Wallys//DR6018V4&DR6018-S V02&DR6018(CP01)/Qualcomm-Atheros IPQ6010 QCN9074 WIFI6E Card

DR6018 V4

Quad-core ARM 64bit A53 @1.8GHz Processor

1GB DDRL3L System Memory

32MB NOR Flash, 256MB NAND Flash

Supports Dynamic Frequency Selection (DFS)

2x2 On-board 2.4GHz radio, up to 573Mbps physical Data Rate

2x2 On-board 5GHz radio, up to 1201Mbps physical Data Rate

Support: QUECTEL RM500Q-GL

Support: QCN9074 WiFi 6E Card

Absolute Maximum Ratin

Parameter Rating Unit

Supply Voltage 24V~48 V

Operating Temperature Range -40 to +70 ºC

Storage Temperature Range -45 to +105 ºC

Operating Humidity Range5 to +95 (non-condensing) %

Hardware Specifications

Symbol Parameter

CPU Qualcomm-Atheros IPQ6010

CPU Frequency

Quad-core ARM 64 bit A53 @1.8 GHz processor

System Memory

1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design

Ethernet Port

1 x 1Gbps Ethernet Ports & POE3 x 1Gbps Ethernet Ports , 1x 2.5Gbps Ethernet Port

NGFF Slot

M.2 (NGFF) “E Key” Socket with MiniPCIe 3.0

SD Card Slot

1x SD Card Slot

USB /header 1x USB 2.0 Port

POE 24V~48V passive POE/Active POE(Suport 802.3bt)

DC Jack 24V power supply

LED header FFC/FPC Connector

Serial Port 1x Serial Port 4 Pin Connector

Wireless

On-board 2x2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax, max 23dBm per chain

On-board 2x2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax, max 20dBm per chain

4 x MMCX Connectors

Bluetooth CSR8811 BLE 4.2

Nor Flash 32MB

Nand Flash 256MB

DDR 256MB~512MB

Dimension 185mm x 116mm

Radio TX Specifications(5180MHz-5825MHz)

DR6018-S V01

https://www.wallystech.com/Routerboard/DR6018CV01-wifi6-Qualcomm-IPQ6010-IPQ6018-FAMILY-2T2R-2.5G-ETH-port-supporting-5G-celluar-Modem-802-11AX-MU-MIMO-OFDMA-SFP.html

Quad-core ARM 64bit A53 @1.8GHz Processor

1GB DDRL3L System Memory

8MB NOR Flash, 256MB NAND Flash

Supports Dynamic Frequency Selection (DFS)

2x2 On-board 2.4GHz radio, up to 573Mbps physical Data Rate

2x2 On-board 5GHz radio, up to 1201Mbps physical Data Rate

Absolute Maximum Rating

Paramete Rating Unit

Supply Voltage 24V~48V(DC Jack) V

Operating Temperature Range -40 to +70 ºC

Storage Temperature Range -45 to +105 ºC

Hardware Specifications

Symbol Parameter

CPU Qualcomm-Atheros IPQ6010

CPU Frequency Quad-core ARM 64 bit A53 @1.8 GHz processor

System Memory 1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design

Ethernet Port 1 x 1Gbps Ethernet Ports & POE 1x 1Gbps Ethernet Ports

NGFF Slot M.2 (NGFF) “E Key” Socket with MiniPCIe 3.0(For WiFi Module)

SD Card Slot 1x SD Card Slot(Option)

USB /header 1x USB 3.0 Port(Option)

POE 24V~48V passive POE/Active POE(Suport 802.3bt)

DC Jack 24V~48V power supply

LED header 2.0 pitch pin header

Serial Port 1x Serial Port 4 Pin Connector

Wireless

On-board 2x2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax, max 23dBm per chain

On-board 2x2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax, max 20dBm per chain

4 x MMCX Connectors

Nor Flash 8MB

Nand Flash 256MB

DDR 256MB~512MB

Dimension

125mm x 105mm x 20mmOperating Humidity Range 5 to +95 (non-condensing) %

DR6018(CP01)

https://www.wallystech.com/Routerboard/DR6018-CP01-wifi6-Qualcomm-IPQ6010-IPQ6018-FAMILY-2T2R-2.5G-ETH-port-CP01-802-11AX-MU-MIMO-OFDMA.html

Quad-core ARM 64bit A53 @1.8GHz Processor

1GB DDRL3L System Memory

32MB NOR Flash, 256MB NAND Flash

Supports Dynamic Frequency Selection (DFS)

2x2 On-board 2.4GHz radio, up to 573Mbps physical Data Rate

2x2 On-board 5GHz radio, up to 1201Mbps physical Data Rate

Absolute Maximum Rating

Parameter Rating Unit

Supply Voltage 24V~48 V

Operating Temperature Range -40 to +70 ºC

Storage Temperature Range -45 to +105 ºC

Operating Humidity Range 5 to +95 (non-condensing %

Hardware Specifications

Symbol Parameter

CPU Qualcomm-Atheros IPQ6018

CPU Frequency

Quad-core ARM 64 bit A53 @1.8 GHz processor

System Memory 1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design

Ethernet Port 5x 1Gbps Ethernet Ports , 1x 2.5Gbps Ethernet Port

NGFF Slot M.2 (NGFF) “E Key” Socket with MiniPCIe 3.0

SD Card Slot 1x SD Card Slot

USB /header 1x USB 2.0 Port, 1x USB 3.0 Type-C Port

POE 24V~48V passive POE

DC Jack 12V power supply

LED header FFC/FPC Connector

Serial Port 1x Serial Port 12 Pin Connector

Wireless

On-board 2x2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax, max 23dBm per chain

On-board 2x2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax, max 20dBm per chain

4x U.FL Connectors

Nor Flash 32MB

Nand Flash 256MB

DDR 256MB~512MB

Dimension (W x H x D) 219mm x 150mm x 16.5mm (Without Heatsink)
