1.背景概述

在一次主从复制架构中，由于主节点binlog损坏，导致从节点无法正常同步数据，只能重做从节点；因此使用MySQL 8.0.17开始提供的clone技术进行恢复，恢复后的2天都发生了主从报错数据冲突。

通过解析binlog发现，同一时刻主从节点都在执行同一条语句，因此询问业务是否在主从节点都执行了定时任务，业务回复定时任务只在主节点执行。

最后排查发现，克隆后的从节点的定时任务也会是开启的状态，因此同一时刻，主从节点同时执行定时任务，导致主从报错，最终将从节点的定时任务关闭后解决此问题。

2.问题复现

本次测试基于 GreatSQL 8.0.32-24

greatsql> SELECT VERSION();
+-----------+
| VERSION() |
+-----------+
| 8.0.32-24 |
+-----------+
1 row in set (0.00 sec)

1.搭建一套主从架构

略

2.创建event

greatsql> create database test;
greatsql> use test;
greatsql> CREATE TABLE `test` (
 `id` int(11) unsigned NOT NULL AUTO_INCREMENT COMMENT 'ID',
 `now` datetime DEFAULT NULL COMMENT '时间',
 PRIMARY KEY (`id`)
);

greatsql> CREATE EVENT event_test
ON SCHEDULE EVERY 1 MINUTE
ON COMPLETION PRESERVE
ENABLE
COMMENT '每隔1分钟向test表插入记录'
DO INSERT INTO test VALUES(NULL, now());

3.查看event状态

主节点，默认情况下event状态为 ENABLED

greatsql> show events;
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+---------+------------+----------------------+----------------------+--------------------+
| Db  | Name    | Definer | Time zone | Type    | Execute at | Interval value | Interval field | Starts        | Ends | Status  | Originator | character_set_client | collation_connection | Database Collation |
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+---------+------------+----------------------+----------------------+--------------------+
| test | event_test | root@%  | SYSTEM   | RECURRING | NULL    | 1        | MINUTE     | 2023-10-12 17:11:14 | NULL | ENABLED |      1 | utf8mb4        | utf8mb4_unicode_ci  | utf8mb4_unicode_ci |
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+---------+------------+----------------------+----------------------+--------------------+
1 row in set (0.00 sec)

从节点，默认情况下event状态为 SLAVESIDE_DISABLED

greatsql> show events;
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+--------------------+------------+----------------------+----------------------+--------------------+
| Db  | Name    | Definer | Time zone | Type    | Execute at | Interval value | Interval field | Starts        | Ends | Status       | Originator | character_set_client | collation_connection | Database Collation |
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+--------------------+------------+----------------------+----------------------+--------------------+
| test | event_test | root@%  | SYSTEM   | RECURRING | NULL    | 1        | MINUTE     | 2023-10-12 17:11:14 | NULL | SLAVESIDE_DISABLED |      1 | utf8mb4        | utf8mb4_unicode_ci  | utf8mb4_unicode_ci |
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+--------------------+------------+----------------------+----------------------+--------------------+
1 row in set (0.00 sec)

4.查看数据

greatsql> select * from test.test;
+----+---------------------+
| id | now                 |
+----+---------------------+
|  1 | 2023-08-08 16:00:39 |
|  2 | 2023-08-08 16:01:39 |
|  3 | 2023-08-08 16:02:39 |
+----+---------------------+
3 rows in set (0.00 sec)

5.从节点进行克隆

# 安装克隆插件，主从节点都需要

greatsql> install plugin clone soname 'mysql_clone.so';

# 从节点进行clone

greatsql> set global clone_valid_donor_list='172.17.137.162:6001';

greatsql> clone instance from root@'172.17.137.162':6001 identified by 'greatsql';

6.重新建立主从复制

greatsql> change master to master_user='root',master_password='greatsql',master_host='172.17.137.162',master_port=6001,master_auto_position=1;
Query OK, 0 rows affected, 7 warnings (0.04 sec)

greatsql> start slave;
Query OK, 0 rows affected, 1 warning (0.04 sec)

7.查看主从状态

greatsql> show slave status\G
*************************** 1. row ***************************
               Slave_IO_State: Waiting for source to send event
                  Master_Host: 172.17.137.162
                  Master_User: root
                  Master_Port: 6001
                Connect_Retry: 60
              Master_Log_File: binlog.000001
          Read_Master_Log_Pos: 2959
               Relay_Log_File: relaylog.000002
                Relay_Log_Pos: 395
        Relay_Master_Log_File: binlog.000001
             Slave_IO_Running: Yes
            Slave_SQL_Running: No
              Replicate_Do_DB:
          Replicate_Ignore_DB:
           Replicate_Do_Table:
       Replicate_Ignore_Table:
      Replicate_Wild_Do_Table:
  Replicate_Wild_Ignore_Table:
                   Last_Errno: 1062
                   Last_Error: Coordinator stopped because there were error(s) in the worker(s). The most recent failure being: Worker 1 failed executing transaction 'e8bf88f9-2acd-11ee-a98a-00163e605c74:8' at master log binlog.000001, end_log_pos 2606. See error log and/or performance_schema.replication_applier_status_by_worker table for more details about this failure or others, if any.
                 Skip_Counter: 0
          Exec_Master_Log_Pos: 2307
              Relay_Log_Space: 1242
              Until_Condition: None
               Until_Log_File:
greatsql> select * from performance_schema.replication_applier_status_by_worker limit 1\G
*************************** 1. row ***************************
                                           CHANNEL_NAME:
                                              WORKER_ID: 1
                                              THREAD_ID: NULL
                                          SERVICE_STATE: OFF
                                      LAST_ERROR_NUMBER: 1062
                                     LAST_ERROR_MESSAGE: Worker 1 failed executing transaction 'e8bf88f9-2acd-11ee-a98a-00163e605c74:8' at master log binlog.000001, end_log_pos 2606; Could not execute Write_rows event on table test.test; Duplicate entry '5' for key 'test.PRIMARY', Error_code: 1062; handler error HA_ERR_FOUND_DUPP_KEY; the event's master log FIRST, end_log_pos 2606
                                   LAST_ERROR_TIMESTAMP: 2023-08-08 16:03:39.033240
                               LAST_APPLIED_TRANSACTION:
     LAST_APPLIED_TRANSACTION_ORIGINAL_COMMIT_TIMESTAMP: 0000-00-00 00:00:00.000000
    LAST_APPLIED_TRANSACTION_IMMEDIATE_COMMIT_TIMESTAMP: 0000-00-00 00:00:00.000000
         LAST_APPLIED_TRANSACTION_START_APPLY_TIMESTAMP: 0000-00-00 00:00:00.000000
           LAST_APPLIED_TRANSACTION_END_APPLY_TIMESTAMP: 0000-00-00 00:00:00.000000
                                   APPLYING_TRANSACTION: e8bf88f9-2acd-11ee-a98a-00163e605c74:8
         APPLYING_TRANSACTION_ORIGINAL_COMMIT_TIMESTAMP: 2023-08-08 16:02:45.795753
        APPLYING_TRANSACTION_IMMEDIATE_COMMIT_TIMESTAMP: 2023-08-08 16:02:45.795753
             APPLYING_TRANSACTION_START_APPLY_TIMESTAMP: 2023-08-08 16:03:39.032510
                 LAST_APPLIED_TRANSACTION_RETRIES_COUNT: 0
   LAST_APPLIED_TRANSACTION_LAST_TRANSIENT_ERROR_NUMBER: 0
  LAST_APPLIED_TRANSACTION_LAST_TRANSIENT_ERROR_MESSAGE:
LAST_APPLIED_TRANSACTION_LAST_TRANSIENT_ERROR_TIMESTAMP: 0000-00-00 00:00:00.000000
                     APPLYING_TRANSACTION_RETRIES_COUNT: 0
       APPLYING_TRANSACTION_LAST_TRANSIENT_ERROR_NUMBER: 0
      APPLYING_TRANSACTION_LAST_TRANSIENT_ERROR_MESSAGE:
    APPLYING_TRANSACTION_LAST_TRANSIENT_ERROR_TIMESTAMP: 0000-00-00 00:00:00.000000
1 row in set (0.00 sec）

可以看到从节点报错发生了主键冲突。

8.查看从节点定时任务状态

当前从节点定时任务状态为 ENABLED

greatsql> show events;
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+---------+------------+----------------------+----------------------+--------------------+
| Db  | Name    | Definer | Time zone | Type    | Execute at | Interval value | Interval field | Starts        | Ends | Status  | Originator | character_set_client | collation_connection | Database Collation |
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+---------+------------+----------------------+----------------------+--------------------+
| test | event_test | root@%  | SYSTEM   | RECURRING | NULL    | 1        | MINUTE     | 2023-08-08 15:58:45 | NULL | ENABLED |      1 | utf8mb4        | utf8mb4_unicode_ci  | utf8mb4_unicode_ci |
+------+------------+---------+-----------+-----------+------------+----------------+----------------+---------------------+------+---------+------------+---------------------+----------------------+--------------------+
1 row in set (0.00 sec)

可以看到由于从节点的定时任务也执行了，从节点写入数据，导致主键冲突。

9.故障解决

greatsql> alter event event_test DISABLE;
Query OK, 0 rows affected (0.01 sec)

关闭从节点的定时任务event，然后跳过主键冲突的报错，最后重新启动主从复制。

3.总结

1.如果主库有定时任务，通过clone的方式搭建从库，在从库恢复之后需要关闭定时任务，避免主从同时执行定时任务导致主从故障。

2.克隆时，如果捐赠节点有主从复制信息，则克隆后的接收节点也会克隆此复制信息，并在克隆完成自动重启实例后，自动启动复制；避免此问题可以在接收节点的配置文件中增加 skip-slave-start，避免节点重启后自动启动复制。

Enjoy GreatSQL :)
