本文介绍如何在Android中使用ViewPager组件，并通过设置android:clipToPadding=false实现自定义布局效果。同时展示了ViewPager的基本使用方法，包括初始化、设置页面间距及创建适配器。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

 android:clipToPadding="false"


//布局文件
<?xml version="1.0" encoding="utf-8"?>
    <RelativeLayout
        xmlns:android="http://schemas.android.com/apk/res/android"
        android:background="@color/colorAccent"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
       >

        <android.support.v4.view.ViewPager
            android:id="@+id/viewpager"
            android:layout_width="match_parent"
            android:layout_height="200dp"
            android:clipToPadding="false"
            android:paddingBottom="24dp"
            android:paddingLeft="58dp"
            android:paddingRight="58dp"
            android:paddingTop="24dp"/>
    </RelativeLayout>



//--初始化viewpager

viewPager = (ViewPager) findViewById(R.id.viewpager);
List<Integer> list = new ArrayList<>();
list.add(R.drawable.p1);
list.add(R.drawable.p2);
list.add(R.drawable.p3);
list.add(R.drawable.p4);
list.add(R.drawable.p5);
MyAdapter adapter = new MyAdapter(this, list);
viewPager.setAdapter(adapter);
viewPager.setPageMargin(60);



//--适配器

public class MyAdapter extends PagerAdapter {
    private List<Integer> list;
    private Context context;

    public MyAdapter(Context context, List<Integer> list) {
        this.context = context;
        this.list = list;
    }

    @Override
    public int getCount() {
        return list.size();
    }

    @Override
    public boolean isViewFromObject(View view, Object object) {
        return view == object;
    }

    @Override
    public Object instantiateItem(ViewGroup container, int position) {
        ImageView iv = new ImageView(context);
        iv.setImageResource(list.get(position));
        container.addView(iv);
        return iv;
    }

    @Override
    public void destroyItem(ViewGroup container, int position, Object object) {
        container.removeView((View) object);
    }
}
