android ListView实现圆角

最新推荐文章于 2021-11-25 17:19:07 发布

转载最新推荐文章于 2021-11-25 17:19:07 发布 · 649 阅读

android 专栏收录该内容

3 篇文章

订阅专栏

本文介绍了解决Android中ListView项选中状态时顶部和底部圆角丢失的问题，提供了五种不同的实现方法，包括自定义ListView、使用不同选择器资源及自定义绘制等技术手段。

方法一：定义


   1<?xml version ="1.0" encoding ="UTF-8" ?>

   2<shape xmlns:android ="http://schemas.android.com/apk/res/android" android:shape ="rectangle" >

   3       <gradient android:startColor ="#B0BCCD" android:endColor ="#6D84A2" android:angle ="270" />

   4       <corners android:bottomRightRadius  ="8dp" android:bottomLeftRadius ="8dp"  android:topLeftRadius ="8dp"

   5              android:topRightRadius ="8dp"  />

   6

   7</shape>

布局文件中的ListView属性android:listSelector="@drawable/shape"

存在问题是，ListView最上面或者最下面的item选中时，圆角背景变成直角的

方法二：修改选中item


   01public  class RoundedRectListView extends ListView {

   02        private Context mContext;

   03        public RoundedRectListView( Context context) {

   04                super ( context) ;

   05                this .mContext = context;

   06                init( ) ;

   07        }

   08        public RoundedRectListView( Context context, AttributeSet attrs) {

   09                super ( context, attrs) ;

   10                this .mContext = context;

   11                init( ) ;

   12        }

   13        public RoundedRectListView( Context context, AttributeSet attrs, int defStyle) {

   14                super ( context, attrs, defStyle) ;

   15                this .mContext = context;

   16                init( ) ;

   17        }

   18        protected void init( ) {

   19                setBackgroundDrawable( mContext.getResources ( ) .getDrawable ( R.drawable .background_rounded_white ) ) ;

   20                setCacheColorHint( Color .WHITE ) ;

   21                setFooterDividersEnabled( false ) ;

   22        }

   23        @Override

   24        public boolean onInterceptTouchEvent( MotionEvent ev) {

   25

   26                switch ( ev.getAction ( ) ) {

   27                case MotionEvent.ACTION_DOWN :

   28                        int x = ( int  ) ev.getX ( ) ;

   29                        int y = ( int  ) ev.getY ( ) ;

   30                        int itemnum = pointToPosition( x, y) ;

   31                        if ( itemnum == AdapterView.INVALID_POSITION )

   32                                break ;

   33                        else

   34                        {

   35                                if ( itemnum== 0) {

   36                                        if ( itemnum== ( getAdapter( ) .getCount ( ) - 1) )

   37                                                setSelector( R.drawable .listview_selection_shade_rounded ) ;

   38                                        else

   39                                                setSelector( R.drawable .listview_selection_shade_top_rounded ) ;

   40                                }

   41                                else if ( itemnum== ( getAdapter( ) .getCount ( ) - 1) )

   42                                        setSelector( R.drawable .listview_selection_shade_bottom_rounded ) ;

   43                                else

   44                                        setSelector( R.drawable .listview_selection_shade ) ;

   45                        }

   46                        break ;

   47                case MotionEvent.ACTION_UP :

   48                        break ;

   49                }

   50                return true ;

   51        }

   52}

方法三：定义selector


   01public  class RoundedRectListView extends ListView {

   02        private Context mContext;

   03

   04        public RoundedRectListView( Context context) {

   05                super ( context) ;

   06                this .mContext = context;

   07                init( ) ;

   08        }

   09        public RoundedRectListView( Context context, AttributeSet attrs) {

   10                super ( context, attrs) ;

   11                this .mContext = context;

   12                init( ) ;

   13        }

   14        public RoundedRectListView( Context context, AttributeSet attrs, int defStyle) {

   15                super ( context, attrs, defStyle) ;

   16                this .mContext = context;

   17                init( ) ;

   18        }

   19        protected void init( ) {

   20                setBackgroundDrawable( mContext.getResources ( ) .getDrawable ( R.drawable .background_rounded_white ) ) ;

   21                setCacheColorHint( Color .WHITE ) ;

   22                setFooterDividersEnabled( false ) ;

   23        }

   24        @Override

   25        public boolean onInterceptTouchEvent( MotionEvent ev) {

   26

   27                switch ( ev.getAction ( ) ) {

   28                case MotionEvent.ACTION_DOWN :

   29                        int x = ( int  ) ev.getX ( ) ;

   30                        int y = ( int  ) ev.getY ( ) ;

   31                        int itemnum = pointToPosition( x, y) ;

   32

   33                        if ( itemnum == AdapterView.INVALID_POSITION )

   34                                break ;

   35                        else

   36                        {

   37                                if ( itemnum== 0) {

   38                                        if ( itemnum== ( getAdapter( ) .getCount ( ) - 1) )

   39                                                setSelector( R.drawable .listview_selection_shade_rounded ) ;

   40                                        else

   41                                                setSelector( R.drawable .listview_selection_shade_top_rounded ) ;

   42                                }

   43                                else if ( itemnum== ( getAdapter( ) .getCount ( ) - 1) )

   44                                        setSelector( R.drawable .listview_selection_shade_bottom_rounded ) ;

   45                                else

   46                                        setSelector( R.drawable .listview_selection_shade ) ;

   47                        }

   48                        break ;

   49                case MotionEvent.ACTION_UP :

   50                        break ;

   51                }

   52                return true ;

   53        }

   54}

方法四：方法二和方法三的结合


   001public  class RoundedRectListView extends ListView {

   002

   003        private Context mContext;

   004

   005        public RoundedRectListView( Context context) {

   006                super ( context) ;

   007                this .mContext = context;

   008                init( ) ;

   009        }

   010        public RoundedRectListView( Context context, AttributeSet attrs) {

   011                super ( context, attrs) ;

   012                this .mContext = context;

   013                init( ) ;

   014        }

   015        public RoundedRectListView( Context context, AttributeSet attrs, int defStyle) {

   016                super ( context, attrs, defStyle) ;

   017                this .mContext = context;

   018                init( ) ;

   019        }

   020       protected void init( ) {

   021                setBackgroundDrawable( mContext.getResources ( ) .getDrawable ( R.drawable .background_rounded_white ) ) ;

   022                setCacheColorHint( Color .WHITE ) ;

   023                setFooterDividersEnabled( false ) ;

   024                setSelector( new Selector( RoundedRectListView.this ,- 1) ) ;

   025        }

   026   @Override

   027        public boolean onInterceptTouchEvent( MotionEvent ev) {

   028                switch ( ev.getAction ( ) ) {

   029                case MotionEvent.ACTION_DOWN :

   030                        int x = ( int  ) ev.getX ( ) ;

   031                        int y = ( int  ) ev.getY ( ) ;

   032                        int itemnum = pointToPosition( x, y) ;

   033                        if ( itemnum == AdapterView.INVALID_POSITION )

   034                                break ;

   035                        else

   036                        {

   037                           setSelector( new Selector( RoundedRectListView.this ,itemnum) ) ;

   038                        }

   039                        break ;

   040                case MotionEvent.ACTION_UP :

   041                        break ;

   042                }

   043                return true ;

   044        }

   045    class Selector extends Drawable {

   046        private static final  String TAG = "Selector"  ;

   047        private Paint mPaint;

   048        private AdapterView mList;

   049        private RectF mRectF;

   050        private int position;

   051

   052        public Selector( AdapterView list,int position) {

   053            mList = list;

   054            mPaint = new Paint ( ) ;

   055            mRectF = new RectF( ) ;

   056            this .position = position

   057

   058            LinearGradient g= new LinearGradient( mRectF.top ,mRectF.left ,mRectF.right ,mRectF.bottom ,Color .parseColor ( "#058cf5" ) ,Color .parseColor ( "#015fe6" ) ,TileMode.REPEAT ) ;

   059

   060    mPaint.setShader ( g) ;

   061        }

   062        @Override

   063        public void draw( Canvas canvas) {

   064            Rect b = getBounds( ) ;

   065            int mPosition = mList.getSelectedItemPosition ( ) ;

   066            if ( mPosition==- 1) {

   067                mPosition= position;

   068            }

   069            Log.d ( TAG, "Position :" + mPosition) ;

   070            canvas.save ( ) ;

   071            canvas.clipRect ( b.left , b.top , b.right , ( b.bottom + b.top ) / 2) ;

   072            drawHalf( canvas, b, mPosition == 0) ;

   073            canvas.restore ( ) ;

   074            canvas.save ( ) ;

   075            canvas.clipRect ( b.left , ( b.bottom + b.top ) / 2, b.right , b.bottom ) ;

   076            drawHalf( canvas, b, mPosition == mList.getAdapter ( ) .getCount ( ) - 1 && b.bottom == mList.getHeight ( ) ) ;

   077            canvas.restore ( ) ;

   078            Log.d ( TAG, "draw " + b) ;

   079        }

   080        private void drawHalf( Canvas canvas, Rect b ,boolean round) {

   081

   082            if ( round) {

   083                mRectF.set ( b) ;

   084                canvas.drawRoundRect ( mRectF, 10, 10, mPaint) ;

   085            } else {

   086                canvas.drawRect ( b, mPaint) ;

   087            }

   088        }

   089        @Override

   090        public int getOpacity( ) {

   091            return 0 ;

   092        }

   093        @Override

   094        public void setAlpha(  int alpha) {

   095        }

   096        @Override

   097        public void setColorFilter( ColorFilter cf) {

   098        }

   099    }

   100}

方法五：


   01public  class RoundedRectListView extends ListView {

   02    private static final  float RADIUS = 16 ;

   03    private Path mClip;

   04    public RoundedRectListView( Context context, AttributeSet attrs) {

   05        super ( context, attrs) ;

   06        init( ) ;

   07    }

   08    private void init( ) {

   09        GradientDrawable gd = new GradientDrawable( ) ;

   10        gd.setCornerRadius ( RADIUS) ;

   11        gd.setColor ( 0xff208020) ;

   12        setBackgroundDrawable( gd) ;

   13        setCacheColorHint( 0) ;

   14        setVerticalFadingEdgeEnabled( false ) ;

   15        StateListDrawable sld = new StateListDrawable( ) ;

   16        sld.addState (

   17                PRESSED_ENABLED_STATE_SET,

   18                new GradientDrawable( Orientation.LEFT_RIGHT , new int [ ] { 0xffa58cf5, 0xffa13f99} ) ) ;

   19        sld.addState (

   20                EMPTY_STATE_SET,

   21                new GradientDrawable( Orientation.LEFT_RIGHT , new int [ ] { 0xff058cf5, 0xff013f99} ) ) ;

   22        setSelector( sld) ;

   23    }

   24    @Override

   25    protected void onSizeChanged(  int w, int h, int  oldw, int oldh) {

   26        super .onSizeChanged ( w, h, oldw, oldh) ;

   27        mClip = new Path( ) ;

   28        RectF rect = new RectF(  0, 0, w, h) ;

   29        mClip.addRoundRect ( rect, RADIUS, RADIUS, Direction.CW ) ;

   30    }

   31   @Override

   32    protected void dispatchDraw( Canvas canvas) {

   33        canvas.save ( ) ;

   34        canvas.clipPath ( mClip) ;

   35        super .dispatchDraw ( canvas) ;

   36        canvas.restore ( ) ;

   37    }
