有耗介质中波的传播

 1 %1D FDTD simulation with a simple absorbing boundary condition
 2 % and a TFSF boundary between hy[49] and ez[50].
 3 % dielectric material located ez[100]
 4 SIZE = 300;
 5 LOSS = 0.01;
 6 ez = zeros(1,SIZE);
 7 hy = zeros(1,SIZE-1);
 8 ceze = zeros(1,SIZE);
 9 cezh = zeros(1,SIZE);
10 imp0=377.0;
11 maxTime = 10000;
12 % initialize update coefficient
13 for mm = 1 : 1 : SIZE -1
14     if mm < 150
15         ceze(mm) =  1.0;
16         cezh(mm) = imp0;
17     else
18        ceze(mm) =  (1-LOSS)/(1+LOSS);
19        cezh(mm) = imp0 /9/(1+LOSS);
20     end
21 end
22
23 for qTime = 0 : 1 : maxTime
24     % hy(SIZE)=hy(SIZE-1);%
25
26     % update magnetic field
27     for mm = 1 : 1 : SIZE -1
28         hy(mm) = hy(mm) + (ez(mm+1)- ez(mm))/imp0;
29     end
30 % correction for Hy adjacent to TFSF boundary */
31  hy(50)=hy(50)-exp(-(qTime - 30)*(qTime - 30) / 100) / imp0;
32
33     figure(1); t_hy = plot(hy);
34     title('Magnetic Field');
35
36     % ABC
37     ez(1)=ez(2);%
38 %     ez(SIZE)=ez(SIZE-1);%
39
40     for mm = 2 : 1 : SIZE-1
41          ez(mm) = ez(mm)*ceze(mm) + (hy(mm)- hy(mm-1))*cezh(mm);
42     end
43     figure(2); t_ez = plot(ez);
44     title('Electric Field')
45     ez(51) = ez(51) + exp(-(qTime+0.5-(-0.5)-30.0)*(qTime+0.5-(-0.5)-30.0)/100.0);
46
47 %     pause(0.01);
48 % %     refreshdata(t_hy);
49 %     refreshdata(t_ez);
50 %     drawnow;
51 end
