments = listOf<Fragment>(GoodsFragment(), SellerFragment(), CommentsFragment())
    val titles = listOf<String>("商品", "商家", "评论")

    /**
     * 把转化功能添加到Int类中作为扩展函数
     */
    fun Int.dp2px(): Int {
        return TypedValue.applyDimension(
            TypedValue.COMPLEX_UNIT_DIP,
            toFloat(), resources.displayMetrics
        ).toInt()

    }

    //获取是否存在NavigationBar
    fun checkDeviceHasNavigationBar(context: Context): Boolean {
        var hasNavigationBar = false
        val rs = context.getResources()
        val id = rs.getIdentifier("config_showNavigationBar", "bool", "android")
        if (id > 0) {
            hasNavigationBar = rs.getBoolean(id)
        }
        try {
            val systemPropertiesClass = Class.forName("android.os.SystemProperties")
            val m = systemPropertiesClass.getMethod("get", String::class.java)
            val navBarOverride = m.invoke(systemPropertiesClass, "qemu.hw.mainkeys") as String
            if ("1" == navBarOverride) {
                hasNavigationBar = false
            } else if ("0" == navBarOverride) {
                hasNavigationBar = true
            }
        } catch (e: Exception) {

        }

        return hasNavigationBar
    }

    inner class BusinessFragmentPagerAdapter : FragmentPagerAdapter(supportFragmentManager) {

        override fun getPageTitle(position: Int): CharSequence {
            return titles.get(position)
        }

        override fun getItem(position: Int): Fragment {
            return fragments.get(position)
        }

        override fun getCount(): Int {
            return titles.size
        }

    }

    /**
     * 增加的按钮
     */
    fun addImageButton(ib: ImageButton, width: Int, height: Int) {
        fl_Container.addView(ib, width, height)
    }

    fun getCartLocation(): IntArray {
        val destLocation = IntArray(2)
        imgCart.getLocationInWindow(destLocation)
        return destLocation
    }

    /**
     * 更新购物车
     */
    fun updateCartUi() {
        //更新数量,更新总价
        var count = 0
        var countPrice = 0.0f
        //哪些商品属于购物车?
        val goodsFragment: GoodsFragment = fragments.get(0) as GoodsFragment
        val cartList = goodsFragment.goodsFragmentPresenter.getCartList()
        for (i in 0 until cartList.size) {
            val goodsInfo = cartList.get(i)
            count += goodsInfo.count
            countPrice += goodsInfo.count * goodsInfo.newPrice.toFloat()
        }
        tvSelectNum.text = count.toString()
        if (count > 0) {
            tvSelectNum.visibility = View.VISIBLE
        } else {
            tvSelectNum.visibility = View.GONE
        }
        tvCountPrice.text = PriceFormater.format(countPrice)
    }
}

GoodsAdapter.kt点击事件以后调用Activity刷新UI

package com.example.takeout.ui.adapter

import android.graphics.Color
import android.graphics.Paint
import android.util.Log
import android.view.LayoutInflater
import android.view.View
import android.view.ViewGroup
import android.view.animation.*
import android.widget.BaseAdapter
import android.widget.ImageButton
import android.widget.ImageView
import android.widget.TextView
import androidx.fragment.app.FragmentActivity
import com.example.takeout.R
import com.example.takeout.model.beans.GoodsInfo
import com.example.takeout.ui.activity.BusinessActivity
import com.example.takeout.ui.fragment.GoodsFragment
import com.example.takeout.utils.PriceFormater
import com.example.takeout.utils.TakeoutApp
import com.squareup.picasso.Picasso
import org.jetbrains.anko.find
import se.emilsjolander.stickylistheaders.StickyListHeadersAdapter

class GoodsAdapter(val context: FragmentActivity?, val goodsFragment: GoodsFragment) : BaseAdapter(), StickyListHeadersAdapter {

    val host = "http://127.0.0.1:8090/image?name="
    val DURATION: Long = 1000 //持续时间


    var goodsList: List<GoodsInfo> = ArrayList()

    fun setDatas(goodsInfoList: List<GoodsInfo>) {
        this.goodsList = goodsInfoList
        notifyDataSetChanged()
    }

    inner class GoodsItemHolder(itemView: View) : View.OnClickListener {

        override fun onClick(v: View?) {
            var isAdd: Boolean = false
            when (v?.id) {
                R.id.ib_add -> {
                    isAdd = true
                    doAddOperation()
                }
                R.id.ib_minus -> doMinusOperation()
            }
            processRedDotCount(isAdd)
            (goodsFragment.activity as BusinessActivity).updateCartUi();
        }

        private fun processRedDotCount(isAdd: Boolean) {
            //找到此商品属于的类别
            val typeId = goodsInfo.typeId
            //找到此类别在左侧列表中的位置(遍历)
            val typePosition = goodsFragment.goodsFragmentPresenter.getTypePositionByTypeId(typeId)
            //最后找出tvRedDotCount
            val goodsTypeInfo = goodsFragment.goodsFragmentPresenter.goodstypeList.get(typePosition)
            var redDotCount = goodsTypeInfo.redDotCount
            if (isAdd) {
                redDotCount++
            } else {
                redDotCount--
            }
            goodsTypeInfo.redDotCount = redDotCount
            //刷新左侧列表
            goodsFragment.goodsTypeAdapter.notifyDataSetChanged()
        }

        private fun doMinusOperation() {
            //改变count值
            var count = goodsInfo.count
            if (count == 1) {
                //最后一次点击减号执行动画集
                val hideAnimationSet: AnimationSet = getHideAnimation()
                tvCount.startAnimation(hideAnimationSet)
                btnMinus.startAnimation(hideAnimationSet)
                //删除缓存
//                TakeoutApp.sInstance.deleteCacheSelectedInfo(goodsInfo.id)
            }else{
                //更新缓存
//                TakeoutApp.sInstance.updateCacheSelectedInfo(goodsInfo.id, Constants.MINUS)
            }
            count--
            //改变数据层
            goodsInfo.count = count
            notifyDataSetChanged()
        }

        private fun doAddOperation() {
            //改变count值
            var count = goodsInfo.count
            if (count == 0) {
                //第一次点击加号执行动画集
                val showAnimationSet: AnimationSet = getShowAnimation()
                tvCount.startAnimation(showAnimationSet)
                btnMinus.startAnimation(showAnimationSet)
                //添加缓存
//                TakeoutApp.sInstance.addCacheSelectedInfo(CacheSelectedInfo(goodsInfo.sellerId,goodsInfo.typeId,goodsInfo.id,1))
            }else{
                //更新缓存
//                TakeoutApp.sInstance.updateCacheSelectedInfo(goodsInfo.id, Constants.ADD)
            }
            count++
            //改变数据层
            goodsInfo.count = count
            notifyDataSetChanged()

            //抛物线

            //1.克隆+号,并且添加到acitivty上
            var ib = ImageButton(context)
            //大小,位置、背景全部相同
            ib.setBackgroundResource(R.mipmap.button_add)
//            btnAdd.width
            val srcLocation = IntArray(2)
            btnAdd.getLocationInWindow(srcLocation)
            Log.e("location", srcLocation[0].toString() + ":" + srcLocation[1])
            ib.x = srcLocation[0].toFloat()
            ib.y = srcLocation[1].toFloat()
            (goodsFragment.activity as BusinessActivity).addImageButton(ib, btnAdd.width, btnAdd.height)
            //2.执行抛物线动画(水平位移,垂直加速位移)
            val destLocation = (goodsFragment.activity as BusinessActivity).getCartLocation()
            val parabolaAnim: AnimationSet = getParabolaAnimation(ib, srcLocation, destLocation)
            ib.startAnimation(parabolaAnim)
            //3.动画完成后回收克隆的+号
        }

        /**
         * 抛物线动画
         */
        private fun getParabolaAnimation(ib: ImageButton, srcLocation: IntArray, destLocation: IntArray): AnimationSet {
            val parabolaAnim: AnimationSet = AnimationSet(false)
            parabolaAnim.duration = DURATION
            val translateX = TranslateAnimation(
                Animation.ABSOLUTE, 0f,
                Animation.ABSOLUTE, destLocation[0].toFloat() - srcLocation[0].toFloat(),
                Animation.ABSOLUTE, 0.0f,
                Animation.ABSOLUTE, 0.0f)
            translateX.duration = DURATION
            parabolaAnim.addAnimation(translateX)
            val translateY = TranslateAnimation(
                Animation.ABSOLUTE, 0F,
                Animation.ABSOLUTE, 0F,
                Animation.ABSOLUTE, 0f,
                Animation.ABSOLUTE, destLocation[1].toFloat() - srcLocation[1].toFloat())
            translateY.setInterpolator(AccelerateInterpolator())
            translateY.duration = DURATION
            parabolaAnim.addAnimation(translateY)
            parabolaAnim.setAnimationListener(object : Animation.AnimationListener {
                override fun onAnimationEnd(animation: Animation?) {
                    val viewParent = ib.parent
                    if (viewParent != null) {
                        (viewParent as ViewGroup).removeView(ib)
                    }
                }

                override fun onAnimationRepeat(animation: Animation?) {
                }

                override fun onAnimationStart(animation: Animation?) {

                }
            })
            return parabolaAnim
        }

        /**
         * 隐藏动画
         */
        private fun getHideAnimation(): AnimationSet {
            var animationSet: AnimationSet = AnimationSet(false)
            animationSet.duration = DURATION
            val alphaAnim: Animation = AlphaAnimation(1f, 0.0f)
            alphaAnim.duration = DURATION
            animationSet.addAnimation(alphaAnim)
            val rotateAnim: Animation = RotateAnimation(720.0f, 0.0f, Animation.RELATIVE_TO_SELF, 0.5f, Animation.RELATIVE_TO_SELF, 0.5f)
            rotateAnim.duration = DURATION
            animationSet.addAnimation(rotateAnim)
            val translateAnim: Animation = TranslateAnimation(
                Animation.RELATIVE_TO_SELF, 0.0f,
                Animation.RELATIVE_TO_SELF, 2.0f,
                Animation.RELATIVE_TO_SELF, 0.0f,
                Animation.RELATIVE_TO_SELF, 0.0f)
            translateAnim.duration = DURATION
            animationSet.addAnimation(translateAnim)
            return animationSet
        }

        /**
         * 动画
         */
        private fun getShowAnimation(): AnimationSet {
            var animationSet: AnimationSet = AnimationSet(false)
            animationSet.duration = DURATION
            //透明度
            val alphaAnim: Animation = AlphaAnimation(0.0f, 1.0f)
            alphaAnim.duration = DURATION
            animationSet.addAnimation(alphaAnim)
            //旋转
            val rotateAnim: Animation = RotateAnimation(0.0f, 720.0f, Animation.RELATIVE_TO_SELF, 0.5f, Animation.RELATIVE_TO_SELF, 0.5f)
            rotateAnim.duration = DURATION
            animationSet.addAnimation(rotateAnim)
            val translateAnim: Animation = TranslateAnimation(
                Animation.RELATIVE_TO_SELF, 2.0f,
                Animation.RELATIVE_TO_SELF, 0.0f,
                Animation.RELATIVE_TO_SELF, 0.0f,
                Animation.RELATIVE_TO_SELF, 0.0f)
            translateAnim.duration = DURATION
            animationSet.addAnimation(translateAnim)
            return animationSet
        }

        val ivIcon: ImageView
        val tvName: TextView
        val tvForm: TextView
        val tvMonthSale: TextView
        val tvNewPrice: TextView
        val tvOldPrice: TextView
        val btnAdd: ImageButton
        val btnMinus: ImageButton
        val tvCount: TextView
        lateinit var goodsInfo: GoodsInfo

        init {
            ivIcon = itemView.find(R.id.iv_icon)
            tvName = itemView.find(R.id.tv_name)
            tvForm = itemView.find(R.id.tv_form)
            tvMonthSale = itemView.find(R.id.tv_month_sale)
            tvNewPrice = itemView.find(R.id.tv_newprice)
            tvOldPrice = itemView.find(R.id.tv_oldprice)
            tvCount = itemView.find(R.id.tv_count)
            btnAdd = itemView.find(R.id.ib_add)
            btnMinus = itemView.find(R.id.ib_minus)
            btnAdd.setOnClickListener(this)
            btnMinus.setOnClickListener(this)
        }

        fun bindData(goodsInfo: GoodsInfo) {
            this.goodsInfo = goodsInfo
            //图片路径http://127.0.0.1:8090/image?name=takeout/businessimg/goods/0.jpg
            Picasso.with(context).load(host + goodsInfo.icon).into(ivIcon)
            tvName.text = goodsInfo.name
//            tvForm.text = goodsInfo.form
            tvMonthSale.text = "月售${goodsInfo.monthSaleNum}份"
            tvNewPrice.text = PriceFormater.format(goodsInfo.newPrice.toFloat())
//            tvNewPrice.text = "$${goodsInfo.newPrice}"
            tvOldPrice.text = "¥${goodsInfo.oldPrice}"
            tvOldPrice.paint.flags = Paint.STRIKE_THRU_TEXT_FLAG
            if (goodsInfo.oldPrice > 0) {
                tvOldPrice.visibility = View.VISIBLE
            } else {
                tvOldPrice.visibility = View.GONE
            }
            tvCount.text = goodsInfo.count.toString()
            if (goodsInfo.count > 0) {
                tvCount.visibility = View.VISIBLE
                btnMinus.visibility = View.VISIBLE
            } else {
                tvCount.visibility = View.INVISIBLE
                btnMinus.visibility = View.INVISIBLE
            }
        }
    }

    override fun getCount(): Int {
        return goodsList.size
    }

    override fun getItem(position: Int): Any {
        return goodsList.get(position)
    }

    override fun getItemId(position: Int): Long {
        return position.toLong()
    }

    override fun getView(position: Int, convertView: View?, parent: ViewGroup?): View {
        var itemView: View
        val goodsItemHolder: GoodsItemHolder
        if (convertView == null) {
            itemView = LayoutInflater.from(context).inflate(R.layout.item_goods, parent, false)
            goodsItemHolder = GoodsItemHolder(itemView)
            itemView.tag = goodsItemHolder
        } else {
            itemView = convertView
            goodsItemHolder = convertView.tag as GoodsItemHolder
        }
        goodsItemHolder.bindData(goodsList.get(position))
        return itemView
    }

    override fun getHeaderView(position: Int, convertView: View?, parent: ViewGroup?): View {
        val goodsInfo: GoodsInfo = goodsList.get(position)
        val typeName = goodsInfo.typeName
        val textView: TextView = LayoutInflater.from(context).inflate(R.layout.item_type_header, parent, false) as TextView
        textView.text = typeName
        textView.setTextColor(Color.BLACK)
        return textView
    }

    override fun getHeaderId(position: Int): Long {
        val goodsInfo: GoodsInfo = goodsList.get(position)
        return goodsInfo.typeId.toLong()
    }
}

GoodsFragmentPresenter.kt界面刷新的业务逻辑的处理

package com.example.takeout.presenter

import android.util.Log
import com.example.takeout.model.beans.GoodsInfo
import com.example.takeout.model.beans.GoodsTypeInfo
import com.example.takeout.ui.fragment.GoodsFragment
import com.google.gson.Gson
import com.google.gson.reflect.TypeToken
import org.json.JSONObject

class GoodsFragmentPresenter(val goodsFragment: GoodsFragment) : NetPresenter() {

    var goodstypeList: List<GoodsTypeInfo> = arrayListOf()
    val allTypeGoodsList: ArrayList<GoodsInfo> = arrayListOf()

    //连接服务器拿到此商家所有商品
    fun getBusinessInfo() {
        val businessCall = takeoutService.getBusinessInfo()
        businessCall.enqueue(callback)
    }


    override fun parserJson(json: String) {
        val gson = Gson()
        val jsoObj = JSONObject(json)
        val allStr = jsoObj.getString("list")
        //商品类型的集合
        goodstypeList = gson.fromJson(allStr, object : TypeToken<List<GoodsTypeInfo>>() {
        }.type)
        Log.e("business", "该商家一共有" + goodstypeList.size + "个类别商品")
        for (i in 0 until goodstypeList.size) {
            val goodsTypeInfo = goodstypeList.get(i)
            var aTypeCount = 0
            val aTypeList: List<GoodsInfo> = goodsTypeInfo.list
            for (j in 0 until aTypeList.size) {
                val goodsInfo = aTypeList.get(j)
                //建立双向绑定关系
                goodsInfo.typeName = goodsTypeInfo.name
                goodsInfo.typeId = goodsTypeInfo.id
            }
            allTypeGoodsList.addAll(goodsTypeInfo.list)
        }
        goodsFragment.onLoadBusinessSuccess(goodstypeList, allTypeGoodsList)
    }

    //根据商品类别id找到此类别第一个商品的位置
    fun getGoodsPositionByTypeId(typeId: Int): Int {
        var position = -1 //-1表示未找到
        for(j in 0 until  allTypeGoodsList.size){
            val goodsInfo = allTypeGoodsList.get(j)
            if(goodsInfo.typeId == typeId){
                position = j
                break;
            }
        }
        return position
    }

    //根据类别id找到其在左侧列表中的position,遍历左侧的列表
    fun getTypePositionByTypeId(newTypeId: Int):Int {
        var position = -1 //-1表示未找到
        for(i in 0 until  goodstypeList.size){
            val goodsTypeInfo = goodstypeList.get(i)
            if(goodsTypeInfo.id == newTypeId){
                position = i
                break;
            }
        }
        return position
    }

    fun getCartList() : ArrayList<GoodsInfo> {
        val cartList = arrayListOf<GoodsInfo>()
        //count >0的为购物车商品
        for(j in 0 until  allTypeGoodsList.size){
            val goodsInfo = allTypeGoodsList.get(j)
            if(goodsInfo.count>0){
                cartList.add(goodsInfo)
            }
        }
        return cartList
    }
}

效果如下:



下载方式:https://pan.quark.cn/s/a4b39357ea24 布线问题(分支限界算法)是计算机科学和电子工程领域中一个广为人知的议题,它主要探讨如何在印刷电路板上定位两个节点间最短的连接路径。 在这一议题中,电路板被构建为一个包含 n×m 个方格的矩阵,每个方格能够被界定为可通行或不可通行,其核心任务是定位从初始点到最终点的最短路径。 分支限界算法是处理布线问题的一种常用策略。 该算法与回溯法有相似之处,但存在差异,分支限界法仅需获取满足约束条件的一个最优路径,并按照广度优先或最小成本优先的原则来探索解空间树。 树 T 被构建为子集树或排列树,在探索过程中,每个节点仅被赋予一次成为扩展节点的机会,且会一次性生成其全部子节点。 针对布线问题的解决,队列式分支限界法可以被采用。 从起始位置 a 出发,将其设定为首个扩展节点,并将与该扩展节点相邻且可通行的方格加入至活跃节点队列中,将这些方格标记为 1,即从起始方格 a 到这些方格的距离为 1。 随后,从活跃节点队列中提取队首节点作为下一个扩展节点,并将与当前扩展节点相邻且未标记的方格标记为 2,随后将这些方格存入活跃节点队列。 这一过程将持续进行,直至算法探测到目标方格 b 或活跃节点队列为空。 在实现上述算法时,必须定义一个类 Position 来表征电路板上方格的位置,其成员 row 和 col 分别指示方格所在的行和列。 在方格位置上,布线能够沿右、下、左、上四个方向展开。 这四个方向的移动分别被记为 0、1、2、3。 下述表格中,offset[i].row 和 offset[i].col(i=0,1,2,3)分别提供了沿这四个方向前进 1 步相对于当前方格的相对位移。 在 Java 编程语言中,可以使用二维数组...
源码来自:https://pan.quark.cn/s/a4b39357ea24 在VC++开发过程中,对话框(CDialog)作为典型的用户界面组件,承担着与用户进行信息交互的重要角色。 在VS2008SP1的开发环境中,常常需要满足为对话框配置个性化背景图片的需求,以此来优化用户的操作体验。 本案例将系统性地阐述在CDialog框架下如何达成这一功能。 首先,需要在资源设计工具中构建一个新的对话框资源。 具体操作是在Visual Studio平台中,进入资源视图(Resource View)界面,定位到对话框(Dialog)分支,通过右键选择“插入对话框”(Insert Dialog)选项。 完成对话框内控件的布局设计后,对对话框资源进行保存。 随后,将着手进行背景图片的载入工作。 通常有两种主要的技术路径:1. **运用位图控件(CStatic)**:在对话框界面中嵌入一个CStatic控件,并将其属性设置为BST_OWNERDRAW,从而具备自主控制绘制过程的权限。 在对话框的类定义中,需要重写OnPaint()函数,负责调用图片资源并借助CDC对象将其渲染到对话框表面。 此外,必须合理处理WM_CTLCOLORSTATIC消息,确保背景图片的展示不会受到其他界面元素的干扰。 ```cppvoid CMyDialog::OnPaint(){ CPaintDC dc(this); // 生成设备上下文对象 CBitmap bitmap; bitmap.LoadBitmap(IDC_BITMAP_BACKGROUND); // 获取背景图片资源 CDC memDC; memDC.CreateCompatibleDC(&dc); CBitmap* pOldBitmap = m...
评论
成就一亿技术人!
拼手气红包6.0元
还能输入1000个字符

红包 添加红包
表情包 插入表情
 条评论被折叠 查看
添加红包

请填写红包祝福语或标题

红包个数最小为10个

红包金额最低5元

当前余额3.43前往充值 >
需支付:10.00
成就一亿技术人!
领取后你会自动成为博主和红包主的粉丝 规则
hope_wisdom
发出的红包
实付
使用余额支付
点击重新获取
扫码支付
钱包余额 0

抵扣说明:

1.余额是钱包充值的虚拟货币,按照1:1的比例进行支付金额的抵扣。
2.余额无法直接购买下载,可以购买VIP、付费专栏及课程。

余额充值
