自定义控件（1）- 标签页

功能：

1，使用Masonry实现的标签页，内部自动根据内容提高自身约束高度

2，有三种模式（多选，单选，和点击），标签本身能够携带数据，能够设置默认选中值，能够拿到已选中标签的数据，能够显示图片

---



注意：

1，选中和未选中图片需要自己进入.m设置

2，必须设置最大宽度，否者布局会错

3, 内部使用的button是自定义能够携带数据的BZButton（就是给button加了一个id类型的data属性，用来携带数据）

---



源码地址：

https://github.com/SSBun/iOS-Custom-Control/tree/master/自适应标签页（1）

---



//  BZFallsSelectView.h
//  668PetHotel
//
//  Created by 蔡士林 on 15/12/10.
//  Copyright © 2015年 wby. All rights reserved.
//  需要使用Masonry

// BZFallsSelectView.h

typedef enum : NSUInteger {
    BZFallsSelectViewTypeMultiSelect, // default 多选标签
    BZFallsSelectViewTypeRadioSelect, // 单选标签
    BZFallsSelectViewTypeTag,         // 点击标签
} BZFallsSelectViewType;

#import <UIKit/UIKit.h>
/// 标签的数据源协议
@interface BZFallsSelectViewModel : NSObject
/// 标签标题
@property (copy, nonatomic) NSString *title;
/// 标签携带的数据
@property (strong, nonatomic) id data;
/// 标签的图片
@property (strong, nonatomic) UIImage *iconImage;
@end

@class BZFallsSelectView;
@protocol BZFallsSelectViewDelegate <NSObject>
/**
 *    @brief  点击标签时触发
 */
- (void)fallsSelectView:(BZFallsSelectView *)fallsSelectView didSelected:(BZFallsSelectViewModel *)selectedModel;

@end

@interface BZFallsSelectView : UIView
/// 所有的选项数据
@property (strong, nonatomic) NSArray<BZFallsSelectViewModel *> *datas;
/// 默认选中的值
@property (strong, nonatomic) NSArray<BZFallsSelectViewModel *> *defaultDatas;
/// 最大宽度（使用masonry自动布局，所以需要知道）
@property (assign, nonatomic) CGFloat maxWidth;
/// 选中后的值
@property (strong, nonatomic) NSMutableArray<BZFallsSelectViewModel *> *selectedDatas;
/// 标签页类型
@property (assign, nonatomic) BZFallsSelectViewType fallsSelectViewType;
/// 代理协议
@property (weak, nonatomic) id <BZFallsSelectViewDelegate> delegate;
/// 布局完成后当前视图的高度
@property (assign, nonatomic) CGFloat currentHeight;
@end

//
//  BZFallsSelectView.m
//  668PetHotel
//
//  Created by 蔡士林 on 15/12/10.
//  Copyright © 2015年 wby. All rights reserved.
//

// BZFallsSelectView.m

#define kMargin  15
#define kLeading 10
#define kBtnH    25
#import "BZFallsSelectView.h"
#import "BZButton.h"

@implementation BZFallsSelectViewModel

@end

@interface BZFallsSelectView ()
@property (strong, nonatomic) BZButton *allBtn;
@property (strong, nonatomic) NSMutableArray *btnArr;

@property (strong, nonatomic) UIButton *lastBtn;
@end

@implementation BZFallsSelectView

- (instancetype)initWithFrame:(CGRect)frame
{
    self = [super initWithFrame:frame];
    if (self) {
        self.defaultDatas = [NSArray array];
        self.fallsSelectViewType = BZFallsSelectViewTypeMultiSelect;
        [self setUpUI];
    }
    return self;
}

- (void)setUpUI
{
    BZButton *allBtn = [self addSelectBtn:@"全选" data:nil];
    self.allBtn = allBtn;
}

- (BZButton *)addSelectBtn:(NSString *)title data:(BZFallsSelectViewModel *)data
{
    BZButton *btn = [[BZButton alloc]init];
    btn.data = data;
    btn.titleLabel.font = [UIFont systemFontOfSize:11];
    [btn setBackgroundImage:[UIImage resizeImageWithName:@"shezhi_xuanze_da_anxia"] forState:UIControlStateNormal];
    [btn setBackgroundImage:[UIImage resizeImageWithName:@"shezhi_xuanze_da_zhengchang"] forState:UIControlStateSelected];
    [btn setTitle:title forState:UIControlStateNormal];
    [btn setImage:data.iconImage forState:UIControlStateNormal];
    [btn setTitleColor:[UIColor whiteColor] forState:UIControlStateSelected];
    [btn  setTitleColor:[UIColor blackColor] forState:UIControlStateNormal];
    [btn addTarget:self action:@selector(btnDidClick:) forControlEvents:UIControlEventTouchUpInside];
    [self addSubview:btn];
    return btn;
}

- (void)btnDidClick:(BZButton *)sender
{
    if (self.fallsSelectViewType == BZFallsSelectViewTypeTag) {
        if ([self.delegate respondsToSelector:@selector(fallsSelectView:didSelected:)]) {
            [self.delegate fallsSelectView:self didSelected:sender.data];
        }
    }
    else if (self.fallsSelectViewType == BZFallsSelectViewTypeRadioSelect)
    {
        self.lastBtn.selected = NO;
        sender.selected = YES;
        self.lastBtn = sender;
    }
    else
    {
        sender.selected = !sender.isSelected;
        if ([sender.titleLabel.text isEqualToString:@"全选"]) {
            for (BZButton *btn in self.btnArr) {
                btn.selected = sender.isSelected;
            }
        }
    }
}

- (CGSize)sizeOfBtnWithString:(NSString *)title
{
    CGSize size = [title boundingRectWithSize:CGSizeMake(CGFLOAT_MAX, kBtnH) options:NSStringDrawingUsesFontLeading attributes:@{NSFontAttributeName : [UIFont systemFontOfSize:11]} context:nil].size;
    size = CGSizeMake(size.width + 20, kBtnH);
    return size;
}

- (void)setDatas:(NSArray<BZFallsSelectViewModel *> *)datas
{
    _datas = datas;
    for (UIButton *btn in self.btnArr) {
        [btn removeFromSuperview];
    }
    self.btnArr = nil;
    self.btnArr = [NSMutableArray array];
    for (BZFallsSelectViewModel *model in datas) {
        BZButton *btn = [self addSelectBtn:model.title data:model];
        for (BZFallsSelectViewModel *defaultModel in self.defaultDatas) {
            if ([model.title isEqualToString:defaultModel.title]) {
                btn.selected = YES;
                continue;
            }
        }
        [self.btnArr addObject:btn];
    }
    [self setUpLayout];
}

- (void)setDefaultDatas:(NSArray *)defaultDatas
{
    _defaultDatas = defaultDatas;
    if (self.btnArr.count > 0) {
        for (BZButton *btn in self.btnArr) {
            BZFallsSelectViewModel *btnModel = (BZFallsSelectViewModel *)btn.data;
            for (BZFallsSelectViewModel *defaultModel in self.defaultDatas) {
                if ([btnModel.title isEqualToString:defaultModel.title]) {
                    btn.selected = YES;
                    continue;
                }
            }
        }
    }
}

- (void)setUpLayout
{
    if (self.fallsSelectViewType == BZFallsSelectViewTypeMultiSelect) {
        self.allBtn.frame = CGRectMake(kMargin, 0, [self sizeOfBtnWithString:@"全部"].width,kBtnH);
    }
    else
    {
        self.allBtn.frame = CGRectMake(0, 0, 0, 0);
    }
    NSInteger currRow = 0;
    BZButton *lastBtn = self.allBtn;

    for (BZButton *btn in self.btnArr) {
        BZFallsSelectViewModel *btnModel = (BZFallsSelectViewModel *)btn.data;
        btn.width = [self sizeOfBtnWithString:btnModel.title].width;
        btn.height = kBtnH;
        btn.y = (kBtnH + kLeading) * currRow;
        CGFloat btnEndX = CGRectGetMaxX(lastBtn.frame) + kMargin + btn.width;
        if (btnEndX > self.maxWidth) {
            btn.x = kMargin;
            currRow ++;
            btn.y = (kBtnH + kLeading) * currRow;
        }
        else
        {
            btn.x = CGRectGetMaxX(lastBtn.frame) + kMargin;
        }
        lastBtn = btn;
    }
    [self mas_updateConstraints:^(MASConstraintMaker *make) {
        make.height.mas_equalTo(CGRectGetMaxY(lastBtn.frame));
    }];
    self.height = CGRectGetMaxY(lastBtn.frame);
}

- (NSMutableArray *)selectedDatas
{
    NSMutableArray *tempArr = [NSMutableArray array];
    for (BZButton *btn  in self.btnArr) {
        if (btn.isSelected) {
            [tempArr addObject:btn.data];
        }
    }
    return tempArr;
}

@end





转载于:https://www.cnblogs.com/SSBun/p/5142021.html
