【源码解析】SpringBoot @Bean 注解的实现原理

前言

AbstractApplicationContext#refresh，Spring刷新容器的核心方法。最关键的就是

• AbstractApplicationContext#invokeBeanFactoryPostProcessors，扫描Bean
• AbstractApplicationContext#finishBeanFactoryInitialization，生成Bean。

@Bean标注的Spring实例生成也是分为上面两个步骤。

扫描Bean

ConfigurationClassParser#doProcessConfigurationClass，处理带有@Bean注解的方法，设置到configClass中。

	protected final SourceClass doProcessConfigurationClass(
			ConfigurationClass configClass, SourceClass sourceClass, Predicate<String> filter)
			throws IOException {

		if (configClass.getMetadata().isAnnotated(Component.class.getName())) {
			// Recursively process any member (nested) classes first
			processMemberClasses(configClass, sourceClass, filter);
		}

		// Process any @PropertySource annotations
		for (AnnotationAttributes propertySource : AnnotationConfigUtils.attributesForRepeatable(
				sourceClass.getMetadata(), PropertySources.class,
				org.springframework.context.annotation.PropertySource.class)) {
			if (this.environment instanceof ConfigurableEnvironment) {
				processPropertySource(propertySource);
			}
			else {
				logger.info("Ignoring @PropertySource annotation on [" + sourceClass.getMetadata().getClassName() +
						"]. Reason: Environment must implement ConfigurableEnvironment");
			}
		}

		// Process any @ComponentScan annotations
		Set<AnnotationAttributes> componentScans = AnnotationConfigUtils.attributesForRepeatable(
				sourceClass.getMetadata(), ComponentScans.class, ComponentScan.class);
		if (!componentScans.isEmpty() &&
				!this.conditionEvaluator.shouldSkip(sourceClass.getMetadata(), ConfigurationPhase.REGISTER_BEAN)) {
			for (AnnotationAttributes componentScan : componentScans) {
				// The config class is annotated with @ComponentScan -> perform the scan immediately
				Set<BeanDefinitionHolder> scannedBeanDefinitions =
						this.componentScanParser.parse(componentScan, sourceClass.getMetadata().getClassName());
				// Check the set of scanned definitions for any further config classes and parse recursively if needed
				for (BeanDefinitionHolder holder : scannedBeanDefinitions) {
					BeanDefinition bdCand = holder.getBeanDefinition().getOriginatingBeanDefinition();
					if (bdCand == null) {
						bdCand = holder.getBeanDefinition();
					}
					if (ConfigurationClassUtils.checkConfigurationClassCandidate(bdCand, this.metadataReaderFactory)) {
						parse(bdCand.getBeanClassName(), holder.getBeanName());
					}
				}
			}
		}

		// Process any @Import annotations
		processImports(configClass, sourceClass, getImports(sourceClass), filter, true);

		// Process any @ImportResource annotations
		AnnotationAttributes importResource =
				AnnotationConfigUtils.attributesFor(sourceClass.getMetadata(), ImportResource.class);
		if (importResource != null) {
			String[] resources = importResource.getStringArray("locations");
			Class<? extends BeanDefinitionReader> readerClass = importResource.getClass("reader");
			for (String resource : resources) {
				String resolvedResource = this.environment.resolveRequiredPlaceholders(resource);
				configClass.addImportedResource(resolvedResource, readerClass);
			}
		}

		// Process individual @Bean methods
		Set<MethodMetadata> beanMethods = retrieveBeanMethodMetadata(sourceClass);
		for (MethodMetadata methodMetadata : beanMethods) {
			configClass.addBeanMethod(new BeanMethod(methodMetadata, configClass));
		}

		// Process default methods on interfaces
		processInterfaces(configClass, sourceClass);

		// Process superclass, if any
		if (sourceClass.getMetadata().hasSuperClass()) {
			String superclass = sourceClass.getMetadata().getSuperClassName();
			if (superclass != null && !superclass.startsWith("java") &&
					!this.knownSuperclasses.containsKey(superclass)) {
				this.knownSuperclasses.put(superclass, configClass);
				// Superclass found, return its annotation metadata and recurse
				return sourceClass.getSuperClass();
			}
		}

		// No superclass -> processing is complete
		return null;
	}

ConfigurationClassPostProcessor#processConfigBeanDefinitions，根据configClasses来加载BeanDefinition。this.reader.loadBeanDefinitions(configClasses)

	public void processConfigBeanDefinitions(BeanDefinitionRegistry registry) {
		// ...

		// Parse each @Configuration class
		ConfigurationClassParser parser = new ConfigurationClassParser(
				this.metadataReaderFactory, this.problemReporter, this.environment,
				this.resourceLoader, this.componentScanBeanNameGenerator, registry);

		Set<BeanDefinitionHolder> candidates = new LinkedHashSet<>(configCandidates);
		Set<ConfigurationClass> alreadyParsed = new HashSet<>(configCandidates.size());
		do {
			StartupStep processConfig = this.applicationStartup.start("spring.context.config-classes.parse");
			parser.parse(candidates);
			parser.validate();

			Set<ConfigurationClass> configClasses = new LinkedHashSet<>(parser.getConfigurationClasses());
			configClasses.removeAll(alreadyParsed);

			// Read the model and create bean definitions based on its content
			if (this.reader == null) {
				this.reader = new ConfigurationClassBeanDefinitionReader(
						registry, this.sourceExtractor, this.resourceLoader, this.environment,
						this.importBeanNameGenerator, parser.getImportRegistry());
			}
			this.reader.loadBeanDefinitions(configClasses);
			alreadyParsed.addAll(configClasses);
			processConfig.tag("classCount", () -> String.valueOf(configClasses.size())).end();

			candidates.clear();
			if (registry.getBeanDefinitionCount() > candidateNames.length) {
				String[] newCandidateNames = registry.getBeanDefinitionNames();
				Set<String> oldCandidateNames = new HashSet<>(Arrays.asList(candidateNames));
				Set<String> alreadyParsedClasses = new HashSet<>();
				for (ConfigurationClass configurationClass : alreadyParsed) {
					alreadyParsedClasses.add(configurationClass.getMetadata().getClassName());
				}
				for (String candidateName : newCandidateNames) {
					if (!oldCandidateNames.contains(candidateName)) {
						BeanDefinition bd = registry.getBeanDefinition(candidateName);
						if (ConfigurationClassUtils.checkConfigurationClassCandidate(bd, this.metadataReaderFactory) &&
								!alreadyParsedClasses.contains(bd.getBeanClassName())) {
							candidates.add(new BeanDefinitionHolder(bd, candidateName));
						}
					}
				}
				candidateNames = newCandidateNames;
			}
		}
		while (!candidates.isEmpty());

		// Register the ImportRegistry as a bean in order to support ImportAware @Configuration classes
		if (sbr != null && !sbr.containsSingleton(IMPORT_REGISTRY_BEAN_NAME)) {
			sbr.registerSingleton(IMPORT_REGISTRY_BEAN_NAME, parser.getImportRegistry());
		}

		if (this.metadataReaderFactory instanceof CachingMetadataReaderFactory) {
			// Clear cache in externally provided MetadataReaderFactory; this is a no-op
			// for a shared cache since it'll be cleared by the ApplicationContext.
			((CachingMetadataReaderFactory) this.metadataReaderFactory).clearCache();
		}
	}

ConfigurationClassBeanDefinitionReader#loadBeanDefinitions，加载BeanDefinition。加载@Bean注解的实例，是在loadBeanDefinitionsForBeanMethod。

	public void loadBeanDefinitions(Set<ConfigurationClass> configurationModel) {
		TrackedConditionEvaluator trackedConditionEvaluator = new TrackedConditionEvaluator();
		for (ConfigurationClass configClass : configurationModel) {
			loadBeanDefinitionsForConfigurationClass(configClass, trackedConditionEvaluator);
		}
	}

	private void loadBeanDefinitionsForConfigurationClass(
			ConfigurationClass configClass, TrackedConditionEvaluator trackedConditionEvaluator) {

		if (trackedConditionEvaluator.shouldSkip(configClass)) {
			String beanName = configClass.getBeanName();
			if (StringUtils.hasLength(beanName) && this.registry.containsBeanDefinition(beanName)) {
				this.registry.removeBeanDefinition(beanName);
			}
			this.importRegistry.removeImportingClass(configClass.getMetadata().getClassName());
			return;
		}

		if (configClass.isImported()) {
			registerBeanDefinitionForImportedConfigurationClass(configClass);
		}
		for (BeanMethod beanMethod : configClass.getBeanMethods()) {
			loadBeanDefinitionsForBeanMethod(beanMethod);
		}

		loadBeanDefinitionsFromImportedResources(configClass.getImportedResources());
		loadBeanDefinitionsFromRegistrars(configClass.getImportBeanDefinitionRegistrars());
	}

ConfigurationClassBeanDefinitionReader#loadBeanDefinitionsForBeanMethod，ConfigurationClassBeanDefinition设置了uniqueFactoryMethodName和factoryBeanName。

	private void loadBeanDefinitionsForBeanMethod(BeanMethod beanMethod) {
		ConfigurationClass configClass = beanMethod.getConfigurationClass();
		MethodMetadata metadata = beanMethod.getMetadata();
		String methodName = metadata.getMethodName();

		// Do we need to mark the bean as skipped by its condition?
		if (this.conditionEvaluator.shouldSkip(metadata, ConfigurationPhase.REGISTER_BEAN)) {
			configClass.skippedBeanMethods.add(methodName);
			return;
		}
		if (configClass.skippedBeanMethods.contains(methodName)) {
			return;
		}

		AnnotationAttributes bean = AnnotationConfigUtils.attributesFor(metadata, Bean.class);
		Assert.state(bean != null, "No @Bean annotation attributes");

		// Consider name and any aliases
		List<String> names = new ArrayList<>(Arrays.asList(bean.getStringArray("name")));
		String beanName = (!names.isEmpty() ? names.remove(0) : methodName);

		// Register aliases even when overridden
		for (String alias : names) {
			this.registry.registerAlias(beanName, alias);
		}

		// Has this effectively been overridden before (e.g. via XML)?
		if (isOverriddenByExistingDefinition(beanMethod, beanName)) {
			if (beanName.equals(beanMethod.getConfigurationClass().getBeanName())) {
				throw new BeanDefinitionStoreException(beanMethod.getConfigurationClass().getResource().getDescription(),
						beanName, "Bean name derived from @Bean method '" + beanMethod.getMetadata().getMethodName() +
						"' clashes with bean name for containing configuration class; please make those names unique!");
			}
			return;
		}

		ConfigurationClassBeanDefinition beanDef = new ConfigurationClassBeanDefinition(configClass, metadata, beanName);
		beanDef.setSource(this.sourceExtractor.extractSource(metadata, configClass.getResource()));

		if (metadata.isStatic()) {
			// static @Bean method
			if (configClass.getMetadata() instanceof StandardAnnotationMetadata) {
				beanDef.setBeanClass(((StandardAnnotationMetadata) configClass.getMetadata()).getIntrospectedClass());
			}
			else {
				beanDef.setBeanClassName(configClass.getMetadata().getClassName());
			}
			beanDef.setUniqueFactoryMethodName(methodName);
		}
		else {
			// instance @Bean method
			beanDef.setFactoryBeanName(configClass.getBeanName());
			beanDef.setUniqueFactoryMethodName(methodName);
		}

		if (metadata instanceof StandardMethodMetadata) {
			beanDef.setResolvedFactoryMethod(((StandardMethodMetadata) metadata).getIntrospectedMethod());
		}

		beanDef.setAutowireMode(AbstractBeanDefinition.AUTOWIRE_CONSTRUCTOR);
		beanDef.setAttribute(org.springframework.beans.factory.annotation.RequiredAnnotationBeanPostProcessor.
				SKIP_REQUIRED_CHECK_ATTRIBUTE, Boolean.TRUE);

		AnnotationConfigUtils.processCommonDefinitionAnnotations(beanDef, metadata);

		Autowire autowire = bean.getEnum("autowire");
		if (autowire.isAutowire()) {
			beanDef.setAutowireMode(autowire.value());
		}

		boolean autowireCandidate = bean.getBoolean("autowireCandidate");
		if (!autowireCandidate) {
			beanDef.setAutowireCandidate(false);
		}

		String initMethodName = bean.getString("initMethod");
		if (StringUtils.hasText(initMethodName)) {
			beanDef.setInitMethodName(initMethodName);
		}

		String destroyMethodName = bean.getString("destroyMethod");
		beanDef.setDestroyMethodName(destroyMethodName);

		// Consider scoping
		ScopedProxyMode proxyMode = ScopedProxyMode.NO;
		AnnotationAttributes attributes = AnnotationConfigUtils.attributesFor(metadata, Scope.class);
		if (attributes != null) {
			beanDef.setScope(attributes.getString("value"));
			proxyMode = attributes.getEnum("proxyMode");
			if (proxyMode == ScopedProxyMode.DEFAULT) {
				proxyMode = ScopedProxyMode.NO;
			}
		}

		// Replace the original bean definition with the target one, if necessary
		BeanDefinition beanDefToRegister = beanDef;
		if (proxyMode != ScopedProxyMode.NO) {
			BeanDefinitionHolder proxyDef = ScopedProxyCreator.createScopedProxy(
					new BeanDefinitionHolder(beanDef, beanName), this.registry,
					proxyMode == ScopedProxyMode.TARGET_CLASS);
			beanDefToRegister = new ConfigurationClassBeanDefinition(
					(RootBeanDefinition) proxyDef.getBeanDefinition(), configClass, metadata, beanName);
		}

		if (logger.isTraceEnabled()) {
			logger.trace(String.format("Registering bean definition for @Bean method %s.%s()",
					configClass.getMetadata().getClassName(), beanName));
		}
		this.registry.registerBeanDefinition(beanName, beanDefToRegister);
	}

生成Bean

AbstractApplicationContext#finishBeanFactoryInitialization，执行beanFactory.preInstantiateSingletons()，生成标注@Bean注解的实例。

	protected void finishBeanFactoryInitialization(ConfigurableListableBeanFactory beanFactory) {
		// Initialize conversion service for this context.
		if (beanFactory.containsBean(CONVERSION_SERVICE_BEAN_NAME) &&
				beanFactory.isTypeMatch(CONVERSION_SERVICE_BEAN_NAME, ConversionService.class)) {
			beanFactory.setConversionService(
					beanFactory.getBean(CONVERSION_SERVICE_BEAN_NAME, ConversionService.class));
		}

		// Register a default embedded value resolver if no BeanFactoryPostProcessor
		// (such as a PropertySourcesPlaceholderConfigurer bean) registered any before:
		// at this point, primarily for resolution in annotation attribute values.
		if (!beanFactory.hasEmbeddedValueResolver()) {
			beanFactory.addEmbeddedValueResolver(strVal -> getEnvironment().resolvePlaceholders(strVal));
		}

		// Initialize LoadTimeWeaverAware beans early to allow for registering their transformers early.
		String[] weaverAwareNames = beanFactory.getBeanNamesForType(LoadTimeWeaverAware.class, false, false);
		for (String weaverAwareName : weaverAwareNames) {
			getBean(weaverAwareName);
		}

		// Stop using the temporary ClassLoader for type matching.
		beanFactory.setTempClassLoader(null);

		// Allow for caching all bean definition metadata, not expecting further changes.
		beanFactory.freezeConfiguration();

		// Instantiate all remaining (non-lazy-init) singletons.
		beanFactory.preInstantiateSingletons();
	}

DefaultListableBeanFactory#preInstantiateSingletons，获取到所有的RootBeanDefinition，如果isFactoryBean返回为false，执行getBean(beanName)。

	@Override
	public void preInstantiateSingletons() throws BeansException {
		if (logger.isTraceEnabled()) {
			logger.trace("Pre-instantiating singletons in " + this);
		}

		// Iterate over a copy to allow for init methods which in turn register new bean definitions.
		// While this may not be part of the regular factory bootstrap, it does otherwise work fine.
		List<String> beanNames = new ArrayList<>(this.beanDefinitionNames);

		// Trigger initialization of all non-lazy singleton beans...
		for (String beanName : beanNames) {
			RootBeanDefinition bd = getMergedLocalBeanDefinition(beanName);
			if (!bd.isAbstract() && bd.isSingleton() && !bd.isLazyInit()) {
				if (isFactoryBean(beanName)) {
					Object bean = getBean(FACTORY_BEAN_PREFIX + beanName);
					if (bean instanceof FactoryBean) {
						FactoryBean<?> factory = (FactoryBean<?>) bean;
						boolean isEagerInit;
						if (System.getSecurityManager() != null && factory instanceof SmartFactoryBean) {
							isEagerInit = AccessController.doPrivileged(
									(PrivilegedAction<Boolean>) ((SmartFactoryBean<?>) factory)::isEagerInit,
									getAccessControlContext());
						}
						else {
							isEagerInit = (factory instanceof SmartFactoryBean &&
									((SmartFactoryBean<?>) factory).isEagerInit());
						}
						if (isEagerInit) {
							getBean(beanName);
						}
					}
				}
				else {
					getBean(beanName);
				}
			}
		}

		// Trigger post-initialization callback for all applicable beans...
		for (String beanName : beanNames) {
			Object singletonInstance = getSingleton(beanName);
			if (singletonInstance instanceof SmartInitializingSingleton) {
				StartupStep smartInitialize = this.getApplicationStartup().start("spring.beans.smart-initialize")
						.tag("beanName", beanName);
				SmartInitializingSingleton smartSingleton = (SmartInitializingSingleton) singletonInstance;
				if (System.getSecurityManager() != null) {
					AccessController.doPrivileged((PrivilegedAction<Object>) () -> {
						smartSingleton.afterSingletonsInstantiated();
						return null;
					}, getAccessControlContext());
				}
				else {
					smartSingleton.afterSingletonsInstantiated();
				}
				smartInitialize.end();
			}
		}
	}

AbstractAutowireCapableBeanFactory#createBeanInstance，创建Bean的时候，判断getFactoryMethodName是否为空，不为空，调用方法来进行初始化。

	protected BeanWrapper createBeanInstance(String beanName, RootBeanDefinition mbd, @Nullable Object[] args) {
		// Make sure bean class is actually resolved at this point.
		Class<?> beanClass = resolveBeanClass(mbd, beanName);

		if (beanClass != null && !Modifier.isPublic(beanClass.getModifiers()) && !mbd.isNonPublicAccessAllowed()) {
			throw new BeanCreationException(mbd.getResourceDescription(), beanName,
					"Bean class isn't public, and non-public access not allowed: " + beanClass.getName());
		}

		Supplier<?> instanceSupplier = mbd.getInstanceSupplier();
		if (instanceSupplier != null) {
			return obtainFromSupplier(instanceSupplier, beanName);
		}

		if (mbd.getFactoryMethodName() != null) {
			return instantiateUsingFactoryMethod(beanName, mbd, args);
		}

		// Shortcut when re-creating the same bean...
		boolean resolved = false;
		boolean autowireNecessary = false;
		if (args == null) {
			synchronized (mbd.constructorArgumentLock) {
				if (mbd.resolvedConstructorOrFactoryMethod != null) {
					resolved = true;
					autowireNecessary = mbd.constructorArgumentsResolved;
				}
			}
		}
		if (resolved) {
			if (autowireNecessary) {
				return autowireConstructor(beanName, mbd, null, null);
			}
			else {
				return instantiateBean(beanName, mbd);
			}
		}

		// Candidate constructors for autowiring?
		Constructor<?>[] ctors = determineConstructorsFromBeanPostProcessors(beanClass, beanName);
		if (ctors != null || mbd.getResolvedAutowireMode() == AUTOWIRE_CONSTRUCTOR ||
				mbd.hasConstructorArgumentValues() || !ObjectUtils.isEmpty(args)) {
			return autowireConstructor(beanName, mbd, ctors, args);
		}

		// Preferred constructors for default construction?
		ctors = mbd.getPreferredConstructors();
		if (ctors != null) {
			return autowireConstructor(beanName, mbd, ctors, null);
		}

		// No special handling: simply use no-arg constructor.
		return instantiateBean(beanName, mbd);
	}
