仿手Q空间首页_可渐变的TopBar

关注公众号“码农帮派”，查看更多系列技术文章：



首先是模仿效果：



项目模仿了手Q空间首页，主要是实现了一个可以随着ListView的滑动，逐渐改变自身Alpha数值的TopBar。



使用了View自定义属性，首先需要在res/values/attrs.xml中声明新属性：



<?xml version="1.0" encoding="utf-8"?>
<resources>

    <declare-styleable name="TopBar">
        <attr name="titleTextColor" format="color"/>
        <attr name="titleTextSize" format="dimension"/>
        <attr name="titleText" format="string"/>
    </declare-styleable>

</resources>







TopBar的布局文件（res/layout/activity_main.xml）：



<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:orientation="vertical">

    <LinearLayout
        android:id="@+id/relative_main_bottom"
        android:layout_width="match_parent"
        android:layout_height="60dp"
        android:layout_alignParentBottom="true"
        android:layout_marginBottom="-1dp"
        android:layout_marginLeft="-1dp"
        android:layout_marginRight="-1dp"
        android:background="@drawable/shape_bottom"
        android:gravity="center_vertical"
        android:orientation="horizontal"
        >


        <Button
            android:layout_width="0dp"
            android:layout_height="50dp"
            android:layout_gravity="center_vertical"
            android:layout_marginLeft="8dp"
            android:layout_marginRight="4dp"
            android:layout_weight="1"
            android:background="@drawable/shape_qqphone"
            android:gravity="center"
            android:text="QQ电话"
            android:textColor="@color/blue_app"
            android:textSize="16dp"
            />

        <Button
            android:layout_width="0dp"
            android:layout_height="50dp"
            android:layout_gravity="center_vertical"
            android:layout_marginLeft="4dp"
            android:layout_marginRight="8dp"
            android:layout_weight="1"
            android:background="@drawable/shape_sendmsg"
            android:gravity="center"
            android:text="发消息"
            android:textColor="@color/white"
            android:textSize="16dp"
            />

    </LinearLayout>


    <ListView
        android:id="@+id/listView_main"
        android:layout_width="match_parent"
        android:layout_height="wrap_content"
        android:layout_above="@id/relative_main_bottom"
        android:layout_marginBottom="13dp"
        android:divider="@color/white"
        android:dividerHeight="0dp"
        />


    <com.tencent.alphatopbar.TopBar
        android:id="@+id/topBar_main"
        android:layout_width="match_parent"
        android:layout_height="@dimen/mTopbatTargetOffset"
        android:background="@color/colorPrimary"
        app:titleText="个人资料"
        app:titleTextColor="@color/white"
        app:titleTextSize="17dp"
        >

        <LinearLayout
            android:id="@+id/line_main_back"
            android:layout_width="wrap_content"
            android:layout_height="match_parent"
            android:layout_alignParentLeft="true"
            android:gravity="center_vertical"
            android:orientation="horizontal"
            >

            <ImageView
                android:layout_width="23dp"
                android:layout_height="23dp"
                android:layout_gravity="center_vertical"
                android:layout_marginLeft="9dp"
                android:background="@drawable/back_bg_icon"
                />

            <TextView
                android:id="@+id/tv_main_back"
                android:layout_width="wrap_content"
                android:layout_height="wrap_content"
                android:layout_gravity="center_vertical"
                android:text="返回"
                android:textColor="@color/white"
                android:textSize="15dp"
                />

        </LinearLayout>

    </com.tencent.alphatopbar.TopBar>
</RelativeLayout>







[注意]

以为TopBar继承了RelativeLayout，因此可以像RelativeLayout一样布局内部控件。



下面是最重要的部分，TopBar的实现：



package com.tencent.alphatopbar;

import android.annotation.TargetApi;
import android.content.Context;
import android.content.res.TypedArray;
import android.graphics.Canvas;
import android.graphics.Color;
import android.graphics.Paint;
import android.graphics.Rect;
import android.os.Build;
import android.text.TextUtils;
import android.util.AttributeSet;
import android.util.Log;
import android.widget.RelativeLayout;
import android.widget.TextView;

/**
 * Created by maxiaodong on 16/8/3.
 */
public class TopBar extends RelativeLayout
{

    Paint mPaint = null;
    private String titleText = "";
    private int titleTextColor = 0x000000;
    private int titleTextSize = 12;

    Rect mBounds;

    public TopBar(Context context)
    {
        super(context);
    }

    public TopBar(Context context, AttributeSet attrs)
    {
        super(context, attrs);

        init(context, attrs);
    }

    public TopBar(Context context, AttributeSet attrs, int defStyleAttr)
    {
        super(context, attrs, defStyleAttr);

        init(context, attrs);
    }

    private void init(Context context, AttributeSet attrs)
    {
        mPaint = new Paint();
        TypedArray array = context.obtainStyledAttributes(attrs, R.styleable.TopBar);

        titleText = array.getString(R.styleable.TopBar_titleText);
        if (TextUtils.isEmpty(titleText))
        {
            titleText = "";
        }
        titleTextColor = array.getColor(R.styleable.TopBar_titleTextColor, Color.BLACK);
        titleTextSize = array.getDimensionPixelSize(R.styleable.TopBar_titleTextSize, 12);
        array.recycle();

        mPaint = new Paint(Paint.ANTI_ALIAS_FLAG);
        mBounds = new Rect();

        mPaint.setColor(titleTextColor);
        mPaint.setTextSize(titleTextSize);
    }

    @Override
    protected void onDraw(Canvas canvas)
    {
        super.onDraw(canvas);

        mPaint.getTextBounds(titleText, 0, titleText.length(), mBounds);
        float textWidth = mBounds.width();
        float textHeight = mBounds.height();

        canvas.drawText(titleText, getWidth() / 2 - textWidth / 2, getHeight() / 2
                + textHeight / 2, mPaint);
    }

    /**
     * 修改TopBar背景的透明度
     *
     * @alpha 透明度 取值范围在[0, 255]
     */
    public void setBackgroundAlpha(int alpha)
    {
        this.getBackground().setAlpha(alpha);
    }

    /***
     * 计算TopBar当前的透明度
     *
     * @param currentOffset
     * @param alphaTargetOffset currentOffset == alphaTargetOffset时，透明度为1
     */
    public void computeAndsetBackgroundAlpha(int currentOffset, int alphaTargetOffset)
    {
        float alpha = currentOffset * 1.0f / alphaTargetOffset;
        alpha = Math.max(0, Math.min(alpha, 1));
        int alphaInt = (int) (alpha * 255);
        this.setBackgroundAlpha(alphaInt);
    }

}







最后要在MainActivity.java中，将ListView的滑动和TopBar绑定在一起，这样才能实现TopBar背景的渐变：



listView_main.setOnScrollListener(new AbsListView.OnScrollListener()
{
    @Override
    public void onScrollStateChanged(AbsListView absListView, int i)
    {
    }

    @Override
    public void onScroll(AbsListView absListView, int i, int i1, int i2)
    {
        topBar_main.computeAndsetBackgroundAlpha(getScrollY() / 1, mTopbatTargetOffset);
    }
});







注意：因为项目中使用到了v7中的RecycleView，所以需要引入（app/build.gradle）：



compile "com.android.support:recyclerview-v7:${supportLibVersion}"



当然此处也可以使用Android的画廊布局gallery，但是gallery已经被抛弃。



完整的项目下载（代码比较乱，仅提供TopBar渐变的参考）：

https://github.com/BaijiaDong/-Q-.git
