本文介绍了如何在UIButton上实现图文混排的功能，通过使用NSAttributedString和NSAttributedStringDrawingOptions，结合使用NSFont、NSForegroundColor等属性，以及调整图像和文本的位置，实现了按钮的高大上效果。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

之前做了个排序按钮是继承UIButton来实现的, 这次在UIbutton上添加 (高大上就是所谓的图文混排),主要还是EdgeInsets。

#import <Foundation/Foundation.h>
#import <UIKit/UIKit.h>
@interface CustomDropBtn : NSObject
+(UIButton *)DropBtnWithFrame:(CGRect) farme withTitle:(NSString *)title;
@end

#import "CustomDropBtn.h"
#define RGB(r,g,b)                  [UIColor colorWithRed:r/255.0 green:g/255.0 blue:b/255.0 alpha:1.0]

@implementation CustomDropBtn
+(UIButton *)DropBtnWithFrame:(CGRect) frame withTitle:(NSString *)title
{
    NSDictionary *attributes=@{NSFontAttributeName: [UIFont systemFontOfSize:20.f],NSForegroundColorAttributeName:RGB(26, 26, 26)};
    CGRect titleframe=[title boundingRectWithSize:CGSizeMake(MAXFLOAT, MAXFLOAT) options:NSStringDrawingUsesLineFragmentOrigin attributes:attributes context:nil];

    UIButton *dropBtn = [UIButton buttonWithType:UIButtonTypeCustom];
    [dropBtn setFrame:frame];
    [dropBtn setImage:[UIImage imageNamed:@"yzp_data_dropdown.png"] forState:UIControlStateNormal];
    [dropBtn setImage:[UIImage imageNamed:@"yzp_data_dropback.png"] forState:UIControlStateSelected];
    [dropBtn setImageEdgeInsets:UIEdgeInsetsMake((frame.size.height-5)/2, frame.size.width-20-8, (frame.size.height-5)/2, 20)];
    [dropBtn setTitle:title forState:UIControlStateNormal];
    [dropBtn setTitleColor:RGB(26, 26, 26) forState:UIControlStateNormal];
    [dropBtn.titleLabel setFont:[UIFont systemFontOfSize:20.0]];

    [dropBtn setTitleEdgeInsets:UIEdgeInsetsMake((frame.size.height-titleframe.size.height)/2,(frame.size.width-titleframe.size.width)/2-28, (frame.size.height-titleframe.size.height)/2,0)];

    [dropBtn setContentHorizontalAlignment:UIControlContentHorizontalAlignmentLeft];
    return dropBtn;
}

@end
