Flutter 与原生交互之BasicMessageChannel

该方式可以实现双向通道, 感觉适用于Android或ios的数据需要实时刷新在ui上,碎片连续性的消息传递。

直接上效果图





直接上代码 首先是Flutter端  分为2步

1.发送消息，获取回调

首先获取 BasicMessageChannel 的对象，注册消息通道，原生端也要注册，字符串必须跟原生一致

 static const messageChannel = const BasicMessageChannel(
      'com.demo.test.messageChannel', StandardMessageCodec());

然后Flutter发送消息到原生，并接收原生函数的回调。

Map<String, String> map = {
     "text": "BasicMessageChannel 发送了一条消息给原生",
};
String message = await MethodChannelManage.messageChannel.send(map);

2.监听原生端主动发送的消息

注册监听

MethodChannelManage.messageChannel.setMessageHandler((message){
      // 这个message就是原生发送的消息
    });

接下来是Android端的代码

  public static String BASIC_MESSAGE_CHANNEL = "com.demo.test.messageChannel";

  static BasicMessageChannel basicMessageChannel;

  public static void registerWith(PluginRegistry.Registrar registrar) {
        basicMessageChannel = new BasicMessageChannel<>(registrar.messenger(), BASIC_MESSAGE_CHANNEL, StandardMessageCodec.INSTANCE);
        //setMethodCallHandler在此通道上接收方法调用的回调
        basicMessageChannel.setMessageHandler(new BasicMessageChannel.MessageHandler() {
            @Override
            public void onMessage(Object message, BasicMessageChannel.Reply reply){
                Map<String, String> arguments = (Map<String, String>) message;
                String str = arguments.get("text");
                reply.reply("Android接收到Flutter返回的消息:" + str + "  单次函数回调");
                androidToFlutter();
            }
        });
    }

 private static void androidToFlutter() {
    basicMessageChannel.send("Android主动发送消息，Flutter监听。消息 " + duration);
 }

然后是ios端的代码

-(void) BasicMessageChannelFunction{
    //获取当前的 controller
    FlutterViewController* controller = (FlutterViewController*)self.window.rootViewController;
    messageChannel = [FlutterBasicMessageChannel messageChannelWithName:@"com.demo.test.messageChannel" binaryMessenger:controller];

    // 接收消息监听
    [messageChannel setMessageHandler:^(id message, FlutterReply callback) {

        NSString *method=message[@"text"];

        NSMutableDictionary *dic = [NSMutableDictionary dictionary];

        callback(@"IOS接收到Flutter返回的消息: 单次函数回调");

        [messageChannel sendMessage:@"IOS主动发送消息，Flutter监听"];
    }];

}
