The Fork/Join library introduced in Java 7 extends the existing Java concurrency package with support for hardware parallelism, a key feature of multicore systems. In this Java Tip Madalin Ilie demonstrates the performance impact of replacing the Java 6 ExecutorService class with Java 7's ForkJoinPool in a web crawler application.

FEATURED RESOURCE
Presented by Zero Turnaround
Coding with JRebel: Java Forever Changed

With JRebel, developers get to see their code changes immediately, fine-tune their code with

LEARN MORE

Web crawlers, also known as web spiders, are key to the success of search engines. These programs perpetually scan the web, gathering up millions of pages of data and sending it back to search-engine databases. The data is then indexed and processed algorithmically, resulting in faster, more accurate search results. While they are most famously used for search optimization, web crawlers also can be used for automated tasks such as link validation or finding and returning specific data (such as email addresses) in a collection of web pages.

Architecturally, most web crawlers are high-performance multithreaded programs, albeit with relatively simple functionality and requirements. Building a web crawler is therefore an interesting way to practice, as well as compare, multithreaded, or concurrent, programming techniques.

The return of Java Tips!

Java Tips are short, code-driven articles that invite JavaWorld readers to share their programming skills and discoveries. Let us know if you have a tip to share with the JavaWorld community. Also check out the Java Tips Archive for more programming tips from your peers.

In this article I'll walk through two approaches to writing a web crawler: one using the Java 6 ExecutorService, and the other Java 7's ForkJoinPool. In order to follow the examples, you'll need to have (as of this writing) Java 7 update 2installed in your development environment, as well as the third-party libraryHtmlParser.

Two approaches to Java concurrency

The ExecutorService class is part of the java.util.concurrent revolution introduced in Java 5 (and part of Java 6, of course), which simplified thread-handling on the Java platform. ExecutorService is an Executor that provides methods to manage the progress-tracking and termination of asynchronous tasks. Prior to the introduction of java.util.concurrent, Java developers relied on third-party libraries or wrote their own classes to manage concurrency in their programs.

Fork/Join, introduced in Java 7, isn't intended to replace or compete with the existing concurrency utility classes; instead it updates and completes them. Fork/Join addresses the need for divide-and-conquer, or recursivetask-processing in Java programs (see Resources).

Fork/Join's logic is very simple: (1) separate (fork) each large task into smaller tasks; (2) process each task in a separate thread (separating those into even smaller tasks if necessary); (3) join the results.

The two web crawler implementations that follow are simple programs that demonstrate the features and functionality of the Java 6ExecutorService and the Java 7 ForkJoinPool.

Building and benchmarking the web crawler

Our web crawler's task will be to find and follow links. Its purpose could be link validation, or it could be gathering data. (You might, for instance, instruct the program to search the web for pictures of Angelina Jolie, or Brad Pitt.)

The application architecture consists of the following:

  1. An interface that exposes basic operations to interact with links; i.e., get the number of visited links, add new links to be visited in queue, mark a link as visited
  2. An implementation for this interface that will also be the starting point of the application
  3. A thread/recursive action that will hold the business logic to check whether a link has already been visited. If not, it will gather all the links in the corresponding page, create a new thread/recursive task, and submit it to the ExecutorService orForkJoinPool
  4. An ExecutorService or ForkJoinPool to handle waiting tasks

Note that a link is considered "visited" after all links in the corresponding page have been returned.

In addition to comparing ease of development using the concurrency tools available in Java 6 and Java 7, we'll compare application performance based on two benchmarks:

  • Search coverage: Measures the time required to visit 1,500 distinct links
  • Processing power: Measures the time in seconds required to visit 3,000 non-distinct links; this is like measuring how many kilobits per second your Internet connection processes.

While relatively simple, these benchmarks will provide at least a small window into the performance of Java concurrency in Java 6 versus Java 7 for certain application requirements.

A Java 6 web crawler built with ExecutorService

For the Java 6 web crawler implementation we'll use a fixed-thread pool of 64 threads, which we create by calling the Executors.newFixedThreadPool(int) factory method. Listing 1 shows the main class implementation.

Listing 1. Constructing a WebCrawler

package insidecoding.webcrawler;

import java.util.Collection;
import java.util.Collections;
import java.util.concurrent.ExecutorService;
import java.util.concurrent.Executors;
import insidecoding.webcrawler.net.LinkFinder;
import java.util.HashSet;

/**
 *
 * @author Madalin Ilie
 */
public class WebCrawler6 implements LinkHandler {

    private final Collection<String> visitedLinks = Collections.synchronizedSet(new HashSet<String>());
//    private final Collection<String> visitedLinks = Collections.synchronizedList(new ArrayList<String>());
    private String url;
    private ExecutorService execService;

    public WebCrawler6(String startingURL, int maxThreads) {
        this.url = startingURL;
        execService = Executors.newFixedThreadPool(maxThreads);
    }

    @Override
    public void queueLink(String link) throws Exception {
        startNewThread(link);
    }

    @Override
    public int size() {
        return visitedLinks.size();
    }

    @Override
    public void addVisited(String s) {
        visitedLinks.add(s);
    }

    @Override
    public boolean visited(String s) {
        return visitedLinks.contains(s);
    }

    private void startNewThread(String link) throws Exception {
        execService.execute(new LinkFinder(link, this));
    }

    private void startCrawling() throws Exception {
        startNewThread(this.url);
    }

    /**
     * @param args the command line arguments
     */
    public static void main(String[] args) throws Exception {
        new WebCrawler("http://www.javaworld.com", 64).startCrawling();
    }
}

In the above WebCrawler6 constructor, we create a fixed-size thread pool of 64 threads. We then start the program by calling the startCrawling method, which creates the first thread and submits it to the ExecutorService.

Next, we create a LinkHandler interface, which exposes helper methods to interact with URLs. Requirements are as follows: (1) mark a URL as visited using theaddVisited() method; (2) get the number of the visited URLs through the size() method; (3) determine whether a URL has been already visited using the visited() method; and (4) add a new URL in the queue through the queueLink() method.

Listing 2. The LinkHandler interface

package insidecoding.webcrawler;

/**
 *
 * @author Madalin Ilie
 */
public interface LinkHandler {

    /**
     * Places the link in the queue
     * @param link
     * @throws Exception
     */
    void queueLink(String link) throws Exception;

    /**
     * Returns the number of visited links
     * @return
     */
    int size();

    /**
     * Checks if the link was already visited
     * @param link
     * @return
     */
    boolean visited(String link);

    /**
     * Marks this link as visited
     * @param link
     */
    void addVisited(String link);
}

Now, as we crawl pages, we need to start up the rest of the threads, which we do via the LinkFinder interface, as shown in Listing 3. Note the linkHandler.queueLink(l)line.

Listing 3. LinkFinder

package insidecoding.webcrawler.net;

import java.net.URL;
import org.htmlparser.Parser;
import org.htmlparser.filters.NodeClassFilter;
import org.htmlparser.tags.LinkTag;
import org.htmlparser.util.NodeList;
import insidecoding.webcrawler.LinkHandler;

/**
 *
 * @author Madalin Ilie
 */
public class LinkFinder implements Runnable {

    private String url;
    private LinkHandler linkHandler;
    /**
     * Used fot statistics
     */
    private static final long t0 = System.nanoTime();

    public LinkFinder(String url, LinkHandler handler) {
        this.url = url;
        this.linkHandler = handler;
    }

    @Override
    public void run() {
        getSimpleLinks(url);
    }

    private void getSimpleLinks(String url) {
        //if not already visited
        if (!linkHandler.visited(url)) {
            try {
                URL uriLink = new URL(url);
                Parser parser = new Parser(uriLink.openConnection());
                NodeList list = parser.extractAllNodesThatMatch(new NodeClassFilter(LinkTag.class));
                List<String> urls = new ArrayList<String>();

                 for (int i = 0; i < list.size(); i++) {
                    LinkTag extracted = (LinkTag) list.elementAt(i);

                    if (!extracted.getLink().isEmpty()
                            && !linkHandler.visited(extracted.getLink())) {

                        urls.add(extracted.getLink());
                    }

                }
                //we visited this url
                linkHandler.addVisited(url);

                if (linkHandler.size() == 1500) {
                    System.out.println("Time to visit 1500 distinct links = " + (System.nanoTime() - t0));
                }

                for (String l : urls) {
                    linkHandler.queueLink(l);
                }

             } catch (Exception e) {
                //ignore all errors for now
            }
        }
    }
}

The logic of the LinkFinder is simple: (1) we start parsing a URL; (2) after we gather all the links within the corresponding page, we mark the page as visited; and (3) we send each found link to a queue by calling thequeueLink() method. This method will actually create a new thread and send it to the ExecutorService. If "free" threads are available in the pool, the thread will be executed; otherwise it will be placed in a waiting queue. After we reach 1,500 distinct links visited, we print the statistics and the program continues to run.

A Java 7 web crawler with ForkJoinPool

The Fork/Join framework introduced in Java 7 is actually an implementation of the Divide and Conquer algorithm (see Resources), in which a central ForkJoinPoolexecutes branching ForkJoinTasks. For this example we'll use a ForkJoinPool"backed" by 64 threads. I say backed because ForkJoinTasks are lighter than threads. In Fork/Join, a large number of tasks can be hosted by a smaller number of threads.

Similar to the Java 6 implementation, we start by instantiating in the WebCrawler7constructor a ForkJoinPool object backed by 64 threads.

Listing 4. Java 7 LinkHandler implementation

package insidecoding.webcrawler7;

import java.util.Collection;
import java.util.Collections;
import java.util.concurrent.ForkJoinPool;
import insidecoding.webcrawler7.net.LinkFinderAction;
import java.util.HashSet;

/**
 *
 * @author Madalin Ilie
 */
public class WebCrawler7 implements LinkHandler {

    private final Collection<String> visitedLinks = Collections.synchronizedSet(new HashSet<String>());
//    private final Collection<String> visitedLinks = Collections.synchronizedList(new ArrayList<>());
    private String url;
    private ForkJoinPool mainPool;

    public WebCrawler7(String startingURL, int maxThreads) {
        this.url = startingURL;
        mainPool = new ForkJoinPool(maxThreads);
    }

    private void startCrawling() {
        mainPool.invoke(new LinkFinderAction(this.url, this));
    }

    @Override
    public int size() {
        return visitedLinks.size();
    }

    @Override
    public void addVisited(String s) {
        visitedLinks.add(s);
    }

    @Override
    public boolean visited(String s) {
        return visitedLinks.contains(s);
    }

    /**
     * @param args the command line arguments
     */
    public static void main(String[] args) throws Exception {
        new WebCrawler7("http://www.javaworld.com", 64).startCrawling();
    }
}

Note that the LinkHandler interface in Listing 4 is almost the same as the Java 6 implementation from Listing 2. It's only missing the queueLink() method. The most important methods to look at are the constructor and the startCrawling() method. In the constructor, we create a new ForkJoinPool backed by 64 threads. (I've chosen 64 threads instead of 50 or some other round number because in the ForkJoinPoolJavadoc it states that the number of threads must be a power of two.) The pool invokes a new LinkFinderAction, which will recursively invoke further ForkJoinTasks. Listing 5 shows the LinkFinderAction class:

Listing 5. LinkFinderAction

package insidecoding.webcrawler7.net;

import java.net.URL;
import java.util.ArrayList;
import java.util.List;
import java.util.concurrent.RecursiveAction;
import org.htmlparser.Parser;
import org.htmlparser.filters.NodeClassFilter;
import org.htmlparser.tags.LinkTag;
import org.htmlparser.util.NodeList;
import insidecoding.webcrawler7.LinkHandler;

/**
 *
 * @author Madalin Ilie
 */
public class LinkFinderAction extends RecursiveAction {

    private String url;
    private LinkHandler cr;
    /**
     * Used for statistics
     */
    private static final long t0 = System.nanoTime();

    public LinkFinderAction(String url, LinkHandler cr) {
        this.url = url;
        this.cr = cr;
    }

    @Override
    public void compute() {
        if (!cr.visited(url)) {
            try {
                List<RecursiveAction> actions = new ArrayList<RecursiveAction>();
                URL uriLink = new URL(url);
                Parser parser = new Parser(uriLink.openConnection());
                NodeList list = parser.extractAllNodesThatMatch(new NodeClassFilter(LinkTag.class));

                for (int i = 0; i < list.size(); i++) {
                    LinkTag extracted = (LinkTag) list.elementAt(i);

                    if (!extracted.extractLink().isEmpty()
                            && !cr.visited(extracted.extractLink())) {

                        actions.add(new LinkFinderAction(extracted.extractLink(), cr));
                    }
                }
                cr.addVisited(url);

                if (cr.size() == 1500) {
                    System.out.println("Time for visit 1500 distinct links= " + (System.nanoTime() - t0));
                }

                //invoke recursively
                invokeAll(actions);
            } catch (Exception e) {
                //ignore 404, unknown protocol or other server errors
            }
        }
    }
}

The application logic so far is the same as it was in the Java 6 implementation. The difference in the code is that instead of manually queuing the new links through theLinkHandler class, we submit them to the ForkJoinPoolthrough the invokeAll() static method. Note theinvokeAll(actions) line. The ForkJoinPool will schedule these tasks in the best possible way using the available 64 threads. A recursive action is over when the submitted link has been visited (see if (!cr.visited(url))).

Comparative benchmarks for search coverage: 1,500 distinct links

Now it's time to compare benchmarks. I accounted for JVM warmup when timing the two different implementations: first I ran each program 10 times ignoring the results, then I ran it again 10 times again to compute an average timing. Between running the Java 6 and Java 7 code I also called System.gc() numerous times to manually activate the garbage collector. I invoked both applications using the JVM flags -d64 -Xmx1512m, thus setting the platform to 64 bits and the maximum heap size to 1512 MB (see Resources).

I ran the tests on a Windows 7 SP1 64-bit machine, Intel Core i5 @2.67 GHz with 4,00 GB of RAM. I have installed the 64-bit version of JDK 7 update 2.

The timing of the Java 6 code is as follows (an average of all 10 runs):

Time to visit 1,500 distinct links: 45,404,628,454 nanoseconds
Fastest time: 43,989,514,242 nanoseconds
Slowest time: 47,077,714,098 nanoseconds

And here's the timing for the Java 7 implementation:

Time to visit 1,500 distinct links: 45,269,306,013 nanoseconds
Fastest time: 42,365,714,625 nanoseconds
Slowest time: 59,042,391,887 nanoseconds

As you can see, when accounting for search coverage (tasked with following 1,500 distinct links) there's not much difference between the two implementations.

Comparative benchmarks for processing power: 3,000 non-distinct links

In order to to test the second scenario I had to make some adjustments to both implementations. In both theWebCrawler6 and WebCrawler7 classes, I uncommented the synchronized List and commented the synchronized Set. For a benchmark based on following non-distinct links theSet implementation isn't required, but the List is.

// private final Collection<String> visitedLinks = Collections.synchronizedSet(new HashSet<String>());

private final Collection<String> visitedLinks = Collections.synchronizedList(new ArrayList<String>());

I also changed the visited() method to always return false, because for this benchmark it doesn't matter whether a link has been visited or not.


 @Override
    public boolean visited(String s) {
        return false;//visitedLinks.contains(s);
    }

Finally, I changed the conditions in the LinkFinder and LinkFinderAction classes to check for 3,000 links instead of 1,500:

if (cr.size() == 3000) {
System.out.println("Time for visit 3000 non-distinct links= " + (System.nanoTime() - t0));
}

The resulting benchmarks show that Fork/Join fared better when measuring processing power -- i.e., how many links each application processed per second.

Here's the timing of the Java 6 code, an average of the results for all 10 runs:

Time to visit 3,000 non-distinct links: 48,510,285,967 nanoseconds
Fastest time: 44,189,380,355 nanoseconds
Slowest time: 52,132,053,413 nanoseconds

This measurement is equivalent to 61.8425 links per second.

And here's the timing for the program written using Java 7:

Time to visit 3,000 non-distinct links: 31,343,446,584 nanoseconds
Fastest time: 30,533,600,312 nanoseconds
Slowest time: 33,308,851,937 nanoseconds

This is equivalent to 95.7137 links per second.

The code based on Java 7's ForkJoinPool was 1.5x times faster than the Java 6 code -- a significant performance gain.

Figures 1 and 2 shows the CPU history for each implementation. Note that CPU usage is pretty much the same, even though the ForkJoinPool implementation is faster.

Figure 1. CPU usage for the Java 6 ExecutorService implementation

Figure 2. CPU usage for the Java 7 ForkJoinPool implementation

In conclusion: Fork/Join for recursive programming

While relatively simple, my benchmarks demonstrate that Fork/Join offers serious gains for solving problems that involve recursion. Because recursion is fundamental to parallel programming on multicore platforms (see Resources) Fork/Join is an essential addition to Java platform concurrency. That said, it does not replace the original java.util.concurrencypackage. As I've demonstrated, ExecutorService continues to be a fine solution for many concurrent programming tasks. In a programming scenario such as the one I set up, where effective recursion is key to processing power, Fork/Join is likely to be the most effective solution.

Learn more

This article has briefly introduced two approaches to Java concurrency and demonstrated each one's applicability to two common program requirements: data collection and search coverage. See the Resources section to learn more about java.util.concurrency and the uses of Fork/Join in Java 7.

Madalin Ilie is a software development lead at Endava Romania. He has more than five years' programming experience and has worked in a variety of project domains, from mobile development to heavy financial applications.

Learn more about this topic

Reference: http://www.javaworld.com/article/2078440/enterprise-java/java-tip-when-to-use-forkjoinpool-vs-executorservice.html?null
Java 线程池 ForkJoinPool（一）
gmHappy
12-14 1006
线程管理器（ThreadPool）：用于创建并管理线程池，包括创建线程池，销毁线程池，添加新任务。工作线程（PoolWorker）：线程池中的线程，在没有任务时处于等待状态，可以循环的执行任务；任务接口（Task）：每个任务必须实现的接口，以供工作线程调度任务的执行，它注意规定了任务的入口，任务执行完后的收尾工作，任务的执行状态等；任务队列（taskQueue）：用于存放没有处理的任务，提供一种缓冲机制。
ForkJoinPool VS ExecutorService 实例分析
zhrglchp的专栏
05-30 306
主题：ForkJoinPool VS ExecutorService 实例分析 http://www.iteye.com/topic/1117483
Fork/Join 与 ExecutorService比较
russle的专栏
06-23 4047
上一遍简单介绍了Fork/Join， 很多人自然会产生疑问，Fork/Join与ExecutorService有什么区别，应该选择用哪个？本文简要比较这两者。 先给出官方介绍。oracle关于ForkJoin的官方教程在https://docs.oracle.com/javase/tutorial/essential/concurrency/forkjoin.html 差异： Fork/Jo...
ForkJoinPoll
weixin_34239592的博客
03-16 361
2019独角兽企业重金招聘Python工程师标准>>> ...
ForkJoinPool和ExecutorService实现1到10000的加法
coding change your life
09-23 943
///ForkJoinPool public class Main { public static void main(String[] args) { ForkJoinPool pool=new ForkJoinPool(); CountTask task =new CountTask(1, 1000000); long start=System.currentTimeMill
JDK 7中引入的并发框架Fork/Join（^_^）
jaryle的专栏
09-27 430
Fork/Join 框架是 JDK 1.7 提供的并行执行任务框架，这个框架通过（递归）把问题划分为子任务，然后并行的执行这些子任务，等所有的子任务都结束的时候，再合并最终结果的这种方式来支持并行计算编程。 总体的设计参考了为 Cilk 设计的work-stealing 框架。 Fork/Join 并行方式是获取良好的并行计算性能的一种最简单同时也是最有效的设计技术，是分治算法（Divid...
Java 并发编程笔记：如何使用 ForkJoinPool 以及原理
qq_17312239的博客
03-27 297
前言 Java 1.7 引入了一种新的并发框架—— Fork/Join Framework。 本文的主要目的是介绍 ForkJoinPool 的适用场景，实现原理，以及示例代码。 TLDR;如果觉得文章太长的话，以下就是结论： ForkJoinPool不是为了替代ExecutorService，而是它的补充，在某些应用场景下性能比ExecutorService更好。（见Java...
java fork join原理_ForkJoinPool 的使用以及原理
weixin_35294082的博客
02-24 291
ForkJoinPool 是Java 1.7 引入的一种新的并发框架—— ForkJoin Framework。以下是重要的几点特性：ForkJoinPool 不是为了替代 ExecutorService，而是它的补充，在某些应用场景下性能比 ExecutorService 更好。(见 Java Tip: When to use ForkJoinPool vs ExecutorService )F...
ForkJoinPool 的使用以及原理
weixin_33955681的博客
01-29 490
2019独角兽企业重金招聘Python工程师标准>>> ...
十二：并发编程之Future&ForkJoin框架原理分析
Xx__WangQi的博客
05-25 357
目录 任务性质类型 CPU密集型（CPU-bound） IO密集型（I/O bound） CPU密集型 vs IO密集型 一、什么是 Fork/Join 框架？ 二、工作窃取算法 三、fork/join的使用 四、fork/join框架原理 常量介绍 ForkJoinPool 中的相关常量和实例字段: ForkJoinPool 的内部状态都是通过一个64位的 long 型 变量ctl来存储，它由四个16位的子域组成: 1、异常处理 2、ForkJoinPool构造函数 3、For
如何在Java中使用线程池优化并发性能：从ExecutorService到ForkJoinPool
微赚淘客系统开发者博客
08-18 488
线程池是提高并发性能的重要工具，它可以帮助我们管理和优化线程的创建与销毁，提高系统的吞吐量和响应速度。线程池是一个包含多个线程的池，它可以有效地重用线程，避免频繁创建和销毁线程带来的性能开销。线程池的基本思想是将线程的创建、调度、管理和销毁交给线程池来完成，从而提升系统的整体性能。是Java 7引入的一个特殊线程池，用于处理分治算法中的任务。是Java标准库提供的一个线程池接口，它定义了一组方法来管理线程池的生命周期和任务执行。方法，我们优雅地关闭了线程池，并等待所有任务完成。
Java多线程ForkJoinPool实例详解
08-29
ForkJoinPool的主要组成部分有两个类：ForkJoinPool和ForkJoinTask。ForkJoinPool类实现了ExecutorService接口和工作窃取算法，管理工作者线程，并提供任务的状态信息和执行信息。ForkJoinTask类是一个将在ForkJoin...
Java8多线程ForkJoinPool：处理异常
最佳 Java 编程
05-27 2258
引入Java8 lambda背后的主要动机之一是能够尽可能轻松地使用多核的能力（请参阅精通Lambdas：多核世界中的Java编程 ）。 只需将代码从collection.stream()...更改为collection.parallelStream()...您就可以使用即时多线程，从而为您的计算机带来所有CPU功能。 （在这一点上，让我们忽略争用。） 如果打印出parallelStre...
BRAPH 2.0 is a comprehensive software package for the analys
09-03
BRAPH 2.0 is a comprehensive software package for the analysis and visualization of brain connectivity data, offering flexible customization, rich visualization capabilities, and a platform for collaboration in neuroscience research..zip
光流法C++源代码
09-03
### 光流法C++源代码解析与应用 #### 光流法原理 光流法是一种在计算机视觉领域中用于追踪视频序列中运动物体的方法。它基于亮度不变性假设，即场景中的点在时间上保持相同的灰度值，从而通过分析连续帧之间的像素变化来估计运动方向和速度。在数学上，光流场可以表示为像素位置和时间的一阶导数，即Ex、Ey（空间梯度）和Et（时间梯度），它们共同构成光流方程的基础。 #### C++实现细节 在给定的C++源代码片段中，`calculate`函数负责计算光流场。该函数接收一个图像缓冲区`buf`作为输入，并初始化了几个关键变量：`Ex`、`Ey`和`Et`分别代表沿x轴、y轴和时间轴的像素强度变化；`gray1`和`gray2`用于存储当前帧和前一帧的平均灰度值；`u`则表示计算出的光流矢量大小。 #### 图像处理流程 1. **初始化和预处理**：`memset`函数被用来清零`opticalflow`数组，它将保存计算出的光流数据。同时，`output`数组被填充为白色，这通常用于可视化结果。 2. **灰度计算**：对每一像素点进行处理，计算其灰度值。这里采用的是RGB通道平均值的计算方法，将每个像素的R、G、B值相加后除以3，得到一个近似灰度值。此步骤确保了计算过程的鲁棒性和效率。 3. **光流向量计算**：通过比较当前帧和前一帧的灰度值，计算出每个像素点的Ex、Ey和Et值。这里值得注意的是，光流向量的大小`u`是通过`Et`除以`sqrt(Ex^2 + Ey^2)`得到的，再乘以10进行量化处理，以减少计算复杂度。 4. **结果存储与阈值处理**：计算出的光流值被存储在`opticalflow`数组中。如果`u`的绝对值超过10，则认为该点存在显著运动，因此在`output`数组中将对应位置标记为黑色，形成运动区域的可视化效果。 5. **状态更新**：通过`memcpy`函数将当前帧复制到`prevframe`中，为下一次迭代做准备。 #### 扩展应用：Lukas-Kanade算法 除了上述基础的光流计算外，代码还提到了Lukas-Kanade算法的应用。这是一种更高级的光流计算方法，能够提供更精确的运动估计。在`ImgOpticalFlow`函数中，通过调用`cvCalcOpticalFlowLK`函数实现了这一算法，该函数接受前一帧和当前帧的灰度图，以及窗口大小等参数，返回像素级别的光流场信息。 在实际应用中，光流法常用于目标跟踪、运动检测、视频压缩等领域。通过深入理解和优化光流算法，可以进一步提升视频分析的准确性和实时性能。 光流法及其C++实现是计算机视觉领域的一个重要组成部分，通过对连续帧间像素变化的精细分析，能够有效捕捉和理解动态场景中的运动信息
Rust库，用于构建将C_C代码编译为Rust库的脚本_Rust library for build scripts t
09-03
Rust库，用于构建将C_C代码编译为Rust库的脚本_Rust library for build scripts to compile C_C++ code into a Rust library.zip
微信小程序开发项目源码及效果演示资源
09-03
微信小程序作为腾讯推出的一种轻型应用形式，因其便捷性与高效性，已广泛应用于日常生活中。以下为该平台的主要特性及配套资源说明： 特性方面： 操作便捷，即开即用：用户通过微信内搜索或扫描二维码即可直接使用，无需额外下载安装，减少了对手机存储空间的占用，也简化了使用流程。 多端兼容，统一开发：该平台支持在多种操作系统与设备上运行，开发者无需针对不同平台进行重复适配，可在一个统一的环境中完成开发工作。 功能丰富，接口完善：平台提供了多样化的API接口，便于开发者实现如支付功能、用户身份验证及消息通知等多样化需求。 社交整合，传播高效：小程序深度嵌入微信生态，能有效利用社交关系链，促进用户之间的互动与传播。 开发成本低，周期短：相比传统应用程序，小程序的开发投入更少，开发周期更短，有助于企业快速实现产品上线。 资源内容： “微信小程序-项目源码-原生开发框架-含效果截图示例”这一资料包，提供了完整的项目源码，并基于原生开发方式构建，确保了代码的稳定性与可维护性。内容涵盖项目结构、页面设计、功能模块等关键部分，配有详细说明与注释，便于使用者迅速理解并掌握开发方法。此外，还附有多个实际运行效果的截图，帮助用户直观了解功能实现情况，评估其在实际应用中的表现与价值。该资源适用于前端开发人员、技术爱好者及希望拓展业务的机构，具有较高的参考与使用价值。欢迎查阅，助力小程序开发实践。资源来源于网络分享，仅用于学习交流使用，请勿用于商业，如有侵权请联系我删除！
芋道ruoyi-vue-pro 工作流最新sql
最新发布
09-03
芋道ruoyi-vue-pro 工作流最新sql 注意，bpm_process_definition_info表中deleted这个字段的默认值为0，并没有写手sql语句，请手劝添加！
【最新版】 GJBZ 37.1A-2017《军用电阻器和电位器系列型谱 固定电阻器》.rar
09-03
【最新版】 GJBZ 37.1A-2017《军用电阻器和电位器系列型谱 固定电阻器》.rar
Java线程泄漏问题：ForkJoinPool线程数量持续增长分析
4. 缺乏适当的线程回收机制：ForkJoinPool依赖于工作窃取算法来高效地使用线程，但如果没有适当的任务来窃取，空闲线程将会保持活跃状态等待新任务，这可能会导致线程数量不断上升。 5. 缺少对ForkJoinPool状态的...
评论
添加红包

请填写红包祝福语或标题

个

红包个数最小为10个

元

红包金额最低5元

当前余额3.43元 前往充值 >
需支付：10.00元
成就一亿技术人!
领取后你会自动成为博主和红包主的粉丝 规则
hope_wisdom
发出的红包
实付元
使用余额支付
点击重新获取
扫码支付
钱包余额 0

抵扣说明：

1.余额是钱包充值的虚拟货币，按照1:1的比例进行支付金额的抵扣。
2.余额无法直接购买下载，可以购买VIP、付费专栏及课程。

余额充值
