* iford.dtsi- Sigmastar
*
* Copyright (c) [2019~2020] SigmaStar Technology.
*
*
* This software is licensed under the terms of the GNU General Public
* License version 2, as published by the Free Software Foundation, and
* may be copied, distributed, and modified under those terms.
*
* This program is distributed in the hope that it will be useful,
* but WITHOUT ANY WARRANTY; without even the implied warranty of
* MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
* GNU General Public License version 2 for more details.
*
*/
#include <generated/autoconf.h>
#include "../../../../drivers/sstar/include/iford/irqs.h"
#include "../../../../drivers/sstar/include/iford/gpio.h"
#include <dt-bindings/interrupt-controller/irq.h>
#include <dt-bindings/interrupt-controller/arm-gic.h>
#include <dt-bindings/input/input.h>
#include <linux/kconfig.h>
/ {
cpus {
#address-cells = <1>;
#size-cells = <0>;
cpu@0 {
device_type = "cpu";
compatible = "arm,cortex-a32";
clock-frequency = <1000000000>;
clocks = <&CLK_cpu_pll>;
reg = <0x0>;
operating-points-v2 = <&cpu0_opp_table>;
};
#ifdef CONFIG_SMP
cpu@1 {
device_type = "cpu";
compatible = "arm,cortex-a32";
clock-frequency = <1000000000>;
clocks = <&CLK_cpu_pll>;
reg = <0x1>;
#if CONFIG_ENABLE_METHOD_PSCI
enable-method = "psci";
#endif
};
#endif
};
cpu0_opp_table
: opp_table0 {
compatible = "operating-points-v2";
opp-shared;
opp00 {
opp-hz = /bits/ 64 <1000000000>;
opp-microvolt = <910000 890000 910000>;
status = "ok";
};
};
xtal
: oscillator {
compatible = "fixed-clock";
#clock-cells = <0>;
clock-frequency = <24000000>;
};
#if CONFIG_ARM_PSCI
psci {
compatible = "arm,psci-1.0";
method = "smc";
};
#endif
aliases {
console = &uart0;
serial0 = &uart0;
serial1 = &uart1;
serial2 = &fuart;
serial3 = &pm_fuart;
serial4 = &pm_fuart1;
};
#ifdef CONFIG_OPTEE
firmware {
optee {
compatible = "linaro,optee-tz";
method = "smc";
#interrupt-cells = <3>;
interrupt-parent = <&gic>;
interrupts = <GIC_SPI 31 IRQ_TYPE_EDGE_RISING>;
};
};
#endif
soc {
compatible = "simple-bus";
interrupt-parent = <&sstar_main_intc>;
#address-cells = <1>;
#size-cells = <1>;
ranges;
gic
: gic@16000000 {
compatible = "arm,gic-v3";
#interrupt-cells = <3>;
#address-cells = <1>;
#size-cells = <1>;
interrupt-controller;
interrupt-parent = <&gic>;
redistributor-stride = <0x0 0x20000>;
#redistributor-regions = <1>;
reg = <0x16000000 0x20000>,
<0x16040000 0x80000>;
};
sstar_main_intc
: sstar_main_intc {
compatible = "sstar,main-intc";
#interrupt-cells = <3>;
#address-cells = <1>;
#size-cells = <1>;
interrupt-parent=<&gic>;
interrupt-controller;
};
sstar_pm_main_intc
: sstar_pm_main_intc {
compatible = "sstar,pm-main-intc";
#interrupt-cells = <1>;
interrupt-parent=<&sstar_main_intc>;
interrupt-controller;
interrupts = <GIC_SPI INT_IRQ_IRQ_FRM_PM IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI INT_IRQ_IRQ_FRM_PM IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
sstar_pm_gpi_intc
: sstar_pm_gpi_intc {
compatible = "sstar,pm-gpi-intc";
#interrupt-cells = <1>;
interrupt-parent=<&sstar_main_intc>;
interrupt-controller;
interrupts = <GIC_SPI INT_IRQ_PM_SLEEP IRQ_TYPE_LEVEL_HIGH>;
};
sstar_gpi_intc
: sstar_gpi_intc {
compatible = "sstar,gpi-intc";
#interrupt-cells = <1>;
interrupt-parent=<&sstar_main_intc>;
interrupt-controller;
interrupts = <GIC_SPI INT_IRQ_GPI_OUT IRQ_TYPE_LEVEL_HIGH>;
};
arch_timer {
compatible = "arm,cortex-a32-timer", "arm,armv8-timer";
interrupt-parent=<&gic>;
interrupts = <GIC_PPI 13 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_LOW)>,
<GIC_PPI 14 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_LOW)>,
<GIC_PPI 11 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_LOW)>,
<GIC_PPI 10 (GIC_CPU_MASK_SIMPLE(2) | IRQ_TYPE_LEVEL_LOW)>;
clock-frequency = <6000000>; /* arch_timer must use clock-frequency*/
};
pmu {
compatible = "arm,cortex-a53-pmu";
interrupt-parent=<&gic>;
interrupts = <GIC_SPI 10 IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI 16 IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI 22 IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI 28 IRQ_TYPE_LEVEL_HIGH>;
};
clks
: clocks{
#address-cells = <1>;
#size-cells = <1>;
ranges;
};
cpufreq {
compatible = "sstar,infinity-cpufreq";
clocks = <&CLK_sar>;
status = "ok";
};
miu {
compatible = "sstar,miu";
interrupts=<GIC_SPI INT_IRQ_MIU IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
light_misc_control {
compatible = "sstar,light_misc_control";
lightsensor-i2c = <0>;
ir-ctrlmode = /bits/ 8 <0>; // 0
:GPIO 1
:PWM default is 0
ir-pad = <PAD_PM_PSPI0_INT>;
//ir-pad = /bits/ 64 <8 41666 11249>; // <pwm_channel> <period> <duty>
ircut-pad = <PAD_PM_GPIO9 PAD_PM_GPIO10>;
status = "ok";
};
mmu {
compatible = "sstar,mmu";
interrupts=<GIC_SPI INT_IRQ_MMU IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
/*
timer_clockevent
: timer@1F006040 {
compatible = "sstar,piu-clockevent";
reg = <0x1F006040 0x100>;
interrupts=<GIC_SPI INT_FIQ_TIMER_0 IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_xtali_12m>;
};
*/
uart0
: uart0@1F221000 {
compatible = "sstar,uart";
reg = <0x1F221000 0x100>, <0x1F220E00 0x100>;
interrupts= <GIC_SPI INT_IRQ_FUART0 IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_FUART0_MERGE IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_FUART0_MERGE IRQ_TYPE_LEVEL_HIGH>;
#if
!(defined(CONFIG_SS_DUALOS) || defined(CONFIG_OPTEE))
dma-enable;
#endif
rx_fifo_level = <0>;
tx_fifo_level = <0>;
digmux = <0>;
clocks = <&CLK_fuart0>, <&CLK_mcu>;
status = "ok";
};
uart1
: uart1@1F221200 {
compatible = "sstar,uart";
reg = <0x1F221200 0x100>, < 0x1F221C00 0x100>;
interrupts= <GIC_SPI INT_IRQ_FUART1 IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_FUART1_MERGE IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_FUART1_MERGE IRQ_TYPE_LEVEL_HIGH>;
#if
!(defined(CONFIG_SS_DUALOS) || defined(CONFIG_OPTEE))
dma-enable;
#endif
#if defined(CONFIG_PM_MCU_USE_UART1)
no-suspend;
#endif
rx_fifo_level = <0>;
tx_fifo_level = <0>;
digmux = <3>;
clocks = <&CLK_fuart1>, <&CLK_mcu>;
status = "ok";
};
fuart
: fuart@1F220400 {
compatible = "sstar,uart";
reg = <0x1F220400 0x100>, <0x1F220600 0x100>;
interrupts= <GIC_SPI INT_IRQ_FUART IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_FUART_MERGE IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_FUART_MERGE IRQ_TYPE_LEVEL_HIGH>;
#if
!(defined(CONFIG_SS_DUALOS) || defined(CONFIG_OPTEE))
dma-enable;
#endif
#if defined(CONFIG_PM_MCU_USE_FUART)
no-suspend;
#endif
sctp_enable = <0>;
rx_fifo_level = <0>;
tx_fifo_level = <0>;
digmux = <1>;
clocks = <&CLK_fuart>, <&CLK_mcu>;
status = "ok";
};
pm_fuart
: pm_fuart@1F006C00 {
compatible = "sstar,uart";
reg = <0x1F006C00 0x100>, <0x1F006E00 0x100>;
interrupt-parent = <&sstar_pm_main_intc>;
interrupts= <INT_PMSLEEP_IRQ_PM_FUART>, <INT_PMSLEEP_IRQ_PM_FUART_MERGE>, <INT_PMSLEEP_IRQ_PM_FUART_MERGE>;
#if
!(defined(CONFIG_SS_DUALOS) || defined(CONFIG_OPTEE))
dma-enable;
#endif
sctp_enable = <0>;
rx_fifo_level = <0>;
tx_fifo_level = <0>;
clocks = <&CLK_pm_fuart0>;
status = "okay";
};
pm_fuart1
: pm_fuart1@1F00A400 {
compatible = "sstar,uart";
reg = <0x1F00A400 0x100>, <0x1F00A600 0x100>;
interrupt-parent = <&sstar_pm_main_intc>;
interrupts= <INT_PMSLEEP_IRQ_PM_FUART1>, <INT_PMSLEEP_IRQ_PM_FUART1_MERGE>, <INT_PMSLEEP_IRQ_PM_FUART1_MERGE>;
#if
!(defined(CONFIG_SS_DUALOS) || defined(CONFIG_OPTEE))
dma-enable;
#endif
sctp_enable = <0>;
rx_fifo_level = <0>;
tx_fifo_level = <0>;
clocks = <&CLK_pm_fuart1>;
status = "okay";
};
dla {
compatible = "sstar,dla";
interrupts = <GIC_SPI INT_IRQ_DLA_TOP_0 IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_ipupll_clk>, <&CLK_ipu>, <&CLK_ipuff>;
status = "ok";
};
bdma0 {
compatible = "sstar,bdma0";
interrupts = <GIC_SPI INT_IRQ_BDMA IRQ_TYPE_LEVEL_HIGH>;
reg = <0x1F200400 0x80>;
clocks = <&xtal>;
status = "ok";
};
bdma1 {
compatible = "sstar,bdma1";
interrupts = <GIC_SPI INT_IRQ_BDMA IRQ_TYPE_LEVEL_HIGH>;
reg = <0x1F200480 0x80>;
clocks = <&xtal>;
status = "ok";
};
bdma2 {
compatible = "sstar,bdma2";
interrupts = <GIC_SPI INT_IRQ_BDMA IRQ_TYPE_LEVEL_HIGH>;
reg = <0x1F200500 0x80>;
clocks = <&xtal>;
status = "ok";
};
bdma8 {
compatible = "sstar,bdma8";
interrupts = <GIC_SPI INT_IRQ_PM_BDMA IRQ_TYPE_LEVEL_HIGH>;
reg = <0x1F008A00 0x80>;
clocks = <&xtal>;
status = "ok";
};
/*
bdma9 {
compatible = "sstar,bdma9";
interrupts = <GIC_SPI INT_IRQ_PM_BDMA IRQ_TYPE_LEVEL_HIGH>;
reg = <0x1F008A80 0x80>;
clocks = <&xtal>;
status = "ok";
};
*/
/*
xordma {
compatible = "sstar,xordma";
interrupts = <GIC_SPI INT_IRQ_BDMA_3 IRQ_TYPE_LEVEL_HIGH>;
reg = <0x1F200C00 0x100>,<0x1F201800 0x100>;
clocks = <&xtal>;
status = "ok";
};
*/
#ifdef CONFIG_OPTEE
tzsp {
compatible = "sstar,tzsp";
interrupts = <GIC_SPI INT_FIQ_ERROR_RESP IRQ_TYPE_EDGE_RISING>;
status = "ok";
};
tzsp_dla {
compatible = "sstar,tzsp_dla";
interrupt-parent=<&gic>;
interrupts = <GIC_SPI 8 IRQ_TYPE_LEVEL_HIGH>;
};
tzimi {
compatible = "sstar,tzimi";
interrupts = <GIC_SPI INT_IRQ_TZIMI IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
tzemi {
compatible = "sstar,tzemi";
interrupts = <GIC_SPI INT_IRQ_TZEMI IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
#endif
fsp-qspi0 {
compatible = "sstar,fsp-qspi";
reg = <0x1F201A00 0x200>, <0x1F201C00 0x200>;
clocks = <&CLK_fsp_qspi>, <&CLK_spi_nonpm>, <&CLK_spi_synth_pll>;
cs-num = <2>;
cs-mode = <0>;
//cs-ext = <PAD_GPIO0>;
engine = <0>;
dma = <1>;
status = "ok";
};
nandflash0 {
compatible = "sstar-nandflash";
engine = <0>;
cs-select = <0>;
fcie-interface = <0>;
status = "ok";
};
#if IS_ENABLED(CONFIG_SSTAR_NOR)
norflash0 {
compatible = "sstar-norflash";
engine = <0>;
cs-select = <0>;
status = "ok";
};
/*
norflash1 {
compatible = "sstar-norflash";
engine = <0>;
cs-select = <2>;
status = "ok";
};
*/
#endif
#if IS_ENABLED(CONFIG_SSTAR_MSPI)
spi@1f222000 {
compatible = "sstar,mspi";
mspi-group = <0>;
#ifdef CONFIG_CAM_CLK
camclk = <CAMCLK_mspi0>;
#else
clocks = <&CLK_mspi0>;
#endif
reg = <0x1F222000 0x200>;
#address-cells = <1>;
#size-cells = <0>;
interrupts = <GIC_SPI INT_IRQ_MSPI_0 IRQ_TYPE_LEVEL_HIGH>;
#if
!defined(CONFIG_SS_DUALOS)
dma-enable;
#endif
cs-num = <2>;
//cs-ext = <PAD_UNKNOWN>;
//4to3-mode;
//clk-out-mode = <27000000>;
status = "ok";
#ifdef CONFIG_SS_GYRO_TRANSFER_SPI
gyro@0 {
compatible = "sstar,gyro_spi";
devid = <0>;
reg = <0x0>;
spi-
max-frequency = <7000000>;
};
#endif
#ifdef CONFIG_SPI_SPIDEV
spidev0@0 {
compatible = "
lwn,bk4";
spi-
max-frequency = <2000000>;
reg = <0>;
};
spidev1@1 {
compatible = "
lwn,bk4";
spi-
max-frequency = <2000000>;
reg = <1>;
};
#endif
};
#endif
#if IS_ENABLED(CONFIG_SSTAR_PSPI)
pspi
: spi@1F003200 {
compatible = "sstar,pspi";
reg = <0x1F003200 0x200>;
#address-cells = <1>;
#size-cells = <0>;
interrupts = <GIC_SPI INT_IRQ_PSPI02HOST IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_pm_pspi0>;
#ifdef CONFIG_SPI_SLAVE
pspi-slave;
ready-gpios = <&gpio PAD_GPIO1 0>;
#endif
dma-enable;
group = <1>;
cs-num = <1>;
status = "okay";
#ifdef CONFIG_SPI_SLAVE
slave@0 {
compatible = "ge,achc";
reg = <0>;
};
#else
spidev1@0 {
compatible = "ge,achc";
reg = <0>;
};
#endif
};
#endif
#if IS_ENABLED(CONFIG_SSTAR_I2C)
i2c0
: i2c@1f222800 {
compatible = "sstar,i2c";
reg = <0x1F222800 0x200>;
#address-cells = <1>;
#size-cells = <0>;
interrupts = <GIC_SPI INT_IRQ_MIIC IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_miic0>;
#if
!defined(CONFIG_SS_DUALOS)
dma-enable;
#endif
group = <0>;
#ifdef CONFIG_SS_GYRO_TRANSFER_I2C
speed = <600000>;
#else
speed = <200000>;//if u want set tSU/tHD, do not set 0, tSU = (t-su-* / i2c-srcclk)S, tHD = (t-hd-* / i2c-srcclk)S
#endif
t-su-sta = <0>;
t-hd-sta = <0>;
t-su-sto = <0>;
t-hd-sto = <0>;
//1->open drain; 2->open drain + one push; 3->open drain + one push + clock push; 4->push-pull
output-mode = <4>;
status = "ok";
#ifdef CONFIG_SS_GYRO_TRANSFER_I2C
gyro@d0 {
compatible = "sstar,gyro";
devid = <0>;
#ifdef CONFIG_SS_GYRO_CHIP_ICM40607
reg = <0x69>;
#endif
#ifdef CONFIG_SS_GYRO_CHIP_ICM42607
reg = <0x68>;
#endif
#ifdef CONFIG_SS_GYRO_CHIP_ICG20660
reg = <0x68>;
#endif
};
#endif
};
#endif
emac0
: emac0 {
compatible = "sstar-emac";
interrupts = <GIC_SPI INT_IRQ_EMAC IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_FIQ_LAN_ESD IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_IRQ_EMAC_SCATTER IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_emac_ahb>;
reg = <0x1F2A2000 0x800>, <0x1F304200 0x600>, <0x1F2A3000 0x600>;
// reg = <0x1F2A2000 0x800>, <0x1F304200 0x600>, <0x00000000 0x000>;
pad = <0x1F203C38 0x0001 0x0001>; // pad selection from 0x0001
bus-mode = <1>;//1
:MII 2
:RMII
phy-handle = <&phy0>;
cpu-affinity = <0>; //0
:single cpu 1
:multi cpu
status = "ok";
mdio-bus@emac0 {
phy0
: ethernet-phy@0 {
// phy-mode = "rmii";
phy-mode = "mii";
};
};
};
#if IS_ENABLED(CONFIG_SSTAR_SDMMC)
#ifdef CONFIG_SSTAR_SELECT_EMMC
sstar_sdmmc0
: sstar_sdmmc0 {
compatible = "sstar,sdmmc";
bus-width = <4>;
max-frequency = <48000000>;
non-removable;
//broken-cd;
cap-mmc-highspeed;
//sd-uhs-sdr50;
//sd-uhs-sdr104;
//sd-uhs-ddr50;
//cap-sdio-irq;
no-sdio;
no-sd;
//no-mmc;
//reg = <0x1F008400 0x200>;
reg = <0x1F282600 0x200>;
pll-reg = <0x1F283200 0x200>;
//cifd-reg = <0x1F008600 0x200>;
cifd-reg = <0x1F282800 0x200>;
//pwr-save-reg = <0x1F008800 0x200>;
pwr-save-reg = <0x1F282A00 0x200>;
ip-
order = /bits/ 8 <0>;
pad-
order = /bits/ 8 <0>;
//pad-
order = /bits/ 8 <1>;
trans-mode = /bits/ 8 <1>; // 0
:dma 1
:adma default is 1
fake-cdz = /bits/ 8 <0>;
rev-cdz = /bits/ 8 <0>;
//cdz-pad = <PAD_PM_SD_CDZ>;
//pwr-pad = <PAD_FUART_RTS>;
pwr-on-delay = <1>;
pwr-off-delay = <30>;
//sdio-use-1bit = /bits/ 8 <0>;
cifd-mcg-off = /bits/ 8 <0>; // mcg on/off in cifd
support-cmd23 = /bits/ 8 <1>;
clk-driving = <1>;
cmd-driving = <1>;
data-driving = <1>;
en-clk-phase = /bits/ 8 <0>; //0/1
rx-clk-phase = <0>; //0-3
tx-clk-phase = <0>; //0-3
en-eight-phase = /bits/ 8 <0>; //0/1
rx-eight-phase = /bits/ 8 <0>; //0/1
tx-eight-phase = /bits/ 8 <0>; //0/1
interrupts = <GIC_SPI INT_IRQ_SD IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI INT_IRQ_SDIO IRQ_TYPE_LEVEL_HIGH>;
interrupt-names = "mie0_irq", "mie1_irq";
clocks = <&CLK_sd>, <&CLK_pm_sdio>, <&CLK_mcu_pm>;
clock-names = "clk_sdmmc0", "clk_sdmmc1", "pm_mcu_sdmmc1";
status = "ok";
};
sstar_sdmmc1
: sstar_sdmmc1 {
compatible = "sstar,sdmmc";
bus-width = <4>;
max-frequency = <50000000>;
//non-removable;
//broken-cd;
cap-mmc-highspeed;
cap-sd-highspeed;
//sd-uhs-sdr50;
//sd-uhs-sdr104;
//sd-uhs-ddr50;
cap-sdio-irq;
//no-sdio;
//no-sd;
no-mmc;
reg = <0x1F008400 0x200>;
//reg = <0x1F282600 0x200>;
pll-reg = <0x1F283400 0x200>;
cifd-reg = <0x1F008600 0x200>;
//cifd-reg = <0x1F282800 0x200>;
pwr-save-reg = <0x1F008800 0x200>;
//pwr-save-reg = <0x1F282A00 0x200>;
ip-
order = /bits/ 8 <1>;
pad-
order = /bits/ 8 <0>;
trans-mode = /bits/ 8 <1>; // 0
:dma 1
:adma default is 1
cifd-mcg-off = /bits/ 8 <0>; // mcg on/off in cifd
support-runtime-pm = /bits/ 8 <0>; // sd/sdio runtime-pm default disable
support-cmd23 = /bits/ 8 <1>;
fake-cdz = <0>;
rev-cdz = /bits/ 8 <0>;
cdz-pad = <PAD_PM_SDIO_INT>;
pwr-pad = <PAD_PM_GPIO12>;
//cdz-pad = <PAD_SD0_CDZ>;
//pwr-pad = <PAD_PM_GPIO11>;
pwr-on-delay = <1>;
pwr-off-delay = <30>;
sdio-use-1bit = /bits/ 8 <0>;
clk-driving = <1>;
cmd-driving = <1>;
data-driving = <1>;
en-clk-phase = /bits/ 8 <0>; //0/1
rx-clk-phase = <0>; //0-3
tx-clk-phase = <0>; //0-3
en-eight-phase = /bits/ 8 <0>; //0/1, only support
:000,001,010,011,100
rx-eight-phase = /bits/ 8 <0>; //0/1
tx-eight-phase = /bits/ 8 <0>; //0/1
interrupts = <GIC_SPI INT_IRQ_SDIO IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI INT_FIQ_PAD2SDIO_SD_CDZ IRQ_TYPE_LEVEL_HIGH>;
interrupt-names = "mie1_irq", "cdz_slot1_irq";
//interrupts = <GIC_SPI INT_IRQ_SD IRQ_TYPE_LEVEL_HIGH>,
// <GIC_SPI INT_FIQ_SD_CDZ_0 IRQ_TYPE_LEVEL_HIGH>;
//interrupt-names = "mie0_irq", "cdz_slot0_irq";
clocks = <&CLK_sd>, <&CLK_pm_sdio>, <&CLK_mcu_pm>;
clock-names = "clk_sdmmc0", "clk_sdmmc1", "pm_mcu_sdmmc1";
status = "ok";
};
#else
sstar_sdmmc0
: sstar_sdmmc0 {
compatible = "sstar,sdmmc";
bus-width = <4>;
max-frequency = <50000000>;
non-removable;
//broken-cd;
cap-mmc-highspeed;
//sd-uhs-sdr50;
//sd-uhs-sdr104;
//sd-uhs-ddr50;
//cap-sdio-irq;
no-sdio;
no-sd;
//no-mmc;
reg = <0x1F008400 0x200>;
//reg = <0x1F282600 0x200>;
pll-reg = <0x1F283200 0x200>;
cifd-reg = <0x1F008600 0x200>;
//cifd-reg = <0x1F282800 0x200>;
pwr-save-reg = <0x1F008800 0x200>;
//pwr-save-reg = <0x1F282A00 0x200>;
ip-
order = /bits/ 8 <1>;
pad-
order = /bits/ 8 <0>;
//pad-
order = /bits/ 8 <1>;
trans-mode = /bits/ 8 <1>; // 0
:dma 1
:adma default is 1
fake-cdz = /bits/ 8 <0>;
rev-cdz = /bits/ 8 <0>;
//cdz-pad = <PAD_PM_SD_CDZ>;
//pwr-pad = <PAD_FUART_RTS>;
pwr-on-delay = <1>;
pwr-off-delay = <30>;
//sdio-use-1bit = /bits/ 8 <0>;
cifd-mcg-off = /bits/ 8 <0>; // mcg on/off in cifd
support-cmd23 = /bits/ 8 <1>;
clk-driving = <1>;
cmd-driving = <1>;
data-driving = <1>;
en-clk-phase = /bits/ 8 <0>; //0/1
rx-clk-phase = <0>; //0-3
tx-clk-phase = <0>; //0-3
en-eight-phase = /bits/ 8 <0>; //0/1, only support
:000,001,010,011,100
rx-eight-phase = /bits/ 8 <0>; //0/1
tx-eight-phase = /bits/ 8 <0>; //0/1
interrupts = <GIC_SPI INT_IRQ_SD IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI INT_IRQ_SDIO IRQ_TYPE_LEVEL_HIGH>;
interrupt-names = "mie0_irq", "mie1_irq";
clocks = <&CLK_sd>, <&CLK_pm_sdio>, <&CLK_mcu_pm>;
clock-names = "clk_sdmmc0", "clk_sdmmc1", "pm_mcu_sdmmc1";
status = "ok";
};
sstar_sdmmc1
: sstar_sdmmc1 {
compatible = "sstar,sdmmc";
bus-width = <4>;
max-frequency = <48000000>;
//non-removable;
//broken-cd;
cap-mmc-highspeed;
cap-sd-highspeed;
//sd-uhs-sdr50;
//sd-uhs-sdr104;
//sd-uhs-ddr50;
cap-sdio-irq;
//no-sdio;
//no-sd;
no-mmc;
//reg = <0x1F008400 0x200>;
reg = <0x1F282600 0x200>;
pll-reg = <0x1F283400 0x200>;
//cifd-reg = <0x1F008600 0x200>;
cifd-reg = <0x1F282800 0x200>;
//pwr-save-reg = <0x1F008800 0x200>;
pwr-save-reg = <0x1F282A00 0x200>;
ip-
order = /bits/ 8 <0>;
pad-
order = /bits/ 8 <0>;
trans-mode = /bits/ 8 <1>; // 0
:dma 1
:adma default is 1
cifd-mcg-off = /bits/ 8 <0>; // mcg on/off in cifd
support-runtime-pm = /bits/ 8 <0>; // sd/sdio runtime-pm default disable
support-cmd23 = /bits/ 8 <1>;
fake-cdz = <0>;
rev-cdz = /bits/ 8 <0>;
//cdz-pad = <PAD_PM_SDIO_INT>;
//pwr-pad = <PAD_PM_GPIO12>;
cdz-pad = <PAD_SD0_CDZ>;
pwr-pad = <PAD_PM_GPIO11>;
pwr-on-delay = <1>;
pwr-off-delay = <30>;
sdio-use-1bit = /bits/ 8 <0>;
clk-driving = <1>;
cmd-driving = <1>;
data-driving = <1>;
en-clk-phase = /bits/ 8 <0>; //0/1
rx-clk-phase = <0>; //0-3
tx-clk-phase = <0>; //0-3
en-eight-phase = /bits/ 8 <0>; //0/1
rx-eight-phase = /bits/ 8 <0>; //0/1
tx-eight-phase = /bits/ 8 <0>; //0/1
//interrupts = <GIC_SPI INT_IRQ_SDIO IRQ_TYPE_LEVEL_HIGH>,
// <GIC_SPI INT_FIQ_PAD2SDIO_SD_CDZ IRQ_TYPE_LEVEL_HIGH>;
//interrupt-names = "mie1_irq", "cdz_slot1_irq";
interrupts = <GIC_SPI INT_IRQ_SD IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI INT_FIQ_SD_CDZ_0 IRQ_TYPE_LEVEL_HIGH>;
interrupt-names = "mie0_irq", "cdz_slot0_irq";
clocks = <&CLK_sd>, <&CLK_pm_sdio>, <&CLK_mcu_pm>;
clock-names = "clk_sdmmc0", "clk_sdmmc1", "pm_mcu_sdmmc1";
status = "ok";
};
#endif
#endif
hst0to1 {
compatible = "sstar,hst0to1"; // mailbox int
interrupts = <GIC_SPI INT_FIQ_CPU0TO2_TOP IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
#if IS_ENABLED(CONFIG_SSTAR_RIU_DBG)
riu {
#address-cells = <1>;
#size-cells = <1>;
compatible = "sstar,riu";
ranges;
status = "ok";
#if CONFIG_SSTAR_RIU_TIMEOUT
timeout {
reg = <0x1F000200 0x200>, <0x1F200200 0x200>, <0x1F2CE000 0x200>;
interrupts = <GIC_SPI INT_FIQ_PM_XIU_TIMEOUT IRQ_TYPE_LEVEL_HIGH>, <GIC_SPI INT_FIQ_XIU_TIMEOUT IRQ_TYPE_LEVEL_HIGH>,
<GIC_SPI INT_FIQ_XIU_XIU_TIMEOUT IRQ_TYPE_LEVEL_HIGH>;
print-on;
//bug-on;
status = "ok";
};
#endif
#if CONFIG_SSTAR_RIU_REC
ORDER
rec
order {
reg = <0x1F229600 0x200>, <0x1F229800 0x200>, <0x1F229A00 0x200>, <0x1F229C00 0x200>;
interrupts = <GIC_SPI INT_IRQ_RIU_RECORDING IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_wdma>;
print-on;
//bug-on;
status = "ok";
};
#endif
};
#endif
#if IS_ENABLED(CONFIG_SSTAR_TIMER)
timer0
: timer0@0x1F006040 {
compatible = "sstar,timer";
clocks = <&CLK_mcu_pm_p>;
reg = <0x1F006040 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer1
: timer1@0x1F006080 {
compatible = "sstar,timer";
clocks = <&CLK_mcu_pm_p>;
reg = <0x1F006080 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer2
: timer2@0x1F0060C0 {
compatible = "sstar,timer";
clocks = <&CLK_mcu_pm_p>;
reg = <0x1F0060C0 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer3
: timer3@0x1F006100 {
compatible = "sstar,timer";
clocks = <&CLK_mcu_pm_p>;
reg = <0x1F006100 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer4
: timer4@0x1F006140 {
compatible = "sstar,timer";
clocks = <&CLK_pm_timer4>;
clock-on-demand;
reg = <0x1F006140 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer5
: timer5@0x1F006180 {
compatible = "sstar,timer";
clocks = <&CLK_pm_timer5>;
clock-on-demand;
reg = <0x1F006180 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer6
: timer6@0x1F0061C0 {
compatible = "sstar,timer";
clocks = <&CLK_pm_timer6>;
clock-on-demand;
reg = <0x1F0061C0 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer7
: timer7@0x1F006440 {
compatible = "sstar,timer";
clocks = <&CLK_pm_timer7>;
clock-on-demand;
reg = <0x1F006440 0x40>;
interrupts = <GIC_SPI INT_FIQ_TIMER IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
timer8
: timer8@0x1F2CDE40 {
compatible = "sstar,timer";
clocks = <&CLK_mcu>;
reg = <0x1F2CDE40 0x40>;
interrupts = <GIC_SPI INT_FIQ_NONPM_TIMER_0 IRQ_TYPE_EDGE_RISING>;
status = "ok";
};
timer9
: timer9@0x1F2CDE80 {
compatible = "sstar,timer";
clocks = <&CLK_mcu>;
reg = <0x1F2CDE80 0x40>;
interrupts = <GIC_SPI INT_FIQ_NONPM_TIMER_1 IRQ_TYPE_EDGE_RISING>;
status = "ok";
};
timer10
: timer10@0x1F2CDEC0 {
compatible = "sstar,timer";
clocks = <&CLK_mcu>;
reg = <0x1F2CDEC0 0x40>;
interrupts = <GIC_SPI INT_FIQ_NONPM_TIMER_2 IRQ_TYPE_EDGE_RISING>;
status = "ok";
};
timer11
: timer11@0x1F2CDF00 {
compatible = "sstar,timer";
clocks = <&CLK_mcu>;
reg = <0x1F2CDF00 0x40>;
interrupts = <GIC_SPI INT_FIQ_NONPM_TIMER_3 IRQ_TYPE_EDGE_RISING>;
status = "ok";
};
#endif
watchdog0 {
compatible = "sstar,wdt";
clocks = <&CLK_wdt>;
reg = <0x1F006000 0x40>;
interrupts = <GIC_SPI INT_FIQ_WDT IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
#if defined(CONFIG_SSTAR_LH_RTOS_VIRTIO)
rpmsg
: rpmsg {
compatible = "sstar,sstar-lh-rtos-virtio";
};
#endif
aesdma {
compatible = "sstar,aesdma";
interrupts=<GIC_SPI INT_IRQ_WADR_ERR IRQ_TYPE_LEVEL_HIGH>;
clocks = <&CLK_aesdma>;
#ifdef CONFIG_CAM_CLK
camclk = <CAMCLK_aesdma>;
#endif
status = "ok";
};
rng {
compatible = "sstar,rng";
clocks = <&CLK_miu_boot>;
status = "ok";
};
gpio
: gpio {
compatible = "sstar,gpio";
#gpio-cells = <2>;
status = "ok";
};
clkinit {
compatible = "sstar,clkinit";
#ifdef CONFIG_SSTAR_CLK_PSPI_EXT
clocks = <&CLK_pm_high_ext>;
default-parent = <2>;
#endif
status = "ok";
};
#if IS_ENABLED(CONFIG_SSTAR_ADCLP)
adclp0
: adclp0@1f002800 {
compatible = "sstar,adclp";
interrupt-parent = <&sstar_pm_main_intc>;
interrupts = <INT_PMSLEEP_IRQ_SAR_KP>;
reg = <0x1F002800 0x200>;
clocks = <&CLK_sar>;
interrupt-enable;
channel = <0>;
ref-voltage = <1800>;
upper-bound = <0x3FF>;
lower-bound = <0>;
#io-channel-cells = <1>;
status = "ok";
};
adclp1
: adclp1@1f002800 {
compatible = "sstar,adclp";
interrupt-parent = <&sstar_pm_main_intc>;
interrupts = <INT_PMSLEEP_IRQ_SAR_KP>;
reg = <0x1F002800 0x200>;
clocks = <&CLK_sar>;
interrupt-enable;
channel = <1>;
ref-voltage = <1800>;
upper-bound = <0x3FF>;
lower-bound = <0>;
#io-channel-cells = <1>;
status = "ok";
};
adclp2
: adclp2@1f002800 {
compatible = "sstar,adclp";
interrupt-parent = <&sstar_pm_main_intc>;
interrupts = <INT_PMSLEEP_IRQ_SAR_KP>;
reg = <0x1F002800 0x200>;
clocks = <&CLK_sar>;
interrupt-enable;
channel = <2>;
ref-voltage = <1800>;
upper-bound = <0x3FF>;
lower-bound = <0>;
#io-channel-cells = <1>;
status = "ok";
};
adclp3
: adclp3@1f002800 {
compatible = "sstar,adclp";
interrupt-parent = <&sstar_pm_main_intc>;
interrupts = <INT_PMSLEEP_IRQ_SAR_KP>;
reg = <0x1F002800 0x200>;
clocks = <&CLK_sar>;
interrupt-enable;
channel = <3>;
ref-voltage = <1800>;
upper-bound = <0x3FF>;
lower-bound = <0>;
#io-channel-cells = <1>;
status = "ok";
};
adclp4
: adclp4@1f002800 {
compatible = "sstar,adclp";
interrupt-parent = <&sstar_pm_main_intc>;
interrupts = <INT_PMSLEEP_IRQ_SAR_KP>;
reg = <0x1F002800 0x200>;
clocks = <&CLK_sar>;
interrupt-enable;
channel = <4>;
ref-voltage = <1800>;
upper-bound = <0x3FF>;
lower-bound = <0>;
#io-channel-cells = <1>;
status = "ok";
};
#endif
#if IS_ENABLED(CONFIG_SSTAR_RTC)
rtcpwc
: rtcpwc {
compatible = "sstar,rtcpwc";
reg = <0x1F006800 0x200>;
interrupts=<GIC_SPI INT_IRQ_FLAG_POC IRQ_TYPE_LEVEL_HIGH>;
// io0-hiz;
// io2-wos = <1>; //0
:CMPHL 1
:CMPHL 2
:CMPL 3
:CMPH
// io2-wos-v = <0x2 0x3>; //<vl vh> 0<vl<8 0<vh<8
// io3-pu;
// offset-count = <100>;
// offset-nagative;
// iso-auto-regen;
/*
* io4 control source selection
* io0/io1/io2/io3 ctrl bit0
* alarm ctrl bit1
* sw ctrl bit2
* support the combination of above ways
*/
io4-enable = <3>;
/*
* io5 control source selection
* io4 ctrl bit0
* alarm ctrl bit1
* sw ctrl bit2
* support the combination of above ways
*/
io5-enable = <7>; // for demo board,use 3,default hight
// io5-no-poweroff; // io5 keep when excute 'poweroff' use for wakeup pm51
status = "ok";
#ifdef CONFIG_SSTAR_PWC_IO_POLLING
poll-interval = <10>;
#endif /* CONFIG_SSTAR_PWC_IO_POLLING */
io1 {
num = <1>;
keycode = <KEY_WAKEUP>;
#ifdef CONFIG_SSTAR_PWC_IO_POLLING
debounce-interval = <10>;
#endif /* CONFIG_SSTAR_PWC_IO_POLLING */
#ifdef CONFIG_SSTAR_PWC_IO_INTERRUPT
interrupt-parent = <&sstar_pm_gpi_intc>;
interrupts = <INT_PM_GPI_FIQ_PAD_RTC_IO1>;
#endif /* CONFIG_SSTAR_PWC_IO_INTERRUPT */
};
};
#endif
#if IS_ENABLED (CONFIG_SSTAR_PWM)
pwm0
: pwm@0x1F203200{
compatible = "sstar,pwm";
reg = <0x1F203200 0x37>;
#pwm-cells = <3>;
channel = <0>;
group = <0>;
clocks = <&CLK_pwm>;
clk-select = <0>;
interrupts=<GIC_SPI INT_IRQ_PWM IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
pwm1
: pwm@0x1F203280 {
compatible = "sstar,pwm";
reg = <0x1F203280 0x37>;
#pwm-cells = <3>;
channel = <1>;
group = <0>;
clocks = <&CLK_pwm>;
clk-select = <0>;
interrupts=<GIC_SPI INT_IRQ_PWM IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
pwm2
: pwm@0x1F203300 {
compatible = "sstar,pwm";
reg = <0x1F203300 0x37>;
#pwm-cells = <3>;
channel = <2>;
group = <0>;
clocks = <&CLK_pwm>;
clk-select = <0>;
interrupts=<GIC_SPI INT_IRQ_PWM IRQ_TYPE_LEVEL_HIGH>;
status = "ok";
};
#endif
#if IS_ENABLED(CONFIG_SSTAR_IR)
ir
: ir@1F007A00 {
compatible = "sstar,ir";
reg = <0x1F007A00 0x200>;
clocks = <&CLK_ir>;
interrupts = <GIC_SPI INT_FIQ_IR IRQ_TYPE_LEVEL_HIGH>,<GIC_SPI INT_FIQ_IR_RC IRQ_TYPE_LEVEL_HIGH>;
group = <0>;
/*
* decode mode selection
* FULL 1 Format
: NEC/NECX
* RAW 2 Format
: NEC/NECX
* RC5 3 Format
: RC5
* SW 4 Format
: /
*/
mode = <2>;
//choose enum rc_proto for sw mode
protocol = <9>;
vendor = <0x000E>;
product = <0x3412>;
//rc-map-table = <customer_code + command_code input_key_code>
rc-map-table =
//NEC Remote Control NO.1
<0x00FFA8 KEY_POWER>, <0x00FFC0 KEY_F5>, <0x00FFDD KEY_GREEN>,
<0x00FF44 KEY_F19>, <0x00FFCA KEY_UP>, <0x00FFD2 KEY_DOWN>,
<0x00FF99 KEY_LEFT>, <0x00FFC1 KEY_RIGHT>, <0x00FFCE KEY_ENTER>,
<0x00FFCB KEY_BACK>, <0x00FF87 KEY_HOMEPAGE>, <0x00FF97 KEY_COMPOSE>,
<0x00FF41 KEY_PLAYPAUSE>, <0x00FF0F KEY_F16>, <0x00FF60 KEY_F20>,
<0x00FF90 KEY_VOLUMEUP>, <0x00FF98 KEY_VOLUMEDOWN>, <0x00FFD1 KEY_MUTE>,
//NEC Remote Control NO.2
<0x807F46 KEY_POWER>, <0x807F50 KEY_0>, <0x807F49 KEY_1>,
<0x807F55 KEY_2>, <0x807F59 KEY_3>, <0x807F4D KEY_4>,
<0x807F51 KEY_5>, <0x807F5D KEY_6>, <0x807F48 KEY_7>,
<0x807F54 KEY_8>, <0x807F58 KEY_9>, <0x807F47 KEY_RED>,
<0x807F4B KEY_GREEN>, <0x807F57 KEY_YELLOW>, <0x807F5B KEY_BLUE>,
<0x807F52 KEY_UP>, <0x807F13 KEY_DOWN>, <0x807F06 KEY_LEFT>,
<0x807F1A KEY_RIGHT>, <0x807F0F KEY_ENTER>, <0x807F1F KEY_CHANNELUP>,
<0x807F19 KEY_CHANNELDOWN>, <0x807F16 KEY_VOLUMEUP>, <0x807F15 KEY_VOLUMEDOWN>,
<0x807F03 KEY_PAGEUP>, <0x807F05 KEY_PAGEDOWN>, <0x807F17 KEY_HOME>,
<0x807F07 KEY_MENU>, <0x807F1B KEY_BACK>, <0x807F5A KEY_MUTE>,
<0x807F0D KEY_RECORD>, <0x807F42 KEY_HELP>, <0x807F14 KEY_INFO>,
<0x807F40 KEY_KP0>, <0x807F04 KEY_KP1>, <0x807F0E KEY_REWIND>,
<0x807F12 KEY_FORWARD>, <0x807F4C KEY_ZOOM>, <0x807F02 KEY_PREVIOUSSONG>,
<0x807F1E KEY_NEXTSONG>, <0x807F01 KEY_PLAY>, <0x807F1D KEY_PAUSE>,
<0x807F11 KEY_STOP>, <0x807F44 KEY_AUDIO>, <0x807F56 KEY_CAMERA>,
<0x807F5C KEY_CHANNEL>, <0x807F45 KEY_SLEEP>, <0x807F4A KEY_EPG>,
<0x807F10 KEY_LIST>, <0x807F53 KEY_SUBTITLE>, <0x807F41 KEY_FN_F1>,
<0x807F4E KEY_FN_F2>, <0x807F0A KEY_FN_F3>, <0x807F09 KEY_FN_F4>,
<0x807F1C KEY_FN_F5>, <0x807F08 KEY_FN_F6>, <0x807F0B KEY_F1>,
<0x807F18 KEY_F2>, <0x807F00 KEY_F3>, <0x807F0C KEY_F4>,
<0x807F4F KEY_F5>, <0x807F5E KEY_F6>, <0x807F43 KEY_F7>,
<0x807F5F KEY_F8>, <0x807FFE KEY_POWER2>, <0x807FFF KEY_OK>,
//RC5 Remote Control
<0x150C KEY_POWER>, <0x153F KEY_AUX>, <0x141D KEY_MEDIA_REPEAT>,
<0x141C KEY_SHUFFLE>, <0x100D KEY_MUTE>, <0x104F KEY_F4>,
<0x143F KEY_F1>, <0x112D KEY_F2>, <0x112E KEY_F3>,
<0x1010 KEY_VOLUMEUP>, <0x1011 KEY_VOLUMEDOWN>, <0x1521 KEY_PREVIOUSSONG>,
<0x1520 KEY_NEXTSONG>, <0x1536 KEY_PAUSE>, <0x1535 KEY_PLAY>,
<0x151F KEY_BACK>, <0x151E KEY_FORWARD>, <0x1063 KEY_
MAX>,
<0x1040 KEY_F6>, <0x1120 KEY_CHANNELUP>, <0x1121 KEY_CHANNELDOWN>;
status = "ok";
};
#endif
#if IS_ENABLED(CONFIG_USB_SUPPORT)
usb2phy1_utmi
: utmi@0x1f284200 {
compatible="syscon";
reg = <0x1f284200 0x200>;
reg-io-width = <2>;
};
usb2phy1_bc
: bc@0x1f284400 {
compatible="syscon";
reg = <0x1f284400 0x200>;
reg-io-width = <2>;
};
usb2phy1_usbc
: usbc@0x1f284600 {
compatible="syscon";
reg = <0x1f284600 0x200>;
reg-io-width = <2>;
};
usb2phy1_uhc
: uhc@0x1f284800 {
compatible="syscon";
reg = <0x1f284800 0x200>;
reg-io-width = <2>;
};
sstar_u2phy1
: u2phy1 {
compatible = "sstar, u2phy1";
syscon-utmi = <&usb2phy1_utmi>;
syscon-uhc = <&usb2phy1_uhc>;
syscon-usbc = <&usb2phy1_usbc>;
syscon-bc = <&usb2phy1_bc>;
//utmi_dp_dm_swap = <0>;
#phy-cells = <0>;
status = "okay";
};
#endif
#if IS_ENABLED(CONFIG_USB_EHCI_HCD)
sstar-ehci-1 {
compatible = "sstar-ehci-1";
reg-names = "ehc_base";
reg = <0x1f284800 0x200>;
syscon-utmi = <&usb2phy1_utmi>;
syscon-usbc = <&usb2phy1_usbc>;
syscon-bc = <&usb2phy1_bc>;
clocks = <&CLK_upll_960m>;
interrupts = <GIC_SPI INT_IRQ_UHC IRQ_TYPE_LEVEL_HIGH>;
phys = <&sstar_u2phy1>;
phy-names = "usb";
support_high_2g_access_patch;
//gpio_vbus_power = <PAD_GPIO8>;
status = "ok";
};
#endif
#if IS_ENABLED(CONFIG_USB_SUPPORT)
msb250x-udc-p0 {
compatible = "sstar,msb250x-udc";
reg = <0x1f284200 0x200>, <0x1f284600 0x200>, <0x1f284a00 0x400>, <0x1f203c00 0x200>;
reg-names = "utmi", "usb0", "otg", "chiptop";
interrupts = <GIC_SPI INT_IRQ_OTG IRQ_TYPE_LEVEL_HIGH>;
interrupt-names = "msb250x_udc_p0";
maximum-speed = "high-speed";
ep_name = "ep0", "ep1" , "ep2", "ep3", "ep4", "ep5", "ep6";
ep_
maxpkt_limit = <64>, <1024>, <1024>, <64>, <512>, <512>, <64>;
ep_fifo_size = <64>, <8192>, <1024>, <64>, <512>, <512>, <64>;
dma_channel_num = <7>;
clocks = <&CLK_upll_960m>;
status = "okay";
};
#endif
};
};
&clks {
#include "../../../../drivers/sstar/include/iford/reg_clks.h"
#if defined(CONFIG_SSTAR_DUALOS_DRIVER)
#include "iford-clks-dualos-lite.dtsi"
#else
#include "iford-clks.dtsi"
#endif
};
扫一扫
672
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
