项目场景：
需要实现一个横向滑动的效果，外加一个点击箭头滑动的效果，滑动以后默认还是选中第一个。
使用技术
首先需要一个工具类，直接导入就行，可以直接使用：
public class PagingScrollHelper {
RecyclerView mRecyclerView = null;
private MyOnScrollListener mOnScrollListener = new MyOnScrollListener();
private MyOnFlingListener mOnFlingListener = new MyOnFlingListener();
private int offsetY = 0;
private int offsetX = 0;
int startY = 0;
int startX = 0;
enum ORIENTATION {
HORIZONTAL, VERTICAL, NULL
}
private ORIENTATION mOrientation = ORIENTATION.HORIZONTAL;
public void setUpRecycleView(RecyclerView recycleView) {
if (recycleView == null) {
throw new IllegalArgumentException("recycleView must be not null");
}
mRecyclerView = recycleView;
//处理滑动
recycleView.setOnFlingListener(mOnFlingListener);
//设置滚动监听，记录滚动的状态，和总的偏移量
recycleView.addOnScrollListener(mOnScrollListener);
//记录滚动开始的位置
recycleView.setOnTouchListener(mOnTouchListener);
//获取滚动的方向
updateLayoutManger();
}
public void removeScrollListener(){
mRecyclerView.removeOnScrollListener(mOnScrollListener);
}
public void updateLayoutManger() {
RecyclerView.LayoutManager layoutManager = mRecyclerView.getLayoutManager();
if (layoutManager != null) {
if (layoutManager.canScrollVertically()) {
mOrientation = ORIENTATION.VERTICAL;
} else if (layoutManager.canScrollHorizontally()) {
mOrientation = ORIENTATION.HORIZONTAL;
} else {
mOrientation = ORIENTATION.NULL;
}
if (mAnimator != null) {
mAnimator.cancel();
}
startX = 0;
startY = 0;
offsetX = 0;
offsetY = 0;
}
}
/**
* 获取总共的页数
*/
public int getPageCount() {
if (mRecyclerView != null) {
if (mOrientation == ORIENTATION.NULL) {
return 0;
}
if (mOrientation == ORIENTATION.VERTICAL && mRecyclerView.computeVerticalScrollExtent() != 0) {
return mRecyclerView.computeVerticalScrollRange() / mRecyclerView.computeVerticalScrollExtent();
} else if (mRecyclerView.computeHorizontalScrollExtent() != 0) {
Log.i("zzz", "rang=" + mRecyclerView.computeHorizontalScrollRange() + " extent=" + mRecyclerView.computeHorizontalScrollExtent());
return mRecyclerView.computeHorizontalScrollRange() / mRecyclerView.computeHorizontalScrollExtent();
}
}
return 0;
}
ValueAnimator mAnimator = null;
public void scrollToPosition(int position) {
if (mAnimator == null) {
mOnFlingListener.onFling(0, 0);
}
if (mAnimator != null) {
int startPoint = mOrientation == ORIENTATION.VERTICAL ? offsetY : offsetX, endPoint = 0;
if (mOrientation == ORIENTATION.VERTICAL) {
endPoint = mRecyclerView.getHeight() * position;
} else {
endPoint = mRecyclerView.getWidth() * position;
}
if (startPoint != endPoint) {
mAnimator.setIntValues(startPoint, endPoint);
mAnimator.start();
}
}
}
public class MyOnFlingListener extends RecyclerView.OnFlingListener {
@Override
public boolean onFling(int velocityX, int velocityY) {
if (mOrientation == ORIENTATION.NULL) {
return false;
}
//获取开始滚动时所在页面的index
int p = getStartPageIndex();
//记录滚动开始和结束的位置
int endPoint = 0;
int startPoint = 0;
//如果是垂直方向
if (mOrientation == ORIENTATION.VERTICAL) {
startPoint = offsetY;
if (velocityY < 0) {
p--;
} else if (velocityY > 0) {
p++;
}
//更具不同的速度判断需要滚动的方向
//注意，此处有一个技巧，就是当速度为0的时候就滚动会开始的页面，即实现页面复位
endPoint = p * mRecyclerView.getHeight();
} else {
startPoint = offsetX;
if (velocityX < 0) {
p--;
} else if (velocityX > 0) {
p++;
}
endPoint = p * mRecyclerView.getWidth();
}
if (endPoint < 0) {
endPoint = 0;
}
//使用动画处理滚动
if (mAnimator == null) {
mAnimator = new ValueAnimator().ofInt(startPoint, endPoint);
mAnimator.setDuration(300);
mAnimator.addUpdateListener(new ValueAnimator.AnimatorUpdateListener() {
@Override
public void onAnimationUpdate(ValueAnimator animation) {
int nowPoint = (int) animation.getAnimatedValue();
if (mOrientation == ORIENTATION.VERTICAL) {
int dy = nowPoint - offsetY;
//这里通过RecyclerView的scrollBy方法实现滚动。
mRecyclerView.scrollBy(0, dy);
} else {
int dx = nowPoint - offsetX;
mRecyclerView.scrollBy(dx, 0);
}
}
});
mAnimator.addListener(new AnimatorListenerAdapter() {
@Override
public void onAnimationEnd(Animator animation) {
//回调监听
if (null != mOnPageChangeListener) {
mOnPageChangeListener.onPageChange(getPageIndex());
}
//修复双击item bug
mRecyclerView.stopScroll();
startY = offsetY;
startX = offsetX;
}
});
} else {
mAnimator.cancel();
mAnimator.setIntValues(startPoint, endPoint);
}
mAnimator.start();
return true;
}
}
public class MyOnScrollListener extends RecyclerView.OnScrollListener {
@Override
public void onScrollStateChanged(RecyclerView recyclerView, int newState) {
//newState==0表示滚动停止，此时需要处理回滚
if (newState == 0 && mOrientation != ORIENTATION.NULL) {
boolean move;
int vX = 0, vY = 0;
if (mOrientation == ORIENTATION.VERTICAL) {
int absY = Math.abs(offsetY - startY);
//如果滑动的距离超过屏幕的一半表示需要滑动到下一页
move = absY > recyclerView.getHeight() / 2;
vY = 0;
if (move) {
vY = offsetY - startY < 0 ? -1000 : 1000;
}
} else {
int absX = Math.abs(offsetX - startX);
move = absX > recyclerView.getWidth() / 2;
if (move) {
vX = offsetX - startX < 0 ? -1000 : 1000;
}
}
mOnFlingListener.onFling(vX, vY);
}
}
@Override
public void onScrolled(RecyclerView recyclerView, int dx, int dy) {
//滚动结束记录滚动的偏移量
offsetY += dy;
offsetX += dx;
}
}
private MyOnTouchListener mOnTouchListener = new MyOnTouchListener();
private boolean firstTouch = true;
public class MyOnTouchListener implements View.OnTouchListener {
@Override
public boolean onTouch(View v, MotionEvent event) {
//手指按下的时候记录开始滚动的坐标
if (firstTouch) {
//第一次touch可能是ACTION_MOVE或ACTION_DOWN,所以使用这种方式判断
firstTouch = false;
startY = offsetY;
startX = offsetX;
}
if (event.getAction() == MotionEvent.ACTION_UP || event.getAction() == MotionEvent.ACTION_CANCEL) {
firstTouch = true;
}
return false;
}
}
private int getPageIndex() {
int p = 0;
if (mRecyclerView.getHeight() == 0 || mRecyclerView.getWidth() == 0) {
return p;
}
if (mOrientation == ORIENTATION.VERTICAL) {
p = offsetY / mRecyclerView.getHeight();
} else {
p = offsetX / mRecyclerView.getWidth();
}
return p;
}
private int getStartPageIndex() {
int p = 0;
if (mRecyclerView.getHeight() == 0 || mRecyclerView.getWidth() == 0) {
//没有宽高无法处理
return p;
}
if (mOrientation == ORIENTATION.VERTICAL) {
p = startY / mRecyclerView.getHeight();
} else {
p = startX / mRecyclerView.getWidth();
}
return p;
}
onPageChangeListener mOnPageChangeListener;
public void setOnPageChangeListener(onPageChangeListener listener) {
mOnPageChangeListener = listener;
}
public interface onPageChangeListener {
void onPageChange(int index);
}
}
这个工具类主要是实现，滑动的时候，当前的下标。
页面开发和调用：
在initview初始化的是需要先调用一下这些adapter和工具类：
//使用通用RecyclerView组件
//初始化横向管理器
PagingScrollHelper scrollHelper = new PagingScrollHelper();
HorizontalPageLayoutManager horizontalPageLayoutManager = new HorizontalPageLayoutManager(1, 1);//这里两个参数是行列，这里实现的是一行三列
scrollHelper.setUpRecycleView(recyclerView);//将横向布局管理器和recycler view绑定到一起
scrollHelper.setOnPageChangeListener(new PagingScrollHelper.onPageChangeListener() {
@SuppressLint("NotifyDataSetChanged")
@Override
public void onPageChange(int index) {
Log.i("onPageChange", "安全环保-index " + index);
if (maps != null) {
Log.i("onPageChange", "安全环保-maps " + maps.size());
if (maps.size() > 1) {
//实现箭头点击滑动
if (index == 0) {
EventBus.getDefault().post(new SafetyEvent(false, true));
} else if (index > 0 && index < maps.size() - 1) {
EventBus.getDefault().post(new SafetyEvent(true, true));
} else if (index == maps.size() - 1) {
EventBus.getDefault().post(new SafetyEvent(true, false));
} else if (maps.size() == 1) {
EventBus.getDefault().post(new SafetyEvent(false, false));
}
//滑动以后默认选中第一个
for (int i = 0; i < maps.size(); i++) {
List<SafetyBean.ListBean> defaultList = maps.get(i).getList();
for (int j = 0; j < defaultList.size(); j++) {
defaultList.get(j).setCheck(false);
}
}
maps.get(index).getList().get(0).setCheck(true);
safetyAdapter.notifyDataSetChanged();
for (int i = 0; i < maps.size(); i++) {
List<SafetyBean.ListBean> defaultList = maps.get(i).getList();
for (int j = 0; j < defaultList.size(); j++) {
if (defaultList.get(j).isCheck()) {
int ordinal = defaultList.get(j).getKey();
if (baseordinal == ordinal) {
} else {
newSafetyFragmentPresenter.DataShow(new SafetyListRequest(ordinal), ordinal);
}
}
}
}
}
}
}
});
//设置滑动监听
recyclerView.setLayoutManager(horizontalPageLayoutManager);//设置为横向
recyclerView.setHorizontalScrollBarEnabled(true);
if (safetyAdapter == null){
safetyAdapter = new SafetyAdapter(getContext());
recyclerView.setAdapter(safetyAdapter);
}
if (safetyListAdapter == null){
safetyListAdapter = new SafetyListAdapter(mcontext);
RecyclerViewHelper.initRecyclerViewV(getActivity(), recy_list, new SlideInBottomAnimationAdapter(safetyListAdapter));
}
newSafetyFragmentPresenter.getDataShow(new OperationBaseRequest());//接口调用
然后就是一级标题拿到数据以后赋值：
private List<SafetyBean> maps; private int indexPos = 0;@SuppressLint("NotifyDataSetChanged") public void ItemTab(List<SafetyBean.ListBean> data) { newSafetyFragmentPresenter.DataShow(new SafetyListRequest(data.get(0).getKey()), data.get(0).getKey()); Log.i("", "ItemTab: " + data.size()); //默认选中第一个item data.get(0).setCheck(true); //一级列表数据 maps = new ArrayList<>(); maps = PageUtil.SafetyformatPageData(data);//手动分页 if (maps.size() > 1) { Log.i("mapsmapsmapsmaps", " " + maps.size()); iv_img.setVisibility(View.VISIBLE); iv_img_left.setVisibility(View.GONE); } iv_img.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View view) { if (maps.size() > 0) { indexPos = indexPos + 1; scrollHelper.scrollToPosition(indexPos);//默认滑动到第一页 } } }); iv_img_left.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View view) { if (maps.size() > 0) { indexPos = indexPos - 1; scrollHelper.scrollToPosition(indexPos);//默认滑动到第一页 if (indexPos == 0) { iv_img.setVisibility(View.VISIBLE); iv_img_left.setVisibility(View.GONE); } } } }); safetyAdapter.updateItems(maps); safetyAdapter.notifyDataSetChanged(); }
一级标题的适配器 因为是需要滑动的，所以他是列表套着列表的：
public class SafetyAdapter extends BaseQuickAdapter<SafetyBean> { private Context context; public SafetyAdapter(Context context) { super(context); this.context = context; } public SafetyAdapter(Context context, List<SafetyBean> data) { super(context, data); } @Override protected int attachLayoutRes() { return R.layout.item_new_title; } @Override protected void convert(BaseViewHolder holder,SafetyBean item) { RecyclerView recyclerView = holder.getView(R.id.recyclerView); LinearLayoutPagerManager layoutManager = new LinearLayoutPagerManager(context, LinearLayoutManager.HORIZONTAL, false, 4); layoutManager.setOrientation(LinearLayoutManager.HORIZONTAL); recyclerView.setLayoutManager(layoutManager); recyclerView.setItemAnimator(new DefaultItemAnimator()); NewSafetyTitleAdapter adapter = new NewSafetyTitleAdapter(context,item.getList(), getData()); recyclerView.setAdapter(adapter); adapter.setOnItemClickListener(new OnItemsClickListener() { @SuppressLint("NotifyDataSetChanged") @Override public void onItemClickListener(View view) { notifyDataSetChanged(); } }); } private OnItemsClickListener onItemsClickListener; private void setOnItemClickListener(OnItemsClickListener onItemsClickListeners){ onItemsClickListener = onItemsClickListeners; } }
一级标题的内部列表 （赋值的）：
public class NewSafetyTitleAdapter extends BaseQuickAdapter<SafetyBean.ListBean> {
private List<SafetyBean> data;
public NewSafetyTitleAdapter(Context context, List<SafetyBean.ListBean> defaultList, List<SafetyBean> data) {
super(context, defaultList);
this.data = data;
}
@Override
protected int attachLayoutRes() {
return R.layout.new_safety_title;
}
@Override
protected void convert(BaseViewHolder holder, SafetyBean.ListBean item) {
TextView tvTitle = holder.getView(R.id.tv_title);
ImageView iv_indicator = holder.getView(R.id.iv_indicator);
tvTitle.setText(item.getTitle());
if (item.isCheck()) {
iv_indicator.setVisibility(View.VISIBLE);
tvTitle.getPaint().setFakeBoldText(true);
tvTitle.setTextColor(ContextCompat.getColor(mContext, R.color.c_171A1D));
} else {
iv_indicator.setVisibility(View.INVISIBLE);
tvTitle.getPaint().setFakeBoldText(false);
tvTitle.setTextColor(ContextCompat.getColor(mContext, R.color.c_737577));
}
//通过EventBus将数据和点击事件发送给首页
holder.getConvertView().setOnClickListener(new View.OnClickListener() {
@SuppressLint("NotifyDataSetChanged")
@Override
public void onClick(View view) {
onItemsClickListener.onItemClickListener(view);
if (item.getTitle() != null) {
EventBus.getDefault().post(new NewSafetyListEvent(true, item.getKey()));
} else {
EventBus.getDefault().post(new NewSafetyListEvent(false, item.getKey()));
}
for (int i = 0; i < data.size(); i++) {
for (SafetyBean.ListBean bean : data.get(i).getList()) {
bean.setCheck(false);
}
}
item.setCheck(true);
notifyDataSetChanged();
}
});
}
private OnItemsClickListener onItemsClickListener;
public void setOnItemClickListener(OnItemsClickListener onItemsClickListeners) {
onItemsClickListener = onItemsClickListeners;
}
}
二级列表的数据对应的赋值：
private int baseordinal = -1;//用来获取一级列表下对应的二级数据
public void getFunctionType(List<SafetyListBean.ResultBean> result, int id) { if (result == null || result.size() == 0) { iv_empty.setVisibility(View.VISIBLE); } else { iv_empty.setVisibility(View.GONE); } baseordinal = id; safetyListAdapter = new SafetyListAdapter(mcontext, result, id); // recy_list.addItemDecoration(new RoundedRectItemDecoration(5, 5)); recy_list.setAdapter(safetyListAdapter); }
二级列表的适配器（赋值，做了点击事件）：
public class SafetyListAdapter extends BaseQuickAdapter<SafetyListBean.ResultBean> { private Context mcontext; private int id; private List<SafetyListBean.ResultBean> data; public SafetyListAdapter(Context context) { super(context); this.mcontext = context; } public SafetyListAdapter(Context context, List<SafetyListBean.ResultBean> data, int id) { super(context, data); this.data = data; this.mcontext = context; this.id = id; } @Override protected int attachLayoutRes() { return R.layout.item_safety_list; } @Override protected void convert(BaseViewHolder holder, SafetyListBean.ResultBean item) { int bindingAdapterPosition = holder.getBindingAdapterPosition(); TextView tv_title = holder.getView(R.id.tv_title); TextView tv_cont = holder.getView(R.id.tv_cont); View views = holder.getView(R.id.view); View viewss = holder.getView(R.id.viewss); ConstraintLayout rl_show = holder.getView(R.id.rl_show); tv_title.setText(item.getCategoryName()); RecyclerView rv_list = holder.getView(R.id.rv_list); ArrayList<SafetyListBean.ResultBean.ListBean> listBeans = new ArrayList<>(); for (int i = 0; i < item.getList().size(); i++) { SafetyListBean.ResultBean.ListBean listBean = new SafetyListBean.ResultBean.ListBean(); String title = item.getList().get(i).getTitle(); String createTime = item.getList().get(i).getCreateTime(); String url = item.getList().get(i).getUrl(); String categoryName = item.getList().get(i).getCategoryName(); String fileUrl = item.getList().get(i).getFileUrl(); listBean.setFileUrl(fileUrl); listBean.setUrl(url); listBean.setCategoryName(categoryName); listBean.setTitle(title); listBean.setCreateTime(createTime); listBeans.add(listBean); } SafetyListsAdapter safetyListsAdapter = new SafetyListsAdapter(mcontext, listBeans); RecyclerViewHelper.initRecyclerViewV(mcontext, rv_list, new SlideInBottomAnimationAdapter(safetyListsAdapter)); safetyListsAdapter.cleanItems(); safetyListsAdapter.updateItems(listBeans); if (item.getTotal() > 3) { views.setVisibility(View.VISIBLE); rl_show.setVisibility(View.VISIBLE); viewss.setVisibility(View.GONE); tv_cont.setText("查看更多"); } else { rl_show.setVisibility(View.GONE); views.setVisibility(View.GONE); viewss.setVisibility(View.VISIBLE); } tv_cont.setOnClickListener(new View.OnClickListener() { @Override public void onClick(View view) { EventBus.getDefault().post(new NewSafetyListsEvent(item.getList().get(bindingAdapterPosition).getCategoryName(), item.getList().get(bindingAdapterPosition).getCategoryId())); } }); } }
箭头的显示和隐藏使用的是eventbus：
//显示/隐藏箭头 @Subscribe(threadMode = ThreadMode.MAIN) public void onMainThreadEvent(SafetyEvent event) { if (event.isStart()) { iv_img_left.setVisibility(View.VISIBLE); } else { iv_img_left.setVisibility(View.GONE); } if (event.isEnd()) { iv_img.setVisibility(View.VISIBLE); } else { iv_img.setVisibility(View.GONE); } }
点击或者滑动到下一页的刷新方法：
@Subscribe(threadMode = ThreadMode.MAIN) public void onMainThreadEvent(SafeRefreshEvent event) { if (isCreate){ scrollHelper.removeScrollListener(); initViews(); recyclerView.scrollToPosition(0);//周历滑动到第几页 scrollHelper.scrollToPosition(0);//默认滑动到第一页 } } //点击按钮刷新列表 @Subscribe(threadMode = ThreadMode.MAIN) public void onMainThreadEvent(NewSafetyListEvent event) { if (event.isHasData()) { recyclerView.setVisibility(View.VISIBLE); recy_list.setVisibility(View.VISIBLE); newSafetyFragmentPresenter.DataShow(new SafetyListRequest(event.getPos()), event.getPos()); } else { recy_list.setVisibility(View.GONE); recyclerView.setVisibility(View.GONE); } }
最后效果图展示：
