android 数字递增动画,Android自定义带增长动画和点击弹窗提示效果的柱状图DEMO...

于 2021-05-26 01:47:49 发布
阅读量497 收藏
点赞数
文章标签： android 数字递增动画

项目中最近用到各种图表，本来打算用第三方的，例如MPAndroid,这是一个十分强大的图表库，应用起来十分方便，但是最终发现和设计不太一样，没办法，只能自己写了。今天将写好的柱状图的demo贴在这，该柱状图可根据数据的功能有一下几点：

1. 根据数据的多少，动态的绘制柱状图柱子的条数；

2. 柱状图每条柱子的绘制都有动态的动画效果；

3. 每条柱子有点击事件，点击时弹出提示框，显示相关信息，规定时间后，弹窗自动消失。

好了，先上演示图：


下边贴出相关代码：

自定义柱状图类：

package com.example.histogram;

import android.content.Context;

import android.graphics.Canvas;

import android.graphics.Color;

import android.graphics.Paint;

import android.graphics.RectF;

import android.os.Handler;

import android.text.TextPaint;

import android.util.AttributeSet;

import android.util.Log;

import android.view.MotionEvent;

import android.view.View;

import com.example.histogram.UI.UI;

import java.text.NumberFormat;

/**

* Created by ZHANGZDon 2016/6/16 0016.

* 柱状图

*/

public class HistoGram extends View implements Runnable {

private Handler handler = new Handler(); // 用于延时更新，实现动画

private float animHeight; // 进度条动画高度

private Paint axisLinePaint; // 坐标轴画笔

private Paint hLinePaint; // 内部水平虚线画笔

private Paint textPaint; // 绘制文本的画笔

private Paint recPaint; // 绘制柱状图阴影背景的画笔

private Paint dataPaint; // 绘制柱状图的画笔

private Paint textPaint2; // 绘制白色文本的画笔

private Paint textPaint3; // 绘制坐标的画笔

private Paint textPaint4; // 绘制x轴上的白色竖线的画笔

private String[] xTitleString; // x轴刻度

private String[] yTitleString; // y轴刻度

private String[] data; // 接口返回的indicatordata，用于计算柱子高度

NumberFormat numberFormat; //用于格式化数字

private float currentHeight; // 当前柱状图应有的高度，应由计算得来

private int num = -1; // 画多少条柱子，因为存在刚开机数据不足24条的情况

private float mRelativePxInHeight;

private float mRelativePxInWidth;

private OnChartClickListener listener;

private int mDist;

public void setNum(int num) {

this.num = num;

invalidate();

}

public void setData(String[] data) {

this.data = data;

invalidate();

}

public void setxTitleString(String[] title) {

this.xTitleString = title;

invalidate();

}

public HistoGram(Context context) {

this(context, null);

}

public HistoGram(Context context, AttributeSet attrs) {

this(context, attrs, 0);

}

public void setTitle(String[] title) {

this.xTitleString = title;

}

public HistoGram(Context context, AttributeSet attrs, int defStyleAttr) {

super(context, attrs, defStyleAttr);

init(context, attrs);

}

/**

* 进行相关初始化操作

* @param context

* @param attrs

*/

private void init(Context context, AttributeSet attrs) {

axisLinePaint = new Paint();

hLinePaint = new Paint();

textPaint = new Paint();

recPaint = new Paint();

dataPaint = new Paint();

textPaint2 = new Paint();

textPaint3 = new Paint();

textPaint4 = new Paint();

numberFormat = NumberFormat.getNumberInstance();

numberFormat.setMinimumFractionDigits(3); //设置打印时保留三位小数

axisLinePaint.setColor(Color.parseColor("#dbdde4")); //设置坐标轴的颜色为白色

hLinePaint.setARGB(51, 255, 255, 255);

textPaint.setColor(Color.parseColor("#8593a1"));

// textPaint.setTextSize(29);

textPaint.setTextSize(UI.dip2px(getContext(), 12));

recPaint.setColor(Color.parseColor("#f2f5fc"));

dataPaint.setColor(Color.CYAN);

textPaint2.setColor(Color.WHITE);

textPaint2.setTextSize(UI.dip2px(getContext(), 12));

textPaint3.setColor(Color.parseColor("#000000"));

textPaint3.setTextSize(UI.dip2px(getContext(), 9));

textPaint4.setColor(Color.parseColor("#8593a1"));

textPaint4.setTextSize(UI.dip2px(getContext(), 6));

axisLinePaint.setAntiAlias(true);

hLinePaint.setAntiAlias(true);

textPaint.setAntiAlias(true);

recPaint.setAntiAlias(true);

dataPaint.setAntiAlias(true);

textPaint2.setAntiAlias(true);

textPaint3.setAntiAlias(true);

textPaint4.setAntiAlias(true);

}

@Override

protected void onDraw(Canvas canvas) {

super.onDraw(canvas);

if(data == null || xTitleString == null || num < 0 ) {

return;

}

//绘制y轴刻度

Paint.FontMetrics metrics = textPaint3.getFontMetrics();

int decent = (int) metrics.descent;

float width = getWidth();

float height = getHeight();

//根据原型图得出，图中每px高度在实际中的相对尺寸

mRelativePxInHeight = height / 470;

//根据原型图得出，图中每px宽度在实际中的相对尺寸

mRelativePxInWidth = width / 690;

textPaint3.setTextAlign(Paint.Align.RIGHT);

//绘制纵坐标

yTitleString = new String[6];

yTitleString[5] = "0";

yTitleString[4] = "20";

yTitleString[3] = "40";

yTitleString[2] = "60";

yTitleString[1] = "80";

yTitleString[0] = "100";

for (int i = 0; i < yTitleString.length; i++) {

canvas.drawText(yTitleString[i], 88 * mRelativePxInWidth, (72 + i * 56) * mRelativePxInHeight + decent, textPaint3);

}

//绘制x轴刻度

textPaint3.setTextAlign(Paint.Align.CENTER);

textPaint4.setTextAlign(Paint.Align.CENTER);

TextPaint textPaint = new TextPaint();

textPaint.setColor(Color.parseColor("#000000"));

textPaint.setTextSize(UI.dip2px(getContext(), 9));

//计算柱子之间的间隔

//最左侧位置100 * mRelativePxInWidth,最右侧位置630 ePxInWidth,

float totalWidth = 630 - 100;

// 柱子与之子之间的间隔

mDist = (int) (totalWidth / (xTitleString.length + 1));

for (int i = 0; i < xTitleString.length; i++) {

//绘制白色竖线

canvas.drawLine((100 + (i+1) * mDist) * mRelativePxInWidth, 348 * mRelativePxInHeight, (100 + (i+1) * mDist) * mRelativePxInWidth, 352 * mRelativePxInHeight, axisLinePaint);

//绘制x轴文字

canvas.drawText(xTitleString[i], (100 + (i+1) * mDist) * mRelativePxInWidth, 370 * mRelativePxInHeight, textPaint3);

}

// 绘制矩形阴影

for (int i = 0; i < num; i++) {

RectF rectF = new RectF();

// rectF.left = 111 * relativePxInWidth + i * 22 * relativePxInWidth;

// rectF.right = 121 * relativePxInWidth + i * 22 * relativePxInWidth;

rectF.left = 95 * mRelativePxInWidth + (i+1) * mDist * mRelativePxInWidth;

rectF.right = 105 * mRelativePxInWidth +(i+1) * mDist * mRelativePxInWidth;

rectF.top = 70 * mRelativePxInHeight;

rectF.bottom = 338 * mRelativePxInHeight;

canvas.drawRoundRect(rectF, 10, 10, recPaint);

}

// 绘制x轴坐标线

for (int i = 0; i < 6; i++) {

canvas.drawLine(100 * mRelativePxInWidth, (66 + i * 56) * mRelativePxInHeight + decent, 630 * mRelativePxInWidth, (66 + i * 56) * mRelativePxInHeight + decent, axisLinePaint);

}

// 延时绘制，实现动画效果。数字越大，延时越久，动画效果就会越慢

handler.postDelayed(this, 1);

for (int i = 0; i < num; i++) {

RectF dataRectF = new RectF();

dataRectF.left = 95 * mRelativePxInWidth + (i + 1) * mDist * mRelativePxInWidth;

dataRectF.right = 105 * mRelativePxInWidth + (i + 1) * mDist * mRelativePxInWidth;

dataPaint.setColor(Color.parseColor("#3ac2d9"));

//获取柱子高度

currentHeight = Float.parseFloat(data[num - 1 - i]);

if (currentHeight == 0) {

dataRectF.top = 346 * mRelativePxInHeight;

} else if (currentHeight == 100) {

dataRectF.top = 70 * mRelativePxInHeight;

} else {

if (animHeight >= currentHeight) {

dataRectF.top = 346 * mRelativePxInHeight - currentHeight / 100 * 276 * mRelativePxInHeight;

} else {

dataRectF.top = 346 * mRelativePxInHeight - 276 * mRelativePxInHeight * (animHeight / 100);

}

}

dataRectF.bottom = 346 * mRelativePxInHeight;

// 限制最高高度

if (dataRectF.top < 70 * mRelativePxInHeight) {

dataRectF.top = 70 * mRelativePxInHeight;

}

canvas.drawRoundRect(dataRectF, 10, 10, dataPaint);

}

}

//实现柱子增长的动画效果

@Override

public void run() {

animHeight += 1;

if (animHeight >= 276 * mRelativePxInHeight) {

return;

} else {

invalidate();

}

}

@Override

public boolean onTouchEvent(MotionEvent event) {

switch (event.getAction()) {

case MotionEvent.ACTION_DOWN: {

//获取点击坐标

float x = event.getX();

float y = event.getY();

//判断点击点的位置

float leftx = 0;

float rightx = 0;

for (int i = 0; i < num; i++) {

leftx = 95 * mRelativePxInWidth + (i+ 1) * mDist * mRelativePxInWidth - mDist/2 * mRelativePxInWidth;

rightx = 105 * mRelativePxInWidth + (i+ 1) * mDist * mRelativePxInWidth + mDist/2 * mRelativePxInWidth;

if (x < leftx) {

continue;

}

if (leftx <= x && x <= rightx) {

//获取点击的柱子区域的y值

float top = 346 * mRelativePxInHeight - Float.parseFloat(data[num - 1 - i])/ 100 * 276 * mRelativePxInHeight;

float bottom = 346 * mRelativePxInHeight;

if (y >= top && y <= bottom) {

//判断是否设置监听

//将点击的第几条柱子，点击柱子顶部的坐值，用于弹出dialog提示数据，还要返回百分比currentHeidht = Float.parseFloat(data[num - 1 - i])

if(listener != null) {

Log.e("ss","x" + x +";y:" + y);

listener.onClick(i + 1, leftx + mDist/2,top,Float.parseFloat(data[num - 1 - i]));

}

break;

}

}

}

break;

}

case MotionEvent.ACTION_MOVE:

Log.e("touch", "ACTION_MOVE");

break;

case MotionEvent.ACTION_UP:

Log.e("touch", "ACTION_UP");

break;

}

return true;

}

/**

* 柱子点击时的监听接口

*/

public interface OnChartClickListener {

void onClick(int num, float x, float y, float value);

}

/**

* 设置柱子点击监听的方法

* @param listener

*/

public void setOnChartClickListener(OnChartClickListener listener) {

this.listener = listener;

}

}

在xml文件中的应用：

xmlns:android="http://schemas.android.com/apk/res/android"

xmlns:tools="http://schemas.android.com/tools"

android:id="@+id/activity_main"

android:layout_width="match_parent"

android:layout_height="match_parent"

android:orientation="vertical"

tools:context="com.example.histogram.MainActivity">

android:layout_width="match_parent"

android:layout_height="40dp"

android:gravity="center"

android:text="繁忙度指示图(%)"

android:textSize="15sp"

android:textColor="#000000"

/>

android:id="@+id/staticview"

android:layout_width="400dp"

android:layout_height="500dp"

android:layout_gravity="center_horizontal"

android:layout_marginBottom="14dp"

android:layout_marginTop="5dp"/>

在activity中的实现：

package com.example.histogram;

import android.os.Bundle;

import android.os.Handler;

import android.support.v7.app.AppCompatActivity;

import android.util.Log;

import android.view.View;

import android.widget.PopupWindow;

import android.widget.TextView;

public class MainActivity extends AppCompatActivity {

private PopupWindow mPopupWindow;

@Override

protected void onCreate(Bundle savedInstanceState) {

super.onCreate(savedInstanceState);

setContentView(R.layout.activity_main);

final HistoGram histoGram = (HistoGram) findViewById(R.id.staticview);

String[] data ={"100","20","40","20","80","20","60","30","5","20","60","30","5","5","20","60","30","5"};

final String[] title = {"1","2","3","4","5","6","7","8","9","6","7","8","9","9","6","7","8","9"};

histoGram.setNum(title.length);

histoGram.setData(data);

histoGram.setxTitleString(title);

histoGram.setOnChartClickListener(new HistoGram.OnChartClickListener() {

@Override

public void onClick(int num, float x, float y, float value) {

//显示提示窗

View inflate = View.inflate(MainActivity.this, R.layout.popupwindow, null);

TextView textView = (TextView) inflate.findViewById(R.id.main_tv);

textView.setText(value + "%\n" + title[num - 1]);

if(mPopupWindow != null) {

mPopupWindow.dismiss();

}

mPopupWindow = new PopupWindow(inflate,140, 60, true);

mPopupWindow.setTouchable(true);

Log.e("ss","num" + num +";x" + x+";y"+ y + ";value" + value

+";(int)((- histoGram.getHeight()) + y - 65)"

+(int)((- histoGram.getHeight()) + y - 65)

+ "histoGram.getHeight()" + histoGram.getHeight());

// 设置好参数之后再show

// Toast.makeText(MainActivity.this, "num" + num +";x" + x+";y"+ y + ";value" + value

// +";popupWindow.getWidth()"+ mPopupWindow.getWidth()+";"+ mPopupWindow.getHeight(), Toast.LENGTH_SHORT).show();

mPopupWindow.showAsDropDown(histoGram,(int)(x - 65),(int)((- histoGram.getHeight()) + y - 65) );

mPopupWindow.setBackgroundDrawable(getResources().getDrawable(R.mipmap.databg_busyness));

new Handler().postDelayed(new Runnable(){

public void run() {

mPopupWindow.dismiss();

}

}, 1000);

}

});

}

}

以上所述是小编给大家介绍的Android自定义带增长动画和点击弹窗提示效果的柱状图,实现一个模拟后台数据登入的效果，希望对大家有所帮助，如果大家有任何疑问请给我留言，小编会及时回复大家的。在此也非常感谢大家对脚本之家网站的支持！
