提及6600W高功率TVS二极管，电子工程师们更多想到的可能是DO-218AB封装SM8S系列汽车级瞬态抑制TVS二极管，关于SM8S系列TVS管这方面的知识，之前科普过好多次了。接下来，TVS保护管厂家东沃电子要科普的是另一款6600W的二极管6.6SMDJ系列。
东沃电子推出的TVS二极管6.6SMDJ系列，封装SMC、功率6600W、工作电压17V到85V、钳位电压27.6V到137V、峰值脉冲电流48.2A到239.1A，型号齐全。查看东沃电子“TVS-6.6SMDJ Series Datasheet”产品手册可知：
TVS二极管6.6SMDJ系列特性
√ 6600W peak pulsepower capability at 10 x 1000μs waveform, repetition rate (duty cycle): 0.01%
√ Glass Passivated chip junction
√ For surface mounted applications to optimize board space
√ Low profile package
√ Built-in strain relief
√ Low incremental surge resistance
√ Excellent clamping capability
√ Plastic package has UL flammability classification 94V-O
√ Fast response time: typically less than 1.0ps from 0 Volts to BV min
√ Typical IR less than
