微信小程序自定义顶部导航栏

前言

现成轮子网上很多，但是想实现自己的需求，还得自己再造一遍轮子，有一篇文章写的很好：微信小程序自定义navigationBar

效果图

亮点

✅保证安卓和IOS显示效果一致
拓展🉑️同时显示返回上一页和返回首页
点击标题🉑️返回顶部
预留slot进行拓展

代码

index.js

Component({
  properties: {
    title: { // 标题
      type: String,
      value: 'hello world',
    },
    showGoBack: { // 显示返回按钮
      type: Boolean,
      value: false,
    },
    showHome: { // 显示返回主页按钮
      type: Boolean,
      value: false,
    },
    position: { // 是否开启绝对定位
      type: Boolean,
      value: false,
    },
    bgColor: { // 导航栏背景颜色
      type: String,
      value: 'transparent',
    },
    titleColor: { // 导航栏标题颜色
      type: String,
      value: '#000000',
    },
    showSlot: { // 是否开启slot
      type: Boolean,
      value: false,
    },
    showBlankBlock: { // 是否开启空白块占位
      type: Boolean,
      value: false,
    },
  },

  lifetimes: {
    async attached() {
      const systemInfo = await wx.getSystemInfo()

      const {
        statusBarHeight,
        windowWidth
      } = systemInfo

      const rightCapsule = wx.getMenuButtonBoundingClientRect()

      const {
        top,
        right,
        width,
        height
      } = rightCapsule

      const navBarYPadding = top - statusBarHeight

      const navBarXPadding = windowWidth - right

      const navBarHeight = height + (navBarYPadding * 2)

      const navBarBodyHeight = height

      const rightCapsuleWidth = width

      const styleData = `--bgColor: ${this.properties.bgColor};
        --statusBarHeight: ${statusBarHeight}px;
        --navBarHeight: ${navBarHeight}px;
        --navBarBodyHeight: ${navBarBodyHeight}px;
        --navBarYPadding: ${navBarYPadding}px;
        --navBarXPadding: ${navBarXPadding}px;
        --rightCapsuleWidth: ${rightCapsuleWidth}px;
        --rightCapsuleHeight: ${navBarBodyHeight}px;
        --rightCapsuleRadius: ${navBarBodyHeight / 2}px;
        --titleColor: ${this.properties.titleColor};
        `



      this.setData({
        statusBarHeight,
        navBarHeight,
        navBarBodyHeight,
        navBarYPadding,
        navBarXPadding,
        rightCapsuleWidth,
        styleData,
        backIconUrl,
        homeIconUrl,
      })
    },
  },

  data: {
    statusBarHeight: 20, // 状态栏高度
    navBarHeight: 40, // 导航栏高度
    navBarBodyHeight: 32, // 导航栏内容高度
    navBarYPadding: 4, // 导航栏Y轴内间距
    navBarXPadding: 8, // 导航栏X轴内间距
    rightCapsuleWidth: 87, // 右边胶囊宽度
    styleData: '', // 样式变量
    backIconUrl: '', // 返回icon
    homeIconUrl: '', // 主页icon
  },

  methods: {
    goBack() {
      // console.log('goBack');

      const pages = getCurrentPages()

      // 单曲页面栈小于等于一个页面，直接返回首页
      if (pages.length <= 1) {
        this.goHome()
      } else {
        wx.navigateBack()
      }
    },

    goHome() {
      // console.log('goHome');

      // 小程序中页面栈最多十层
      // 返回的页面数，如果 delta 大于现有页面数，则返回到首页。
      wx.navigateBack({
        delta: 10
      })
    },

    backTop() {
      wx.pageScrollTo({
        scrollTop: 0,
        duration: 300
      })
    },
  }
})

index.wxml

<view style="{{styleData}}">

  <view class="c-navbar {{position ? 'c-navbar--position' : ''}}">
    <!-- 状态栏 -->
    <view class="c-navbar__status-bar"></view>

    <!-- 导航栏 -->
    <view class="c-navbar__body" wx:if="{{!showSlot}}">
      <!-- 导航栏左边 => 胶囊 -->
      <view class="c-navbar__body__left">
        <view class="c-navbar__body__left__back" wx:if="{{showGoBack && (!showHome)}}" bindtap="goBack">
          <image src="{{backIconUrl}}" class="c-navbar__body__icon c-navbar__body__left__icon--back"></image>
          <text>返回</text>
        </view>

        <view class="c-navbar__body__left__home" wx:if="{{showGoBack && showHome}}">
          <view class="c-navbar__body__left__home__back" bindtap="goBack">
            <image src="{{backIconUrl}}" class="c-navbar__body__icon c-navbar__body__left__home--back"></image>
          </view>
          <view class="c-navbar__body__left__home--division"></view>
          <view class="c-navbar__body__left__home__home" bindtap="goHome">
            <image src="{{homeIconUrl}}" class="c-navbar__body__icon c-navbar__body__left__home--home"></image>
          </view>
        </view>
      </view>

      <!-- 导航栏中间 => 标题 -->
      <view class="c-navbar__body__title" bindtap="backTop">
        {{title}}
      </view>

      <!-- 导航栏右边 => 胶囊 -->
      <view class="c-navbar__body__right"></view>
    </view>

    <!-- 开启slot -->
    <view class="c-navbar__body" wx:if="{{showSlot}}">
      <view class="c-navbar__body--slot">
        <slot></slot>
      </view>

      <!-- 导航栏右边 => 胶囊 -->
      <view class="c-navbar__body__right"></view>
    </view>
  </view>

  <!-- 空白块占位符, 用于解决下拉刷新导航栏掉下来的问题, 需要配合开启position -->
  <view class="c-blank-block" wx:if="{{showBlankBlock}}"></view>
</view>

index.wxss

.c-navbar {
    position: -webkit-sticky;
    position: sticky;
    top: 0;
    left: 0;
    z-index: 9999;
    width: 100vw;
    box-sizing: border-box;

    background-color: var(--bgColor);
}

.c-navbar--position {
    position: fixed;
}

.c-navbar__status-bar {
    width: 100vw;
    height: var(--statusBarHeight);
}

.c-navbar__body {
    width: 100vw;
    height: var(--navBarHeight);
    padding: 0 var(--navBarXPadding);
    overflow: hidden;
    box-sizing: border-box;
    overflow: hidden;

    display: -webkit-flex;
    display: flex;
    /* -webkit-justify-content: center;
    justify-content: center; */
    -webkit-align-items: center;
    align-items: center;
    flex-wrap: wrap;
}

.c-navbar__body__left {
    width: var(--rightCapsuleWidth);
    height: var(--rightCapsuleHeight);
    box-sizing: border-box;
    font-size: 16px;
    font-weight: 500;

    display: -webkit-flex;
    display: flex;
    -webkit-justify-content: center;
    justify-content: center;
    -webkit-align-items: center;
    align-items: center;
    flex-wrap: wrap;
}

.c-navbar__body__title {
    box-sizing: border-box;
    flex: 1;
    padding: 0 var(--navBarXPadding);

    text-align: center;
    white-space: nowrap;
    overflow: hidden;
    text-overflow: ellipsis;

    color: var(--titleColor);
    font-size: 18px;
    font-weight: 500;
}

.c-navbar__body__right {
    width: var(--rightCapsuleWidth);
    height: var(--rightCapsuleHeight);
}

.c-navbar__body__icon {
    display: inline-block;
    width: 20px;
    height: 20px;
}

.c-navbar__body__left__back {
    height: 100%;
    background-color: rgba(255, 255, 255, .6);
    border: 1px solid rgba(0, 0, 0, .1);
    border-radius: var(--rightCapsuleRadius);
    box-sizing: border-box;
    padding: 0 calc(var(--navBarXPadding) * 2);

    display: -webkit-flex;
    display: flex;
    -webkit-justify-content: center;
    justify-content: center;
    -webkit-align-items: center;
    align-items: center;
    flex-wrap: wrap;
}

.c-navbar__body__left__icon--back {
    margin-left: -5px;
}

.c-navbar__body__left__home {
    position: relative;

    width: 100%;
    height: 100%;
    background-color: rgba(255, 255, 255, .6);
    border: 1px solid rgba(0, 0, 0, .1);
    border-radius: var(--rightCapsuleRadius);
    box-sizing: border-box;

    display: -webkit-flex;
    display: flex;
}

.c-navbar__body__left__home__back {
    flex: 1;

    display: -webkit-flex;
    display: flex;
    -webkit-justify-content: center;
    justify-content: center;
    -webkit-align-items: center;
    align-items: center;
    flex-wrap: wrap;
}

.c-navbar__body__left__home__home {
    flex: 1;

    display: -webkit-flex;
    display: flex;
    -webkit-justify-content: center;
    justify-content: center;
    -webkit-align-items: center;
    align-items: center;
    flex-wrap: wrap;
}

.c-navbar__body__left__home--back {
    width: 22px;
    height: 22px;
    box-sizing: border-box;
}

.c-navbar__body__left__home--home {
    width: 19px;
    height: 19px;
    box-sizing: border-box;
}

.c-navbar__body__left__home--division {
    position: absolute;
    top: 50%;
    left: 50%;
    transform: translate(-50%, -50%);

    width: 1px;
    height: 20px;
    background-color: rgba(0, 0, 0, .1);
}

.c-navbar__body--slot {
    flex: 1;
}

.c-blank-block {
    width: 100vw;
    height: calc(var(--statusBarHeight) + var(--navBarHeight));
    background-color: transparent;
}

index.json

{
    "component": true,
    "usingComponents": {}
}

属性

属性	描述	默认值
title	标题	hello world
showGoBack	显示返回按钮	false
showHome	显示返回主页按钮	false
position	是否开启绝对定位	false
bgColor	导航栏背景颜色	white
titleColor	导航栏标题颜色	#000000
showSlot	是否开启slot	false
showBlankBlock	是否开启空白块占位	false

使用

index.json

{
    "usingComponents": {
        "wmp-navbar": "@chenbz/wmp-navbar"
    },
    "navigationStyle": "custom"
}

index.wxml

<view>
  <wmp-navbar title="标题"></wmp-navbar>
</view>

npm

组件已打包发布到npm，欢迎移步至@chenbz/wmp-navbar
