PagerSlidingTabStrip的使用

布局

 1 <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
 2     xmlns:tools="http://schemas.android.com/tools"
 3     android:layout_width="match_parent"
 4     android:layout_height="match_parent" >
 5
 6     <com.astuetz.PagerSlidingTabStrip
 7         android:id="@+id/mTabStrip"
 8         android:layout_width="match_parent"
 9         android:layout_height="50dp"
10         android:layout_alignParentTop="true" >
11
12     </com.astuetz.PagerSlidingTabStrip>
13
14     <android.support.v4.view.ViewPager
15         android:id="@+id/mViewPager"
16         android:layout_width="match_parent"
17         android:layout_height="match_parent"
18         android:layout_below="@+id/mTabStrip" >
19     </android.support.v4.view.ViewPager>
20
21 </RelativeLayout>

实现代码

 1 import java.util.ArrayList;
 2 import java.util.List;
 3
 4 import com.astuetz.PagerSlidingTabStrip;
 5 import com.wangzhen.adapter.MyPagerAdapter;
 6
 7 import android.os.Bundle;
 8 import android.support.v4.app.Fragment;
 9 import android.support.v4.view.ViewPager;
10 import android.view.LayoutInflater;
11 import android.view.View;
12 import android.view.ViewGroup;
13
14 public class FragmentConversation extends Fragment {
15
16     private PagerSlidingTabStrip mTabStrip;
17     private ViewPager mViewPager;
18
19     private MyPagerAdapter mAdapter;
20
21     public View onCreateView(LayoutInflater inflater, ViewGroup container,
22             Bundle savedInstanceState) {
23         View view = inflater.inflate(R.layout.fragment_conversation, container,
24                 false);
25         mTabStrip = (PagerSlidingTabStrip) view.findViewById(R.id.mTabStrip);
26         mViewPager = (ViewPager) view.findViewById(R.id.mViewPager);
27         return view;
28     };
29
30     @Override
31     public void onActivityCreated(Bundle savedInstanceState) {
32         super.onActivityCreated(savedInstanceState);
33
34         List<Fragment> list = new ArrayList<Fragment>();
35         list.add(new FragmentContact());
36         list.add(new FragmentPlugin());
37         list.add(new FragmentContact());
38         list.add(new FragmentContact());
39         list.add(new FragmentPlugin());
40         list.add(new FragmentContact());
41         list.add(new FragmentContact());
42         list.add(new FragmentPlugin());
43         list.add(new FragmentContact());
44
45         mAdapter = new MyPagerAdapter(getFragmentManager(), list);
46         mViewPager.setAdapter(mAdapter);
47
48         mTabStrip.setViewPager(mViewPager);
49     }
50 }

 1 import java.util.ArrayList;
 2 import java.util.List;
 3
 4 import android.support.v4.app.Fragment;
 5 import android.support.v4.app.FragmentManager;
 6 import android.support.v4.app.FragmentPagerAdapter;
 7
 8 public class MyPagerAdapter extends FragmentPagerAdapter {
 9
10     private List<String> mTitles;
11     private List<Fragment> mDatas;
12
13     public MyPagerAdapter(FragmentManager fm, List<Fragment> data) {
14         super(fm);
15         mDatas = data;
16         mTitles = new ArrayList<String>();
17         for (int i = 0; i < mDatas.size(); i++) {
18             mTitles.add("Tab " + (i + 1));
19         }
20     }
21
22     @Override
23     public CharSequence getPageTitle(int position) {
24         return mTitles.get(position);
25     }
26
27     @Override
28     public Fragment getItem(int position) {
29         return mDatas.get(position);
30     }
31
32     @Override
33     public int getCount() {
34         return mDatas.size();
35     }
36
37 }

 PagerSlidingTabStrip下载
