class reg_agent;//包含了monitor，driver，让driver，monitor工作起来
local string name;
reg_driver driver;
reg_monitor monitor;
local virtual reg_intf vif;
function new(string name = “reg_agent”);
this.name = name;
this.driver = new({name, “.driver”});
this.monitor = new({name, “.monitor”});
endfunction
function void set\_interface(virtual reg_intf vif);
this.vif = vif;
driver.set\_interface(vif);
monitor.set\_interface(vif);
endfunction
task run();
fork
driver.run();
monitor.run();
join
endtask
endclass
激励的类型、发送激励、产生激励、检测激励、agent
## 2. fmt\_apk
chnl和reg的driver都是主动的发送数据给dut，而fmt的driver是被动的接受发送出来的数据。所以fmt像一个fifo，储存发送出来的数据。
需要设计fifo的大小宽度，来储存发送出来的数据。
package fmt_pkg;
import rpt_pkg:😗;
//传出来的数据可能有不同的带宽、需要的fifo大小也不同，把可能需要的都枚举出来。
typedef enum {SHORT_FIFO, MED_FIFO, LONG_FIFO, ULTRA_FIFO} fmt_fifo_t;
typedef enum {LOW_WIDTH, MED_WIDTH, HIGH_WIDTH, ULTRA_WIDTH} fmt_bandwidth_t;
### 2.1 fmt\_trans
class fmt_trans;
rand fmt_fifo_t fifo;
rand fmt_bandwidth_t bandwidth;
bit [9:0] length;
bit [31:0] data[];
bit [1:0] ch_id;
bit rsp;
constraint cstr{
soft fifo == MED_FIFO;//fifo
soft bandwidth == MED_WIDTH;//带宽
};
function fmt_trans clone();
fmt_trans c = new();
c.fifo = this.fifo;
c.bandwidth = this.bandwidth;
c.length = this.length;
c.data = this.data;
c.ch_id = this.ch_id;
c.rsp = this.rsp;
return c;
endfunction
function string sprint();
string s;
s = {s, $sformatf("=======================================\n")};
s = {s, $sformatf("fmt\_trans object content is as below: \n")};
s = {s, $sformatf("fifo = %s: \n", this.fifo)};
s = {s, $sformatf("bandwidth = %s: \n", this.bandwidth)};
s = {s, $sformatf("length = %s: \n", this.length)};
foreach(data[i]) s = {s, $sformatf("data[%0d] = %8x \n", i, this.data[i])};
s = {s, $sformatf("ch\_id = %0d: \n", this.ch_id)};
s = {s, $sformatf("rsp = %0d: \n", this.rsp)};
s = {s, $sformatf("=======================================\n")};
return s;
endfunction
function bit compare(fmt_trans t);//当前的与传进来的数作比较
string s;
compare = 1;
s = "\n=======================================\n";
s = {s, $sformatf("COMPARING fmt\_trans object at time %0d \n", $time)};
if(this.length != t.length) begin
compare = 0;
s = {s, $sformatf("sobj length %0d != tobj length %0d \n", this.length, t.length)};
end
if(this.ch_id != t.ch_id) begin
compare = 0;
s = {s, $sformatf("sobj ch\_id %0d != tobj ch\_id %0d\n", this.ch_id, t.ch_id)};
end
foreach(this.data[i]) begin
if(this.data[i] != t.data[i]) begin
compare = 0;
s = {s, $sformatf("sobj data[%0d] %8x != tobj data[%0d] %8x\n", i, this.data[i], i, t.data[i])};
end
end
if(compare == 1) s = {s, "COMPARED SUCCESS!\n"};
else s = {s, "COMPARED FAILURE!\n"};
s = {s, "=======================================\n"};
rpt_pkg::rpt\_msg("[CMPOBJ]", s, rpt_pkg::INFO, rpt_pkg::MEDIUM);
endfunction
endclass
### 2.2 fmt\_driver
class fmt_driver;
local string name;
local virtual fmt_intf intf;
mailbox #(fmt_trans) req_mb;
mailbox #(fmt_trans) rsp_mb;
local mailbox #(bit[31:0]) fifo;
local int fifo_bound;//长度
local int data_consum_peroid;//消耗周期，侧面反应带宽，带宽越大，消耗周期越短
function new(string name = "fmt\_driver");
this.name = name;
this.fifo = new();//fifo初始化
this.fifo_bound = 4096;
this.data_consum_peroid = 1;
endfunction
function void set\_interface(virtual fmt_intf intf);
if(intf == null)
$error("interface handle is NULL, please check if target interface has been intantiated");
else
this.intf = intf;
endfunction
task run();
fork
this.do\_receive();
this.do\_consume();
this.do\_config();
this.do\_reset();
join
endtask
//配置fifo长或者短，消耗数据快还是慢
task do_config();//配置driver，配置完成后重新例化fifo
fmt_trans req, rsp;
forever begin
this.req_mb.get(req);
case(req.fifo)//配置为不同长度
SHORT_FIFO: this.fifo_bound = 64;
MED_FIFO: this.fifo_bound = 256;
LONG_FIFO: this.fifo_bound = 512;
ULTRA_FIFO: this.fifo_bound = 2048;
endcase
this.fifo = new(this.fifo_bound);//重新例化，并且规定长度
case(req.bandwidth)
LOW_WIDTH: this.data_consum_peroid = 8;
MED_WIDTH: this.data_consum_peroid = 4;
HIGH_WIDTH: this.data_consum_peroid = 2;
ULTRA_WIDTH: this.data_consum_peroid = 1;
endcase
rsp = req.clone();
rsp.rsp = 1;
this.rsp_mb.put(rsp);
end
endtask
task do\_reset();
forever begin
@(negedge intf.rstn)
intf.fmt_grant <= 0;
end
endtask
task do\_receive();//模拟从formater接受数据
forever begin
@(posedge intf.fmt_req);//fmt的req拉高
forever begin
@(posedge intf.clk);//等待一拍
if((this.fifo_bound-this.fifo.num()) >= intf.fmt_length)//fifo最大容量-已经存放了多少>=即将存放的数据长度
break;
end
intf.drv_ck.fmt_grant <= 1;//可以存放数据，让grant为1
@(posedge intf.fmt_start);
fork
begin
@(posedge intf.clk);
intf.drv_ck.fmt_grant <= 0;//过一拍置0
end
join_none
repeat(intf.fmt_length) begin//把传进来的数据在每一拍做采样，重复采样length次。
@(negedge intf.clk);
this.fifo.put(intf.fmt_data);
end
end
endtask
task do\_consume();//不断的消耗数据，每过一拍拿一组数据
bit[31:0] data;
forever begin
void'(this.fifo.try\_get(data));
repeat($urandom\_range(1, this.data_consum_peroid)) @(posedge intf.clk);
end
endtask
endclass
### 2.3 fmt\_generator
class fmt_generator;
rand fmt_fifo_t fifo = MED_FIFO;
rand fmt_bandwidth_t bandwidth = MED_WIDTH;
mailbox #(fmt_trans) req_mb;
mailbox #(fmt_trans) rsp_mb;
constraint cstr{
soft fifo == MED_FIFO;
soft bandwidth == MED_WIDTH;
}
function new();
this.req_mb = new();
this.rsp_mb = new();
endfunction
task start();
send\_trans();
endtask
// generate transaction and put into local mailbox
task send\_trans();
fmt_trans req, rsp;
req = new();
assert(req.randomize with {local::fifo != MED_FIFO -> fifo == local::fifo;
local::bandwidth != MED_WIDTH -> bandwidth == local::bandwidth;
})
else $fatal("[RNDFAIL] formatter packet randomization failure!");
$display(req.sprint());
this.req_mb.put(req);
this.rsp_mb.get(rsp);
$display(rsp.sprint());
assert(rsp.rsp)
else $error("[RSPERR] %0t error response received!", $time);
endtask
function string sprint();
string s;
s = {s, $sformatf("=======================================\n")};
s = {s, $sformatf("fmt\_generator object content is as below: \n")};
s = {s, $sformatf("fifo = %s: \n", this.fifo)};
s = {s, $sformatf("bandwidth = %s: \n", this.bandwidth)};
s = {s, $sformatf("=======================================\n")};
return s;
endfunction
function void post\_randomize();
string s;
s = {"AFTER RANDOMIZATION \n", this.sprint()};
$display(s);
endfunction
endclass
### 2.4 fmt\_monitor
class fmt_monitor;
local string name;
local virtual fmt_intf intf;
mailbox #(fmt_trans) mon_mb;
function new(string name=“fmt_monitor”);
this.name = name;
endfunction
function void set_interface(virtual fmt_intf intf);
if(intf == null)
$error(“interface handle is NULL, please check if target interface has been intantiated”);
else
this.intf = intf;
endfunction
task run();
this.mon\_trans();
endtask
task mon\_trans();
fmt_trans m;
string s;
forever begin
@(posedge intf.mon_ck.fmt_start);//假定协议是正常的
m = new();
m.length = intf.mon_ck.fmt_length;
m.ch_id = intf.mon_ck.fmt_chid;
m.data = new[m.length];
foreach(m.data[i]) begin
@(posedge intf.clk);
m.data[i] = intf.mon_ck.fmt_data;//每一次数据来的时候，都存放在动态数组
end
mon_mb.put(m);//放好数据后，放入信箱
s = $sformatf("=======================================\n");
s = {s, $sformatf("%0t %s monitored a packet: \n", $time, this.name)};
s = {s, $sformatf("length = %0d: \n", m.length)};
s = {s, $sformatf("chid = %0d: \n", m.ch_id)};
foreach(m.data[i]) s = {s, $sformatf("data[%0d] = %8x \n", i, m.data[i])};
s = {s, $sformatf("=======================================\n")};
$display(s);
end
endtask
endclass
### 2.5 fmt\_agent
class fmt_agent;
local string name;
fmt_driver driver;
fmt_monitor monitor;
local virtual fmt_intf vif;
function new(string name = “fmt_agent”);
this.name = name;
this.driver = new({name, “.driver”});
this.monitor = new({name, “.monitor”});
endfunction
function void set\_interface(virtual fmt_intf vif);
this.vif = vif;
driver.set\_interface(vif);
monitor.set\_interface(vif);
endfunction
task run();
fork
driver.run();
monitor.run();
join
endtask
endclass
endpackage
## 3. checker
* 检测到的数据传到checker，3个chnl、fmt、reg的数据都会存放在checke已经例化好的信箱里。而fmt和3个chnl的数据格式是完全不同的。fmt对数据进行了打包，把数据整合成了新格式。
* 所以比较输入输出先要把chnl、reg的数据需要先整形转化，模拟mcdf的行为。模拟打包后再进行数据的比较。
* refmod利用句柄把数据拿出来，模拟硬件对数据打包。从chnl拿数据，按照长度的不同把数据放入三个输出端。
其中：
* doreset对寄存器复位，清空信箱中的数据。
* doregupdate更新checker中寄存器的配置。
* dopackage对三个chnl做打包。
包含了checker、env和test。
`include “param_def.v”
package mcdf_pkg;
import chnl_pkg:😗;
import reg_pkg:😗;
import arb_pkg:😗;
import fmt_pkg:😗;
import rpt_pkg:😗;
typedef struct packed {
bit[2:0] len; //长度
bit[1:0] prio;//
bit en;//fifo使能
bit[7:0] avail;//表示fifo可选余量
} mcdf_reg_t;
typedef enum {RW_LEN, RW_PRIO, RW_EN, RD_AVAIL} mcdf_field_t;
### 3.1 mcdf\_refmod
模拟mcdf的功能接受寄存器的读写行为，对检测来的数据进行打包。
class mcdf_refmod;//模拟mcdf的功能接受寄存器的读写行为，对数据进行打包
local virtual mcdf_intf intf;
local string name;
mcdf_reg_t regs[3];
mailbox #(reg_trans) reg_mb;
mailbox #(mon_data_t) in_mbs[3];
mailbox #(fmt_trans) out_mbs[3];
function new(string name="mcdf\_refmod");
this.name = name;
foreach(this.out_mbs[i]) this.out_mbs[i] = new();
endfunction
task run();
fork
do\_reset();
this.do\_reg\_update();//模拟寄存器
do\_packet(0);
do\_packet(1);
do\_packet(2);
join
endtask
task do\_reg\_update();//硬件上对寄存器的读写更新到仿真中
reg_trans t;//引用regtrans里的数据
forever begin
this.reg_mb.get(t);
if(t.addr[7:4] == 0 && t.cmd == `WRITE) begin
this.regs[t.addr[3:2]].en = t.data[0];
this.regs[t.addr[3:2]].prio = t.data[2:1];
this.regs[t.addr[3:2]].len = t.data[5:3];
end
else if(t.addr[7:4] == 1 && t.cmd == `READ) begin
this.regs[t.addr[3:2]].avail = t.data[7:0];
end
end
endtask
task do\_packet(int id);//把chnl的数据打包
fmt_trans ot;
mon_data_t it;
forever begin
this.in_mbs[id].peek(it);
ot = new();
ot.length = 4 << (this.get\_field\_value(id, RW_LEN) & 'b11);//拿到打包的长度
ot.data = new[ot.length];//开辟空间
ot.ch_id = id;
foreach(ot.data[m]) begin//拿完数据，把ot放到对应的信箱。
this.in_mbs[id].get(it);
ot.data[m] = it.data;
end
this.out_mbs[id].put(ot);
end
endtask
function int get\_field\_value(int id, mcdf_field_t f);
case(f)
RW_LEN: return regs[id].len;
RW_PRIO: return regs[id].prio;
RW_EN: return regs[id].en;
RD_AVAIL: return regs[id].avail;
endcase
endfunction
task do\_reset();//寄存器复位
forever begin
@(negedge intf.rstn);
foreach(regs[i]) begin
regs[i].len = 'h0;
regs[i].prio = 'h3;
regs[i].en = 'h1;
regs[i].avail = 'h20;
end
end
endtask
function void set\_interface(virtual mcdf_intf intf);
if(intf == null)
$error("interface handle is NULL, please check if target interface has been intantiated");
else
this.intf = intf;
endfunction
endclass
3.2 mcdf_checker
class mcdf_checker;
local string name;
local int err_count;
local int total_count;
local int chnl_count[3];
local virtual mcdf_intf intf;
local mcdf_refmod refmod;
mailbox #(mon_data_t) chnl_mbs[3];
mailbox #(fmt_trans) fmt_mb;
mailbox #(reg_trans) reg_mb;
mailbox #(fmt_trans) exp_mbs[3];
function new(string name="mcdf\_checker");
this.name = name;
foreach(this.chnl_mbs[i]) this.chnl_mbs[i] = new();
this.fmt_mb = new();
this.reg_mb = new();
this.refmod = new();
foreach(this.refmod.in_mbs[i]) begin
this.refmod.in_mbs[i] = this.chnl_mbs[i];
this.exp_mbs[i] = this.refmod.out_mbs[i];
end
this.refmod.reg_mb = this.reg_mb;
this.err_count = 0;
this.total_count = 0;
foreach(this.chnl_count[i]) this.chnl_count[i] = 0;
endfunction
function void set\_interface(virtual mcdf_intf intf);
if(intf == null)
$error("interface handle is NULL, please check if target interface has been intantiated");
else
this.intf = intf;
this.refmod.set\_interface(intf);
endfunction
task run();
fork
this.do\_compare();
this.refmod.run();
join
endtask
task do\_compare();
fmt_trans expt, mont;
bit cmp;
forever begin
this.fmt_mb.get(mont);
this.exp_mbs[mont.ch_id].get(expt);
cmp = mont.compare(expt);
this.total_count++;
this.chnl_count[mont.ch_id]++;
if(cmp == 0) begin
this.err_count++;
rpt_pkg::rpt\_msg("[CMPFAIL]",
$sformatf("%0t %0dth times comparing but failed! MCDF monitored output packet is different with reference model output", $time, this.total_count),
rpt_pkg::ERROR,
rpt_pkg::TOP,
rpt_pkg::LOG);
end
else begin
rpt_pkg::rpt\_msg("[CMPSUCD]",
$sformatf("%0t %0dth times comparing and succeeded! MCDF monitored output packet is the same with reference model output", $time, this.total_count),
rpt_pkg::INFO,
rpt_pkg::HIGH);
end
end
endtask
function void do\_report();
string s;
s = "\n---------------------------------------------------------------\n";
s = {s, "CHECKER SUMMARY \n"};
s = {s, $sformatf("total comparison count: %0d \n", this.total_count)};
foreach(this.chnl_count[i]) s = {s, $sformatf(" channel[%0d] comparison count: %0d \n", i, this.chnl_count[i])};
s = {s, $sformatf("total error count: %0d \n", this.err_count)};
foreach(this.chnl_mbs[i]) begin
if(this.chnl_mbs[i].num() != 0)
s = {s, $sformatf("WARNING:: chnl\_mbs[%0d] is not empty! size = %0d \n", i, this.chnl_mbs[i].num())};
end
if(this.fmt_mb.num() != 0)
s = {s, $sformatf("WARNING:: fmt\_mb is not empty! size = %0d \n", this.fmt_mb.num())};
s = {s, "---------------------------------------------------------------\n"};
rpt_pkg::rpt\_msg($sformatf("[%s]",this.name), s, rpt_pkg::INFO, rpt_pkg::TOP);
endfunction
endclass
3.2 mcdf_env
class mcdf_env;
chnl_agent chnl_agts[3];
reg_agent reg_agt;
fmt_agent fmt_agt;
mcdf_checker chker;
protected string name;
function new(string name = "mcdf\_env");//做例化和连接
this.name = name;
this.chker = new();
foreach(chnl_agts[i]) begin
this.chnl_agts[i] = new($sformatf("chnl\_agts[%0d]",i));
this.chnl_agts[i].monitor.mon_mb = this.chker.chnl_mbs[i];
end
this.reg_agt = new("reg\_agt");
this.reg_agt.monitor.mon_mb = this.chker.reg_mb;
this.fmt_agt = new("fmt\_agt");
this.fmt_agt.monitor.mon_mb = this.chker.fmt_mb;
$display("%s instantiated and connected objects", this.name);
endfunction
virtual task run();
$display($sformatf("\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*%s started\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*\*", this.name));
this.do\_config();
fork
this.chnl_agts[0].run();
this.chnl_agts[1].run();
this.chnl_agts[2].run();
this.reg_agt.run();
this.fmt_agt.run();
this.chker.run();
join
endtask
virtual function void do\_config();
endfunction
virtual function void do\_report();
this.chker.do\_report();
endfunction
endclass
3.3 test
class mcdf_base_test;
chnl_generator chnl_gens[3];
reg_generator reg_gen;
fmt_generator fmt_gen;
mcdf_env env;
protected string name;
function new(string name = "mcdf\_base\_test");
this.name = name;
this.env = new("env");
foreach(this.chnl_gens[i]) begin
this.chnl_gens[i] = new();
this.env.chnl_agts[i].driver.req_mb = this.chnl_gens[i].req_mb;
this.env.chnl_agts[i].driver.rsp_mb = this.chnl_gens[i].rsp_mb;
end
this.reg_gen = new();
this.env.reg_agt.driver.req_mb = this.reg_gen.req_mb;
this.env.reg_agt.driver.rsp_mb = this.reg_gen.rsp_mb;
this.fmt_gen = new();
this.env.fmt_agt.driver.req_mb = this.fmt_gen.req_mb;
this.env.fmt_agt.driver.rsp_mb = this.fmt_gen.rsp_mb;
rpt_pkg::logname = {this.name, "\_check.log"};
rpt_pkg::clean\_log();
$display("%s instantiated and connected objects", this.name);
endfunction
virtual task run();
fork
env.run();
join_none
rpt_pkg::rpt\_msg("[TEST]",
$sformatf("=====================%s AT TIME %0t STARTED=====================", this.name, $time),
rpt_pkg::INFO,
rpt_pkg::HIGH);
this.do\_reg();
this.do\_formatter();//先配置fmt的fifo
this.do\_data();
rpt_pkg::rpt\_msg("[TEST]",
$sformatf("=====================%s AT TIME %0t FINISHED=====================", this.name, $time),
rpt_pkg::INFO,
rpt_pkg::HIGH);
this.do\_report();
$finish();
endtask
// do register configuration
virtual task do\_reg();
endtask
// do external formatter down stream slave configuration
virtual task do\_formatter();
endtask
// do data transition from 3 channel slaves
virtual task do\_data();
endtask
// do simulation summary
virtual function void do\_report();
this.env.do\_report();
rpt_pkg::do\_report();
endfunction
virtual function void set\_interface(virtual chnl_intf ch0_vif
,virtual chnl_intf ch1_vif
,virtual chnl_intf ch2_vif
,virtual reg_intf reg_vif
,virtual fmt_intf fmt_vif
,virtual mcdf_intf mcdf_vif
);
this.env.chnl_agts[0].set\_interface(ch0_vif);
this.env.chnl_agts[1].set\_interface(ch1_vif);
this.env.chnl_agts[2].set\_interface(ch2_vif);
this.env.reg_agt.set\_interface(reg_vif);
this.env.fmt_agt.set\_interface(fmt_vif);
this.env.chker.set\_interface(mcdf_vif);
endfunction
virtual function bit diff\_value(int val1, int val2, string id = "value\_compare");
if(val1 != val2) begin
rpt_pkg::rpt\_msg("[CMPERR]",
$sformatf("ERROR! %s val1 %8x != val2 %8x", id, val1, val2),
rpt_pkg::ERROR,
rpt_pkg::TOP);
return 0;
end
else begin
rpt_pkg::rpt\_msg("[CMPSUC]",
$sformatf("SUCCESS! %s val1 %8x == val2 %8x", id, val1, val2),
rpt_pkg::INFO,
rpt_pkg::HIGH);
return 1;
end
endfunction
virtual task idle\_reg();
void'(reg_gen.randomize() with {cmd == `IDLE; addr == 0; data == 0;});
reg_gen.start();
endtask
virtual task write\_reg(bit[7:0] addr, bit[31:0] data);
void'(reg_gen.randomize() with {cmd == `WRITE; addr == local::addr; data == local::data;});
reg_gen.start();
endtask
virtual task read\_reg(bit[7:0] addr, output bit[31:0] data);
void'(reg_gen.randomize() with {cmd == `READ; addr == local::addr;});
reg_gen.start();
data = reg_gen.data;
endtask
endclass
3.5 子类test
3.51 完整性测试
class mcdf_data_consistence_basic_test extends mcdf_base_test;
function new(string name = "mcdf\_data\_consistence\_basic\_test");
super.new(name);
endfunction
task do\_reg();
bit[31:0] wr_val, rd_val;
//寄存器规定了第三位为1、2、3时对应8、16、32。
// slv0 with len=8, prio=0, en=1
wr_val = (1<<3)+(0<<1)+1;
this.write\_reg(`SLV0_RW_ADDR, wr_val); // 把值写进去
this.read\_reg(`SLV0_RW_ADDR, rd_val);//再把写进去的值读回来
void'(this.diff\_value(wr_val, rd_val, "SLV0\_WR\_REG"));//作比较
// slv1 with len=16, prio=1, en=1
wr_val = (2<<3)+(1<<1)+1;
this.write\_reg(`SLV1_RW_ADDR, wr_val);
this.read\_reg(`SLV1_RW_ADDR, rd_val);
void'(this.diff\_value(wr_val, rd_val, "SLV1\_WR\_REG"));
// slv2 with len=32, prio=2, en=1
wr_val = (3<<3)+(2<<1)+1;
this.write\_reg(`SLV2_RW_ADDR, wr_val);
this.read\_reg(`SLV2_RW_ADDR, rd_val);
void'(this.diff\_value(wr_val, rd_val, "SLV2\_WR\_REG"));
// send IDLE command
this.idle\_reg();
endtask
task do\_formatter(); //定义了fmt的fifo为LONG\_FIFO， HIGH\_WIDTH
void'(fmt_gen.randomize() with {fifo == LONG_FIFO; bandwidth == HIGH_WIDTH;});
fmt_gen.start();
endtask
task do\_data();//发送数据
void'(chnl_gens[0].randomize() with {ntrans==100; ch_id==0; data_nidles==0; pkt_nidles==1; data_size==8; });
void'(chnl_gens[1].randomize() with {ntrans==100; ch_id==1; data_nidles==1; pkt_nidles==4; data_size==16;});
void'(chnl_gens[2].randomize() with {ntrans==100; ch_id==2; data_nidles==2; pkt_nidles==8; data_size==32;});
fork
chnl_gens[0].start();
chnl_gens[1].start();
chnl_gens[2].start();
**既有适合小白学习的零基础资料，也有适合3年以上经验的小伙伴深入学习提升的进阶课程，涵盖了95%以上Go语言开发知识点，真正体系化！**
**由于文件比较多，这里只是将部分目录截图出来，全套包含大厂面经、学习笔记、源码讲义、实战项目、大纲路线、讲解视频，并且后续会持续更新**
**[如果你需要这些资料，可以戳这里获取](https://bbs.youkuaiyun.com/topics/618658159)**
endtask
task do\_data();//发送数据
void'(chnl_gens[0].randomize() with {ntrans==100; ch_id==0; data_nidles==0; pkt_nidles==1; data_size==8; });
void'(chnl_gens[1].randomize() with {ntrans==100; ch_id==1; data_nidles==1; pkt_nidles==4; data_size==16;});
void'(chnl_gens[2].randomize() with {ntrans==100; ch_id==2; data_nidles==2; pkt_nidles==8; data_size==32;});
fork
chnl_gens[0].start();
chnl_gens[1].start();
chnl_gens[2].start();
[外链图片转存中...(img-3Ca5sNAj-1715906401075)]
[外链图片转存中...(img-ZE3DNtOl-1715906401075)]
[外链图片转存中...(img-jnPHjmYV-1715906401075)]
**既有适合小白学习的零基础资料，也有适合3年以上经验的小伙伴深入学习提升的进阶课程，涵盖了95%以上Go语言开发知识点，真正体系化！**
**由于文件比较多，这里只是将部分目录截图出来，全套包含大厂面经、学习笔记、源码讲义、实战项目、大纲路线、讲解视频，并且后续会持续更新**
**[如果你需要这些资料，可以戳这里获取](https://bbs.youkuaiyun.com/topics/618658159)**
扫一扫
432
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
