成电作业1在内存中构建一个10叉非完全树T10并读出来

原创于 2020-11-19 13:57:51 发布 · 123 阅读

0 ·

CC 4.0 BY-SA版权

该博客围绕实验展开，先阐述代码思想，即创建随机非完全10叉树，用1 - 9表示节点值、0表示空节点，将其存入文件，再读文件创建对应二叉树并输出。还包含创建树和读树的代码。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

实验要求

在这里插入图片描述

代码思想

首先创建随机的非完全10叉树，使用1-9表示节点的值，0表示空节点，将该完全10叉树存入文件中，后读文件创造出对应的二叉树并输出。

创建树代码

#include<stdio.h>
#include<stdlib.h>
#define TEN 10
#define MAXLEVEL 7
#define MaxSize 10000000
typedef struct tree{

    int     data;
    int Level;
    struct tree   *children[TEN];

}tree;

//初始化队头和队尾指针开始时都为0
typedef struct queue{
    struct tree* numQ[MaxSize];
    int front;
    int rear;
}Queue;
Queue Q;

void initilize() { //初始化队列
    Q.front = 0;
    Q.rear = 0;
}

void Push(struct tree* root) { //入队
    Q.numQ[++Q.rear] = root;
}

struct tree* Pop() { //出队
    return Q.numQ[++Q.front];
}

int empty() { //判断对列是否为空
    return Q.rear == Q.front;
}


int num = 1;


void LevelOrderTraversal (struct tree* root) { //层次遍历用于查看树
    struct tree *temp;
    int NowLevel=root->Level;
    Push(root);
    while (!empty()) {
        temp = Pop();
        if(NowLevel!=temp->Level)
        {
            printf("\n");
            NowLevel=temp->Level;
        }
        printf("%d ", temp->data);  //输出队首结点
        for (int i = 0; i < TEN; i++){
            if(NowLevel<MAXLEVEL)
            {
                if(temp->children[i])
                    Push(temp->children[i]);
                else
                    {
                    tree *NodeNULL;
                    NodeNULL=(tree*)malloc(sizeof(tree));
                    NodeNULL->data=0;
                    NodeNULL->Level=NowLevel+1;
                    for(int j=0;j<TEN;j++)
                    {
                        NodeNULL->children[j]=NULL;
                    }
                    Push(NodeNULL);
                    }

                //break;
            }

        }
    }
}
void preOrderTraversal (struct tree* root,int Level) { //前序遍历用于输出树
        int RootLevel=Level;
        if(root&&RootLevel<=MAXLEVEL)
        {

            printf("%d ",root->data);
            FILE *fp=NULL;
            if((fp=fopen("/Users/apple/Documents/Linuxhomework1/Ftree.txt", "a+"))!=NULL)
                {
                        ;
                }
            else
                printf("can't open Ftree for write\n");
            fprintf(fp,"%d ",root->data);
            fclose(fp);
            for(int i=0;i<TEN;i++)
            {
                preOrderTraversal(root->children[i],root->Level+1);
            }
        }
        else if(RootLevel<=MAXLEVEL)
        {

            printf("0 ");
            FILE *fp=NULL;
            if((fp=fopen("/Users/apple/Documents/Linuxhomework1/Ftree.txt", "a+"))!=NULL)
                {
                        ;
                }
            else
                printf("can't open Ftree for write\n");
            fprintf(fp,"%d ",0);
            fclose(fp);
        }
        else
        {
                ;
        }

}
tree *CreateTree(int Level)
{
    int RandTEN;
    int j=1;
    tree *Node;
    Node=(tree*)malloc(sizeof(tree));
    //num=rand()%MaxSize;
    num=rand()%9+1;
    //printf("%d\n",num);
    Node->data=num;
    Node->Level=Level;

    for(j=0;j<TEN;j++)
        {
            Node->children[j]=NULL;
        }
    RandTEN=rand()%TEN+1;//最小为1
    if(Level<MAXLEVEL)
    {
        for(j=0;j<RandTEN;j++)
        {
            Node->children[j]=CreateTree(Level+1);
        }
    }
    return Node;
}
int main()
{
    tree *T;
    initilize();
    T=CreateTree(1);
    printf("TreeDone\n");
    preOrderTraversal(T,T->Level);
    printf("predon");
    return 0;
}

读树代码

#include<stdio.h>
#include<stdlib.h>
#define TEN 10
#define MAXLEVEL 7
#define MaxSize 10000000
typedef struct tree{

    int     data;
    int Level;
    struct tree   *children[TEN];

}tree;
//初始化队头和队尾指针开始时都为0
typedef struct queue{
    struct tree* numQ[MaxSize];
    int front;
    int rear;
}Queue;
Queue Q;

void initilize() { //初始化队列
    Q.front = 0;
    Q.rear = 0;
}

void Push(struct tree* root) { //入队
    Q.numQ[++Q.rear] = root;
}

struct tree* Pop() { //出队
    return Q.numQ[++Q.front];
}

int empty() { //判断对列是否为空
    return Q.rear == Q.front;
}

void LevelOrderTraversal (struct tree* root) { //层次遍历用于查看树
    struct tree *temp;
    int NowLevel=root->Level;
    Push(root);
    while (!empty()) {
        temp = Pop();
        if(NowLevel!=temp->Level)
        {
            printf("\n");
            NowLevel=temp->Level;
        }
        printf("%d ", temp->data);  //输出队首结点
        for (int i = 0; i < TEN; i++){
            if(NowLevel<MAXLEVEL)
            {
                if(temp->children[i])
                    Push(temp->children[i]);
                else
                    {
                    tree *NodeNULL;
                    NodeNULL=(tree*)malloc(sizeof(tree));
                    NodeNULL->data=0;
                    NodeNULL->Level=NowLevel+1;
                    for(int j=0;j<TEN;j++)
                    {
                        NodeNULL->children[j]=NULL;
                    }
                    Push(NodeNULL);
                    }

                //break;
            }

        }
    }
}
int  number=0;
int flagfile=0;
FILE *fp=NULL;
tree *CreateTree(int Level)
{

   tree *Node;
   int data;
   if(!flagfile)
    {
        flagfile=flagfile+1;

            if((fp=fopen("/Users/apple/Documents/Linuxhomework1/Ftree.txt", "r"))!=NULL)
                {
                        ;
                }
            else
                printf("can't open Ftree for write\n");
    }
   //fseek(fp, number*sizeof(int), 0);
   number=number+1;
   //printf("number=%d\n",number );
   if(fscanf(fp,"%d ",&data)==EOF)
   {
    return Node;
   }

    if(data==0)
   {
    printf("0 ");
    Node=NULL;
    return Node;
   }
   else if(data!=0)
   {
         Node=(tree*)malloc(sizeof(tree));
         Node->data=data;
         printf("%d ",data);
         Node->Level=Level;
        for (int i = 0; i < TEN; i++)
        {
            Node->children[i] = CreateTree(Level+1);
        }

   }
}
int main()
{
    tree *T;
    initilize();
    T=CreateTree(1);
    printf("TreeDone\n");
    //LevelOrderTraversal(T);
    return 0;
}
