docker日志采集elk efk fluentd采集

第一步: Create docker-compose.yml

创建docker-合成.yml对于Docker Compose。Docker Compose是一个用于定义和运行多容器Docker应用程序的工具。通过下面的YAML文件，您可以通过一个命令创建和启动所有服务（在本例中是Apache、Fluentd、Elasticsearch、Kibana）：

version: '3'
services:
  fluentd:
    build: ./fluentd
    volumes:
      - ./fluentd/conf:/fluentd/etc
    links:
      - "elasticsearch"
    ports:
      - "24224:24224"
      - "24224:24224/udp"

  elasticsearch:
    image: docker.elastic.co/elasticsearch/elasticsearch:7.2.0
    environment:
      - "discovery.type=single-node"
    expose:
      - "9200"
    ports:
      - "9200:9200"

  kibana:
    image: kibana:7.2.0
    links:
      - "elasticsearch"
    ports:
      - "5601:5601"

如果你已经安装es及kibana,则可使用下面的配置

version: '3'
services:
  fluentd:
    build: .
    volumes:
      - ./fluentd/conf:/fluentd/etc
    privileged: true
    ports:
      - "24224:24224"
      - "24224:24224/udp"
    environment:
      - TZ=Asia/Shanghai
    restart: always
    logging:
        driver: "json-file"
        options:
            max-size: 100m
            max-file: "5"

使用Config+插件创建Fluentd映像

使用fluentd官方Docker映像创建包含以下内容的fluentd/Dockerfile；然后安装Elasticsearch插件：

# fluentd/Dockerfile

FROM fluent/fluentd:v1.6-debian-1
USER root
RUN ["gem", "install", "fluent-plugin-elasticsearch", "--no-document", "--version", "4.2.0"]
USER fluent

然后，创建Fluentd配置文件fluentd/conf/fluent.conf。转发输入插件从Docker日志驱动程序接收日志，elasticsearch输出插件将这些日志转发到elasticsearch。

# fluentd/conf/fluent.conf

<source>
  @type forward
  port 24224
  bind 0.0.0.0
</source>
<match docker.**>
  @type copy
  <store>
    @type elasticsearch
    host elasticsearch
    port 9200
    logstash_format true
    logstash_prefix sharechef-logs
    logstash_dateformat %Y%m%d
    include_tag_key true
    type_name access_log
    flush_interval 1s
    include_tag_key true
    reconnect_on_error true
	reload_on_failure true
	reload_connections false
    tag_key @log
  </store>
</match>

第二步：启动容器

$ docker-compose up

第三步: 创建验证nginx

docker run -dit -p 80:80\
             --log-driver=fluentd \
             --log-opt fluentd-address=localhost:24224 \
             --log-opt tag="docker.``.`Name`" \
             --name nginx \
             nginx

curl 127.0.0.1

#查看日志
docker logs fluentd容器id

127.0.0.1:5601
登录kibana
GET _cat/indices

#查看索引
GET /docker-logs-20200925/_search
{
  "query": {
    "match_all": {}
  }
}
