Eharts实现横向柱状图

Eharts版本V=5.2.0实现效果图如下

代码：

const datas = [
   { name: "taskA", percent: "58", total: "158111", finished: "82311" },
   { name: "taskB", percent: "76", total: "16522", finished: "9873"  },
   { name: "taskC", percent: "98", total: "5823", finished: "5500"  },
   { name: "taskD", percent: "77" , total: "3244", finished: "2355" },
   { name: "taskE", percent: "85", total: "15344", finished: "12009"  }
];
const yData = datas.map(item => item.name);
const zData = datas.map(item => item.finished);
const pData = datas.map(item => item.percent);
var xuhaofontsize = 50;

const img1 =
const img2 =
const img3 =
const img4 =

// 设置等长的背景柱状图
const maxData = new Array(yData.length).fill(100);
option = {
   backgroundColor: "#0b1a2a",
   grid: {
      left: "10%",
      right: "10%",
      bottom: "10%",
      top: "10%",
      containLabel: false
   },
   xAxis: [
      {
         show: true
      },
      {
         show: false,
         splitLine: {
            show: false
         }
      }
   ],
   yAxis: [
      {
         show: true,
         data: yData,
         position: "left",
         inverse: true,//横向柱状图由上至下显示
         max:10,//设置类目数量，平均分配坐标轴，避免数据量小时柱子间距太宽
         axisLabel: {
            lineHeight: 0,
            verticalAlign: "bottom",
            fontSize: 14,
            color: "#e6a635",
            // formatter: "{value}",
             formatter: (name, index) => {
            let tempValue;
            for (var i = 0; i < datas.length; i++) {
               if (datas[i].name === name) {
                  tempValue =datas.length-i;
               }
            }

            const id = tempValue;
            if (id < 4) {
               return `{icon${id}|${id}}`;
            } else {
               return `{count|${id}}`;
            }
         },
       rich: {
            icon1: {
               width: xuhaofontsize * 1.5,
               height: xuhaofontsize * 1.5,
               align: 'center',
               padding: [0, 0, 2, 0],
               backgroundColor: {
                  image: img1,
               },
               color: '#ffffff',
               fontSize: xuhaofontsize,
            },
            icon2: {
               width: xuhaofontsize * 1.5,
               height: xuhaofontsize * 1.5,
               padding: [0, 0, 2, 0],
               align: 'center',
               backgroundColor: {
                  image: img2,
               },
               color: '#ffffff',
               fontSize: xuhaofontsize,
            },
            icon3: {
               width: xuhaofontsize * 1.5,
               height: xuhaofontsize * 1.5,
               padding: [0, 0, 2, 0],
               align: 'center',
               backgroundColor: {
                  image: img3,
               },
               color: '#ffffff',
               fontSize: xuhaofontsize,
            },
            count: {
               width: xuhaofontsize * 1.5,
               height: xuhaofontsize * 1.5,
               padding: [0, 0, 2, 0],
               align: 'center',
               backgroundColor: {
                  image: img4,
               },
               color: '#ffffff',
               fontSize: xuhaofontsize,
            }
         },
         },
         axisLine: {
            show: false
         },
         splitLine: {
            show: false
         },
         axisTick: {
            show: false
         }
      },
      {
         show: true,
         data: zData,
         inverse: true,//横向柱状图由上至下显示
         max:10,//设置类目数量，平均分配坐标轴，避免数据量小时柱子间距太宽
         offset: 5,
         position: "right",
         axisLabel: {
            lineHeight: 0,
            verticalAlign: "bottom",
            fontSize: 14,
            color: "#19E5E6",
            formatter: "{value}"+'人次'
         },
         axisLine: {
            show: false
         },
         splitLine: {
            show: false
         },
         axisTick: {
            show: false
         },
      }
   ],
   series: [
      {
         name: "进度",
         show: true,
         type: "bar",
         barGap: "-100%",
         xAxisIndex: 1,
         barWidth: 20,
         itemStyle: {
            borderRadius: 10,
            color: {
               type: 'linear',
               x: 0,
               y: 0,
               x2: 1,
               y2: 0,
               colorStops: [
                  {
                     offset: 0,
                    color:'#1084fa'
                  },
                  {
                     offset: 1,
                    color:'#2bf2ff'
                  },
               ],
               global: false, // 缺省为 false
            }
         },
         label: {
            show: true,
            position: 'insideRight',
            formatter: '{c}%',
            offset: [-10, 2],
            color: '#fff'
         },
         labelLine: {
            show: false
         },
         z: 2,
         data: pData,
         animationDelay: 1000,
         animationDuration: 1000
      },
      {
         name: "百分比",
         z: 1,
         show: true,
         type: "bar",
         xAxisIndex: 1,
         barGap: "-100%",
         barWidth: 20,
         itemStyle: {
            borderRadius: 4,
            color: "rgba(13, 55, 78, 1)"
         },
         label: {
            show: false,
         },
         data: maxData
      }
   ]
};
