关于STL 中allocator的接口与实现，C++标准有比较清楚的定义：
http://en.wikipedia.org/wiki/Allocator_(C%2B%2B)

关于STL的allocator的标准接口阐述，可阅读另外一篇转载文章：allocator

1. SGI STL版本的allocator并没有遵守C++标准。它只提供simple_alloc类共container使用，设计的allocator名字叫做alloc，有二级配置器。第一级配置采用malloc/free来实现allocate/deallocate，第二级配置器采用针对申请的内存有特别处理，如果大小大于128字节，则转调用第一级配置来分配和释放内存，否则采用memory pool的方式来分配这些小额的内存。在SGI STL中，默认采用第二级内存分配器。具体的可以阅读侯捷的《STL源码剖析》第二章。

2. GNU C++的STL内部借鉴SGI STL的实现，不过它对外的的STL allocator严格遵守C++的标准：

看一下它的代码：（定义在bits/allocator.h文件中）

 1 namespace std
 2  {
 3     template<typename _Tp>
 4       class allocator;
 5
 6     template<>
 7       class allocator<void>
 8       {
 9       public:
10        typedef size_t      size_type;
11        typedef ptrdiff_t   difference_type;
12        typedef void*       pointer;
13        typedef const void* const_pointer;
14        typedef void        value_type;
15
16        template<typename _Tp1>
17          struct rebind
18          { typedef allocator<_Tp1> other; };
19      };
20
21    /**
22     *  @brief  The "standard" allocator, as per [20.4].
23     *
24     *  (See @link Allocators allocators info @endlink for more.)
25     */
26    template<typename _Tp>
27      class allocator: public ___glibcxx_base_allocator<_Tp>
28      {
29     public:
30        typedef size_t     size_type;
31        typedef ptrdiff_t  difference_type;
32        typedef _Tp*       pointer;
33        typedef const _Tp* const_pointer;
34        typedef _Tp&       reference;
35        typedef const _Tp& const_reference;
36
37        typedef _Tp        value_type;
38
39        template<typename _Tp1>
40          struct rebind
41          { typedef allocator<_Tp1> other; };
42
43        allocator() throw() { }
44
45        allocator(const allocator& a) throw()
46        : ___glibcxx_base_allocator<_Tp>(a) { }
47
48        template<typename _Tp1>
49          allocator(const allocator<_Tp1>&) throw() { }
50
51        ~allocator() throw() { }
52
53        // Inherit everything else.
54      };
55
56    template<typename _T1, typename _T2>
57      inline bool
58      operator==(const allocator<_T1>&, const allocator<_T2>&)
59      { return true; }
60
61    template<typename _T1, typename _T2>
62      inline bool
63      operator!=(const allocator<_T1>&, const allocator<_T2>&)
64      { return false; }
65
66    // Inhibit implicit instantiations for required instantiations,
67    // which are defined via explicit instantiations elsewhere.
68    // NB: This syntax is a GNU extension.
69  #if _GLIBCXX_EXTERN_TEMPLATE
70    extern template class allocator<char>;
71
72    extern template class allocator<wchar_t>;
73  #endif
74
75    // Undefine.
76  #undef ___glibcxx_base_allocator
77  } // namespace std

template 类___glibcxx_base_allocator 定义在具体的平台相关的头文件中，例如i386-redhat-linux/bits/c++allocator.h:

1 // Define new_allocator as the base class to std::allocator.
2 #include <ext/new_allocator.h>
3 #define ___glibcxx_base_allocator  __gnu_cxx::new_allocator

根据GCC/libstdc++的DOC： http://gcc.gnu.org/onlinedocs/libstdc++/manual/bk01pt04ch11.html，知道

The current default choice for allocator is __gnu_cxx::new_allocator.

可以看出GNU c++的allocator其实采用的是new/delete-based allocation.

 1 namespace __gnu_cxx
 2  {
 3     /**
 4      *  @brief  An allocator that uses global new, as per [20.4].
 5      *
 6      *  This is precisely the allocator defined in the C++ Standard.
 7      *    - all allocation calls operator new
 8      *    - all deallocation calls operator delete
 9      *
10     *  (See @link Allocators allocators info @endlink for more.)
11     */
12    template<typename _Tp>
13      class new_allocator
14      {
15      public:
16        typedef size_t     size_type;
17        typedef ptrdiff_t  difference_type;
18        typedef _Tp*       pointer;
19        typedef const _Tp* const_pointer;
20        typedef _Tp&       reference;
21        typedef const _Tp& const_reference;
22        typedef _Tp        value_type;
23
24        template<typename _Tp1>
25          struct rebind
26          { typedef new_allocator<_Tp1> other; };
27
28        new_allocator() throw() { }
29
30        new_allocator(const new_allocator&) throw() { }
31
32        template<typename _Tp1>
33          new_allocator(const new_allocator<_Tp1>&) throw() { }
34
35        ~new_allocator() throw() { }
36
37
38        pointer
39        address(reference __x) const { return &__x; }
40
41        const_pointer
42        address(const_reference __x) const { return &__x; }
43
44        // NB: __n is permitted to be 0.  The C++ standard says nothing
45        // about what the return value is when __n == 0.
46        pointer
47        allocate(size_type __n, const void* = 0)
48        { return static_cast<_Tp*>(::operator new(__n * sizeof(_Tp))); }
49
50        // __p is not permitted to be a null pointer.
51        void
52        deallocate(pointer __p, size_type)
53        { ::operator delete(__p); }
54
55        size_type
56        max_size() const throw()
57        { return size_t(-1) / sizeof(_Tp); }
58
59        // _GLIBCXX_RESOLVE_LIB_DEFECTS
60        // 402. wrong new expression in [some_] allocator::construct
61        void
62        construct(pointer __p, const _Tp& __val)
63        { ::new(__p) _Tp(__val); }
64
65        void
66        destroy(pointer __p) { __p->~_Tp(); }
67      };
68
69    template<typename _Tp>
70      inline bool
71      operator==(const new_allocator<_Tp>&, const new_allocator<_Tp>&)
72      { return true; }
73
74
75    template<typename _Tp>
76      inline bool
77      operator!=(const new_allocator<_Tp>&, const new_allocator<_Tp>&)
78      { return false; }
79  } // namespace __gnu_cxx
80

不过GNU GCC提供了更多很有意思的定制allocator: __gnu_cxx::malloc_allocator(malloc_allocator.h), __gnu_cxx::bitmap_allocator (bitmap_allocator.h), __gnu_cxx::pool_allocator(pool_allocator.h), and __gnu_cxx::__mt_alloc(mt_allocator.h)

可通过--enable-libstdcxx-allocator 选项来开启其它的allocator，或者在定义一个container时，显式的描述模板参数表示用哪一个allocator:

std::vector <int, __gnu_cxx::malloc_allocator<int> >  malloc_vector;

3. MSVC的STL采用了P.J. Plauger的版本：allocator类定义在了include/xmemory文件中（以VS2008为例）：

        // TEMPLATE FUNCTION _Allocate
template<class _Ty> inline
    _Ty _FARQ *_Allocate(_SIZT _Count, _Ty _FARQ *)
    {    // check for integer overflow
    if (_Count <= 0)
        _Count = 0;
    else if (((_SIZT)(-1) / _Count) < sizeof (_Ty))
        _THROW_NCEE(std::bad_alloc, NULL);

        // allocate storage for _Count elements of type _Ty
    return ((_Ty _FARQ *)::operator new(_Count * sizeof (_Ty)));
    }

        // TEMPLATE FUNCTION _Construct
template<class _T1,
    class _T2> inline
    void _Construct(_T1 _FARQ *_Ptr, const _T2& _Val)
    {    // construct object at _Ptr with value _Val
    void _FARQ *_Vptr = _Ptr;
    ::new (_Vptr) _T1(_Val);
    }

        // TEMPLATE FUNCTION _Destroy
template<class _Ty> inline
    void _Destroy(_Ty _FARQ *_Ptr)
    {    // destroy object at _Ptr
    _DESTRUCTOR(_Ty, _Ptr);
    }

template<> inline
    void _Destroy(char _FARQ *)
    {    // destroy a char (do nothing)
    }

template<> inline
    void _Destroy(wchar_t _FARQ *)
    {    // destroy a wchar_t (do nothing)
    }

它的_Allocate模板函数直接采用全局的operator new来分配内存。

        // TEMPLATE CLASS _Allocator_base
template<class _Ty>
    struct _Allocator_base
    {    // base class for generic allocators
    typedef _Ty value_type;
    };

        // TEMPLATE CLASS _Allocator_base<const _Ty>
template<class _Ty>
    struct _Allocator_base<const _Ty>
    {    // base class for generic allocators for const _Ty
    typedef _Ty value_type;
    };

        // TEMPLATE CLASS allocator
template<class _Ty>
    class allocator
        : public _Allocator_base<_Ty>
    {    // generic allocator for objects of class _Ty
public:
    typedef _Allocator_base<_Ty> _Mybase;
    typedef typename _Mybase::value_type value_type;
    typedef value_type _FARQ *pointer;
    typedef value_type _FARQ& reference;
    typedef const value_type _FARQ *const_pointer;
    typedef const value_type _FARQ& const_reference;

    typedef _SIZT size_type;
    typedef _PDFT difference_type;

    template<class _Other>
        struct rebind
        {    // convert an allocator<_Ty> to an allocator <_Other>
        typedef allocator<_Other> other;
        };

    pointer address(reference _Val) const
        {    // return address of mutable _Val
        return (&_Val);
        }

    const_pointer address(const_reference _Val) const
        {    // return address of nonmutable _Val
        return (&_Val);
        }

    allocator() _THROW0()
        {    // construct default allocator (do nothing)
        }

    allocator(const allocator<_Ty>&) _THROW0()
        {    // construct by copying (do nothing)
        }

    template<class _Other>
        allocator(const allocator<_Other>&) _THROW0()
        {    // construct from a related allocator (do nothing)
        }

    template<class _Other>
        allocator<_Ty>& operator=(const allocator<_Other>&)
        {    // assign from a related allocator (do nothing)
        return (*this);
        }

    void deallocate(pointer _Ptr, size_type)
        {    // deallocate object at _Ptr, ignore size
        ::operator delete(_Ptr);
        }

    pointer allocate(size_type _Count)
        {    // allocate array of _Count elements
        return (_Allocate(_Count, (pointer)0));
        }

    pointer allocate(size_type _Count, const void _FARQ *)
        {    // allocate array of _Count elements, ignore hint
        return (allocate(_Count));
        }

    void construct(pointer _Ptr, const _Ty& _Val)
        {    // construct object at _Ptr with value _Val
        _Construct(_Ptr, _Val);
        }

    void destroy(pointer _Ptr)
        {    // destroy object at _Ptr
        _Destroy(_Ptr);
        }

    _SIZT max_size() const _THROW0()
        {    // estimate maximum array size
        _SIZT _Count = (_SIZT)(-1) / sizeof (_Ty);
        return (0 < _Count ? _Count : 1);
        }
    };

        // allocator TEMPLATE OPERATORS
template<class _Ty,
    class _Other> inline
    bool operator==(const allocator<_Ty>&, const allocator<_Other>&) _THROW0()
    {    // test for allocator equality (always true)
    return (true);
    }

template<class _Ty,
    class _Other> inline
    bool operator!=(const allocator<_Ty>&, const allocator<_Other>&) _THROW0()
    {    // test for allocator inequality (always false)
    return (false);
    }

        // CLASS allocator<void>
template<> class _CRTIMP2_PURE allocator<void>
    {    // generic allocator for type void
public:
    typedef void _Ty;
    typedef _Ty _FARQ *pointer;
    typedef const _Ty _FARQ *const_pointer;
    typedef _Ty value_type;

    template<class _Other>
        struct rebind
        {    // convert an allocator<void> to an allocator <_Other>
        typedef allocator<_Other> other;
        };

    allocator() _THROW0()
        {    // construct default allocator (do nothing)
        }

    allocator(const allocator<_Ty>&) _THROW0()
        {    // construct by copying (do nothing)
        }

    template<class _Other>
        allocator(const allocator<_Other>&) _THROW0()
        {    // construct from related allocator (do nothing)
        }

    template<class _Other>
        allocator<_Ty>& operator=(const allocator<_Other>&)
        {    // assign from a related allocator (do nothing)
        return (*this);
        }
    };
