onerror {resume}
quietly WaveActivateNextPane {} 0
add wave -noupdate -radix decimal /TESTBENCH/reset
add wave -noupdate -radix decimal /TESTBENCH/clk
add wave -noupdate -radix decimal /TESTBENCH/TiData
add wave -noupdate -radix decimal /TESTBENCH/ToData
add wave -noupdate -radix decimal /TESTBENCH/TiDataSingle
add wave -noupdate -radix decimal /TESTBENCH/ToDataSingle
add wave -noupdate -radix decimal /TESTBENCH/i
add wave -noupdate -radix decimal /TESTBENCH/j
add wave -noupdate -radix decimal /TESTBENCH/CONV_start
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/CONV_StartCal
add wave -noupdate -radix decimal /TESTBENCH/CONV_finish
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/ii_count
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/ij_count
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/CONV_iData
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/CONV_iArrayData
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/ci_count
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/cj_count
add wave -noupdate -radix decimal -childformat {{{/TESTBENCH/CONV_T/CONV_core[1]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[2]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[3]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[4]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[5]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[6]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[7]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[8]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_core[9]} -radix decimal}} -subitemconfig {{/TESTBENCH/CONV_T/CONV_core[1]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[2]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[3]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[4]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[5]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[6]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[7]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[8]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_core[9]} {-radix decimal}} /TESTBENCH/CONV_T/CONV_core
add wave -noupdate -radix decimal -childformat {{{/TESTBENCH/CONV_T/CONV_iReCon[1]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[2]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[3]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[4]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[5]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[6]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[7]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[8]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_iReCon[9]} -radix decimal}} -subitemconfig {{/TESTBENCH/CONV_T/CONV_iReCon[1]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[2]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[3]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[4]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[5]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[6]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[7]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[8]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_iReCon[9]} {-radix decimal}} /TESTBENCH/CONV_T/CONV_iReCon
add wave -noupdate -radix decimal -childformat {{{/TESTBENCH/CONV_T/CONV_mul[1]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[2]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[3]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[4]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[5]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[6]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[7]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[8]} -radix decimal} {{/TESTBENCH/CONV_T/CONV_mul[9]} -radix decimal}} -subitemconfig {{/TESTBENCH/CONV_T/CONV_mul[1]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[2]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[3]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[4]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[5]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[6]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[7]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[8]} {-radix decimal} {/TESTBENCH/CONV_T/CONV_mul[9]} {-radix decimal}} /TESTBENCH/CONV_T/CONV_mul
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/CONV_result
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/CONV_oArrayData
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/oi_count
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/oj_count
add wave -noupdate -radix decimal /TESTBENCH/CONV_T/CONV_oData
TreeUpdate [SetDefaultTree]
WaveRestoreCursors {{Cursor 1} {378 us} 0}
configure wave -namecolwidth 150
configure wave -valuecolwidth 100
configure wave -justifyvalue left
configure wave -signalnamewidth 1
configure wave -snapdistance 10
configure wave -datasetprefix 0
configure wave -rowmargin 4
configure wave -childrowmargin 2
configure wave -gridoffset 0
configure wave -gridperiod 1
configure wave -griddelta 40
configure wave -timeline 0
configure wave -timelineunits ns
update
WaveRestoreZoom {0 us} {1050 us}
