5G IMS SIP

Authentication: Digest username="460004000100224@ims.mnc000.mcc460.3gppnetwork.org",realm="ims.mnc000.mcc460.3gppnetwork.org",uri="sip:ims.mnc000.mcc460.3gppnetwork.org",nonce="",response=""

正则表达式

Accept-Contact字段组成

示例

Accept-Contact: *;+g.3gpp.icsi-ref="urn%3Aurn-7%3A3gpp-service.ims.icsi.mmtel"

正则表达式

C

Contact字段组成

示例

Contact: <sip:460004000100224@10.227.173.22:5060>;+sip.instance="<urn:gsma:imei:86130905-414581-0>";+g.3gpp.accesstype="cellular2";audio;video;+g.3gpp.smsip;+g.3gpp.icsi-ref="urn%3Aurn-7%3A3gpp-service.ims.icsi.mmtel"

Contact: <sip:scscf.ims.mnc000.mcc460.3gppnetwork.org>

Contact: <sip:12300100224@10.227.173.22:5060>;+sip.instance="<urn:gsma:imei:86130905-414581-0>"

Contact: <sip:scscf.ims.mnc000.mcc460.3gppnetwork.org:6060>

Contact: <sip:12300100225@10.227.210.228:5060>;+sip.instance="<urn:gsma:imei:86130905-148908-0>";+g.3gpp.icsi-ref="urn%3Aurn-7%3A3gpp-service.ims.icsi.mmtel";audio;video;+g.3gpp.mid-call;+g.3gpp.srvcc-alerting;+g.3gpp.ps2cs-srvcc-orig-pre-alerting

Contact: <sip:12300100225@10.227.210.228:5060>;+g.3gpp.icsi-ref="urn%3Aurn-7%3A3gpp-service.ims.icsi.mmtel"

Contact: <sip:460004000100224@10.227.173.22:5060>;expires=3600;+g.3gpp.icsi-ref="urn%3Aurn-7%3A3gpp-service.ims.icsi.mmtel";+g.3gpp.smsip;video;audio;+g.3gpp.accesstype="cellular2";+sip.instance="<urn:gsma:imei:86130905-414581-0>"

Contact: <sip:12300100224@10.227.210.230:5060>;+g.3gpp.icsi-ref="urn%3Aurn-7%3A3gpp-service.ims.icsi.mmtel";audio;video

正则表达式

Call-ID字段组成

示例

Call-ID: sAecbAz4l@10.227.173.22

正则表达式

CSeq字段组成

示例

CSeq: 1 REGISTER

正则表达式

Content-Length字段组成

示例

Content-Length: 0

正则表达式

Content-Type字段组成

示例

Content-Type: application/reginfo+xml 【注：带有Message Body xml - NOTIFY】

Content-Type: application/sdp【注：带有Message Body sdp - INVITE】

正则表达式

E

Expires字段组成

示例

Expires: 600000

正则表达式

Event字段组成

示例

正则表达式

F

From字段组成

示例

From: <sip:460004000100224@ims.mnc000.mcc460.3gppnetwork.org>;tag=tBecbAz

正则表达式

R

Request-Line字段组成

示例

Request-Line: REGISTER sip:ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: REGISTER sip:scscf.ims.mnc000.mcc460.3gppnetwork.org:6060 SIP/2.0

Request-Line: REGISTER sip:192.168.112.191:7060 SIP/2.0

Request-Line: SUBSCRIBE sip:12300100224@ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: NOTIFY sip:12300100224@10.227.173.22:5060 SIP/2.0

Request-Line: INVITE tel:12300100224;phone-context=ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: INVITE sip:12300100224@ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: INVITE sip:460004000100224@10.227.173.22:5060 SIP/2.0

Request-Line: CANCEL tel:12300100224;phone-context=ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: CANCEL sip:12300100224@ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: CANCEL sip:460004000100224@10.227.173.22:5060 SIP/2.0

Request-Line: ACK sip:460004000100224@10.227.173.22:5060 SIP/2.0

Request-Line: ACK tel:12300100224;phone-context=ims.mnc000.mcc460.3gppnetwork.org SIP/2.0

Request-Line: PRACK sip:12300100224@10.227.210.230:5060;alias=10.227.210.230~5060~1;transport=udp SIP/2.0

Request-Line: UPDATE sip:12300100224@10.227.210.230:5060;alias=10.227.210.230~5060~1;transport=udp SIP/2.0

Request-Line: ACK sip:12300100224@10.227.210.230:5060;alias=10.227.210.230~5060~1;transport=udp SIP/2.0

Request-Line: BYE sip:12300100225@10.227.210.228:5060 SIP/2.0

正则表达式

Require字段组成

示例

Require: sec-agree

Require: path

正则表达式

RSeq字段组成

示例

RSeq: 1

正则表达式

Route字段组成

示例

Route: <sip:192.168.112.191:5060;lr>,<sip:orig@scscf.ims.mnc000.mcc460.3gppnetwork.org:6060;lr>

Route: <sip:mo@192.168.112.191:6060;lr;did=aff.ab21>,<sip:mo@192.168.112.191:6060;lr;did=aff.9b21>,<sip:mo@192.168.112.191;lr;did=aff.c14>

正则表达式

Record-Route字段组成

示例

Record-Route: <sip:mo@192.168.112.191;lr>

Record-Route: <sip:mo@192.168.112.191;lr;did=b6c.2222>

Record-Route: <sip:mo@192.168.112.191:6060;lr;did=aff.9b21>

正则表达式

Reason字段组成

示例

Reason: SIP;cause=487;te
