这篇博客介绍了如何在Android中实现省、市、县三级联动的下拉框（spinner），通过动态加载各级适配器，并在选中值改变时更新下级适配器。XML布局和获取选中值的方法也在内容中给出。
Android实现（省、市、县）三级联动下拉框 下拉列表spinner
主要实现办法：动态加载各级下拉值的适配器
在监听本级下拉框，当本级下拉框的选中值改变时，随之修改下级的适配器的绑定值
XML布局：
-
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
-
xmlns:tools=
"http://schemas.android.com/tools"
-
android:layout_width=
"match_parent"
-
android:layout_height=
"wrap_content"
-
android:orientation=
"horizontal"
-
android:padding=
"8dp" >
-
<Spinner
-
android:id=
"@+id/spin_province"
-
android:layout_width=
"80dp"
-
android:layout_height=
"wrap_content" />
-
-
<Spinner
-
android:id=
"@+id/spin_city"
-
android:layout_width=
"112dp"
-
android:layout_height=
"wrap_content" />
-
-
<Spinner
-
android:id=
"@+id/spin_county"
-
android:layout_width=
"100dp"
-
android:layout_height=
"wrap_content" />
-
</LinearLayout>
实现代码：
-
package com.example.android.demo.spinner;
-
-
import android.os.Bundle;
-
import android.app.Activity;
-
import android.view.View;
-
import android.widget.AdapterView;
-
import android.widget.ArrayAdapter;
-
import android.widget.Spinner;
-
-
-
public
class MainActivity extends Activity
-
{
-
private Spinner provinceSpinner =
null;
//省级（省、直辖市）
-
private Spinner citySpinner =
null;
//地级市
-
private Spinner countySpinner =
null;
//县级（区、县、县级市）
-
ArrayAdapter<String> provinceAdapter =
null;
//省级适配器
-
ArrayAdapter<String> cityAdapter =
null;
//地级适配器
-
ArrayAdapter<String> countyAdapter =
null;
//县级适配器
-
static
int provincePosition =
3;
-
-
-
//省级选项值
-
private String[] province =
new String[] {
"北京",
"上海",
"天津",
"广东"};
//,"重庆","黑龙江","江苏","山东","浙江","香港","澳门"};
-
//地级选项值
-
private String[][] city =
new String[][]
-
{
-
{
"东城区",
"西城区",
"崇文区",
"宣武区",
"朝阳区",
"海淀区",
"丰台区",
"石景山区",
"门头沟区",
-
"房山区",
"通州区",
"顺义区",
"大兴区",
"昌平区",
"平谷区",
"怀柔区",
"密云县",
-
"延庆县" },
-
{
"长宁区",
"静安区",
"普陀区",
"闸北区",
"虹口区" },
-
{
"和平区",
"河东区",
"河西区",
"南开区",
"河北区",
"红桥区",
"塘沽区",
"汉沽区",
"大港区",
-
"东丽区" },
-
{
"广州",
"深圳",
"韶关"
// ,"珠海","汕头","佛山","湛江","肇庆","江门","茂名","惠州","梅州",
-
// "汕尾","河源","阳江","清远","东莞","中山","潮州","揭阳","云浮"
-
}
-
};
-
-
//县级选项值
-
private String[][][] county =
new String[][][]
-
{
-
{
//北京
-
{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},
-
{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"}
-
},
-
{
//上海
-
{
"无"},{
"无"},{
"无"},{
"无"},{
"无"}
-
},
-
{
//天津
-
{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"},{
"无"}
-
},
-
{
//广东
-
{
"海珠区",
"荔湾区",
"越秀区",
"白云区",
"萝岗区",
"天河区",
"黄埔区",
"花都区",
"从化市",
"增城市",
"番禺区",
"南沙区"},
//广州
-
{
"宝安区",
"福田区",
"龙岗区",
"罗湖区",
"南山区",
"盐田区"},
//深圳
-
{
"武江区",
"浈江区",
"曲江区",
"乐昌市",
"南雄市",
"始兴县",
"仁化县",
"翁源县",
"新丰县",
"乳源县"}
//韶关
-
}
-
};
-
-
-
@Override
-
protected void onCreate(Bundle savedInstanceState)
-
{
-
super.onCreate(savedInstanceState);
-
setContentView(R.layout.activity_main);
-
-
setSpinner();
-
}
-
-
-
/*
-
* 设置下拉框
-
*/
-
private void setSpinner()
-
{
-
provinceSpinner = (Spinner)findViewById(R.id.spin_province);
-
citySpinner = (Spinner)findViewById(R.id.spin_city);
-
countySpinner = (Spinner)findViewById(R.id.spin_county);
-
-
//绑定适配器和值
-
provinceAdapter =
new ArrayAdapter<String>(MainActivity.
this,
-
android.R.layout.simple_spinner_item, province);
-
provinceSpinner.setAdapter(provinceAdapter);
-
provinceSpinner.setSelection(
3,
true);
//设置默认选中项，此处为默认选中第4个值
-
-
cityAdapter =
new ArrayAdapter<String>(MainActivity.
this,
-
android.R.layout.simple_spinner_item, city[
3]);
-
citySpinner.setAdapter(cityAdapter);
-
citySpinner.setSelection(
0,
true);
//默认选中第0个
-
-
countyAdapter =
new ArrayAdapter<String>(MainActivity.
this,
-
android.R.layout.simple_spinner_item, county[
3][
0]);
-
countySpinner.setAdapter(countyAdapter);
-
countySpinner.setSelection(
0,
true);
-
-
-
//省级下拉框监听
-
provinceSpinner.setOnItemSelectedListener(
new AdapterView.OnItemSelectedListener()
-
{
-
-
// 表示选项被改变的时候触发此方法，主要实现办法：动态改变地级适配器的绑定值
-
@Override
-
public void onItemSelected(AdapterView<?> arg0, View arg1, int position, long arg3)
-
{
-
//position为当前省级选中的值的序号
-
-
//将地级适配器的值改变为city[position]中的值
-
cityAdapter =
new ArrayAdapter<String>(
-
MainActivity.
this, android.R.layout.simple_spinner_item, city[position]);
-
// 设置二级下拉列表的选项内容适配器
-
citySpinner.setAdapter(cityAdapter);
-
provincePosition = position;
//记录当前省级序号，留给下面修改县级适配器时用
-
}
-
-
@Override
-
public void onNothingSelected(AdapterView<?> arg0)
-
{
-
-
}
-
-
});
-
-
-
//地级下拉监听
-
citySpinner.setOnItemSelectedListener(
new AdapterView.OnItemSelectedListener()
-
{
-
-
@Override
-
public void onItemSelected(AdapterView<?> arg0, View arg1,
-
int position,
long arg3)
-
{
-
countyAdapter =
new ArrayAdapter<String>(MainActivity.
this,
-
android.R.layout.simple_spinner_item, county[provincePosition][position]);
-
countySpinner.setAdapter(countyAdapter);
-
}
-
-
@Override
-
public void onNothingSelected(AdapterView<?> arg0)
-
{
-
-
}
-
});
-
}
-
}
要获取下拉框spinner中选中的值，用下面这方法就OK了
provinceSpinner.getSelectedItem().toString();
citySpinner.getSelectedItem().toString()
countySpinner.getSelectedItem().toString()
