使用goldengate 迁移Oracle到postgresql

 环境：

--源端：

IP：10.0.4.16

hostname：tencent

Oracle数据库版本：12.2.0.1.0

ogg for oracle版本：19.1.0.0.4

SID：orcl

--目标端：

IP：10.0.4.16

hostname：tencent

postgresql数据库版本：14.6

ogg for postgresql版本：21.3.0.0.0

db:ogg

2、安装和配置OGG软件（源端），以下操作都是在源端操作

2.1创建安装目录

mkdir -p /oracle/ogg

2.2设置oracle环境变量

export ORACLE_BASE=/oracle/app/oracle

export ORACLE_HOME=$ORACLE_BASE/product/12.2.0/db_1

export PATH=$ORACLE_HOME/bin:/oracle/ogg:$PATH

export OGGHOME=/oracle/ogg

export ORACLE_SID=orcl

export LD_LIBRARY_PATH=$ORACLE_HOME/lib:$OGGHOME:$LD_LIBRARY_PATH

export TNS_ADMIN=$ORACLE_HOME/network/admin

2.3建立OGG表空间和用户

create tablespace oggtbs datafile '/oradata/orcl/oggtbs.dbf' size 200M autoextend on;

create user ogg identified by ogg default tablespace ogg;

grant connect, resource TO ogg;

grant select any dictionary, select any table TO ogg;

grant flashback any table TO ogg;

grant execute on dbms_flashback TO ogg;

grant ALTER ANY TABLE to ogg;

grant insert any table to ogg;

grant update any table to ogg;

grant delete any table to ogg;

grant create table,create sequence to ogg;

grant execute on utl_file to ogg;

grant dba to ogg;

alter system set enable_goldengate_replication=true;

2.4添加附加日志和force logging，并切换日志

如果源端不开启归档，需添加多组日志。

alter database force logging;

alter database add SUPPLEMENTAL log data;

SQL>select NAME,OPEN_MODE,FORCE_LOGGING,SUPPLEMENTAL_LOG_DATA_MIN from v$database;

NAME OPEN_MODE FORCE_LOGGING SUPPLEME

---

ORCL READ WRITE YES YES

2.5 创建OGG的管理工作目录

在配置OGG进程之前，首先需要创建OGG的管理目录，执行以下操作：

GGSCI (tencent) 3> create subdirs

Creating subdirectories under current directory /oracle/ogg

Parameter file /oracle/ogg/dirprm: created.

Report file /oracle/ogg/dirrpt: created.

Checkpoint file /oracle/ogg/dirchk: created.

Process status files /oracle/ogg/dirpcs: created.

SQL script files /oracle/ogg/dirsql: created.

Database definitions files /oracle/ogg/dirdef: created.

Extract data files /oracle/ogg/dirdat: created.

Temporary files /oracle/ogg/dirtmp: created.

Credential store files /oracle/ogg/dircrd: created.

Masterkey wallet files /oracle/ogg/dirwlt: created.

Dump files /oracle/ogg/dirdmp: created.

只有提交事务的record才会被捕获。抽取、投递、应用日志的单位是record，而不是trail文件。

2.6配置MGR参数文件，并启动mgr

mgr进程是这些进程的管理和守护进程，目标端的mgr进程还与源端进行通信

edit params mgr

PORT 7809

GGSCI (tencent) 7> start mgr

Manager started.

GGSCI (tencent) 8> info all

Program Status Group Lag at Chkpt Time Since Chkpt

MANAGER RUNNING

2.7添加extract进程 抽取进程：负责抓取需要传输的数据（添加进程的时候为抽取点，而不是启动进程的时候） 从21开始OGG需要配置tns #查看当前数据库语言 SQL> select userenv('language') from dual; USERENV('LANGUAGE')

AMERICAN_AMERICA.ZHS16GBK

--配置extract进程

#编辑参数

GGSCI (tencent as ogg@orcl) 21> edit params exta

extract exta

SETENV (NLS_LANG=AMERICAN_AMERICA.ZHS16GBK)

SETENV (ORACLE_HOME=/oracle/app/oracle/product/12.2.0/db_1)

SETENV (ORACLE_SID=orcl)

USERID ogg@orcl, PASSWORD ogg

DISCARDF
