CPU usage

cpu usage 即 cpu 利用率；
cpu 利用率是基于 /proc/stat 文件中的内容得到的；
cpu 利用率的计算方法，先取两个采样点（抽样间隔视具体情况而定），然后基于差值进行利用率计算：

cpu usage = [(user_ cpu 2 + sys_2 + nice_2) - (user_1 + sys_1 + nice_1)] / (total_2 - total_1) * 100;

注意：上述计算方式其实存在不完整的问题；在实际使用过程中，最简单且正确的计算方式是通过 idle 指标进行计算，即

%cpu_usage = 1 - %idle
%cpu usage = 1 - (idle2-idle1)/(total_2-total_1)

下面是一段网友给出的基于 Bash 采集 cpu 利用率的代码：

#!/bin/sh
##echo user nice system idle iowait irq softirq
CPULOG_1=$(cat /proc/stat | grep 'cpu ' | awk '{print $2" "$3" "$4" "$5" "$6" "$7" "$8}')
SYS_IDLE_1=$(echo $CPULOG_1 | awk '{print $4}')
Total_1=$(echo $CPULOG_1 | awk '{print $1+$2+$3+$4+$5+$6+$7}')

sleep 5

CPULOG_2=$(cat /proc/stat | grep 'cpu ' | awk '{print $2" "$3" "$4" "$5" "$6" "$7" "$8}')
SYS_IDLE_2=$(echo $CPULOG_2 | awk '{print $4}')
Total_2=$(echo $CPULOG_2 | awk '{print $1+$2+$3+$4+$5+$6+$7}')

SYS_IDLE=`expr $SYS_IDLE_2 - $SYS_IDLE_1`

Total=`expr $Total_2 - $Total_1`
SYS_USAGE=`expr $SYS_IDLE/$Total*100 |bc -l`     ## 这里的变量名有问题，此处得到的应该是 %idle * 100

SYS_Rate=`expr 100-$SYS_USAGE |bc -l`            ## 此处得到的是 %cpu_usage * 100

Disp_SYS_Rate=`expr "scale=3; $SYS_Rate/1" |bc`  ## 取小数点后 3 位
echo $Disp_SYS_Rate%

CPU load

cpu load 即 cpu 负载；
cpu load 是从 /proc/loadavg 中读取的，该值为所有 cpu 的总体值，计算单个 cpu load 的平局值时，需要除 cpu 的数量；

vagrant@vagrant-ubuntu-trusty:~$ cat /proc/loadavg
0.00 0.01 0.05 1/81 1954

上述输出中每个值的含义依次为：

lavg_1 (0.00) 1-分钟平均负载
lavg_5 (0.01) 5-分钟平均负载
lavg_15(0.05) 15-分钟平均负载
nr_running (1) 在采样时刻，运行队列的任务的数目，与/proc/stat的procs_running表示相同意思
nr_threads (81) 在采样时刻，系统中活跃的任务的个数（不包括运行已经结束的任务）
last_pid(1954) 最大的pid值，包括轻量级进程，即线程。

Linux 的系统负载指运行队列的平均长度，也就是等待 CPU 的平均进程数；

获取 cpu 时间消耗情况的各种命令

top 中的输出

%Cpu(s):  0.0 us,  0.0 sy,  0.0 ni, 99.7 id,  0.3 wa,  0.0 hi,  0.0 si,  0.0 st

sar 中的输出

$sar -u ALL 10 3
Linux 3.10.0-229.11.1.el7.x86_64 (dockermonitor) 06/29/2016 _x86_64_ (2 CPU)

04:03:25 PM CPU %usr %nice %sys %iowait %steal %irq %soft %guest %gnice   %idle
04:03:35 PM    all 5.07   0.00   1.93       0.30     0.15 0.00  0.05    0.00     0.00   92.50
04:03:45 PM    all 2.53   0.00   1.47       0.35     0.10 0.00  0.00    0.00     0.00   95.55
04:03:55 PM    all 2.57   0.00   1.46       0.35     0.05 0.00  0.05    0.00    0.00   95.51
Average:       all 3.39   0.00   1.62       0.34     0.10 0.00  0.03    0.00    0.00   94.52
[#32#root@dockermonitor ~]$

注意：上述指标中 %steal 不为 0 说明，当前 OS 是在虚拟机调度器的管理下运行的，且存在其它 OS 也被虚拟机调度器管理；

man sar 中的内容

-u [ ALL ]
Report CPU utilization.
The ALL keyword indicates that all the CPU fields should be displayed.
The report may show the following fields:

%user
Percentage of CPU utilization that occurred while executing at the user level (application).
Note that this field includes time spent running virtual processors.

%usr
Percentage of CPU utilization that occurred while executing at the user level (application).
Note that this field does NOT include time spent running virtual processors.

%nice
Percentage of CPU utilization that occurred while executing at the user level with nice priority.

%system
Percentage of CPU utilization that occurred while executing at the system level (kernel).

Note that this field includes time spent servicing hardware and software interrupts.

%sys
Percentage of CPU utilization that occurred while executing at the system level (kernel).
Note that this field does NOT include time spent servicing hardware or software interrupts.

%iowait
Percentage of time that the CPU or CPUs were idle during which the system had an outstanding disk I/O request.

%steal
Percentage of time spent in involuntary wait by the virtual CPU or CPUs while the hypervisor was servicing another virtual processor.

%irq
Percentage of time spent by the CPU or CPUs to service hardware interrupts.

%soft
Percentage of time spent by the CPU or CPUs to service software interrupts.

%guest
Percentage of time spent by the CPU or CPUs to run a virtual processor.

%gnice
Percentage of time spent by the CPU or CPUs to run a niced guest.

%idle
Percentage of time that the CPU or CPUs were idle and the system did not have an outstanding disk I/O request.

Note: On SMP machines a processor that does not have any activity at all (0.00 for every field) is a disabled (offline) processor.

mpstat 中的输出

$mpstat -P ALL
Linux 3.10.0-229.11.1.el7.x86_64 (dockermonitor) 06/29/2016 _x86_64_ (2 CPU)

07:20:32 PM CPU %usr %nice %sys %iowait %irq %soft %steal %guest %gnice %idle
07:20:32 PM    all   1.95  0.00    1.19      0.27  0.00  0.08   0.08     0.00     0.00  96.43
07:20:32 PM     0   1.99  0.00    1.25     0.24  0.00  0.08   0.08     0.00     0.00  96.36
07:20:32 PM      1   1.91   0.00    1.14      0.30  0.00  0.08   0.08    0.00     0.00  96.49
[#53#root@dockermonitor ~]$

iostat 中的输出

$iostat
Linux 3.10.0-229.11.1.el7.x86_64 (dockermonitor) 06/29/2016 _x86_64_ (2 CPU)

avg-cpu: %user %nice %system %iowait %steal    %idle
                   1.95   0.00        1.28       0.27    0.08   96.43

Device: tps kB_read/s kB_wrtn/s kB_read kB_wrtn
vda 2.66 1.37 11.09 4190325 33851948
vdb 43.63 4.49 567.16 13713889 1731436536
vdc 0.06 0.21 0.45 629764 1377676
dm-0 21.25 4.11 470.90 12544414 1437579039
dm-4 0.01 0.17 0.06 521344 190041
dm-5 0.07 0.66 1.04 2022838 3160694
dm-6 0.00 0.01 0.00 27485 3210
dm-7 0.00 0.00 0.00 9686 2464
dm-8 0.00 0.00 0.00 9467 2784
dm-9 0.01 0.08 0.27 243767 837085
dm-10 0.45 0.41 10.15 1262443 30974262
dm-1 2.46 0.32 81.93 971740 250114665
dm-2 2.46 0.32 81.93 968732 250115322
dm-3 2.46 0.29 81.93 878884 250116748
dm-11 1.79 0.37 50.01 1142915 152658304
dm-12 0.00 0.02 0.00 54430 2361

[#55#root@dockermonitor ~]$

/proc/stat 中的内容

~$ cat /proc/stat
cpu 851 0 1784 956996 318 176 0 0 0 0
cpu0 851 0 1784 956996 318 176 0 0 0 0
intr 142546 58 10 0 0 0 0 0 0 0 0 0 0 156 0 9444 0 4977 0 0 10027 3894 7365 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ctxt 878495
btime 1467168528
processes 2032
procs_running 1
procs_blocked 0
softirq 102927 0 65552 3845 15021 11176 0 3 0 92 7238
vagrant@vagrant-ubuntu-trusty:~$

The very first "cpu" line aggregates the numbers in all of the other "cpuN" lines.

第一行数值表示 CPU 总的使用情况，因此计算 cpu 使用率只需要使用这一行数据即可；

These numbers identify the amount of time the CPU has spent performing different kinds of work.
Time units are in USER_HZ or Jiffies (typically hundredths of a second).

jiffies 是内核中的一个全局变量，用来记录自系统启动以来产生的节拍数；在 linux 中，一个节拍大致可理解为操作系统进程调度的最小时间片，不同 linux 内核可能值有不同，通常在 1ms 到 10ms 之间；

The meanings of the columns are as follows, from left to right:

user(1): normal processes executing in user mode
从系统启动开始，累计到当前时刻，处于用户态的运行时间，不包含 nice 值为负进程；
nice(2): niced processes executing in user mode
从系统启动开始，累计到当前时刻，nice 值为负的进程所占用的CPU时间；
system(3): processes executing in kernel mode
从系统启动开始，累计到当前时刻，处于核心态的进程的运行时间；
idle(4): twiddling thumbs
从系统启动开始，累计到当前时刻，除IO等待时间以外的其它等待时间；
iowait(5): waiting for I/O to complete
从系统启动开始，累计到当前时刻，IO等待时间(since 2.5.41)；
irq(6): servicing interrupts
从系统启动开始，累计到当前时刻，硬中断时间(since 2.6.0-test4)；
softirq(7): servicing softirqs
从系统启动开始，累计到当前时刻，软中断时间(since 2.6.0-test4)；
steal(8) (since Linux 2.6.11)
Stolen time, which is the time spent in other operating systems when running in a virtualized environment
当运行在虚拟化环境中，花费在其它 OS 中的时间（基于虚拟机监视器 hypervisor 的调度）；可以理解成由于虚拟机调度器将 cpu 时间用于其它 OS 了，故当前 OS 无法使用 CPU 的时间；
guest(9) (since Linux 2.6.24)
Time spent running a virtual CPU for guest operating systems under the control of the Linux kernel.
花费给当前 host 上运行的其它 guest OS 的时间；
guest_nice(10) (since Linux 2.6.33)
Time spent running a niced guest (virtual CPU for guest operating systems under the control of the Linux kernel).

The "intr" line gives counts of interrupts serviced since boot time, for each
of the possible system interrupts. The first column is the total of all interrupts serviced; each subsequent column is the total for that particular interrupt.

The "ctxt" line gives the total number of context switches across all CPUs

The "btime" line gives the time at which the system booted, in seconds since
the Unix epoch.

The "processes" line gives the number of processes and threads created, which includes (but is not limited to) those created by calls to the fork() and clone() system calls.

The "procs_running" line gives the number of processes currently running on CPUs.

The "procs_blocked" line gives the number of processes currently blocked, waiting for I/O to complete.
copied from the kernel documentation of the /proc filesystem

总的 cpu 时间如何计算？要不要算 steal 和 guest 的时间，以及 guest_nice 时间？

totalCpuTime = user + nice + system + idle + iowait + irq + softirq + steal + guest + guest_nice

答：要；在纯粹的一台物理机上（即其上未跑其它 guest OS ，自身也未作为 guest OS 被虚拟机调度器管理），steal/guest/guest_nice 值应该都为 0 ；除此之外，上述值就应该不为 0 ；

进程 cpu 使用率

基于 /proc/<pid>/stat 文件计算

进程的总 Cpu 时间计算公式（该值包括其所有线程的 cpu 时间）

processCpuTime = utime + stime + cutime + cstime

$cat /proc/10996/stat

10996 (docker) S 10970 10996 10970 34845 10996 1077960704 3124 0 1 0 18 27 0 0 20 0 7 0 252734195 222781440 2866 18446744073709551615 4194304 33785809 140732225023424 140732225022864 4652003 0 1945795109 0 2143420159 18446744073709551615 0 0 17 1 0 0 0 0 0 35882968 36246560 44216320 140732225031681 140732225031714 140732225031714 140732225032162 0
[#49#root@dockermonitor ~]$

在 man proc 中可以看到如下信息：

/proc/[pid]/stat
Status information about the process.

utime %lu (14)
Amount of time that this process has been scheduled in user mode, measured in clock ticks (divide by sysconf(_SC_CLK_TCK)). This includes guest time,
guest_time (time spent running a virtual CPU, see below), so that applications that are not aware of the guest time field do not lose that time from their calculations.

该任务在用户态运行的时间，单位为 jiffies ；

stime %lu (15)
Amount of time that this process has been scheduled in kernel mode, measured in clock ticks (divide by sysconf(_SC_CLK_TCK)).

该任务在核心态运行的时间，单位为 jiffies ；

cutime %ld (16)
Amount of time that this process's waited-for children have been scheduled in user mode, measured in clock ticks (divide by sysconf(_SC_CLK_TCK)). (See
also times(2).) This includes guest time, cguest_time (time spent running a virtual CPU, see below).

所有已死线程在用户态运行的时间，单位为 jiffies ；

cstime %ld (17)
Amount of time that this process's waited-for children have been scheduled in kernel mode, measured in clock ticks (divide by sysconf(_SC_CLK_TCK)).

所有已死在核心态运行的时间，单位为 jiffies ；
