ActionBar

菜单项过多溢出

当创建一个ActionBar拥有太多的Action item以至于没有足够的控件来显示会在屏幕的右上角出现一个溢出菜单项，可以通过它来访问溢出部分菜单。

代码示例：

溢出菜单xml

package com.example.androidactionbartest;

import android.os.Bundle;
import android.app.Activity;
import android.view.Menu;
import android.view.MenuInflater;

public class MainActivity extends Activity {

        /** Called when the activity is first created. */
        @Override
        public void onCreate(Bundle savedInstanceState) {
            super.onCreate(savedInstanceState);
            setContentView(R.layout.activity_main);
        }

        @Override
        public boolean onCreateOptionsMenu(Menu menu)
        {
            MenuInflater inflater = getMenuInflater();
            inflater.inflate(R.menu.optionsmenu, menu);
            return true;
        }
    }

View Code

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android" >

    <item
        android:id="@+id/item1"
        android:orderInCategory="1"
        android:showAsAction="ifRoom|withText"
        android:title="save"/>
    <item
        android:id="@+id/item2"
        android:orderInCategory="2"
        android:showAsAction="ifRoom|withText"
        android:title="edit"/>
    <item
        android:id="@+id/item3"
        android:orderInCategory="3"
        android:showAsAction="ifRoom|withText"
        android:title="about"/>
    <item
        android:id="@+id/item4"
        android:orderInCategory="4"
        android:showAsAction="ifRoom|withText"
        android:title="help"/>
    <item
        android:id="@+id/item5"
        android:orderInCategory="5"
        android:showAsAction="ifRoom|withText"
        android:title="file"/>
    <item
        android:id="@+id/item6"
        android:orderInCategory="6"
        android:showAsAction="ifRoom|withText"
        android:title="run"/>
    <item
        android:id="@+id/item7"
        android:orderInCategory="7"
        android:showAsAction="ifRoom|withText"
        android:title="source"/>
    <item
        android:id="@+id/item8"
        android:orderInCategory="8"
        android:showAsAction="ifRoom|withText"
        android:title="navigate"/>
    <item
        android:id="@+id/item9"
        android:orderInCategory="9"
        android:showAsAction="ifRoom|withText"
        android:title="search"/>
    <item
        android:id="@+id/item10"
        android:orderInCategory="10"
        android:showAsAction="ifRoom|withText"
        android:title="project"/>
    <item
        android:id="@+id/item11"
        android:orderInCategory="11"
        android:showAsAction="ifRoom|withText"
        android:title="refactor"/>
    <item
        android:id="@+id/item12"
        android:orderInCategory="12"
        android:showAsAction="ifRoom|withText"
        android:title="window"/>
    <item
        android:id="@+id/item13"
        android:orderInCategory="13"
        android:showAsAction="ifRoom|withText"
        android:title="help"/>

</menu>

View Code

添加活动视图

我们也可以添加一个视图作为一个Action Item.我们可以通过在xml元素的android:actionLayout属性制定我们希望现实布局资源的ID（例如@layout/mysearchview)
我们可以选择添加android:actionViewClass属性分配与完全限定的类名描述我们想要显示的视图(例如android.widget.SearchView)

代码示例：

optionsmenu.xml

<?xml version="1.0" encoding="utf-8"?>
<menu xmlns:android="http://schemas.android.com/apk/res/android" >

    <item
        android:id="@+id/item4"
        android:orderInCategory="4"
        android:showAsAction="ifRoom|withText"
        android:title="help"/>
    <item
        android:id="@+id/item5"
        android:orderInCategory="5"
        android:showAsAction="ifRoom|withText"
        android:title="file"/>
    <item
        android:id="@+id/search"
        android:actionViewClass="android.widget.SearchView"
        android:showAsAction="ifRoom"
        android:title="Search"/>

</menu>

View Code

java程序:

package com.example.androidactionbartest;

import android.os.Bundle;
import android.app.Activity;
import android.view.Menu;
import android.view.MenuInflater;

public class MainActivity extends Activity {

        /** Called when the activity is first created. */
        @Override
        public void onCreate(Bundle savedInstanceState) {
            super.onCreate(savedInstanceState);
            setContentView(R.layout.activity_main);
        }

        @Override
        public boolean onCreateOptionsMenu(Menu menu)
        {
            MenuInflater inflater = getMenuInflater();
            inflater.inflate(R.menu.optionsmenu, menu);
            return true;
        }
    }

View Code

ActionBar 标签

1. ActionBar可以现实选项卡供用户切换浏览该Activity中不同的Fragment
2. 每个标签都可以是一个图标或文本标

主程序:

package com.example.androidactionbartest;

import android.os.Bundle;
import android.annotation.SuppressLint;
import android.app.ActionBar;
import android.app.ActionBar.Tab;
import android.app.Activity;
import android.support.v4.app.Fragment;
import android.support.v4.app.FragmentTransaction;
import android.view.Menu;
import android.view.MenuInflater;

public class MainActivity extends Activity {
        /** Called when the activity is first created. */
        @SuppressLint("NewApi")
        @Override
        public void onCreate(Bundle savedInstanceState)
        {
            super.onCreate(savedInstanceState);
            setContentView(R.layout.activity_main);
            ActionBar bar = getActionBar();
            bar.setNavigationMode(ActionBar.NAVIGATION_MODE_TABS);
            final ActionBar.Tab tabA = bar.newTab().setText("A Tab");
            final ActionBar.Tab tabB = bar.newTab().setText("B Tab");
            final ActionBar.Tab tabC = bar.newTab().setText("C Tab");
            final Fragment fragmentA = new AFragmentTab();
            final Fragment fragmentB = new BFragmentTab();
            final Fragment fragmentC = new CFragmentTab();

            tabA.setTabListener(new MyTabsListener(fragmentA));
            tabB.setTabListener(new MyTabsListener(fragmentB));
            tabC.setTabListener(new MyTabsListener(fragmentC));
            bar.addTab(tabA);
            bar.addTab(tabB);
            bar.addTab(tabC);

        }

        @SuppressLint("NewApi")
        protected class MyTabsListener implements ActionBar.TabListener
        {
            private Fragment fragment;
            public MyTabsListener(Fragment fragment)
            {
                this.fragment = fragment;
            }
            public void onTabSelected(Tab tab, FragmentTransaction ft)
            {
                ft.add(R.id.fragment_place, fragment, null);
            }
            @Override
            public void onTabReselected(Tab arg0,
                    android.app.FragmentTransaction arg1) {
                // TODO Auto-generated method stub

            }
            @Override
            public void onTabSelected(Tab arg0,
                    android.app.FragmentTransaction arg1) {
                // TODO Auto-generated method stub

            }
            @Override
            public void onTabUnselected(Tab arg0,
                    android.app.FragmentTransaction arg1) {
                // TODO Auto-generated method stub

            }
        }

    }

View Code

其余三个类:

package com.example.androidactionbartest;

import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;

public class AFragmentTab extends Fragment
{
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
            Bundle savedInstanceState)
    {
        return inflater.inflate(R.layout.fragment_a, container, false);
    }
}

View Code

package com.example.androidactionbartest;

import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
public class BFragmentTab extends Fragment
{
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
            Bundle savedInstanceState)
    {
        return inflater.inflate(R.layout.fragment_b, container, false);
    }
}

View Code

package com.example.androidactionbartest;

import android.os.Bundle;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;

public class CFragmentTab extends Fragment
{
    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
            Bundle savedInstanceState)
    {
        return inflater.inflate(R.layout.fragment_c, container, false);
    }
}
