本文介绍了一种在Android应用中更新UI的方法，通过处理线程发送包含进度信息的消息给Handler，Handler再更新List的Adapter，从而实现在List视图中动态展示进度。文中提供了一个具体的例子，包括代码实现和布局文件。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

今天看到论坛上有人问这个。估计是要搞一个类似下载软件的东西吧。

所以就有了本篇，原理：

处理线程先给handler发消息，消息中包括进度信息，handler在去更改List的Adapter里面的信息，并通知List更新UI。

原理很简单，就直接上码了：


     001package hol.test.listprogress;

     002

     003import java.util.ArrayList;

     004import java.util.HashMap;

     005import java.util.List;

     006

     007import android.app.Activity;

     008import android.content.Context;

     009import android.os.Bundle;

     010import android.os.Handler;

     011import android.os.Message;

     012import android.view.LayoutInflater;

     013import android.view.View;

     014import android.view.ViewGroup;

     015import android.widget.BaseAdapter;

     016import android.widget.Button;

     017import android.widget.ListView;

     018import android.widget.ProgressBar;

     019import android.widget.TextView;

     020

     021public class TestListProgress extends Activity {

     022    private Button testDo = null;

     023    private ListView progressList = null;

     024    private List<HashMap<String, Object>> list;

     025    private MyAdapter myAdapet;

     026    private MyHandler myHandler;

     027

     028    @Override

     029    public void onCreate(Bundle savedInstanceState) {

     030        super.onCreate(savedInstanceState);

     031        setContentView(R.layout.main);

     032

     033        myHandler = new MyHandler();

     034

     035        findView();

     036        addListerner();

     037        initList();

     038    }

     039

     040    private void findView() {

     041        testDo = (Button) findViewById(R.id.btn_test);

     042        progressList = (ListView) findViewById(R.id.lst_progress);

     043    }

     044

     045    private void addListerner() {

     046        testDo.setOnClickListener(new ClickEvent());

     047    }

     048

     049    private void initList() {

     050        list = new ArrayList<HashMap<String, Object>>();

     051        HashMap<String, Object> dataA = new HashMap<String, Object>();

     052        HashMap<String, Object> dataB = new HashMap<String, Object>();

     053        dataA.put("title", "dataA");

     054        dataA.put("current", 0);

     055        list.add(dataA);

     056        dataB.put("title", "dataB");

     057        dataB.put("current", 0);

     058        list.add(dataB);

     059

     060        myAdapet = new MyAdapter(TestListProgress.this, list);

     061        progressList.setAdapter(myAdapet);

     062

     063    }

     064

     065    // 模拟处理线程

     066    class UpdateRunnable implements Runnable {

     067        int id;

     068        int currentPos = 0;

     069        int delay;

     070        MyHandler handler;

     071

     072        public UpdateRunnable(int id, int delay, MyHandler handler) {

     073            this.id = id;

     074            this.handler = handler;

     075            this.delay = delay;

     076        }

     077

     078        @Override

     079        public void run() {

     080            // TODO Auto-generated method stub

     081            while (currentPos <= 100) {

     082                Message msg = handler.obtainMessage();

     083                msg.what = 1;

     084                msg.arg1 = id;

     085                msg.arg2 = currentPos;

     086                currentPos = currentPos + 5;

     087                msg.sendToTarget();

     088                try {

     089                    Thread.sleep(delay);

     090                } catch (InterruptedException e) {

     091                    // TODO Auto-generated catch block

     092                    e.printStackTrace();

     093                }

     094            }

     095        }

     096

     097    }

     098

     099    // 消息Handler用来更新UI

     100    class MyHandler extends Handler {

     101        @Override

     102        public void handleMessage(Message msg) {

     103            // TODO Auto-generated method stub

     104            switch (msg.what) {

     105            case 1:

     106                int id = msg.arg1;

     107                int current = msg.arg2;

     108                updateProgress(id, current);

     109                break;

     110            }

     111            super.handleMessage(msg);

     112        }

     113

     114        private void updateProgress(int id, int currentPos) {

     115            HashMap<String, Object> dataTemp = list.get(id);

     116            dataTemp.put("current", currentPos);

     117            myAdapet.chargeProgress(id, dataTemp);

     118        }

     119    }

     120

     121    // 按钮事件

     122    class ClickEvent implements View.OnClickListener {

     123

     124        @Override

     125        public void onClick(View v) {

     126            // TODO Auto-generated method stub

     127            switch (v.getId()) {

     128            case (R.id.btn_test):

     129                new Thread(new UpdateRunnable(0, 400, myHandler)).start();

     130                new Thread(new UpdateRunnable(1, 200, myHandler)).start();

     131                System.out.println("OnClick");

     132                break;

     133            }

     134        }

     135

     136    }

     137

     138    // List的显示

     139    class MyAdapter extends BaseAdapter {

     140

     141        List<HashMap<String, Object>> list;

     142        LayoutInflater infl = null;

     143

     144        public MyAdapter(Context context, List<HashMap<String, Object>> list) {

     145            this.infl = (LayoutInflater) context

     146                    .getSystemService(Context.LAYOUT_INFLATER_SERVICE);

     147            this.list = list;

     148        }

     149

     150        @Override

     151        public int getCount() {

     152            // TODO Auto-generated method stub

     153            return list.size();

     154        }

     155

     156        @Override

     157        public Object getItem(int position) {

     158            // TODO Auto-generated method stub

     159            return list.get(position);

     160        }

     161

     162        @Override

     163        public long getItemId(int position) {

     164            // TODO Auto-generated method stub

     165            return position;

     166        }

     167

     168        @Override

     169        public View getView(int position, View convertView, ViewGroup parent) {

     170            // TODO Auto-generated method stub

     171            convertView = infl.inflate(R.layout.list_layout, null);

     172            ProgressBar progressBar = (ProgressBar) convertView

     173                    .findViewById(R.id.progress);

     174            TextView titleView = (TextView) convertView

     175                    .findViewById(R.id.title);

     176

     177            HashMap<String, Object> detail = list.get(position);

     178            String t = (String) detail.get("title");

     179            titleView.setText(t);

     180            int progress = (Integer) detail.get("current");

     181            progressBar.setProgress(progress);

     182            return convertView;

     183        }

     184

     185        // 改变进度，postion就是要改的那个进度

     186        public void chargeProgress(int postion, HashMap<String, Object> detail) {

     187            this.list.set(postion, detail);

     188            // System.out.println("charged:" + detail.get("current"));

     189            notifyDataSetChanged();

     190        }

     191

     192    }

     193}

MyAdapet 里面的 chargeProgress是在用来更新List里面的值。

Message里面arg1就是List中的第几个进度条，arg2就是这个进度条里面的当前应该有的进度。what暂时没什么意义，只是为了标识这类消息是用来更新进度条的。本例也只有这一类消息。

这个是List的LayoutXML文件内容：


     01<LinearLayout

     02  xmlns:android="http://schemas.android.com/apk/res/android"

     03  android:orientation="horizontal"

     04  android:layout_width="fill_parent"

     05  android:layout_height="fill_parent">

     06  <TextView  android:id="@+id/title"

     07    android:layout_width="wrap_content"

     08    android:layout_height="wrap_content"

     09    android:text="In list"

     10    android:layout_marginRight="5dip"

     11    >

     12  </TextView>

     13  <ProgressBar android:id="@+id/progress"

     14    android:layout_width="wrap_content"

     15    android:layout_height="wrap_content"

     16    style="?android:attr/progressBarStyleHorizontal"

     17    android:max="100"

     18    android:layout_weight="1.0"

     19    android:visibility="visible"

     20  />

     21</LinearLayout>

Acitvity的布局：


     01<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"

     02    android:orientation="vertical"

     03    android:layout_width="fill_parent"

     04    android:layout_height="fill_parent"

     05    >

     06<TextView

     07    android:layout_width="fill_parent"

     08    android:layout_height="wrap_content"

     09    android:text="@string/hello"

     10    />

     11    <Button android:id="@+id/btn_test"

     12        android:layout_width="fill_parent"

     13        android:layout_height="wrap_content"

     14        android:text="ListProgress"

     15    />

     16    <ListView android:id="@+id/lst_progress"

     17        android:layout_width="fill_parent"

     18        android:layout_height="wrap_content"

     19        android:layout_weight="1.0"

     20        >

     21    </ListView>

     22</LinearLayout>
