unsigned int outWidth = (unsigned int)(max(fabs(tranX4 - tranX1), fabs(tranX3 - tranX2)) + 1.5);
unsigned int outHeight = (unsigned int)(max(fabs(tranY4 - tranY1), fabs(tranY3 - tranY2)) + 1.5);

QImage* newImage = new QImage(outWidth,outHeight,QImage::Format_ARGB32);

double num1 = -0.5 * outWidth * fCos - 0.5 * outHeight * fSin + 0.5 * image->width();
double num2 =  0.5 * outWidth * fSin - 0.5 * outHeight * fCos + 0.5 * image->height();

unsigned char* copyPixel = NULL;
unsigned char* objPixel = NULL;
int x = 0;
int y = 0;

for(long j = 0; j < (long)outHeight; j++)
{
    for(long i = 0; i <(long)outWidth; i++)
    {
        x = (int)(i * fCos + j * fSin + num1 + 0.5);
        y = (int)(-i * fSin + j * fCos + num2 + 0.5);

        if(x == image->width())
        {
            x--;
        }
        if(y == image->height())
        {
            y--;
        }
        copyPixel = image->bits() + y * image->width() * 4  + x * 4;
        objPixel = newImage->bits() + j * outWidth * 4 + i * 4;

        if(x >= 0 && x < image->width() && y >=0 && y < image->height())
        {
            memcpy(objPixel, copyPixel, 4);
        }
    }
}
return newImage;

}

/图像的旋转函数（双线性插值法） angle为旋转度数，以弧度表示/
QImage* MainWindow::RotateInterpolation(QImage* image,double angle)
{
int srcX1, srcX2, srcX3, srcX4;
int srcY1, srcY2, srcY3, srcY4;

srcX1 = 0;
srcY1 = 0;
srcX2 = image->width() - 1;
srcY2 = 0;
srcX3 = 0;
srcY3 = image->height() - 1;
srcX4 = image->width() - 1;
srcY4 = image->height() - 1;

double fSin = sin(angle);
double fCos = cos(angle);

double tranX1, tranX2, tranX3, tranX4;
double tranY1, tranY2, tranY3, tranY4;

tranX1 = fCos * srcX1 + fSin * srcY1;
tranY1 = -fSin * srcX1 + fCos * srcY1;
tranX2 = fCos * srcX2 + fSin * srcY2;
tranY2 = -fSin * srcX2 + fCos * srcY2;
tranX3 = fCos * srcX3 + fSin * srcY3;
tranY3 = -fSin * srcX3 + fCos * srcY3;
tranX4 = fCos * srcX4 + fSin * srcY4;
tranY4 = -fSin * srcX4 + fCos * srcY4;

long outWidth = (unsigned int)(max(fabs(tranX4 - tranX1), fabs(tranX3 - tranX2)) + 1.5);
long outHeight = (unsigned int)(max(fabs(tranY4 - tranY1), fabs(tranY3 - tranY2)) + 1.5);

QImage* newImage = new QImage(outWidth,outHeight,QImage::Format_ARGB32);

double num1 = -0.5 * outWidth * fCos - 0.5 * outHeight * fSin + 0.5 * image->width();
double num2 =  0.5 * outWidth * fSin - 0.5 * outHeight * fCos + 0.5 * image->height();

double x = 0.0;
double  y = 0.0;

int r,g,b;
for (long  j = 0; j < outHeight; j++)
{

    for(long i =0; i < outWidth; i++)
    {
        x = (i * fCos + j * fSin + num1 + 0.5);
        y = (-i * fSin + j * fCos + num2 + 0.5);


        if (x > image->width() || x < 0 || y > image->height() || y < 0)
            continue;
        int x1, x2, y1, y2;
        x1= ( int)x;
        x2 = x1 + 1;
        y1 = ( int)y;
        y2 = y1 + 1;

        QColor oldcolor1;
        QColor oldcolor2;
        QColor oldcolor3;
        QColor oldcolor4;
        double u, v;
        u = x - x1;
        v = y - y1;
        if ((x >= image->width() - 1 ) && (y >= image->height() - 1 ))
        {
        oldcolor1 = QColor(image->pixel(x1,y1));
        r = oldcolor1.red();
        g = oldcolor1.green();
        b = oldcolor1.blue();
        }
        else if (x >= image->width() - 1)
        {
            oldcolor1 = QColor(image->pixel(x1,y1));
            oldcolor3 = QColor(image->pixel(x1,y2));
            r = oldcolor1.red() * (1 - v) + oldcolor3.red() * v;
            g = oldcolor1.green() * (1 - v) + oldcolor3.green() * v;
            b = oldcolor1.blue() * (1 - v) + oldcolor3.blue() * v;
        }
        else if (x > image->height() - 1)
        {
            oldcolor1 = QColor(image->pixel(x1,y1));
            oldcolor2 = QColor(image->pixel(x2,y1));
            r = oldcolor1.red() * (1 - u) + oldcolor2.red() * u;
            g = oldcolor1.green() * (1 - u) + oldcolor2.green() * u;
            b = oldcolor1.blue() * (1 - u) + oldcolor2.blue() * u;
        }
        else
        {
            oldcolor1 = QColor(image->pixel(x1,y1));
            oldcolor2 = QColor(image->pixel(x2,y1));
            oldcolor3 = QColor(image->pixel(x1,y2));
            oldcolor4 = QColor(image->pixel(x2,y2));
            int r1,g1,b1;
            r = oldcolor1.red() * (1 - u) + oldcolor2.red() * u;
            g = oldcolor1.green() * (1 - u) + oldcolor2.green() * u;
            b = oldcolor1.blue() * (1 - u) + oldcolor2.blue() * u;

            r1 = oldcolor3.red() * (1 - u) + oldcolor4.red() * u;
            g1 = oldcolor3.green() * (1 - u) + oldcolor4.green() * u;
            b1 = oldcolor3.blue() * (1 - u) + oldcolor4.blue() * u;

            r = r * (1 - v) + r1 * v;
            g = g * (1 - v) + g1 * v;
            b = b * (1 - v) + b1 * v;
        }

      newImage->setPixel(i, j, qRgb(r, g, b));
    }
}
return newImage;

}
