/proc/diskstats文件展示了块设备的I/O统计信息，包括读写操作次数、合并次数、读取和写入的扇区数量以及各项操作所花费的时间等14个字段的具体含义。

每一列的含义分别为：

第一列为设备号

（number of issued reads. This is the total number of reads completed successfully.）

第二列为次设备号

（number of reads merged）

第三列为设备名称

（number of sectors read. This is the total number of sectors read successfully.）

第四列为成功完成读的总次数

（number of milliseconds spent reading. This is the total number of milliseconds spent by all reads (as measured from __make_request() to end_that_request_last()).）

第五列为合并读次数，为了效率可能会合并相邻的读和写，从而两次4K的读在它最终被处理到磁盘上之前可能会变成一次8K的读，才被计数（和排队），因此只有一次I/O操作。

（number of writes merged Reads and writes which are adjacent to each other may be merged for efficiency. Thus two 4K reads may become one 8K read before it is ultimately handed to the disk, and so it will be counted (and queued) as only one I/O. This field lets you know how often this was done.）

第六列为读扇区的次数
第七列为读花的时间（ms），这是所有读操作所花费的毫秒数（用__make_request()到end_that_request_last()测量）
第八列到第十一列分别是写
第十二列为 I/O的当前进度，只有这个域应该是0，如果这个值为0，同时write_complete read_complete io_processing 一直不变可能就就是IO hang了。

number of I/Os currently in progress. The only field that should go to zero. Incremented as requests are given to appropriate request_queue_t and decremented as they finish.）

第十三列为输入输入花的时间（ms），花在I/O操作上的毫秒数，这个域会增长只要field 9不为0。

（number of milliseconds spent doing I/Os. This field is increased so long as field 9 is nonzero.）

第十四列为输入/输出操作花费的加权毫秒数，

（number of milliseconds spent doing I/Os. This field is incremented at each I/O start, I/O completion, I/O merge, or read of these stats by the number of I/Os in progress (field 9) times the number of milliseconds spent doing I/O since the last update of this field. This can provide an easy measure of both I/O completion time and the backlog that may be accumulating.）

可以参考：

  The /proc/diskstats file displays the I/O statistics
    of block devices. Each line contains the following 14
    fields:
     1 - major number
     2 - minor mumber
     3 - device name
     4 - reads completed successfully
     5 - reads merged
     6 - sectors read
     7 - time spent reading (ms)
     8 - writes completed
     9 - writes merged
    10 - sectors written
    11 - time spent writing (ms)
    12 - I/Os currently in progress
    13 - time spent doing I/Os (ms)
    14 - weighted time spent doing I/Os (ms)
