Android-RecyclerView滚动控件

Fruit类

public class Fruit {

    private String name;

    private int imageId;

    public Fruit(String name, int imageId){
        this.name=name;
        this.imageId=imageId;
    }

    public String getName(){
        return name;
    }

    public int getImageId(){
        return imageId;
    }
}

FruitAdapter 适配器

/**
 * Created by 13178 on 2018-6-11.
 * 自定义适配器
 */

public class FruitAdapter extends RecyclerView.Adapter<FruitAdapter.ViewHolder> {

    private List<Fruit> mFruitList;

    //内部类ViewHolder
    static class ViewHolder extends RecyclerView.ViewHolder{
        View fruitView;
        ImageView fruitImage;
        TextView fruitName;

        public ViewHolder(View view){
            super(view);
            fruitView = view;
            fruitImage = (ImageView) view.findViewById(R.id.fruit_image);
            fruitName = (TextView) view.findViewById(R.id.fruit_name);
        }
    }
    //构造函数
    public FruitAdapter(List<Fruit> fruitList){
        mFruitList = fruitList;
    }

    //重写下面三个方法
    @Override
    public ViewHolder onCreateViewHolder(ViewGroup parent, int viewType) {
        View view = LayoutInflater.from(parent.getContext()).inflate(R.layout.fruit_item,parent,false);
        final ViewHolder holder = new ViewHolder(view);
        holder.fruitView.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                int position = holder.getAdapterPosition();
                Fruit fruit = mFruitList.get(position);
                Toast.makeText(view.getContext(),"你点击了View"+fruit.getName(),
                        Toast.LENGTH_SHORT).show();
            }
        });
        holder.fruitImage.setOnClickListener(new View.OnClickListener() {
            @Override
            public void onClick(View view) {
                int position = holder.getAdapterPosition();
                Fruit fruit = mFruitList.get(position);
                Toast.makeText(view.getContext(),"你点击了图片"+fruit.getName(),
                        Toast.LENGTH_SHORT).show();
            }
        });
        return holder;
    }

    @Override
    public void onBindViewHolder(ViewHolder holder, int position) {//给RecyclerView子项赋值
        Fruit fruit = mFruitList.get(position);
        holder.fruitImage.setImageResource(fruit.getImageId());
        holder.fruitName.setText(fruit.getName());
    }
    //一共多少子项
    @Override
    public int getItemCount() {
        return mFruitList.size();
    }
}

MainActivity

public class MainActivity extends AppCompatActivity {

    private List<Fruit> fruitList = new ArrayList<>();

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        initFruits();
        RecyclerView recyclerView = (RecyclerView) findViewById(R.id.recycler_view);
        //LinearLayoutManager layoutManager = new LinearLayoutManager(this);
        //layoutManager.setOrientation(LinearLayoutManager.HORIZONTAL);
        StaggeredGridLayoutManager layoutManager = new StaggeredGridLayoutManager(3,StaggeredGridLayoutManager.VERTICAL);
        recyclerView.setLayoutManager(layoutManager);

        FruitAdapter adapter = new FruitAdapter(fruitList);
        recyclerView.setAdapter(adapter);
    }
    private void initFruits(){
        for(int i=0;i<2;i++){
            Fruit apple = new Fruit(getRandomLengthName("苹果"),R.drawable.apple_pic);
            fruitList.add(apple);
            Fruit banana = new Fruit(getRandomLengthName("香蕉"),R.drawable.banana_pic);
            fruitList.add(banana);
            Fruit orange = new Fruit(getRandomLengthName("桔子"),R.drawable.orange_pic);
            fruitList.add(orange);
            Fruit watermelon = new Fruit(getRandomLengthName("西瓜"),R.drawable.watermelon_pic);
            fruitList.add(watermelon);
            Fruit pear = new Fruit(getRandomLengthName("梨子"),R.drawable.pear_pic);
            fruitList.add(pear);
            Fruit grape = new Fruit(getRandomLengthName("葡萄"),R.drawable.grape_pic);
            fruitList.add(grape);
            Fruit pineapple = new Fruit(getRandomLengthName("菠萝"),R.drawable.pineapple_pic);
            fruitList.add(pineapple);
            Fruit strawberry = new Fruit(getRandomLengthName("草莓"),R.drawable.strawberry_pic);
            fruitList.add(strawberry);
            Fruit cherry = new Fruit(getRandomLengthName("樱桃"),R.drawable.cherry_pic);
            fruitList.add(cherry);
            Fruit mango = new Fruit(getRandomLengthName("芒果"),R.drawable.mango_pic);
            fruitList.add(mango);
        }
    }
    private String getRandomLengthName(String name){
        Random random = new Random();
        int length = random.nextInt(10) + 5;
        StringBuilder buider = new StringBuilder();
        for (int i=0 ; i<length ; i++){
            buider.append(name);
        }
        return buider.toString();
    }
}

activity_main.xml

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"

    android:orientation="vertical"
    android:layout_width="match_parent"
    android:layout_height="match_parent">



    <android.support.v7.widget.RecyclerView
        android:id="@+id/recycler_view"
        android:layout_width="match_parent"
        android:layout_height="match_parent"/>

</LinearLayout>

fruit_item.xml

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:orientation="vertical"
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:layout_margin="5dp">

    <ImageView
        android:id="@+id/fruit_image"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_gravity="center_horizontal"/>

    <TextView
        android:id="@+id/fruit_name"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_gravity="left"
        android:layout_marginTop="10dp"/>

</LinearLayout>
