一、高通相关网址
二、高通平台调试手段
一、高通相关网址
- Createpoint:
https://createpoint.qti.qualcomm.com（可下载文档，Release Note，Case，文档，工具等等） - Chipcode:
https://chipcode.qti.qualcomm.com（下载私有代码） - 开源代码:
https://www.codeaurora.org/xwiki/bin/QAEP/release（下载开源代码） - Case:
https://support-qualcomm.force.com/（高通Case） - 高通网站 image 转换工具：
https://cap.qti.qualcomm.com/default.aspx++
二、高通平台调试手段
调试平台信息：【SDM845/670】
以下为参考用例，具体请以 sdm845_caf\vendor\qcom\proprietary\camx\src\core\camxsettings.xml 为准！！！
Camx Log信息相关
- AF相关LOG控制
例： setprop persist.vendor.camera.logInfoMask 0x8000000 //AF info level log
setprop persist.vendor.camera.logVerboseMask 0x8000000 //AF verbose level log
adb shell "echo logInfoMask=0x8000000 >> /vendor/etc/camera/camxoverridesettings.txt"
adb shell "echo logVerboseMask=0x8000000 >> /vendor/etc/camera/camxoverridesettings.txt"
Mask值对应如下：(1 << 27)=0x8000000 即对应AF模块
// The group tag for a given debug print message
typedef UINT32 CamxLogGroup;
static const CamxLogGroup CamxLogGroupNone = (1 << 0); ///< Generic group
static const CamxLogGroup CamxLogGroupSensor = (1 << 1); ///< Sensor
static const CamxLogGroup CamxLogGroupIFace = (1 << 2); ///< IFace
static const CamxLogGroup CamxLogGroupISP = (1 << 3); ///< ISP
static const CamxLogGroup CamxLogGroupPProc = (1 << 4); ///< Post Processor
static const CamxLogGroup CamxLogGroupImgLib = (1 << 5); ///< Image Lib
static const CamxLogGroup CamxLogGroupCPP = (1 << 6); ///< CPP
static const CamxLogGroup CamxLogGroupHAL = (1 << 7); ///< HAL
static const CamxLogGroup CamxLogGroupJPEG = (1 << 8); ///< JPEG
static const CamxLogGroup CamxLogGroupStats = (1 << 9); ///< Stats
static const CamxLogGroup CamxLogGroupCSL = (1 << 10); ///< CSL
static const CamxLogGroup CamxLogGroupApp = (1 << 11); ///< Application
static const CamxLogGroup CamxLogGroupUtils = (1 << 12); ///< Utilities
static const CamxLogGroup CamxLogGroupSync = (1 << 13); ///< Sync
static const CamxLogGroup CamxLogGroupMemSpy = (1 << 14); ///< MemSpy
static const CamxLogGroup CamxLogGroupAssert = (1 << 15); ///< Asserts
static const CamxLogGroup CamxLogGroupCore = (1 << 16); ///< Core
static const CamxLogGroup CamxLogGroupHWL = (1 << 17); ///< HWL
static const CamxLogGroup CamxLogGroupChi = (1 << 18); ///< CHI
static const CamxLogGroup CamxLogGroupDRQ = (1 << 19); ///< DRQ
static const CamxLogGroup CamxLogGroupFD = (1 << 20); ///< FD
static const CamxLogGroup CamxLogGroupIQMod = (1 << 21); ///< IQ module
static const CamxLogGroup CamxLogGroupLRME = (1 << 22); ///< LRME
static const CamxLogGroup CamxLogGroupNCS = (1 << 23); ///< NCS
static const CamxLogGroup CamxLogGroupMeta = (1 << 24); ///< Metadata
static const CamxLogGroup CamxLogGroupAEC = (1 << 25); ///< AEC //0x2000000
static const CamxLogGroup CamxLogGroupAWB = (1 << 26); ///< AWB //0x4000000
static const CamxLogGroup CamxLogGroupAF = (1 << 27); ///< AF //0x8000000禁用深度焦点指示
setprop persist.vendor.camera.af.depthfocus 1
disableFocusIndication=1关闭 PDAF
setprop persist.vendor.camera.disablePDAF 1
disablePDAF=1开启PDLib log
setprop persist.camera.pdaf_logging 1开启PDAF performance log
setprop persist.camera.pdaf_profiling 1开启 AF debug log
setprop persist.camera.stats.af.debug 5
setprop persist.camera.stats.haf.debug 5设置 fullsweep 模式
afFullsweep=0 //fullsweep off
afFullsweep=1 //far to near
afFullsweep=2 //near to far
afFullsweep=3 //bothDump EEPROM 保存OTP数据至 /data/misc/camera/
dumpSensorEEPROMData=13A调试 exif信息
debugDataSizeAEC=6000
debugDataSizeAWB=550000
debugDataSizeAF=70000CHI Override log
persist.vendor.camera.logInfoMask 0x40080 //default:0x0
persist.vendor.camera.logVerboseMask 0x40000 //default:0x0
vendor.debug.camera.overrideLogLevels 0x1F //default:1
<Help>Bitmask of log levels, bit 0 - error, bit 1 - warning, bit 2 - info, bit 3 - debug</Help>
Assert
persist.vendor.camera.assertMask
assertMask=0x2Warning log
persist.vendor.camera.logWarningMask
logWarningMask=0x2Info log
persist.vendor.camera.logInfoMask
logInfoMask=0x2Perf Info log
persist.vendor.camera.logPerfInfoMask
logPerfInfoMask=0x2Verbose Info log
persist.vendor.camera.logVerboseMask
logVerboseMask=0x2Entry/Exit log
persist.vendor.camera.logEntryExitMask
logEntryExitMask=0x2DRQ Log
persist.vendor.camera.logDRQEnable
logDRQEnable=TRUESystem Log Enable
persist.vendor.camera.systemLogEnable
systemLogEnable=FALSELog filename
persist.vendor.camera.debugLogFilename
debugLogFilename=cameralog
--Trace group--
persist.vendor.camera.traceGroupsEnable
traceGroupsEnable=0x2
- Enable FPS Logs
persist.vendor.camera.enableFPSLog
enableFPSLog=TRUE
ChiOverride 设置
（1）开关ZSL
vendor.debug.camera.overrideDisableZSL
adb shell "echo overrideDisableZSL=1 >> /vendor/etc/camera/camxoverridesettings.txt"（2）开关MFNR
vendor.debug.camera.overrideEnableMFNR
adb shell "echo overrideEnableMFNR=1 >> /vendor/etc/camera/camxoverridesettings.txt"（3）强制选择一个usecase
vendor.debug.camera.overrideForceUsecaseId
adb shell "echo overrideForceUsecaseId=8 >> /vendor/etc/camera/camxoverridesettings.txt”（4）强制选择一个sensor mode
vendor.debug.camera.overrideForceSensorMode
adb shell "echo overrideForceSensorMode=1 >> /vendor/etc/camera/camxoverridesettings.txt"（5）启用GPU Node Rotation Usecase
vendor.debug.camera.overrideGPURotationUsecase
adb shell "echo overrideGPURotationUsecase=1 >> /vendor/etc/camera/camxoverridesettings.txt"（6）强制使用不带3A的HFR Usecase
vendor.debug.camera.overrideHFRNo3AUseCase
adb shell "echo overrideHFRNo3AUseCase=1 >> /vendor/etc/camera/camxoverridesettings.txt"（7）允许使用AdvancedCameraUsecase
vendor.debug.camera.overrideUseAdvancedUsecase
adb shell "echo overrideUseAdvancedUsecase=0 >> /vendor/etc/camera/camxoverridesettings.txt"（8）开启 EIS V2/V3
vendor.debug.camera.eisv2enable
adb shell "echo EISV2Enable=1 >> /vendor/etc/camera/camxoverridesettings.txt"
vendor.debug.camera.eisv3enable
adb shell "echo EISV3Enable=1 >> /vendor/etc/camera/camxoverridesettings.txt"（9） EIS V2/V3 Margin
vendor.debug.camera.eisv2margin
adb shell "echo EISV2Margin=0.4 >> /vendor/etc/camera/camxoverridesettings.txt"
vendor.debug.camera.eisv3margin
adb shell "echo EISV3Margin=0.4 >> /vendor/etc/camera/camxoverridesettings.txt"（10）EIS V2/V3 Frame Delay
vendor.debug.camera.eisv2framedelay
adb shell "echo EISV2FrameDelay=1 >> /vendor/etc/camera/camxoverridesettings.txt"
vendor.debug.camera.eisv3framedelay
adb shell "echo EISV3FrameDelay=1 >> /vendor/etc/camera/camxoverridesettings.txt"（11）Number of PCRs before stream on
vendor.debug.camera.numPCRsBeforeStreamOn
adb shell "echo numPCRsBeforeStreamOn=1 >> /vendor/etc/camera/camxoverridesettings.txt"（12）图像 Buffer Count Override （初始化期间分配的图像buffer计数，默认值8）
vendor.debug.camera.overrideImageBufferCount
adb shell "echo overrideImageBufferCount=7 >> /vendor/etc/camera/camxoverridesettings.txt"（13）Stats Frame Skipping 【0: invalid. <default 1: No Skip.> 2: skip 1 frame. 3: skip 2 frames】
vendor.debug.camera.statsProcessingSkipCount
adb shell "echo statsProcessingSkipFactor=2 >> /vendor/etc/camera/camxoverridesettings.txt获取raw和metadata用于ISP调试
（1） Enable Dump
adb shell setprop persist.vendor.camera.imageDumpMask 6 ->No dumps = 0x0
->All output ports for IFE = 0x1
->All output ports for IPE = 0x2
->All output ports for BPS = 0x4
adb shell setprop persist.vendor.camera.offlineImageDumpOnly 1
adb shell setprop persist.vendor.camera.reprocessDump 1
adb shell setprop persist.vendor.camera.autoImageDump 1
adb shell setprop persist.vendor.camera.autoImageDumpIPEoutputPortMask 0x100
<Help>
Output port mask for IPE:
IPEOutputPortDisplay = 0x100;
IPEOutputPortVideo = 0x200;
IPEOutputPortFullRef = 0x400;
IPEOutputPortDS4Ref = 0x800;
IPEOutputPortDS16Ref = 0x1000;
IPEOutputPortDS64Ref = 0x2000;
ALLports = 0x3F00
</Help>
adb shell setprop persist.vendor.camera.autoImageDumpIPEInstanceMask 12
<Help>
IPEInstanceName0 = 0x1;
IPEInstanceName1 = 0x2;
IPEInstanceName2 = 0x4;
IPEInstanceName3 = 0x8;
IPEInstanceName4 = 0x10;
IPEInstanceName5 = 0x20;
IPEInstanceName6 = 0x40;
IPEInstanceName7 = 0x80;
IPEInstanceName8 = 0x100;
IPEInstanceName9 = 0x200;
IPEInstanceName10 = 0x400;
IPEInstanceName11 = 0x800;
IPEInstanceName12 = 0x1000;
IPEInstanceName13 = 0x2000;
IPEInstanceName14 = 0x4000;
IPEInstanceName15 = 0x8000;
IPEInstanceName16 = 0x10000;
IPEInstanceName17 = 0x20000;
IPEInstanceName18 = 0x40000;
IPEInstanceName19 = 0x80000;
IPEInstanceName20 = 0x100000;
IPEInstanceName21 = 0x200000;
AllInstances = 0xFFFFFFFF
</Help>
adb shell setprop persist.vendor.camera.autoImageDumpIFEoutputPortMask 0x100
<Help>
Output port mask:
IFE:
IFEOutputPortFull = 0x1;
IFEOutputPortDS4 = 0x2;
IFEOutputPortDS16 = 0x4;
IFEOutputPortCAMIFRaw = 0x8;
IFEOutputPortLSCRaw = 0x10;
IFEOutputPortGTMRaw = 0x20;
IFEOutputPortFD = 0x40;
IFEOutputPortPDAF = 0x80;
IFEOutputPortRDI0 = 0x100;
IFEOutputPortRDI1 = 0x200;
IFEOutputPortRDI2 = 0x400;
IFEOutputPortRDI3 = 0x800;
IFEOutputPortStatsRS = 0x1000;
IFEOutputPortStatsCS = 0x2000;
IFEOutputPortStatsIHIST = 0x8000;
IFEOutputPortStatsBHIST = 0x10000;
IFEOutputPortStatsHDRBE = 0x20000;
IFEOutputPortStatsHDRBHIST = 0x40000;
IFEOutputPortStatsTLBG = 0x80000;
IFEOutputPortStatsBF = 0x100000;
IFEOutputPortStatsAWBBG = 0x200000;
IFEOutputPortDisplayFull = 0x400000;
IFEOutputPortDisplayDS4 = 0x800000;
IFEOutputPortDisplayDS16 = 0x1000000;
IFEOutputPortStatsDualPD = 0x2000000;
ALLports = 0x3FFBFFF
AllPixelOutput = 0x1C00047
AllRawOutput = 0xFB8
AllRDIOutput = 0xF00
AllStatsOutput = 0x3FB000
</Help>
adb shell setprop persist.vendor.camera.autoImageDumpIFEInstanceMask 0x7
<Help>
Instance mask:
IFE:
IFEInstanceName0 = 0x1;
IFEInstanceName1 = 0x2;
IFEInstanceName2 = 0x4;
AllInstances = 0x7
</Help>或
adb shell "echo autoImageDumpMask=6>>/vendor/etc/camera/camxoverridesettings.txt"
adb shell "echo offlineImageDumpOnly=TRUE>>/vendor/etc/camera/camxoverridesettings.txt"
adb shell "echo reprocessDump=TRUE >>/vendor/etc/camera/camxoverridesettings.txt"
adb shell "echo autoImageDump=TRUE>>/vendor/etc/camera/camxoverridesettings.txt"
...生成路径：++data/misc/camera/++ 或 ++data/vendor/camera/++
使用Chromatix 工具查看：
① *.RAWMIPI → rename to *.RAW, *.YUV420NV21 → Rename to *.YUV
② RAW → BPP 10, pack: mipi pattern: RGGB YUV → BPP 8, Sub-sample: Ycbcr420, Format: Semi-Planar
开启dump后预览会比较卡，可以修改dump部分代码(/src/utils/camximagedump.cpp b/src/utils/camximagedump.cpp)，过滤特定格式缓解卡顿：
#include "camximagedump.h"
#include "camximagebuffer.h"
#include "camximageformatutils.h"
#include <cutils/properties.h>
CAMX_NAMESPACE_BEGIN
@@ -99,6 +100,28 @@ VOID ImageDump::Dump(
OsUtils::SNPrintF(suffix, sizeof(suffix), "ERROR");
break;
}
+// add format mask
+ char value[100] = "\0";
+ static int nFirstTime = 1; + static int nDumpMask = 0;
+ if(nFirstTime)
+ {
+ property_get("persist.camera.dump.formatmask", value, "0");
+ nFirstTime = 0;
+ nDumpMask=atoi(value);
+ }
+ if(nDumpMask > 0)
+ {
+ if(static_cast<INT32>(pDumpInfo->pFormat->format) != nDumpMask)
+ {
+ CAMX_LOG_ERROR(CamxLogGroupUtils, "stop dump format: %d, only dump format: %d\n", pDumpInfo->pFormat->format, nDumpMask);
+ return;
+ }
+ }
+
+//然后可以参考 “camxformats.h”中的掩码定义dump指定的图像格式：
adb shell setprop persist.camera.dump.formatmask 15 // dump YUV420NV12TP10（2）将 TP10 转换成 YUV 10bit 格式
dump到大量TP10格式的YUV文件后，模拟器不能直接支持TP10格式，需要使用Chromatix 7将其转换为Yuv420_10bit的格式，转换步骤如下：
1.打开chromatix 7并打开您的项目。
2.选择视频场景（ video Scenario）。
3.打开TF界面，检查宽度和高度。TF界面中显示的宽度和高度应与文件名中的宽度和高度完全相同。(xxxx[WW]_[HH]xxxx.YUV420NV12TP10）如果不相同，请先更正。
3.1 你需要关闭Chromatix7. 然后进入Chromatix7 工程目录。
3.2 打开并修改 sensorData.txt 中的宽和高。（C7project\Scenario.Default\Sensor.0\Usecase.Video\sensorData.txt，路径取决于您使用的场景）
3.3 修改以下两行并保存，然后再执行第3步。
2036, /* raw image width */
1144, /* raw image height */4. 点击 “TP10 to Planar” 并选择重命名的yuv文件，您只需要选择xxx_0.yuv，工具就可以找到剩余的文件，然后选择输出文件夹。
5. 等几秒钟，您就可以得到输出名如 xxx_pln_0.YUV, xxx_pln_1.YUV … 的文件，所有的tp10文件都被转换了。
（3） Get Meta
步骤： ① 设备开启meta
② 拍照获得jpeg
③ 通过C7获取meta （QualcommSpectraSim280.exe - metaparsetest.jpg -》 C7\Simulator\Spectra280\）
adb shell "echo tuningDumpDataSizeIFE=5000 >> /vendor/etc/camera/camxoverridesettings.txt"
adb shell "echo tuningDumpDataSizeBPS=20000 >> /vendor/etc/camera/camxoverridesettings.txt"
adb shell "echo tuningDumpDataSizeIPE=150000 >> /vendor/etc/camera/camxoverridesettings.txt来源: 影像技术栈
文章作者: Abalone
文章链接: https://camerastacker.com/2023/031240432.html
至此，本篇已结束。转载网络的文章，小编觉得很优秀，欢迎点击阅读原文，支持原创作者，如有侵权，恳请联系小编删除，欢迎您的建议与指正。同时期待您的关注，感谢您的阅读，谢谢！
点个在看，为大佬点赞！
扫一扫
2341
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
