1.安装grafana

[root@mysql /data]# wget https://s3-us-west-2.amazonaws.com/grafana-releases/release/grafana-4.4.3-1.x86_64.rpm
[root@mysql /data]# yum install initscripts fontconfig
[root@mysql /data]# rpm -ivh grafana-4.4.3-1.x86_64.rpm

1.1.安装open-falcon请参考

https://blog.youkuaiyun.com/wanchaopeng/article/details/80826334 #网站

https://blog.youkuaiyun.com/wanchaopeng/article/details/80825114 自动化安装脚本

1.2 报错

[root@mysql /data]# rpm -ivh grafana-4.4.3-1.x86_64.rpm
可能报错:
warning: grafana-4.4.3-1.x86_64.rpm: Header V4 RSA/SHA1 Signature, key ID 24098cb6: NOKEY
error: Failed dependencies:
    urw-fonts is needed by grafana-4.4.3-1.x86_64
解决报错:
[root@mysql /data]# <span style="color:#ff0000;">yum install -y urw-fonts</span>
解决报错

1.3开启服务加入开机自启动

[root@mysql /data]# systemctl start grafana-server.service
[root@mysql /data]# systemctl status grafana-server.service
Active: active (running) since Tue 2018-06-12 18:54:14 CST; 3h 42min ago
[root@mysql /data]# systemctl enable grafana-server.service
[root@mysql /data]# systemctl is-enabled grafana-server.service

配置文件在/etc/grafana目录下,可以在grafana.ini配置文件中能够修改和查看日志等文件的具体路径

1.4.下载open-falcon grafana的plugin

[root@mysql /data]# git clone https://github.com/open-falcon/grafana-openfalcon-datasource
[root@mysql /data]# mv grafana-openfalcon-datasource /var/lib/grafana/plugins/grafana-openfalcon-datasource-master

#移动到grafana目录中并且改名路径要与/etc/grafana/grafana.ini中的路径一致
